TVE-23155011Secured Wireless Access Point

FortiAP S321CR Information Box Includes Information Supplement FortiAP 321CRT-Rail Mounting Kit Wall/Ceiling Mounting Kit Wall Mount Bracket Installation The unit can be mounted on a wall or ceiling using the provided wall/ceiling mounting kit, or to an appropriate ceiling using the T-rail mounting kit. To attach the unit to a T-rail 1. Attach the T-rail clips to the bottom of the unit using two P2.6X10 screws. If extra space is required to accommodate drop ceiling tiles, use the provided spacers and P2.6x25 screws. 2. Line up the connected T-rail clips with an appropriately sized rail, then press the unit into the rail until it snaps into place. To attach the unit to a wall or ceiling 1. Select an appropriate location, then mark the locations on the wall or ceiling where the anchors will be inserted. 2. Drill the mounting holes, then insert the anchors into the holes. 3. Attach the mounting bracket to the anchors using two P3.5x32 screws. 4. Insert two P2.6X15 screws into the bottom of the unit, leaving enough of the screws exposed so that the unit can be mounted to the mounting bracket. If extra space is required between the unit and the mounting bracket, use the spacers and P2.6x25 screws from the T-rail mounting kit. 5. Mount the device on the installed mounting bracket then rotate it clockwise to secure it in place. Note: Two sizes of T-rail clips are included: 2.38cm (15/16in) and 1.43cm (9/16in). To protect your device from unauthorized removal, use the Kensington™ Security Slot to attach a cable lock (not included). Mounting Anchors P3.5x32P2.6x15P2.6x25P2.6x10 Device Guide Kensington™ Security Slot Anti-theft security slot for connecting lock-and-cable apparatus Ethernet Port (RJ-45) Gigabit Ethernet port with Power over Ethernet (PoE) Powered Device (PD) support Power 12V DC, 2A Console Port (RJ-45) Optional management computer connection Provides access to the Command-Line Interface (CLI) USB Port (USB A) Wireless Radios Radio 1 2 FAP-S321CR 2.4G 5G Device Guide Status Green: Controller is managing device Amber: Controller found, device not managed Flashing Amber: Error connecting to the controller Off: Wireless controller not found WiFi 1 Green: Radio is enabled Flashing Green: Transmitting & receiving data at 2.4G Off: Radio disabled or off LAN 1 & 2 Green: Connected at 1Gbps Flashing Amber: Transmitting at 100Mbps Flashing Green: Transmitting & receiving data at 1000Mbps Off: No link established Power Green: Power on and ready for operation Flashing Green: Booting up Off: No power Amber: Customized Configuration WiFi 2 Green: Radio is enabled Flashing Green: Transmitting & receiving data at 5G Off: Radio disabled or off Cautions and Warnings Environmental Specifications Refer to specific Product Model Data Sheet for Environmental Specifications (Operating Temperature, Storage Temperature, Humidity, and Altitude). Référez à la Fiche Technique de ce produit pour les caractéris- tiques environnementales (Température de fonctionnement, température de stockage, humidité et l’altitude). Safety Caution: This equipment is to be used in a Network Environ- ment 0 per IECTR 62101. This product is connected only to PoE networks without routing to the outside plant. Attention: Ce matériel doit être utilisé dans un Environnement Réseau 0 par IECTR 62101. Ce produit est uniquement con- necté aux réseaux PoE sans installation externe de routage. This product is intended to be supplied by a Listed Direct Plug- In Power Unit marked LPS or Class 2 and rated 12 Vdc, 2 A or by 48 Vdc from PoE source. Le produit doit être alimenté par un bloc d’alimentation à courant continu homologué UL de 12 Vdc, 2 A nominal marqué LPS ou Class 2 ou par une source d’alimentation par Ethernet de 48 Vdc (PoE). Regulatory Compliance Federal Communication Commission (FCC) – USA This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received; including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in residential installation. This equipment generates, uses, and can radiate radio frequency energy, and if it is not installed and used in accordance with the instruction manual, it may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. WARNING: Any changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance of 32 cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Caution: Operation of this device is restricted to indoor use only. Industry Canada Equipment Standard for Digital Equipment (ICES) – Canada CAN ICES-3 (B) / NMB-3 (B. Industry Canada (IC RSS) – Canada This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditi…

Text truncated - open the document above for the full version.

