WPEA-111N/W WiFi Module OEM General User and Installation Guide I. OEM Usage Instructions Installation The WPEA-111N/W is a Half Mini PCI-E module contains Atheros AR9280 and SiGe SE2593 as its front end module. The area around WPEA-111N/W should be free of any components that may be in contact to the module unintentionally. Operating Conditions ¦ Operating temperature 0° - 60°C ¦ Storage temperature -20° - 70°C ¦ Input: 3.3VDC 0.67A ¦ Dimensions: 26.65 mm x 29.85 mm x 3.3 mm ¦ Weight: <= 9g. RF Exposure Warning This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This device's external antenna must be installed in accordance with provided instructions and it must be operated with a minimum of 20 cm spacing between antennas and all persons’ bodies (excluding extremities of hands, wrists and feet) during wireless mode of operation. Further, this transmitter must not be co-located or operated in conjunction with any other antenna or transmitter. II. Notice of FCC Regulatory Compliance This module has been tested and found to comply with the FCC Part15 Rules. These limits are designed to provide reasonable protection against harmful interference in approved installations. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Modifications or changes to this equipment not expressly approved by Amp’ed RF Technology Inc. may void the user’s authority to operate this equipment. III. Modular Approval FCC ID: TVE-0600101 In accordance with FCC Part 15, the WPEA-111N/W is listed above as a Limited Modular Transmitter device. In support of the Modular Transmitter Approval, the followings are stated: 1. The module does have buffered modulation / data inputs. 2. The module does regulate its own power supply 3. The module does have a permanently attached antenna. 4. The module can be tested as a stand-alone device. 5. The module is labeled with the proper FCC ID, and labeling instructions are provided to OEM end users for external product labels. 6. The module does have instruction for proper use. 7. The module does meet the FCC RF regulations. 8. The module does have its own RF shielding. III. FCC Label instructions The outside of final products that contain a WPEA-111N/W device must display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: TVE-0600101” or “Contains FCC ID: TVE-0600101”. Any similar wording that expresses the same meaning may be used. The label for the WPEA-111N/W module is listed below:

Fortinet, Inc. FCC ID: TVE-0600101 IC: 7280B-0600101 Report No.: R1005072-15E Page 36 of 39 FCC Part15E/IC RSS-210 Test Report 16 Exhibit C - EUT Photographs 16.1 EUT – Top View (With Shielding) 16.2 EUT- Bottom View (With Shielding) Fortinet, Inc. FCC ID: TVE-0600101 IC: 7280B-0600101 Report No.: R1005072-15E Page 37 of 39 FCC Part15E/IC RSS-210 Test Report 16.3 EUT Antenna View 16.4 EUT with PCI-E Supporting Board Top View Fortinet, Inc. FCC ID: TVE-0600101 IC: 7280B-0600101 Report No.: R1005072-15E Page 38 of 39 FCC Part15E/IC RSS-210 Test Report 16.5 EUT with PCI-E Supporting Board Bottom View 16.6 Support Equipment (Express Card Adapter) View

FCC ID & IC Label FCC ID and IC Label Location

Fortinet, Inc. FCC ID: TVE-0600101 IC: 7280B-0600101 Report No.: R1005072-15E Page 39 of 39 FCC Part15E/IC RSS-210 Test Report 16.7 EUT – Top View (Without Shielding) 16.8 EUT- Bottom View ***** END OF REPORT *****

Fortinet, Inc. FCC ID: TVE-0600101 IC: 7280B-0600101 Report No.: R1005072-15E Page 10 of 39 FCC Part15E/IC RSS-210 Test Report 4 FCC §15.407(f), § 2.1091 & IC RSS-102 – RF Exposure 4.1 Applicable Standard According to FCC §15.407(f) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) Limits for General Population/Uncontrolled Exposure 0.3-1.34 614 1.63 * (100) 30 1.34-30 824/f 2.19/f * (180/f 2 ) 30 30-300 27.5 0.073 0.2 30 300-1500 / / f/1500 30 1500-100,000 / / 1.0 30 f = frequency in MHz 1 = Plane-wave equivalent power density Before equipment certification is granted, the procedure of IC RSS-102 must be followed concerning the exposure of humans to RF fields. According to RSS-102 Issue 2 section 4.1, RF limits used for general public will be applied to the EUT. Frequency Range (MHz) Electric Field (V/m rms) Magnetic Field (A/m rms) Power Density (W/m 2 ) Time Averaging (min) 0.003 - 1 280 2.19 - 6 1 - 10 280 / f 2.19 / f - 6 10 - 30 28 2.19 / f - 6 30 – 300 28 0.073 2* 6 300 – 1 500 1.585 f 0.5 0.0042 f 0.5 f / 150 6 1 500 – 15 000 61.4 0.163 10 6 15 000 – 150 000 61.4 0.163 10 616000 / f 1.2 150 000- 300 000 0.158 f 0.5 4.21 x 10 -4 f 0.5 6.67 x 10 -5 f 616000 / f 1.2 Note: ƒ is frequency in MHz 1 = Power density limit is applicable at frequencies greater than 100 MHz Fortinet, Inc. FCC ID: TVE-0600101 IC: 7280B-0600101 Report No.: R1005072-15E Page 11 of 39 FCC Part15E/IC RSS-210 Test Report 4.2 MPE Prediction Predication of MPE limit at a given distance, Equation from OET Bulletin 65, Edition 97-01 S = PG/4πR² Where: S = power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna 4.3 MPE Results 5150– 5250 MHz (W52) Maximum peak output power at antenna input terminal (dBm):16.70 Maximum peak output power at antenna input terminal (mW): 46.77 Prediction distance (cm): 20 Prediction frequency (MHz): 5230 Maximum Antenna Gain, typical (dBi): 5.0 Maximum Antenna Gain (numeric): 3.16 Power density of prediction frequency at 20.0 cm (mW/cm 2 ): 0.029 Power density of prediction frequency at 20.0 cm (W/m 2 ): 0.29 MPE limit for uncontrolled exposure at prediction frequency (mW/cm 2 ): 1.0 MPE limit for uncontrolled exposure at prediction frequency (W/m 2 ):10 The device is compliant with the requirement MPE limit for uncontrolled exposure. The maximum power density at the distance of 20 cm is 0.029mW/cm 2 (0.29W/m 2 ).Limit is 1 mW/cm 2 (10W/m 2 ).

Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. This report must not be used by the customer to claim product certification, approval, or endorsement by NVLAP*, NIST, or any agency of the Federal Government. * This report may contain data that are not covered by the NVLAP accreditation and are marked with an asterisk “*” (Rev.2) FCC PART 15E IC RSS-210, ISSUE 7, JUNE 2007 TEST AND MEASUREMENT REPORT For Fortinet, Inc. 1090 Kifer Road, Sunnyvale, CA 94086, USA FCC ID: TVE-0600101 IC: 7280B-0600101 Report Type: Original Report Product Type: Dual Band Wi-Fi Module Test Engineers: Dennis Huang Report Number: R1005072-15E Report Date: 2010-06-09 Reviewed By: Victor Zhang RF Engineer, Lead Prepared By: (84) Bay Area Compliance Laboratories Corp. 1274 Anvilwood Avenue, Sunnyvale, CA 94089, USA Tel: (408) 732-9162 Fax: (408) 732-9164 Fortinet, Inc. FCC ID: TVE-0600101 IC: 7280B-0600101 Report No.: R1005072-15E Page 2 of 39 FCC Part15E/IC RSS-210 Test Report TABLE OF CONTENTS 1 General Description .................................................................................................................................................... 5 1.1 Product Description for Equipment Under Test (EUT) ....................................................................................... 5 1.2 Mechanical Description of EUT .......................................................................................................................... 5 1.3 EUT Photo ........................................................................................................................................................... 5 1.4 Objective.............................................................................................................................................................. 5 1.5 Related Submittal(s)/Grant(s) .............................................................................................................................. 6 1.6 Test Methodology................................................................................................................................................ 6 1.7 Measurement Uncertainty.................................................................................................................................... 6 1.8 Test Facility ......................................................................................................................................................... 6 2 System Test Configuration ......................................................................................................................................... 7 2.1 Justification.......................................................................................................................................................... 7 2.2 EUT Exercise Software ....................................................................................................................................... 7 2.3 Equipment Modifications .................................................................................................................................... 7 2.4 Special Accessories ............................................................................................................................................. 7 2.5 Local Support Equipment .................................................................................................................................... 7 2.6 Interface Ports and Cabling ................................................................................................................................. 7 2.7 EUT Internal Configurations ............................................................................................................................... 8 3 Summary of Test Results ............................................................................................................................................ 9 4 FCC §15.407(f), § 2.1091 & IC RSS-102 – RF Exposure ......................................................................................... 10 4.1 Applicable Standard .......................................................................................................................................... 10 4.2 MPE Prediction.................................................................................................................................................. 11 4.3 MPE Results ...................................................................................................................................................... 11 5 FCC §15.203 & IC RSS-Gen §7.1.4 – Antenna Requirement.................................................................................. 12 5.1 Applicable Standard .......................................................................................................................................... 12 5.2 Antenna Gain ..................................................................................................................................................... 12 6 FCC §15.207 & IC RSS-Gen 7.2.2- Conducted Emissions....................................................................................... 13 6.1 Applicable Standards ......................................................................................................................................... 13 6.2 Test Results ....................................................................................................................................................... 13 7 FCC §15.407(b) & IC RSS-210 §A9.3- Spurious Emissions at Antenna Terminals.............................................. 14 7.1 Applicable Standard ..........................................................................................................…

Text truncated - open the document above for the full version.

Fortinet, Inc. FCC ID: TVE-0600101 IC: 7280B-0600101 Report No.: R1005072-15E Page 34 of 39 FCC Part15E/IC RSS-210 Test Report 15 Exhibit B - Test Setup Photographs 15.1 Radiated Emission below 1 GHz - Front View 15.2 Radiated Emission below 1 GHz - Rear View Fortinet, Inc. FCC ID: TVE-0600101 IC: 7280B-0600101 Report No.: R1005072-15E Page 35 of 39 FCC Part15E/IC RSS-210 Test Report 15.3 Radiated Emission above 1 GHz - Front View 15.4 Radiated Emission above 1 GHz - Rear View
