TW5T5703HCTHD WiFi Camera

1 HD WiFi Camera Model: T5703HCT Before using the product, please read the guide carefully to avoid any damages to the product in virtue of faulty operation or misuse. -01--02- Quick Start Guide -03- Package List USB cable Power adapter Quick Guide Screws The picture is only for reference and the real object shall prevail. RESET(Press 'RESET'button ) DC5V power socket Appearance Indicator light Light sensor Camera Lens Camera HD WiFi Camera Model: T5703HAA Before using the product, please read the guide carefully to avoid any damages to the product in virtue of faulty operation or misuse. Quick Start Guide 2 1. Find the power interface behind the product and power on the camera,The indicator will turn on. 2. Please make sure the camera and smart phone are connecting to the same 2.4GHz band WiFi. Connect to the power supply 5 Indicates that power failure or network not connected. Red indicator remains Red indicator flashes Indicates that camera is connecting to network. Green indicator flashes Indicates the router connected successfully (no Internet). Green indicator remains Indicates the camera is connected to server and working well. Camera Indicator Instruction -05- 6 3 Technical Parameters ※
All parameters change without prior notice. The finial right of interpretation is reserved by the company. Resolution Video Format Wireless Transmission Night Vision Remote Intercom Power Input Alerts APP Waterproof Standard Working Temperature 1920*1080P H.264/H.265 802.11b/g/n 2.4GHz Wifi 8m(max) Two-way audio 5V 1A Motion detection Android 4.44 and above, IOS 9.0 and above For indoor USE only -10C°- +50C° Storage 正面 背面 -06- FCC Certification lnfo -07- Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your local authority or retailer for recycling advice. EU Environmental Protection Made in China Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. RF exposure warning : This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment shall be installed and operated with minimum distance 20cm between the radiator & body. This device is acting as slave and operating in the 2.4 GHz (2412 ~2462 MHZ) band. Ad Hoc function is supported but not able to operate on non-US frequencies. Do not use the device with the environment which below minimum -10 °C or maximum over 50°C . Hereby, we declares that this device is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. Notice: Observe the national local regulations in the location where the device is to be used. This device may be restricted for use in some or all member states of the European Union (EU). -04- Preparation for Installation Installation 4 AndroidAndroidIOSAndroid 1. 2.4G wireless router is required； 2. Support Android 4.44 and above, iOS 9.0 and above； 3.Download APP: Please select one of below two methods to download the APP, then complete the installation and account registration， A：Scan the QR code to download APP AndroidAndroidAndroid 4. Add a device: Open the APP home page.click the “Add Device” icon to connect your camera. According to the settings guide in the APP, you can configure multiple cameras at the same time. B：Search the APP name “GOSCOM” on the Google play or App Store Remark: The APP interface may be upgraded and adjusted at any time, subject to app as its actual basis without prior notice

Shenzhen Gospell Smarthome Electronic Co., Ltd. Declaration of difference To Whom It May Concern: We the undersigned hereby confirm that the additional model Y5703HCT is identical with the test model T5703HCT except the model number for marketing purpose. Production name Model No. HD WiFi Camera T5703HCT(test), Y5703HCT Name:Richie Xiao Title:Certified Engineer Signature: FCC ID: TW5T5703HCT Date: 2021/1/6

C5266091_X8_Ed.1 1/1 Letter of Authorization Company: Shenzhen Gospell Smarthome Electronic Co., Ltd. Address: Block A,No.1 Industrial park,Fenghuanggang,Baoan Area,Shenzhen City,P.R.China Product Name: HD WiFi Camera Model Number: T5703HCT, Y5703HCT FCC Identifier: TW5T5703HCT We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Richie Xiao Date: 2021/1/6 Title: Certified Engineer Signature of applicant:

C5266091_X10_Ed.1 1/1 Company: Sh enzhen Gospell Smarth ome Electronic Co., Ltd. Address: Block A,No.1 Industrial park,Fenghuanggang,Baoan Area,Shenzhen City,P.R.China Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2021/1/6 Subject: Request for Confidentiality FCC ID: TW5T5703HCT To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. ExhibitsLong-Term Confidentiality Short-Term Confidentiality ID Label/Location No No Attestation Statement No No External Photos No Block Diagram Schematics Test Report No No Test Setup Photos No User’s Manual Internal Photos Parts List / Tune Up RF Exposure Info Operational Description Cover Letter(s) No No SDR Software / Security Info Above me ntioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Richie Xiao Date: 2021/1/6 Title: Certified Engineer