FortiAP S323CR Information Box Includes Information Supplement FortiAP 323CRT-Rail Mounting Kit Wall/Ceiling Mounting Kit Wall Mount Bracket 3 Antennas Installation The unit can be mounted on a wall or ceiling using the provided wall/ceiling mounting kit, or to an appropriate ceiling using the T-rail mounting kit. To attach the unit to a T-rail 1. Attach the T-rail clips to the bottom of the unit using two P2.6X10 screws. If extra space is required to accommodate drop ceiling tiles, use the provided spacers and P2.6x25 screws. 2. Attach the provided antennas to the device. 3. Line up the connected T-rail clips with an appropriately sized rail, then press the unit into the rail until it snaps into place. To attach the unit to a wall or ceiling 1. Select an appropriate location, then mark the locations on the wall or ceiling where the anchors will be inserted. 2. Drill the mounting holes, then insert the anchors into the holes. 3. Attach the mounting bracket to the anchors using two P3.5x32 screws. 4. Insert two P2.6X15 screws into the bottom of the unit, leaving enough of the screws exposed so that the unit can be mounted to the mounting bracket. If extra space is required between the unit and the mounting bracket, use the spacers and P2.6x25 screws from the T-rail mounting kit. 5. Attach the provided antennas to the device, then mount the device on the installed mounting bracket and rotate it clockwise to secure it in place. Note: Two sizes of T-rail clips are included: 2.38cm (15/16in) and 1.43cm (9/16in). To protect your device from unauthorized removal, use the Kensington™ Security Slot to attach a cable lock (not included). Mounting Anchors P3.5x32P2.6x15P2.6x25P2.6x10 Device Guide Wireless Radios Radio 1 2 FAP-S323CR 2.4G 5G Kensington™ Security Slot Anti-theft security slot for connecting lock-and-cable apparatus Ethernet Port (RJ-45) Gigabit Ethernet port with Power over Ethernet (PoE) Powered Device (PD) support Power 12V DC, 2A Console Port (RJ-45) Optional management computer connection Provides access to the Command-Line Interface (CLI) USB Port (USB A) Device Guide WiFi 1 Green: Radio is enabled Flashing Green: Transmitting & receiving data at 2.4G Off: Radio disabled or off LAN 1 & 2 Green: Connected at 1Gbps Flashing Amber: Transmitting at 100Mbps Flashing Green: Transmitting & receiving data at 1000Mbps Off: No link established Power Green: Power on and ready for operation Flashing Green: Booting up Off: No power Amber: Customized Configuration WiFi 2 Green: Radio is enabled Flashing Green: Transmitting & receiving data at 5G Off: Radio disabled or off Cautions and Warnings Environmental Specifications Refer to specific Product Model Data Sheet for Environmental Specifications (Operating Temperature, Storage Temperature, Humidity, and Altitude). Référez à la Fiche Technique de ce produit pour les caractéris- tiques environnementales (Température de fonctionnement, température de stockage, humidité et l’altitude). Safety Caution: This equipment is to be used in a Network Environ- ment 0 per IECTR 62101. This product is connected only to PoE networks without routing to the outside plant. Attention: Ce matériel doit être utilisé dans un Environnement Réseau 0 par IECTR 62101. Ce produit est uniquement con- necté aux réseaux PoE sans installation externe de routage. This product is intended to be supplied by a Listed Direct Plug- In Power Unit marked LPS or Class 2 and rated 12 Vdc, 2 A or by 48 Vdc from PoE source. Le produit doit être alimenté par un bloc d’alimentation à courant continu homologué UL de 12 Vdc, 2 A nominal marqué LPS ou Class 2 ou par une source d’alimentation par Ethernet de 48 Vdc (PoE). Regulatory Compliance Federal Communication Commission (FCC) – USA This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received; including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in residential installation. This equipment generates, uses, and can radiate radio frequency energy, and if it is not installed and used in accordance with the instruction manual, it may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. WARNING: Any changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance of 32 cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Caution: Operation of this device is restricted to indoor use only. Industry Canada Equipment Standard for Digital Equipment (ICES) – Canada CAN ICES-3 (B) / NMB-3 (B). Industry Canada (IC RSS) – Canada This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this devic…

Text truncated - open the document above for the full version.

