TTUCR870-2QJukeBlox Networked Media

Bang & Olufsen a/s

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Nov 13, 2011
Application Purpose: Original Equipment
Date of Application: Nov 10, 2011
Equipment Note: JukeBlox Networked Media
Frequency Range: 2412.00000000 - 2462.00000000
Company: Bang & Olufsen a/s
Country: Denmark

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Data Sheet: CR Series JukeBlox Networked Media Modules dat_CR860_CR870_3_6_datasheet.doc CONFIDENTIAL Version 3.6 – August 4 th 2011 - Page 1 of 26 JukeBlox Networked Media Module CR Series Datasheet Complete audio networking system on a small module Integrated Ethernet + USB2.0 WiFi-certified 802.11b/g Built-in PIFA antenna Glueless audio, video and control ports FCC certified Ideal for enabling network and USB audio playback for iPod docks, audio systems, AV Receivers, active speaker systems, internet radios, network playback adaptors CONFIDENTIAL Data Sheet: CR Series JukeBlox Networked Media Modules dat_CR860_CR870_3_6_datasheet.doc CONFIDENTIAL Version 3.6 – August 4 th 2011 - Page 2 of 26 Table of Contents 1. Introduction 4 2. Block Diagram 4 3. Board Pictures 5 3.1 Top View of CR870-2A 5 3.2 Bottom View of CR870 types 2A, 2D & 2S 5 3.3 Top View of CR870 types 2C, 2F, 2G, 2I, 2J, 2K & 2R 6 3.4 Bottom View of CR870 types 2C, 2G, 2I, 2J, 2K, 2L, 2N, 2O, 2P & 2R 6 3.5 Top View of CR870 types 2D, 2L, 2N, 2O, 2P, 2Q & 2S 7 4. Ordering Guide 8 5. Electrical Specifications 9 5.1 Absolute Maximum Ratings 9 5.2 Operating Conditions 10 5.3 WiFi Specification (CR870 only) 10 6. Regulatory Compliance and Quality 11 6.1 RoHS 12 6.2 Environmental Test 12 6.3 ESD and Transient Test (Applies to LAN and USB external connections only) 12 6.4 Magnetic Field Test 12 6.5 MTBF 12 6.6 Mechanical Specifications 12 Data Sheet: CR Series JukeBlox Networked Media Modules dat_CR860_CR870_3_6_datasheet.doc CONFIDENTIAL Version 3.6 – August 4 th 2011 - Page 3 of 26 6.7 Module Quality 12 7. Board Dimensions and Weight 13 7.1 Top View and Side View of CR870 modules with PIFA antenna & no shields 13 7.2 Bottom View of CR870 modules with no bottom shield 13 7.3 Top View and Side View of CR870 modules without PIFA antenna 14 7.4 Top View and Side View of CR870 modules with PIFA antenna & top shield 14 7.5 Module weight 15 8. Connectors and Connections 15 8.1 WLAN UFL Antenna Connector (optional) 15 8.1.1 Coaxial antenna connector dimensions 15 8.2 Module Connectors 15 8.2.1 Pin Descriptions 16 8.2.2 Connector PIN Assignments 20 9. Application Guidelines 21 9.1 Power Supply sequencing and Reset Timing 21 9.1.1 Power up, Reset and Power Down Timing 22 9.2 RF Considerations 22 10. Revision Control 23 Module Revision History 26 Trademarks 26 Warranty Limitations 26 Data Sheet: CR Series JukeBlox Networked Media Modules dat_CR860_CR870_3_6_datasheet.doc CONFIDENTIAL Version 3.6 – August 4 th 2011 - Page 4 of 26 1. Introduction The CR-series module is a single-board networked media player module, based on BridgeCo’s DM860 and DM870 media processors, and enables fast product developments with Ethernet, USB and optional WiFi connectivity. The module connects to standard legacy components in various audio, video/LCD and control formats. 