Page 1 of 6 FCC ID: TW5T5703HCT Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] Http://www.uttlab.com APPENDIX 2 PHOTOS OF EUT CONSTRUCTIONAL DETAILS EUT EXTERNAL PHOTOS EUT Photo EUT Photo Page 2 of 6 FCC ID: TW5T5703HCT Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] Http://www.uttlab.com EUT Photo EUT Photo Page 3 of 6 FCC ID: TW5T5703HCT Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] Http://www.uttlab.com EUT Photo EUT Photo Page 4 of 6 FCC ID: TW5T5703HCT Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] Http://www.uttlab.com EUT Photo EUT Photo Page 5 of 6 FCC ID: TW5T5703HCT Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] Http://www.uttlab.com EUT Photo EUT Photo Page 6 of 6 FCC ID: TW5T5703HCT Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] Http://www.uttlab.com EUT Photo EUT Photo

T5703HCT_Label Sample and Label Location

Page 1 of 5 FCC ID: TW5T5703HCT Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] Http://www.uttlab.com APPENDIX 2 PHOTOS OF EUT CONSTRUCTIONAL DETAILS EUT INTERNAL PHOTOS EUT Photo EUT Photo Page 2 of 5 FCC ID: TW5T5703HCT Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] Http://www.uttlab.com EUT Photo EUT Photo Page 3 of 5 FCC ID: TW5T5703HCT Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] Http://www.uttlab.com EUT Photo EUT Photo Page 4 of 5 FCC ID: TW5T5703HCT Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] Http://www.uttlab.com EUT Photo EUT Photo ANT RTL-8188FTV Page 5 of 5 FCC ID: TW5T5703HCT Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] Http://www.uttlab.com EUT Photo EUT Photo

Page 2 of 9 Report No.: 201111007RFC-2 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com UTTR-RF-FCCPART1-V1.0 Version Version No. Date Description V1.0 December 30, 2020 Original Page 3 of 9 Report No.: 201111007RFC-2 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com UTTR-RF-FCCPART1-V1.0 CONTENTS 1. GENERAL INFORMATION ....................................................................................................................................... 4 1.1 CLIENT INFORMATION ........................................................................................................................................ 4 1.2 EUT INFORMATION ............................................................................................................................................ 4 1.3 PRODUCT SPECIFICATION SUBJECTIVE TO THIS STANDARD ................................................................................. 5 1.4 OTHER INFORMATION ......................................................................................................................................... 5 1.5 GENERAL DESCRIPTION OF APPLIED STANDARDS ............................................................................................... 6 1.6 TEST LOCATION ................................................................................................................................................. 6 1.7 TEST FACILITY ................................................................................................................................................... 6 1.8 DEVIATION FROM STANDARDS ............................................................................................................................ 6 1.9 ABNORMALITIES FROM STANDARD CONDITIONS .................................................................................................. 6 1.10 OTHER INFORMATION REQUESTED BY THE CUSTOMER ........................................................................................ 7 2. EQUIPMENT LIST .................................................................................................................................................... 7 3. MPE EVALUATION ................................................................................................................................................... 7 3.1 REFERENCE DOCUMENTS FOR EVALUATION ........................................................................................................ 7 3.2 MPE COMPLIANCE REQUIREMENT ..................................................................................................................... 7 3.2.1 LIMITS ................................................................................................................................................... 7 3.2.2 TEST PROCEDURE ................................................................................................................................. 7 3.3 MPE CALCULATION METHOD ............................................................................................................................. 8 3.4 MPE CALCULATION RESULTS ............................................................................................................................ 8 3.4.1 FOR WLAN ........................................................................................................................................... 8 3.4.2 SIMULTANEOUS MULTI-BAND TRANSMISSION MPE ANALYSIS .................................................................... 8 APPENDIX 1 PHOTOS OF TEST SETUP ....................................................................................................................... 9 APPENDIX 2 PHOTOS OF EUT CONSTRUCTIONAL DETAILS ................................................................................... 9 Page 4 of 9 Report No.: 201111007RFC-2 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com UTTR-RF-FCCPART1-V1.0 1. GENERAL INFORMATION 1.1 CLIENT INFORMATION Applicant: Shenzhen Gospell Smarthome Electronic Co., Ltd. Address of Applicant: Block A,No.1 Industrial park,Fenghuanggang,Baoan Area,Shenzhen City,P.R.China Manufacturer: Shenzhen Gospell Smarthome Electronic Co., Ltd. Address of Manufacturer: Block A,No.1 Industrial park,Fenghuanggang,Baoan Area,Shenzhen City,P.R.China 1.2 EUT INFORMATION Product Name: HD WiFi Camera Model No.: T5703HCT Add. Model No.: Y5703HCT DUT Stage: Production Unit EUT Supports Function: 2.4 GHz ISM Band: IEEE 802.11b/g/n Software Version: V1.0 Hardware Version: T5703HCT-M02 Sample Received Date: November 11, 2020 Sample Tested Date: December 4, 2020 to December 11, 2020 Note: The additional model Y5703HCT is identical with the test model T5703HCT except the model number for marketing purpose. Page 5 of 9 Report No.: 201111007RFC-2 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com UTTR-RF-FCCPART1-V1.0 1.3 PRODUCT SPECIFICATION SUBJECTIVE TO THIS STANDARD For 2.4 GHz ISM Band of Wi-Fi Frequency Band: 2400 MHz to 2483.5 MHz Frequency Range: 2412 MHz to 2462 MHz Support Standards: IEEE 802.11b, IEEE 802.11g, IEEE 802.…