Page 1 CONSTRUCTION PHOTOS OF EUT FAP‐S321CR Page 2 FAP‐S323CR Page 3 Page 4 Page 5 Page 6

Label location

Page 1 CONSTRUCTION PHOTOS OF EUT FAP‐S321CR Page 2 Page 3 Page 4 Page 5 Page 6 Page 7 Page 8 Page 9 FAP‐S323CR Page 10 Page 11 Page 12 Page 13 Page 14 Page 15 Page 16 Page 17 Page 18 Page 19 Page 20 Page 21

Report No.: SA150414C33 Page No. 1 / 6 Report Format Version: 6.1.1 RF Exposure Report Report No.: SA150414C33 FCC ID: TVE-23155011 Test Model: FAP-S321CR, FAP-S323CR Series Model: FortiAP-S321CRxxxxxx, FAP-S321CRxxxxxx, FORTIAP-S321CRxxxxxx, FortiAP-S323CRxxxxxx, FAP-S323CRxxxxxx, FORTIAP-S323CRxxxxxx (where “x” can be used as “A-Z”, or “0-9”, or “-”, or blank for software changes or marketing purposes only) Received Date: Apr. 29, 2015 Test Date: Apr. 29 ~ May 30, 2015 Issued Date: Jun. 11, 2015 Applicant: Fortinet lnc. Address: 899 Kifer Road Sunnyvale, CA 94086 USA Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Lab Address: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan Test Location: No. 19, Hwa Ya 2nd Rd., Wen Hwa Vil., Kwei Shan Dist., Taoyuan City 33383, TAIWAN (R.O.C.) This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. The report must not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: SA150414C33 Page No. 2 / 6 Report Format Version: 6.1.1 Table of Contents Release Control Record .................................................................................................................................. 3 1 Certificate of Conformity ...................................................................................................................... 4 2 RF Exposure .......................................................................................................................................... 5 2.1 Limits For Maximum Permissible Exposure (MPE) ............................................................................. 5 2.2 Mpe Calculation Formula .................................................................................................................... 5 2.3 Classification ....................................................................................................................................... 5 3 Calculation Result Of Maximum Conducted Power .......................................................................... 6 Report No.: SA150414C33 Page No. 3 / 6 Report Format Version: 6.1.1 Release Control Record Issue No. Description Date Issued SA150414C33 Original release. Jun. 11, 2015 Report No.: SA150414C33 Page No. 4 / 6 Report Format Version: 6.1.1 1 Certificate of Conformity Product: Secured Wireless Access Point Brand: Fortinet lnc. Test Model: FAP-S321CR, FAP-S323CR Series Model: FortiAP-S321CRxxxxxx, FAP-S321CRxxxxxx, FORTIAP-S321CRxxxxxx, FortiAP-S323CRxxxxxx, FAP-S323CRxxxxxx, FORTIAP-S323CRxxxxxx (where “x” can be used as “A-Z”, or “0-9”, or “-”, or blank for software changes or marketing purposes only) Sample Status: Engineering sample Applicant: Fortinet lnc. Test Date: Apr. 29 ~ May 30, 2015 Standards: FCC Part 2 (Section 2.1091) KDB 447498 D03 IEEE C95.1 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. Prepared by : , Date:Jun. 11, 2015 Pettie Chen / Senior Specialist Approved by : , Date:Jun. 11, 2015 Ken Liu / Senior Manager Report No.: SA150414C33 Page No. 5 / 6 Report Format Version: 6.1.1 2 RF Exposure 2.1 Limits For Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) Limits For General Population / Uncontrolled Exposure 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 2.2 MPE Calculation Formula Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 2.3 Classification The antenna of this product, under normal use condition, is at least 30cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA150414C33 Page No. 6 / 6 Report Format Version: 6.1.1 3 Calculation Result Of Maximum Conducted Power For Internal antenna: Frequency Band (MHz) Max Power (dBm) Antenna Gain (dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) 2412-2462 29.36 8.01 30 0.483 1 5180-5240 25.88 10.57 30 0.390 1 5745-5825 26.00 10.57 30 0.401 1 Note: 2.4GHz Band: Directional gain = 10 log[(10 G1 /20 + 10 G2 /20 + ... + 10 GN /20 ) 2 /3]= 8.01dBi 5.0GHz Band: Directional gain = 10 log[(10 G1 /20 + 10 G2 /20 + ... + 10 GN /20 )…

Text truncated - open the document above for the full version.