2. Block Diagram Ethernet PHY DM860 or DM870 256 Mbit SDRAM JTAG RJ-45 100B-T Mem USB GPIO 24.000 MHz Reset In NAND 1 GB NAND flash 802.11 RF amp (optional) 802.11 RMII SPI RTC 32.768 kHz USB (Host) USB RST UART 5V 3.3V JukeBlox Networked Media Module – CR Series 1.2V Stereo Out Video Out Audio I/O 4/8bit MMC 3x6bit RGB 2 x UART SPI Ctrl. max. 20 GPIOs 3.3V (RTC) SuperCap IR sensor reset signals analog mute I 2 C bus shift register IC control serial control A/D, D/A S/PDIF CCIR-656 LP 2 HP out Display SD-Card AV Ports LCD SSM DAC PIFA Antenna Switcher 1.9V Data Sheet: CR Series JukeBlox Networked Media Modules dat_CR860_CR870_3_6_datasheet.doc CONFIDENTIAL Version 3.6 – August 4 th 2011 - Page 5 of 26 3. Board Pictures 3.1 Top View of CR870-2A 3.2 Bottom View of CR870 types 2A, 2D & 2S PIFA antenna 802.11b/g front-end BridgeCo processor Ethernet FLASH SDRAM antenna connector Media connector LCD connector Note: Components and Socket to the right of the Ethernet and Flash sections are not installed in production modules. Please see Section 3.3 for example production module top view picture. Note: The connector shown to the left of the LCD connector is not installed on production modules. Please see section 3.4 for example production module bottom view picture. +1.9V DC to DC converter Data Sheet: CR Series JukeBlox Networked Media Modules dat_CR860_CR870_3_6_datasheet.doc CONFIDENTIAL Version 3.6 – August 4 th 2011 - Page 6 of 26 3.3 Top View of CR870 types 2C, 2F, 2G, 2I, 2J, 2K & 2R 3.4 Bottom View of CR870 types 2C, 2G, 2I, 2J, 2K, 2L, 2N, 2O, 2P & 2R Versions with no bottom shield and no LCD connector. Please note that production version does not have exposed solder on the underside of the mounting holes. Version with no top shield. Please note that label text will change to show version, and versions 2I, 2J, 2K will have no Ethernet components mounted. Data Sheet: CR Series JukeBlox Networked Media Modules dat_CR860_CR870_3_6_datasheet.doc CONFIDENTIAL Version 3.6 – August 4 th 2011 - Page 7 of 26 3.5 Top View of CR870 types 2D, 2L, 2N, 2O, 2P, 2Q & 2S Versions with top shield. For versions without PIFA antenna, PIFA antenna is not present and UFL connector is present, see the top view of CR870-2A for location of UFL connector. Data Sheet: CR Series JukeBlox Networked Media Modules dat_CR860_CR870_3_6_datasheet.doc CONFIDENTIAL Version 3.6 – August 4 th 2011 - Page 8 of 26 4. Ordering Guide Part Number BridgeCo ICs WiFi Ethernet USB Real- Time Clock LCD PIFA Antenna Ext. Antenna UFL Conn. SDRAM Top Module Shielding Contains shield Incl. connector CR870-2A DM870+T6201 X X X X X X (X)* 32MB CR870-2C DM870+T6201 X X X X 32MB CR870-2D DM870+T6201 X X X X X 32MB X CR870-2F DM870+T6201 X X X X X X (X)* 32MB CR870-2G DM870+T6201 X X X X 32MB CR870-2I DM870+T6201 X X X 16MB CR870-2J DM870+T6201 X X X X 16MB CR870-2K DM870+T6201 X X X X 16MB CR870-2L DM870+T6201 X X X X 32MB X CR870-2M DM870+T6201 X X X X X X (X)* 32MB X CR870-2N DM870+T6201 X X X 16MB X CR870-2O DM870+T6201 X X X X 16MB X CR870-2P DM870+T6201 X X X X 32MB X CR870-2Q DM870+T6201 X X X X 32MB X CR870-2R DM870+T6201 X X X X 16MB CR87…

Text truncated - open the document above for the full version.

Users Manual

Text truncated - open the document above for the full version.