Text truncated - open the document above for the full version.

Page 2 of 53 Report No.: 201111007RFC-1 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com UTTR-RF-FCCPART15.247-V1.0 Version Version No. Date Description V1.0 December 30, 2020 Original Page 3 of 53 Report No.: 201111007RFC-1 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com UTTR-RF-FCCPART15.247-V1.0 CONTENTS 1. GENERAL INFORMATION ....................................................................................................................................... 4 1.1 CLIENT INFORMATION ........................................................................................................................................ 4 1.2 EUT INFORMATION ............................................................................................................................................ 4 1.2.1 GENERAL DESCRIPTION OF EUT ............................................................................................................ 4 1.2.2 DESCRIPTION OF ACCESSORIES .............................................................................................................. 4 1.3 PRODUCT SPECIFICATION SUBJECTIVE TO THIS STANDARD ................................................................................. 4 1.4 OTHER INFORMATION ......................................................................................................................................... 5 1.5 DESCRIPTION OF SUPPORT UNITS ...................................................................................................................... 5 1.6 TEST LOCATION ................................................................................................................................................. 5 1.7 TEST FACILITY ................................................................................................................................................... 6 1.8 DEVIATION FROM STANDARDS ............................................................................................................................ 6 1.9 ABNORMALITIES FROM STANDARD CONDITIONS .................................................................................................. 6 1.10 OTHER INFORMATION REQUESTED BY THE CUSTOMER ........................................................................................ 6 1.11 MEASUREMENT UNCERTAINTY ........................................................................................................................... 6 2. TEST SUMMARY ...................................................................................................................................................... 7 3. EQUIPMENT LIST .................................................................................................................................................... 8 4. TEST CONFIGURATION .......................................................................................................................................... 9 4.1 ENVIRONMENTAL CONDITIONS FOR TESTING ........................................................................................................ 9 4.1.1 NORMAL OR EXTREME TEST CONDITIONS ............................................................................................... 9 4.1.2 RECORD OF NORMAL ENVIRONMENT....................................................................................................... 9 4.2 TEST CHANNELS ............................................................................................................................................... 9 4.3 EUT TEST STATUS .......................................................................................................................................... 10 4.4 PRE-SCAN ....................................................................................................................................................... 10 4.5 TEST SETUP .................................................................................................................................................... 11 4.5.1 FOR RADIATED EMISSIONS TEST SETUP ................................................................................................ 11 4.5.2 FOR CONDUCTED EMISSIONS TEST SETUP ............................................................................................ 12 4.5.3 FOR CONDUCTED RF TEST SETUP ........................................................................................................ 13 4.6 SYSTEM TEST CONFIGURATION ........................................................................................................................ 13 4.7 DUTY CYCLE ................................................................................................................................................... 14 5. RADIO TECHNICAL REQUIREMENTS SPECIFICATION .................................................................................... 17 5.1 REFERENCE DOCUMENTS FOR TESTING ............................................................................................................ 17 5.2 ANTENNA REQUIREMENT ................................................................................................................................. 17 5.3 CONDUCTED PEAK OUTPUT POWER ................................................................................................................. 18 5.4 6 DB BANDWIDTH ............................................................................................................................................ 19 5…

Text truncated - open the document above for the full version.

