FortiAP U432F FortiAP U234F Quick Start Guide About FAP-U432F IMPORTANT: Supported only from FortiWLC Release 8.6.2 or later and FortiGate with FortiOS Release 6.4.4 and later. The FAP-U432F is a tri-radio, dual band 802.11ax 2.4/5GHz outdoor access point and supports three 4x4 MIMO radios. This high performance device complies with the 802.3bt, 802.3at, and 802.3af PoE specifications and supports BLE and ZigBee. The FAP-U432F supports 11 external 5dBi 2.4/5GHz dual band omni antennas and operates with a default TX power of (To be updated) dBm in 2.4GHz channels and (To be updated) dBm in 5.0GHz channels. The FAP-U432F is compatible with FortiWLC enterprise wireless LAN controllers, integrated FortiGate enterprise firewall LAN controllers, and FortiCloud controllers. This device can be wall mounted or pole mounted. Use the supplied hardware components to complete installing the unit. CAUTION: There is a non-rechargeabe coin battery inside DUT for the RTC function. Do Not recharge the battery as it may overheat and leak. 1 FortiAP-U432F QuickStart Guide FAP-U432F Box Includes 2 Mounting Screws (8) & Bolts (4) Pole Mount Bracket Wall Mount Bracket 7” Pole Mount Strap (2) 3” Pole Mount Strap (2) FAP-U432F Box Includes Sector Antenna Bracket PIN060 POE Adapter Power Cable Grounding Cable 3 Weatherproof Connector Grounding Screw 2.4 GHz Antenna 5 GHz Antenna Dual band (2.4/5GHz) Antenna Ethernet Port (RJ-45) 1 Gigabit Ethernet port with Power over Ethernet (PoE) support Console Port (RJ-45) Optional management computer connection Provides access to the Command-Line Interface (CLI) Serial Baud Rate 115200 4 AP Port (PoE output) Network Port (RJ-45) Gigabit Ethernet port for network connection or internet Power adapter connection Ethernet Port (RJ-45) 2.5 Gigabit Ethernet port with Power Sourcing Equipment (PSE) support FAP-U432F Ports 5 - Bluetooth, ZigBee and Radio 3 No light: Radio 3, BLE, and ZigBee are powered off Green: Radio 3, BLE, and Zigbee are enabled Blinking Green: Data Tx/Rx on Radio 3, BLE, and Zigbee Amber: Radio 3 is up. Blinking Amber: Data Tx/Rx on Radio 3 Blue: BLE is enabled Blinking Blue: Data Tx/Rx on BLE Red: Zigbee is enabled Blinking Red: Data Tx/Rx on Zigbee 4 - WiFi (Radio 1 and 2) No light: Radio 1 and 2 are powered Off Blue: Radio 1 is up. Blinking Blue: Data Tx/Rx on Radio 1. Amber: Radio 2 is up. Blinking Orange : Data Tx/Rx on Radio 2. Green: Both Radio 1 and 2 are up. Blinking Green: Data Tx/Rx on both Radio 1 and 2. 1 - Power No light: Power Off/Wireless controller not found. Steady Green: Power On Blinking Green: Data Tx/Rx at 1Gbps. Blinking Amber: Data Tx/Rx at 100Mbps. 2 - LAN1 and LAN 2 No light: Link Down Green: Link up Blinking Green: Data Tx/Rx at 1Gbps Blinking Orange: Data Tx/Rx at 100Mbps 5 6 FAP-U432F LED Status FAP-U432F Antennas The FortiAP unit provides dual concurrent radio signals. Use the 2.4GHz antennas to access 2.4GHz radio (IEEE 802.11b/g/n) signals and the 5GHz antennas to access 5GHz radio (IEEE 802.11a/n/ac/ax) signals. To use both radio frequencies concurrently, use all 11 WiFi antennas. Follow this procedure to install the antennas. 1. Insert the antenna base firmly into the appropriate antenna mount. 2. Securely hand tighten the fastening collar 3. Repeat for the remaining antennas 7 Follow this procedure to attach the unit to a wall using the supplied equipment. 1. Mark the location of the mounting bolt holes on a flat wall surface, using the wall-mount base as a template. 2. Drill mounting holes in the marked locations and hammer the bolts into the openings. 3. Attach the wall-mount base to the back of the access point using the mounting screws. 8 Wall Mounting FAP-U432F 4. Attach the access point onto the wall using the mounting bolts and secure the mounting base to the wall. 9 Follow this procedure to attach the unit to a pole vertically or horizontally using the supplied pole mount bracket and straps. 1. Attach the wall-mount base to the back of the device and then attach the pole-mount bracket to the wall-mount base using the mounting screws. 10 Pole Mounting FAP-U432F 3. Loop the pole straps through the slots on the bracket and then around the pole. The pole mounting straps can be attached for either vertical or horizontal mounting. 4. Tighten the straps with screws to attach the unit securely to the pole. 11 12 The weatherproof connects are provided for the LAN ports to ensure a watertight seal for connecting the Ethernet cable to the device. 1. Unscrew the coupling ring from the waterproof connector, remove the sealing gland, and thread the RJ-45 plug through the connector components. 2. Insert the RJ-45 plug into the PoE port on the unit and install the weatherproof panel connector onto the threaded coupling at the port. Installing Weatherproof Connectors 3. Slide the sealing gland along the cable into panel connector. 4. Thread the coupling ring onto the panel connector and tighten it until the sealing gland is compressed, making a watertight seal on the cable. 13 About FAP-U234F IMPORTANT: Supported only from FortiWLC Release 8.6.2 or later and FortiGate with FortiOS Release 6.4.4 and later. The FAP-U234F is a tri-radio, dual band 802.11ax 2.4/5GHz outdoor access point and supports three 2x2 MIMO radios. This high performance device complies with the 802.3at and 802.3af PoE specifications and supports BLE and ZigBee. The FAP-U234F operates with a default TX power of (To be updated) dBm in 2.4GHz channels and (To be updated) dBm in 5.0GHz channels. The FAP-U234F is compatible with FortiWLC enterprise wireless LAN controllers, integrated FortiGate enterprise firewall LAN controllers, and FortiCloud controllers. This device can be wall mounted or pole mounted. Use the supplied hardware components to complete installing the unit. CAUTION: There is a non-rechargeabe coin battery inside DUT for the RTC function. Do Not recharge the battery as it may overheat and leak. 14 FortiAP-U234F QuickStart Guide FAP-U234F Box Includes 15…