Cover Letter(s)

Bang & Olufsen A/S FCC ID.: TTUCR870-2Q Peter-Bangs-Vej 15, DK-7600 Struer, Denmark Tel : 004596844896 Bang & Olufsen A/S Peter-Bangs-Vej 15, DK-7600 Struer, Denmark Tel : 004596844896 Fax: 004597855950 Federal Communications Commission Oct. 31, 2011 Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant Hereby requests confidential treatment of information accompanying this Application As outlined below: Schematics: (CR870-2Q) Schem Block Diagram : (CR870-2Q) BlkDia Operational Description: (CR870-2Q) OPDes The above materials contain trade secrets and proprietary information not customarily Released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application.

Cover Letter(s)

RF_734_00, Issue 1 Modular Approval Request FCC (per DA 00-1407) FCC ID: _ TTUCR870-2Q _____ Items to be covered Answer from applicant 1. The modular transmitter must have its own RF shielding. Please review external photos. 2. The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. The buffered integrated in chip 6201C. (Chip_U7). 3. The modular transmitter must have its own power supply regulation. There are regulators in front of these chips, the part number of this regulator is APL5910 (Chip_U11). 4. The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable).. Please review external photos or test report. 5. The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing. This is intended to demonstrate that the module is capable of complying with Part 15 emission limits regardless of the device into which it is eventually installed. Please review test setup photos. 6. The modular transmitter must be labeled with its own FCC ID number, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: XYZMODEL1” or “Contains FCC ID: XYZMODEL1.” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. Please review label sample. 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. For example, there are very strict operational and timing requirements that must be met before a transmitter is authorized for operation under Section 15.231. For instance, data transmission is prohibited, except for operation under Section 15.231(e), in which case there are separate field strength level and timing requirements. Compliance with these requirements must be assured. The EUT is compliant with all applicable FCC rules. Detail instructions for maintaining compliance are given in the Users Manual. 8. The modular transmitter must comply with any applicable RF exposure requirements. For example, FCC Rules in Sections 2.1091, 2.1093 and specific Sections of Part 15, including 15.319(i), 15.407(f), 15.253(f) and 15.255(g), require that Unlicensed PCS, UNII and millimeter wave devices perform routine environmental evaluation for RF Exposure to demonstrate compliance. In addition, spread spectrum transmitters operating under Section 15.247 are required to address RF Exposure compliance in accordance with Section 15.247(b)(4). Modular transmitters approved under other Sections of Part 15, when necessary, may also need to address certain RF Exposure concerns, typically by providing specific installation and operating instructions for users, installers and other interested parties to ensure compliance. The EUT is compliant with all applicable RF exposure requirements. RF Exposure is addressed in the RF exposure exhibition.

Cover Letter(s)

Cover Letter FCC ID: TTUCR870-2Q Date: March 08, 2012 Comments Quietek Lab. 1. Please provide MPE analysis. Note that the sample analysis sent in via e-mail contains an error - the numbers in the 4th column of the tables on Page 3 are not distances as indicated in the footnote for the 1 mW/cm^2 limit but instead the power density at 20 cm. Please see the revised RF Exposure report 2. Page 29 of the OEM/ODM User's Manual contains antenna listing for compliance to Industry Canada regulation. Similar information is needed in the FCC sections. The FCC test report on Page 5 does contain such list. To avoid confusion, the grantee should revise the user's manual. Furthermore, the module's antenna connector is a standard UFL connector, hence it is important to let OEM/ODM who plans to build products for the US market knows the limitation on antenna selection. Please see the revised manual. Antenna listing information for FCC sections is added on page 28/29. 3. The grantee is currently using the manufactuer user's manual which is a BridgeCo confidential and copyrighted document (see Page 26 copyright statements). The grantee should present its own user's manual or obtain authorization, including scope of authorization, from the copyright holder. Please see POA letter.

External Photos

Report No.: 119172R-RFUSP42V01 Page : 1 of 6 Attachment 2 : EUT Detailed Photographs (1) EUT Photo (2) EUT Photo

ID Label/Location Info

Bang & Olufsen A/S FCC ID.: TTUCR870-2Q Peter-Bangs-Vej 15, DK-7600 Struer, Denmark Tel : 004596844896 The FCC ID Label will be placed on the equipment as shown in the photograph below.