Page 28 of 53 Report No.: 201111007RFC-1 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com UTTR-RF-FCCPART15.247-V1.0 IEEE 802.11g In-Band Reference Level Out of Band Emission Lowest Channel Middle Channel Page 29 of 53 Report No.: 201111007RFC-1 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com UTTR-RF-FCCPART15.247-V1.0 Highest Channel Page 30 of 53 Report No.: 201111007RFC-1 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com UTTR-RF-FCCPART15.247-V1.0 IEEE 802.11n-HT20 In-Band Reference Level Out of Band Emission Lowest Channel Middle Channel Page 31 of 53 Report No.: 201111007RFC-1 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com UTTR-RF-FCCPART15.247-V1.0 Highest Channel Page 32 of 53 Report No.: 201111007RFC-1 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com UTTR-RF-FCCPART15.247-V1.0 IEEE 802.11n-HT40 In-Band Reference Level Out of Band Emission Lowest Channel Middle Channel Page 33 of 53 Report No.: 201111007RFC-1 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com UTTR-RF-FCCPART15.247-V1.0 Highest Channel Page 34 of 53 Report No.: 201111007RFC-1 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com UTTR-RF-FCCPART15.247-V1.0 5.7 RADIATED SPURIOUS EMISSIONS Test Requirement: FCC 47 CFR Part 15 Subpart C Section 15.205/15.209 Test Method: ANSI C63.10-2013 Clause 11.11 & Clause 11.12 Receiver Setup: Frequency RBW 0.009 MHz-0.150 MHz 200/300 kHz 0.150 MHz -30 MHz 9/10 kHz 30 MHz-1 GHz 100/120 kHz Above 1 GHz 1 MHz Limits: Spurious Emissions Frequency Field strength (microvolt/meter) Limit (dBμV/m ) Remark Measurement distance (m) 0.009 MHz-0.490 MHz 2400/F(kHz) -- -- 300 0.490 MHz-1.705 MHz 24000/F(kHz) -- -- 30 1.705 MHz-30 MHz 30 -- -- 30 30 MHz-88 MHz 100 40.0 Quasi-peak 3 88 MHz-216 MHz 150 43.5 Quasi-peak 3 216 MHz-960 MHz 200 46.0 Quasi-peak 3 960MHz-1GHz 500 54.0 Quasi-peak 3 Above 1 GHz 500 54.0 Average 3 Remark: 1. The lower limit shall apply at the transition frequencies. 2. Emission level (dBuV/m) = 20 log Emission level (uV/m). 3. For frequencies above 1000 MHz, the field strength limits are based on average detector, however, the peak field strength of any emission shall not exceed the maximum permitted average limits, specified above by more than 20 dB under any condition of modulation. Test Setup: Refer to section 4.5.1 for details. Test Procedures: 1. From 30 MHz to 1GHz test procedure as below: 1) The EUT was placed on the top of a rotating table 0.8 meters above the ground at a 3 meter semi-anechoic camber. The table was rotated 360 degrees to determine the position of the highest radiation. 2) The EUT was set 3 meters away from the interference-receiving antenna, which was mounted on the top of a variable-height antenna tower. 3) The antenna height is varied from one meter to four meters above the ground to determine the maximum value of the field strength. Both horizontal and vertical polarizations of the antenna are set to make the measurement. 4) For each suspected emission, the EUT was arranged to its worst case and then the antenna was tuned to heights from 1 meter to 4 meters (for the test frequency of below 30MHz, the antenna was tuned to heights 1 meter) and the rota table table was turned from 0 degrees to 360 degrees to find the maximum reading. 5) The test-receiver system was set to Peak Detect Function and Specified Bandwidth with Maximum Hold Mode. 6) If the emission level of the EUT in peak mode was 10dB lower than the limit specified, then testing could be stopped and the peak values of the EUT would be reported. Otherwise the emissions that did not have 10dB margin would be re-tested one by one using peak, quasi-peak or average method as specified and then reported in a data sheet. 2. Above 1GHz test procedure as below: 1) Different between above is the test site, change from Semi- Anechoic Chamber to fully Anechoic Chamber and change form table 0.8 meter to 1.5 meter( Above 18GHz the distance is 1 meter and table is 1.5 meter). Page 35 of 53 Report No.: 201111007RFC-1 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com UTTR-RF-FCCPART15.247-V1.0 2) Test the EUT in the lowest channel ,middle channel, the Highest channel 3) The radiation measurements are performed in X, Y, Z axis positionin…

Text truncated - open the document above for the full version.

Page 1 of 2 FCC ID: TW5T5703HCT Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, Chi…

Text truncated - open the document above for the full version.
