TTETPMS1209BTire Pressure Monitoring System

T P M S 1 2 0 9 B TIRE PRESSURE MONITORING SYSTEM USER MANUAL 1. Please do read this Manual carefully before using the product. 2. The system can monitor the tire pressure effectively, but does not warrant to avoid any sudden accidents. User should utilize the system to ensure the tire to be used under a standard pressure and avoid using the poor quality or badly abraded tires. 3. Users are not allowed to open, repair and refit the products by themselves, otherwise the warranty service will be invalid. 4. Users must fill the Warranty Card correctly after buying the product for maintaining their own rights and interests. 5. The final right to interpret the product is reserved by Sate Auto Electronic Co., Ltd. 6. Although equipped with S&T TPMS1209B, we still strongly suggest the User check and adjust the Tire Pressure at least once a month. NOTICE www.satetpms.com S&T TPMS1209B, Full-time Direct TPMS---------------------------------------1 Parts of TPMS1209B---------------------------------------------------------------1 Installation---------------------------------------------------------------------------3 Master Programming--------------------------------------------------------------5 Function------------------------------------------------------------------------------8 Auto Switch Function--------------------------------------------------------------11 Special Annex----------------------------------------------------------------------12 Specification----------------------------------------------------------------------17 Warranty Term---------------------------------------------------------------------18 CATALOGUE S&T TPMS1209B, FULL-TIME DIRECT TPMS TPMS1209B is a full-time direct tire pressure monitoring system which includes one wireless Master and four screw-on Sensors. The sensor can be screw inside the tire instead of the valve to sense the pressure and the temperature inside the tire all the time and transmits the pressure information data to the master by RF technology. The master can receive and deal with the data and issue different alarms if the tire pressure or temperature is in an improper state . S&T TPMS1209B can sense and display the tire pressure and the temperature all the time and can issue an alarm when the tire pressure or the temperature is at an improper level, so as to notify the driver to treat the problem and avoid tire busting or tire damage. Through TPMS, the driver can keep the tire running at a proper pressure so as to avoid excess gasoline consumption and keep the vehicle in an easily controlled state. S&T TPMS1209B PARTS Master 1 Display Select key Enter key Alarm lamp Power switch Power socket Cover of battery box Sonser 3M Dual Lock Fastener Display S&T TPMS1209B PARTS Lighter Plug 2 Big end Small end Pressure Pressure unit,psi Pressure unit,kPa Battery power Temperature unit, F Quick leakage alarm icon Level of low pressure alarm icon Pressure alarm icon High pressure alarm icon Tire position Sensor trouble alarm icon Pressure unit,bar Temperature High Temperature Alarm Icon Standard Pressure Icon Standard Pressure INSTALLATION Master 2. There are 4 pieces of the 3M Dual Lock Fastener in the packing box, you can choose one to affix on the bottom of the Master and choose another one to put it on the dashboard, with the remaining two as spare. Note 1. If you don't want or you are not convenient to use the lighter plug, the rechargeable battery is an optional for powering the master. The operation process for battery power is as follow: 1) Take off the cover of the battery box on the back of the Master; 2) Put three rechargeable batteries into the battery box; 3) Cover the battery box; 4) Turn on the Master. 2. The lighter plug is a special plug with a transformer inside. 3. On some vehicles, the cigarette lighter will power off when the engine powers off. If this happens, or if the user accidentally pulls out the lighter plug from the lighter, if the rechargeable batteries are already emplaced inside the Master, and the power of the batteries is enough to operate the Master, the Master can switch to the battery power mode automatically, with no detriment to the system. 4. If you turn off the Master, the Master can not receive, treat, display and alarm at all. 5.If the Lighter Plug connects to the vehicle power while the car is not used for about 3 months, the vehicle power maybe exhausted and the car perhaps can not start as usual. So we strongly suggest the user to pull out the Lighter Plug or turn off the Master if the vehicle will not be used for a whole month or longer. 3.Plug the small end of the Lighter Plug into the socket on the side of the Master, and put the big end of the lighter plug into the lighter socket of the vehicle. 4.Turn on the Master by moving the power switch. 5.Once the Master starts to work, the screen starts to display the pressure of the four tires in turn. Before installing the sensors, the pressure & the unit information shown on the screen as “ ---psi”. 1.Take out the Master from the box. 2.Choose a suitable location for the Master on the dashboard platform. Make sure to first Scrub the surface of the platform with alcohol .Next, strip off the liner of the 3M Dual Lock Fastener, put the sticky side onto the suitable location, then fix the Master with another side of the 3M Dual Lock Fastener on the platform. Note : 1. In order to stick the Master firmly on to the dashboard, we strongly suggest the user to scrub the location with alcohol. 3 Note : 1. This product is not applicable to those tires with inner tubes. 2. We strongly suggest the user to go to an Auto Service Shop to install the system. 3. If one of the sensors is broken or fails to work, the others can still function properly, only the broken one need to be replaced. please detach the broken sensor and follow the above steps to install the new sensor. Then please follow the ID Number programming steps on page14 to set the ID Number of the new sensor on the mast…