ID Label/Location Info

Bang & Olufsen A/S FCC ID.: TTUCR870-2Q Peter-Bangs-Vej 15, DK-7600 Struer, Denmark Tel : 004596844896 FCC ID Label

Internal Photos

Report No.: 119172R-RFUSP42V01 Page : 2 of 6 (3) EUT Photo (4) EUT Photo Report No.: 119172R-RFUSP42V01 Page : 3 of 6 (5) EUT Photo (6) EUT Photo Report No.: 119172R-RFUSP42V01 Page : 4 of 6 (7) EUT Photo (8) EUT Photo Report No.: 119172R-RFUSP42V01 Page : 5 of 6 (9) EUT Photo (10) EUT Photo (NISSEI / 544116) Report No.: 119172R-RFUSP42V01 Page : 6 of 6 (11) EUT Photo (NISSEI / 544116) (12) EUT Photo

RF Exposure Info

Report No. 119172R-RFUSP42V01 Page: 1 of 3 RF Exposure Evaluation declaration Product Name JukeBlox Networked Media Module Model No. CX870-2Q FCC ID TTUCR870-2Q Applicant Bang & Olufsen A/S Address Peter-Bangs-Vej 15, DK-7600 Struer, Denmark Date of Receipt June 28, 2011 Date of Declaration Oct. 13, 2011 Report No. 119172R-RFUSP42V01 The declaration results relate only to the samples calculated. The declaration shall not be reproduced except in full without the written approval of QuieTek Corporation. This report must not be used to claim product endorsement by NVLAP any agency of the U.S. Government Report No. 119172R-RFUSP42V01 Page: 2 of 3 1. RF Exposure Evaluation 1.1. Limits According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (Minutes) (A) Limits for Occupational/ Control Exposures 300-1500 -- -- F/300 6 1500-100,000 -- -- 5 6 (B) Limits for General Population/ Uncontrolled Exposures 300-1500 -- -- F/1500 6 1500-100,000 -- -- 1 30 F= Frequency in MHz Friis Formula Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. 1.2. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. The temperature and related humidity: 18°Cand 78％ RH. Report No. 119172R-RFUSP42V01 Page: 3 of 3 1.3. Test Result of RF Exposure Evaluation Product : JukeBlox Networked Media Module Test Item : RF Exposure Evaluation Test Site : No.3 OATS External Antenna Gain Antenna Gain: The maximum Gain measured in fully anechoic chamber is 1.92dBi in logarithm scale. 802.11b Output Power Into Antenna & RF Exposure Evaluation Distance (1.92 dBi): Channel Frequency (MHz) Output Power to Antenna (mW) Power Density at R = 20 cm (mW/cm2) 1 2412.00 31.2608 0.009677 6 2437.00 36.2243 0.011213 11 2462.00 37.8443 0.011715 802.11g Output Power Into Antenna & RF Exposure Evaluation Distance (1.92 dBi): Channel Frequency (MHz) Output Power to Antenna (mW) Power Density at R = 20 cm (mW/cm2) 1 2412.00 141.5794 0.043826 6 2437.00 147.9108 0.045786 11 2462.00 138.9953 0.043026 Power density in column 4 is much lower than the limit (1 mW/mc2).

