INSTALLATION OF STI-34071 STI Wireless Conversion Board All specifications and information shown were current as of publication and are subject to change without notice. 34071 OCT2010 ® Safety Technology International, Inc. 2306 Airport Road • Waterford, Michigan 48327-1209 Phone: 248-673-9898 • Fax: 248-673-1246 Toll Free: 800-888-4784 • E-mail: [email protected] Web: www.sti-usa.com Safety Technology International (Europe) Ltd. Unit 49G Pipers Road • Park Farm Industrial Estate • Redditch Worcestershire • B98 0HU • England • Tel: 44 (0) 1527 520 999 Fax: 44 (0) 1527 501 999 • Freephone: 0800 085 1678 (UK only) E-mail: [email protected] • Web: www.sti-europe.com INSTALLATION INSTRUCTIONS 1. Remove Cover. 2. Disconnect 9V battery. 3. Remove the reed sensor from its internal mounting location so that it hangs freely. 4. Keeping the reed sensor wires inward, insert the STI WIRELESS RETRO PCB legs into the PCB mounting slots. Make sure the onboard 9V connector is facing inward towards the horn. 5. Connect the “NC” and “Com” wires on the STI WIRELESS RETRO PCB to the Stopper “NC” and “Com” terminals. (If using externally fed +12VDC power, also connect “GD” and “V+” wires to those Stopper terminals.) 6. Reattach the reed sensor to the internal mounting location being careful not to pull out a connection on the Stopper terminals. 7. Connect the Stopper’s 9V connector to the STI WIRELESS RETRO PCB’s onboard 9V connector. 8. Connect the STI WIRELESS RETRO PCB’s wired 9V Connector to the 9V Battery. 9. Replace cover and screws. IMPORTANT NOTICE: Changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate this equipment. This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference that may be received, including interference that may cause undesired operation. Model: 34071 FCC ID: TXL34071 IC: 6335A-34071 This product meets the applicable Industry Canada technical specifications. Le présent materiel est conforme aux specifications techniques applicables d’Industrie Canada. TO USE WIRELESS SIGNAL WITHOUT AUDIBLE ANNUNCIATION 1. Follow standard installation steps. 2. Connect an additional reed switch connections into “NC” and “COM” on the Stopper terminals with the wires from the STI WIRELESS RETRO PCB. 3. Install the additional reed switch on top of the reed switch connected to the “RS1” Stopper terminal. Use tape to hold the 2 reed switches together. WIRELESS OPERATION: The STI WIRELESS RETRO PCB will send a wireless signal to an STI 433MHz 4 Channel Receiver or 8 Channel Receiver. The STI WIRELESS RETRO PCB sends an Alert signal when the “NC” switch is opened. It sends a Restore-To-Normal signal when the switch is closed. NOTE: To enroll the wireless device signal into the receiver, please see the receiver installation instructions. JP5 JP2 JP4 JP3 JP7 SWITCH ALARM DURATION ALARM VOLUME SWITCH TRIP DELAY SWITCH ARMING SWITCH (FACTORY DEFAULT SETTINGS) (ON) (ON) (OFF) (OFF) (OFF) TERMINAL BLOCK FOR COMPLETE ALARM OPTIONS AND SWITCH SETTINGS SEE CHART ON REVERSE SIDE. PC BOARD JP5 JP2 JP4 JP3 SWITCH ALARM DURATION ALARM VOLUME SWITCH TRIP DELAY SWITCH ARMING SWITCH ( FACTORY DEFAULT SETTINGS (FACTORY DEFAULT SETTINGS) (ON) (ON) (OFF) (OFF) (OFF) WIRES FROM RETRO PCB TO 9V BATTERY WIRES FROM STOPPER PCB TO RETRO PCB BLUE “NC” WIRE GREEN “COM” WIRE WIRELESS TRANSMITTER PCB EXIT ALARM BASE ASSEMBLY