Text truncated - open the document above for the full version.

899 Kifer Road Sunnyvale, CA 94086, USA TEL: 408 235 7700 FAX: 408 235 7737 P R O F E S S I O N A L I N S T A L LA T I O N A T T E S T A T I O N Date: 2021-04-08 FCC ID: TVE-371CBE0271 We, Fortinet Inc., hereby declare that requirements of KDB 353028 D01 Antennas Part 15 Transmitters v01 have been met and shown on the following questions. Further we declare that the info listed below are correct and represent the product in consideration under this filing. 1. Professional installation must be justified. Description: Device is Secured Wireless Access Point and must need special trained professional in configuring and installing the product, more details please refer to user manual exhibit. 2. Professional installation does not permit use of any antenna with the transmitter; the permitted types of antenna specified as below. Description: Below listed of Antennas has been compliance FCC Rule Part 15 requirement, more details please refer to test reports. FAP-U234F Antenna Type Patch Antenna Connector IPEX Antenna No. Gain (dBi) 2400MHz 2450MHz 2500MHz UNII-1 & UNII-2A UNII-2C UNII-3 Ant1 9.45 10.15 9.77 - - - Ant2 9.21 10.12 10.33 - - - Ant3 - - - 9.55 10.23 10.13 Ant4 - - - 9.87 10.39 10.82 Ant5 - - - 9.52 10.29 10.16 Ant6 - - - 9.79 10.21 10.54 Antenna Type Patch Antenna Connector IPEX Scanning Ant1 4.21 4.23 4.64 4.56 4.0 4.12 Scanning Ant2 3.28 4.33 4.05 4.51 4.45 4.91 BLE/Zigbee 3.68 4.22 4.0 - - - 899 Kifer Road Sunnyvale, CA 94086, USA TEL: 408 235 7700 FAX: 408 235 7737 3. The applicant should address the following items when justifying professional installation. (1) To qualify for professional installation, please explain why the hardware is not readily available to average consumer. Description: Due to this product and will not be sold directly to the general public through retail store, therefore the hardware is not readily available to average consumer. (2) Marketing — Applicant must ensure device cannot be sold via retail to the general public or by mail order. Description: This product and will not be sold directly to the general public through retail store. It will be sold to authorized dealers or installers only. (3) Applicant must show that device intended use is not for consumers and general public. Description: Device is for industrial/commercial use. (4) Explain what is unique, sophisticated, complex, or specialized about the equipment that REQUIRES it to be installed by a professional installer? Device is Secured Wireless Access Point and it requires professional installer to ensure the appropriate output power / installation configuration is used during installation to comply with EIRP limits. Device uses unique antenna connectors. 4. Other professional installation requirements (1) Installation must be controlled. Description: The product will be distributed through controlled distribution channel which has special trained professional to install this product (2) Installed by licensed professionals. Description: Device sold to dealer who hires installers and need special trained professional in configuring and installing the product. (3) Installation requires special training. Description: The product need special programming, access to keypad, field strength measurements made, so must need special trained professional in configuring and installing the product. If you should have any question(s) regarding this declaration, please don’t hesitate to contact us. Thank you! ----------------------------------- Andrew Ji / Director TEL: 408 235 7700 FAX: 408 235 7737 E-mail: [email protected]

899 Kifer Road, Sunnyvale, CA 94086 Tel: 408.235.7700 Fax: 408.235.7737 Date: 2021-04-08 FCC ID: TVE-371CBE0271 To the attention of Federal Communications Commission Authorization and Evaluation Division Permanent Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram Operational Description Software Security for U-NII Devices The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, ----------------------------------- Andrew Ji / Director TEL: 408 235 7700 FAX: 408 235 7737 E-mail: [email protected]

899 Kifer Road, Sunnyvale, CA 94086 Tel: 408.235.7700 Fax: 408.235.7737 Date: 2021-04-08 FCC ID: TVE-371CBE0271 AUTHORIZATION LETTER To Whom It May Concern: Fortinet Inc., hereby authorizes Andrea Hsia / Supervisor of Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (“BV CPS Taoyuan”), to act on its behalf in all matters relating to the Federal Communication Commission (“FCC”) application for equipment authorization in connection with the FCC ID listed above, including signing of all documents relating to these matters. Any and all acts carried out by Andrea Hsia/Supervisor of BV CPS Taoyuan on Fortinet Inc.’s behalf, within the scope of the powers granted herein, and shall have the same effect as acts of its own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Sincerely yours, ----------------------------------------------- Andrew Ji / Director TEL: 408 235 7700 FAX: 408 235 7737 E-mail: [email protected]