Report No.: RF150414C33 Page No. 1 / 81 Report Format Version: 6.1.1 FCC Test Report Report No.: RF150414C33 FCC ID: TVE-23155011 Test Model: FAP-S321CR, FAP-S323CR Series Model: FortiAP-S321CRxxxxxx, FAP-S321CRxxxxxx, FORTIAP-S321CRxxxxxx, FortiAP-S323CRxxxxxx, FAP-S323CRxxxxxx, FORTIAP-S323CRxxxxxx (where “x” can be used as “A-Z”, or “0-9”, or “-”, or blank for software changes or marketing purposes only) Received Date: Apr. 29, 2015 Test Date: Apr. 29 ~ May 30, 2015 Issued Date: Jun. 11, 2015 Applicant: Fortinet lnc. Address: 899 Kifer Road Sunnyvale, CA 94086 USA Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Lab Address: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan Test Location: No. 19, Hwa Ya 2nd Rd., Wen Hwa Vil., Kwei Shan Dist., Taoyuan City 33383, TAIWAN (R.O.C.) This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF150414C33 Page No. 2 / 81 Report Format Version: 6.1.1 Table of Contents Release Control Record .................................................................................................................................. 4 1 Certificate of Conformity ...................................................................................................................... 5 2 Summary of Test Results ..................................................................................................................... 6 2.1 Measurement Uncertainty ................................................................................................................... 6 2.2 Modification Record ............................................................................................................................ 6 3 General Information .............................................................................................................................. 7 3.1 General Description of EUT ................................................................................................................ 7 3.2 Description of Test Modes ................................................................................................................... 9 3.2.1 Test Mode Applicability and Tested Channel Detail ........................................................................... 10 3.3 Duty Cycle of Test Signal .................................................................................................................. 12 3.4 Description of Support Units ............................................................................................................. 13 3.4.1 Configuration of System under Test .................................................................................................. 14 3.5 General Description of Applied Standards ........................................................................................ 15 4 Test Types and Results ...................................................................................................................... 16 4.1 Radiated Emission and Bandedge Measurement ............................................................................. 16 4.1.1 Limits of Radiated Emission and Bandedge Measurement .............................................................. 16 4.1.2 Test Instruments ................................................................................................................................ 17 4.1.3 Test Procedures ................................................................................................................................. 18 4.1.4 Deviation from Test Standard ............................................................................................................ 18 4.1.5 Test Set Up ........................................................................................................................................ 19 4.1.6 EUT Operating Conditions ................................................................................................................. 19 4.1.7 Test Results ....................................................................................................................................... 20 4.2 Conducted Emission Measurement .................................................................................................. 48 4.2.1 Limits of Conducted Emission Measurement .................................................................................... 48 4.2.2 Test Instruments ................................................................................................................................ 48 4.2.3 Test…

Text truncated - open the document above for the full version.

Report No.: RF150414C33-1 Page No. 1 / 92 Report Format Version:6.1.1 FCC Test Report Report No.: RF150414C33-1 FCC ID: TVE-23155011 Test Model: FAP-S321CR, FAP-S323CR Series Model: FortiAP-S321CRxxxxxx, FAP-S321CRxxxxxx, FORTIAP-S321CRxxxxxx, FortiAP-S323CRxxxxxx, FAP-S323CRxxxxxx, FORTIAP-S323CRxxxxxx (where “x” can be used as “A-Z”, or “0-9”, or “-”, or blank for software changes or marketing purposes only) Received Date: Apr. 29, 2015 Test Date: Apr. 29 ~ May 30, 2015 Issued Date: Jun. 11, 2015 Applicant: Fortinet lnc. Address: 899 Kifer Road Sunnyvale, CA 94086 USA Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Lab Address: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan Test Location: No. 19, Hwa Ya 2nd Rd., Wen Hwa Vil., Kwei Shan Dist., Taoyuan City 33383, TAIWAN (R.O.C.) This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. The report must not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF150414C33-1 Page No. 2 / 92 Report Format Version:6.1.1 Table of Contents Release Control Record .................................................................................................................................. 4 1 Certificate of Conformity ...................................................................................................................... 5 2 Summary of Test Results ..................................................................................................................... 6 2.1 Measurement Uncertainty ................................................................................................................... 6 2.2 Modification Record ............................................................................................................................ 6 3 General Information .............................................................................................................................. 7 3.1 General Description of EUT ................................................................................................................ 7 3.2 Description of Test Modes ................................................................................................................... 9 3.2.1 Test Mode Applicability and Tested Channel Detail ........................................................................... 10 3.3 Duty Cycle of Test Signal .................................................................................................................. 12 3.4 Description of Support Units ............................................................................................................. 13 3.4.1 Configuration of System under Test .................................................................................................. 14 3.5 General Description of Applied Standard .......................................................................................... 15 4 Test Types and Results ...................................................................................................................... 16 4.1 Radiated Emission and Bandedge Measurement ............................................................................. 16 4.1.1 Limits of Radiated Emission and Bandedge Measurement .............................................................. 16 4.1.2 Test Instruments ................................................................................................................................ 17 4.1.3 Test Procedure .................................................................................................................................. 18 4.1.4 Deviation from Test Standard ............................................................................................................ 18 4.1.5 Test Setup .......................................................................................................................................... 19 4.1.6 EUT Operating Conditions ................................................................................................................. 19 4.1.7 Test Results ....................................................................................................................................... 20 4.2 Conducted Emission Measurement ........................................................................................…

Text truncated - open the document above for the full version.