Authority to Act as Agent November 8, 2010 American Telecommunication Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: ______Rob Hendrickson at Resolution Engineering, Inc.______ is authorized to act on our behalf, until otherwise notified, for applications to American Telecommunication Certification Body, Inc. (ATCB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you, Agency Agreement Expiration Date: November 8, 2011 By: __________ John Taylor (Signature) (Print Name) Title: Executive Vice President On behalf of: Safety Technology International, Inc. Telephone: 248-673-9898

Request for Confidentiality November 8, 2010 Subject: Confidentiality Request for FCC ID: ______TXL-34071_____ Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term External Photos Short Term Permanent* 1 Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Parts List & Placement/BOM Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent* User’s Manual *Note: Safety Technology International, Inc. has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of Not Applicable days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ATCB in the event information regarding the product or the product is made available to the public. ATCB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Sincerely, By: __ /Executive Vice President John Taylor (Signature/Title 2 ) (Print name) 1 - The asterisked items (*) require further justification before permanent confidentiality will be allowed. These also currently require review by the FCC under their Permit-But-Ask policy before the grant is issued and can delay completion of an application. Further justification should be added to the note above. One such example for a potted device would be: “The EUT is FULLY potted using a non-removable epoxy based material. Removal of potting material causes irreparable damage to internal circuitry. See photographs exhibits that outline the device before and after potting.” 2 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

Safety Technology International, Inc. FCC ID: TXL34071 Certification Test Report 2010-10-04 Contents 1. Introduction ............................................................................................................................................................................. 3 2. Statement of Compliance ..................................................................................................................................................... 3 2.1. FCC Part 2 §2.907 ............................................................................................................................................................ 3 2.2. FCC Part 2 §2.911 ............................................................................................................................................................ 3 2.3. FCC Part 2 §2.913 ............................................................................................................................................................ 3 2.4. FCC Part 2 §2.915 ............................................................................................................................................................ 3 2.5. FCC Part 2 §2.925 ............................................................................................................................................................ 4 2.6. FCC Part 2 §2.943, 2.945 ................................................................................................................................................ 4 2.7. FCC Part 2 §2.947 ............................................................................................................................................................ 4 2.8. FCC Part 2 §2.948 ............................................................................................................................................................ 4 2.9. FCC Part 2 §2.1033 .......................................................................................................................................................... 5 3. Discussion of Laboratory Measurements and Rules Compliance ................................................................................ 6 3.1. FCC Part 15 §15.231(a)(1) ............................................................................................................................................. 6 3.2. FCC Part 15 §15.231(a)(2) ............................................................................................................................................. 6 3.3. FCC Part 15 §15.231(a)(3) ............................................................................................................................................. 6 3.4. FCC Part 15 §15.231(a)(4) ............................................................................................................................................. 6 3.5. FCC Part 15 §15.231(a)(5) ............................................................................................................................................. 6 3.6. FCC Part 15 §15.231(b) .................................................................................................................................................. 6 3.6.1. Raw Field Strength Limits ...................................................................................................................................... 6 3.6.2. Duty Cycle Correction Factor and Resulting Limits ......................................................................................... 7 3.6.3. Measured Radiated Field Strength Data ............................................................................................................ 7 3.7. FCC Part 15 §15.231(c) ................................................................................................................................................... 7 1. Introduction The 34071 is a small battery-powered sensor for use in a wireless alert system. Certification is requested under FCC Rules, Part 15, Subpart C, Paragraph 15.231. 2. Statement of Compliance Specific sections of FCC Rules Part 2 that require information or listing are given below. 2.1.FCC Part 2 §2.907 This is an application for certification of original equipment 2.2.FCC Part 2 §2.911 a)This application has been filed electronically using form 731. b) All required information has been supplied in this application and its attachments. c)This applicant has signed the application electronically. d) The technical test data has been signed by the agency performing the testing. e)Signature supplied in appropriate block on form 731. f)Processing fee has been paid by credit card. g)Signatures have been supplied electronically. 2.3.FCC Part 2 §2.913 a)This application has been filed electronically. b) Appropriate fees have been filed electronically. c)Equipment samples shall be supplied as requested. 2.4.FCC Part 2 §2.915 We are requesting a grant of certification. This application shows compliance with the technical standards. 2.5.FCC Part 2 §2.925 A label shall be affixed to each piece of equipment, showing the FCC identifier. The label shall read “FCC ID: TXL34071”. See exhibit “Label.pdf” for photographs showing the label and location on the device. External and internal photos are provided in exhibits “External Photo.pdf” and “Internal Photo.pdf”. 2.6.FCC Part 2 §2.943, 2.945 Sample production equipment shall be submitted to the FCC upon request. 2.7.FCC Part 2 §2.947 a)Measurement procedure follows ANSI C63.4 version 2003 b) A description of utilized test equipment is contained in attached “Radiated Data.pdf”. 2.8.FCC Part 2 §2.948 Radiated measurements were taken at the following FCC-approved facility: Rhein Tech Laboratories, Inc. 360 Herndon Pkwy, Suite 1400 Herndon, VA 20170 Contact: Rick McMurray Phone: 703-689-0368 See exhibit “Test Setup Photos.pdf” for a photo of the test site. 2.9.FCC Part …