Test Report

Report No. 119172R-RFUSP42V01 Page : 1 of 62 Test Report Product Name JukeBlox Networked Media Module Model No CR870-2Q FCC ID. TTUCR870-2Q Applicant Bang & Olufsen A/S Address Peter-Bangs-Vej 15, DK-7600 Struer, Denmark Date of Receipt Feb. 01, 2010 Issue Date Oct. 26, 2011 Report No. 119172R-RFUSP42V01 Report Version V1.0 The test results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. This report must not be used to claim product endorsement by NVLAP any agency of the U.S. Government Report No. 119172R-RFUSP42V01 Page : 2 of 62 Test Report Certification Issue Date: Oct. 26, 2011 Report No.: 119172R-RFUSP42V01 Product Name JukeBlox Networked Media Module Applicant Bang & Olufsen A/S Address Peter-Bangs-Vej 15, DK-7600 Struer, Denmark Manufacturer BridgeCo, Inc Model No. CR870-2Q FCC ID. TTUCR870-2Q EUT Rated Voltage DC 3.3V EUT Test Voltage AC 120V/60Hz Trade Name Bang & Olufsen Applicable Standard FCC CFR Title 47 Part 15 Subpart C: 2010 ANSI C63.4: 2009 Test Result Complied The test results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. This report must not be used to claim product endorsement by NVLAP any agency of the U.S. Government Documented By : ( Senior Adm. Specialist / Rita Huang ) Tested By : ( Engineer / Vincent Chu ) Approved By : ( Manager / Vincent Lin ) Accredited by NIST (NVLAP) NVLAP Lab Code: 200533-0 Report No. 119172R-RFUSP42V01 Page : 3 of 62 TABLE OF CONTENTS Description Page 1. GENERAL INFORMATION .....................................................................................................5 1.1. EUT Description............................................................................................................................5 1.2. Operational Description ................................................................................................................7 1.3. Tested System Details....................................................................................................................8 1.4. Configuration of Tested System ....................................................................................................8 1.5. EUT Exercise Software .................................................................................................................8 1.6. Test Facility ...................................................................................................................................9 2. Conducted Emission..................................................................................................................10 2.1. Test Equipment............................................................................................................................10 2.2. Test Setup ....................................................................................................................................10 2.3. Limits ..........................................................................................................................................11 2.4. Test Procedure .............................................................................................................................11 2.5. Uncertainty ..................................................................................................................................11 2.6. Test Result of Conducted Emission.............................................................................................12 3. Peak Power Output ...................................................................................................................14 3.1. Test Equipment............................................................................................................................14 3.2. Test Setup ....................................................................................................................................14 3.3. Limits ..........................................................................................................................................14 3.4. Test Procedure .............................................................................................................................14 3.5. Uncertainty ..................................................................................................................................14 3.6. Test Result of Peak Power Output...............................................................................................15 4. Radiated Emission .....................................................................................................................17 4.1. Test Equipment............................................................................................................................17 4.2. Test Setup ....................................................................................................................................18 4.3. Limits ..........................................................................................................................................19 4.4. Test Procedure .............................................................................................................................20 4.5. Uncertainty ..................................................................................................................................20 4.6. Test Result of Radiated Emission................................................................................................21 5. RF antenna conducted test........................................................................................................29 5.1. Test Equipment............................................................................................................................29 5.2. Test Setup .............................…

Text truncated - open the document above for the full version.

Test Setup Photos

Report No.: 119172R-RFUSP42V01 Page : 1 of 3 Attachment 1: EUT Test Setup Photographs Front View of Conducted Test Back View of Conducted Test Report No.: 119172R-RFUSP42V01 Page : 2 of 3 Front View of Radiated Test Back View of Radiated Test Report No.: 119172R-RFUSP42V01 Page : 3 of 3 Front View of Radiated Test (Horn) Back View of Radiated Test (Horn)

Contact Information

Applicant

Marlon Schrimpf(Product Compliance Lead)

[email protected]+4915168828926Fax: +4597855950

Technical Contact

QuieTek CorporationVicent Lin

[email protected]

Taiwan

Non-Technical Contact

QuieTek CorporationSabina Chen

[email protected]

Test Firm

DEKRA TESTING AND CERTIFICATION CO., LTD. LinKouMirenda Liao

[email protected]+886-2-2602-7968Fax: +886-2-2602-3286

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.41 GHz - 2.46 GHz	150.00 mW

Modular Type

Single Modular Approval

Confidentiality

Long Term

Grant Notes

Power output listed is conducted. This grant is valid only when the module is sold to OEM integrators and must be installed by the OEM or OEM integrators. The antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users may not be provided with the module installation instructions. OEM integrators and end-users must be provided with transmitter operating conditions for satisfying RF exposure compliance.
