FortiAP 222C QuickStart Guide FortiAP-222C-QuickStart.indd 12014-08-05 3:33:10 PM August 05, 2014 20-520-241153-20140805 Copyright© 2014 Fortinet, Inc. All rights reserved. Fortinet®, FortiGate®, FortiCare® and FortiGuard®, and certain other marks are registered trademarks of Fortinet, Inc., and other Fortinet names herein may also be registered and/or common law trademarks of Fortinet. All other product or company names may be trademarks of their respective owners. Performance and other metrics contained herein were attained in internal lab tests under ideal conditions, and actual performance and other results may vary. Network variables, different network environments and other conditions may affect performance results. Nothing herein represents any binding commitment by Fortinet, and Fortinet disclaims all warranties, whether express or implied, except to the extent Fortinet enters a binding written contract, signed by Fortinet’s General Counsel, with a purchaser that expressly warrants that the identified product will perform according to certain expressly-identified performance metrics and, in such event, only the specific performance metrics expressly identified in such binding written contract shall be binding on Fortinet. For absolute clarity, any such warranty will be limited to performance in the same ideal conditions as in Fortinet’s internal lab tests. Fortinet disclaims in full any covenants, representations,and guarantees pursuant hereto, whether express or implied. Fortinet reserves the right to change, modify, transfer, or otherwise revise this publication without notice, and the most current version of the publication shall be applicable. FortiAP-222C-QuickStart.indd 22014-08-05 3:33:10 PM QuickStart Guide Register for Support Register your Fortinet product to receive: • Technical Support • New product features • Protection from new threats Vous devez enregistrer le produit pour recevoir: • Support technique • Nouvelles fonctionnalitées du produit • Protection contre de nouvelles menaces La reistrazione ti permette di usufruire di: • Supporto Tecnico • Nuove funzionalita • Proteezione dalle ultime minaccce Debe registrar el producto para recibir: • Apoyo técnico • Nuevas funcionalidades del producto • Protección contra ataques 登録のお願い 本日、フォーティネット製品の登録をしてください。 登録すると次のメリットがあります。 テクニカルサポート • 新機能の追加 • 新しい脅威への防御 请马上注册 您的飞塔产品 您在注册以后才能得到技术支持、新产品特点信息、最新威胁防护 http://forti.net/support Toll free: 1 866 648 4638 Phone: 1 408 486 7899 Fax: 1 408 235 7737 Email: [email protected] FortiAP-222C-QuickStart.indd 32014-08-05 3:33:10 PM Box Includes 4 4 PoE Injector Wall-Mount Base Pole-Mount Bracket Power Adapter Pole-Mount Strap Waterproof Connector Mounting Screws (8) and Bolts (4) 2.4GHz Antennae (2) FortiAP 222C QuickStart Guide QuickStart Guide FortiAP 222C 5GHz Antennae (2) 3 Grounding Cables Surge Protector FortiAP-222C-QuickStart.indd 42014-08-05 3:33:14 PM

QuickStart Guide Video http://forti.net/vqsg Before You Begin Write down details that you may need from your network administrator or ISP. 5 DSL PPPoE Username Password Cable Modem DHCP It is normal to not require a hostname, but your ISP may require it. Hostname T1/E1, Static broadband, Cable, or DSL with a static IP address IP Address Subnet Mask Default Gateway Primary/Secondary DNS FortiAP-222C-QuickStart.indd 52014-08-05 3:33:14 PM 66 Installation 1 IMPORTANT NOTE: The device must be professionally installed and must use the supplied antennae. The unit is designed for outdoor use and may be attached to either a pole or wall. A waterproof connector is supplied to ensure a watertight seal for connecting the Ethernet cable to the device. Note: The included PoE injector and surge protector must be mounted indoors, as they are not weatherproof. To mount the device on a wall 1. Using the wall-mount base as a template, mark the location of the mounting bolt holes on a flat wall surface. 2. Drill the mounting holes in the marked locations. 3. Fasten the wall-mount base securely to the back of the unit using the provided mounting screws. 4. Attach the unit and base assembly to the wall using the provided concrete mounting bolts. 5. Securely tighten the mounting bolts. FortiAP-222C-QuickStart.indd 62014-08-05 3:33:15 PM 7 To mount the FortiAP unit on a pole 1. Fasten the wall-mount base securely to the back of the unit using the provided mounting screws. 