Text truncated - open the document above for the full version.

360 Herndon Parkway, Suite 1400 Herndon, VA 20170 Tel: 703-689-0368 Fax: 703-689-2056 Engineering and Testing for EMC and Safety Compliance Radiated Test Data for Model: Exit Stopper for Resolution Engineering RTL Project Number 2010063 Test Engineer: Jon Wilson 360 Herndon Parkway, Suite 1400 Herndon, VA 20170 Tel: 703-689-0368 Fax: 703-689-2056 Radiated Test Data - OATS 1 Test Date: April 07, 2010 - 10:40:37 AM Work Order: 2010063 Customer Reference: BC 019483 Model: Exit Stopper Name: Jon Wilson Limit/Distance: FCC B/3m Emission Frequency (MHz) Test Detector Analyzer Reading (dBuV) Site Correction Factor (dB/m) Emission Level (dBuV/m) Limit (dBuV/m) Margin (dB) Pass/ Fail 433.933 Pk 65.8 32.9 98.7 100.8 -2.1 Pass 867.833 Pk 70.9 0.7 71.6 80.8 -9.2 Pass 1301.747 Pk 57.2 8.4 65.6 80.8 -15.2 Pass 1735.659 Pk 52.6 13.1 65.7 80.8 -15.1 Pass 2,169.574 Pk 51.1 9.3 60.4 80.8 -20.4 Pass 2,603.489 Pk 59.3 10.4 69.7 80.8 -11.1 Pass 3,037.404 Pk 45.4 8.7 54.1 80.8 -26.7 Pass 3,471.319 Pk 59.0 9.3 68.3 80.8 -12.5 Pass 3,905.234 Pk 64.6 11.3 75.9 80.8 -4.9 Pass 4,339.149 Pk 46.4 14.6 61.0 80.8 -19.8 Pass Radiated Emissions Test Equipment Part Manufacturer Model Serial Number RTL Bar Code Calibration Due Date Amplifier (20 MHz-2 GHz) Rhein Tech Laboratories, Inc. PR-1040 900905 900905 4/10/2010 Bilog Periodic Antenna (25 MHz-2 GHz) Schaffner Chase CBL6112 2099 900791 12/12/2010 EMI Receiver RF Section (9 KHz-6.5 GHz) Hewlett Packard 85462A 3325A00159 900913 6/8/2010 RF Filter Section (100 KHz-6.5 GHz) Hewlett Packard 85460A 3330A00107 900914 6/8/2010 Spectrum Analyzer Hewlett Packard 8596EM 3826A00144 901215 11/23/2010 Amplifier (1 GHz – 26.4 GHz) Hewlett Packard 8449B OPT H02 3008A00505 900932 2/22/2011 Horn Antenna, 2.0-4.0 GHz EMCO 3161-02 9804-1044 900772 6/13/2010 Horn Antenna, 4.0-8.2 GHz EMCO 3161-03 9508-1020 900321 6/13/2010 Emissions Testing Software Rhein Tech Laboratories, Inc. Automated Emission Tester Rev. 14.0.2 N/A N/A