2. Attach the pole-mount bracket to the wall-mount base using with the provided screws. The pole-mount bracket can be attached either vertically or horizontally, as required. 3. Loop the provided pole strap through the slots on the pole-mount bracket and then around the pole. 4. Tighten the strap with an appropriate screw driver and ensure that the device is firmly in place. FortiAP-222C-QuickStart.indd 72014-08-05 3:33:17 PM 88 The FortiAP 222C unit provides dual concurrent radio signals. Use the top antenna mounts to access the Radio 1 (802.11 b/g/n at 300Mbps) signals, and the bottom antenna mounts (near the waterproof PoE connector) to access the Radio 2 (802.11 a/n/ac at 867Mbps) signals. To use both radio frequencies concurrently, use all four WiFi antennae. To Install the WiFi antennae 1. Insert the antenna base firmly into the appropriate antenna mount. 2. Securely hand tighten the fastening collar. 3. Repeat for the remaining antennae. Antennae A FortiAP-222C-QuickStart.indd 82014-08-05 3:33:18 PM 9 Cabling B The unit requires 48V DC power, which is delivered by the PoE injector, through the surge protector, over a straight-through Ethernet cable. To install the weatherproof connector 1. Unscrew the coupling ring from the waterproof connector, remove the sealing gland, and thread the RJ-45 plug through the connector components. 2. Insert the RJ-45 plug into the PoE port on the unit and install the weatherproof panel connector onto the threaded coupling at the port. 3. Slide the sealing gland along the cable into panel connector. 4. Thread the coupling ring onto the panel connector and tighten it until the sealing gland is compressed, making a watertight seal on the cable. Coupling RingSealing Gland Waterproof Panel Connector FortiAP-222C-QuickStart.indd 92014-08-05 3:33:18 PM 1010 Connections 2 Adequate grounding must be provided to the FortiAP unit, the PoE injector, and the surge protector; grounding lugs and cables are provided for this purpose. Consult a certified electrician to ensure that all grounding and cabling is installed in compliance with the local electrical code. Use an exterior-grade or direct burial CAT5 Ethernet cable for connecting the outdoor unit to the surge protector. Use the supplied weatherproof connector to ensure a tight seal at the PoE port on the unit. To wire the surge protector 1. Remove the cover of the surge protector using an appropriate screwdriver. 2. Connect the ground wire with the spade lug connector to the grounding post between the two ethernet connectors. 3. Connect the straight-through Ethernet cable that will connect to the FortiAP unit to the Ethernet port on the right side of the surge protector. 4. Connect the straight-through Ethernet cable that will connect to the PoE injector the Ethernet port on the left side of the surge protector. 5. Ensure that the cables comfortably pass through the provided slots on the front of the surge protector. 6. Replace the cover onto the surge protector using an appropriate screwdriver. To FortiAPTo PoE Injector Note: The PoE injector and surge protector units are not weatherproof and must be mounted indoors. They should be mounted as close together as possible. FortiAP-222C-QuickStart.indd 102014-08-05 3:33:19 PM 11 To Connect the FortiAP unit 1. Connect grounding cables to the grounding lugs on both FortiAP unit (bottom middle of unit) and the PoE injector, then connect the other ends of the cables to appropriate ground connections. 2. Connect the surge protector’s grounding cable to an appropriate ground connection. 3. Connect the region-specific AC plug adapter to the AC power adapter by inserting the round disk into the adapter and rotating clockwise until you hear the disk lock in place. 4. Insert the DC plug of the power adapter into the DC IN port on the PoE injector, then plug the AC adapter into an appropriate power outlet. The PWR LED will light up. 5. Connect one end of a cross-over Ethernet cable to the Network port on the PoE injector. Connect the other end to the FortiGate controller or an Internet connection. 6. Using the supplied weatherproof connector, connect the weatherproof, straight-through Ethernet cable on the right side of the surge protector to the PoE port on the bottom of the FortiAP unit, as described in “Cabling” on page 9. 7. Connect the straight-through Ethernet cable on the left side of the surge protector into the AP/Bridge port on the PoE injector. Controller or Internet PoE Injector Power Adapter Surge Protector Intern…
