U27TPMS-8500Tire Pressure Monitoring System

SC-T8000 Series TPMS Fast Installation Guide Bluewave Technology Co., LTD. Tel: 886-2-23451989 Fax: 886-2-23450177 2F.-1, No.5, Lane 178, Jhuangjing Rd., Sinyi District, Taipei City 110, Taiwan, R.O.C. http://www.7brains.com/ Email: [email protected] 2007/4/18 SC-T8000 Fast Installation Guide Installation 1. Check Components Receiver(Passenger) Receiver(Truck) T-Type Sensor Receiver Sensor SC-T8000 1 4 SC-T8060 1 6 SC-T8080 1 8 SC-T8100 1 10 SC-T8120 1 12 One Power Cord One Sucker & Fixture * attention: Four-wheeled passenger and truck’s receivers are different. Please check the left-circle of receiver. 2. Check Sensor Identification Number (Sensor ID) and Set 2.1 Each sensor should be assigned a unique identification number (ID) which was marked on the top of sensor. 2.2 The last two number of sensor ID has given the locating tire position, the order is as following: * SC-T8000 ID locating position 01:left-front tire 02:rght-front tire 04:left-rear tire 03: right-rear tire SC-T8060 ID locating position 01:left-front tire 02:rightfront tire 05:left-rear tire right 03:righr -rear tire right 06:left-rrear tire left 04:righr-rear tire left 3. Install the Sensor into Wheel 3.1 Screw down the original valve cap. 3.2 Follow the ID’s last two number to install the right tire (please refer to the 2.2 illustration) Note: Since sensors being electric isolation processed before shipping, it is recommended, for the first installation, to rotate sensor forward and backward several times to remove isolation coating and ensure the conductivity between sensor and valve stem. 3.3 Screw fixture: Prevent sensor from easy removing also in favor of sensor Welcome to Bluewave Super Cat T-Type 8000 Series Tire Pressure Monitoring System (SC-T8000 TPMS). This Fast installation Guide is intended to give you a fast overview of the key steps required to install your SC-T8000 Series TPMS. For more detailed information, please refer to the SC-T8000 Series TPMS User’s Manual.(http://www.7brains.com) SC-T8000 Fast Installation Guide stationary. Note: (1) User may ignore this fixture, when causing inflation hassle concerns. (2) To ensure LED template display correctly coincide with actual sensor position, Please follow step 4-Sensor alignment in order to get right pressure and temperature from right sensor. 4. Sensor alignment Plug the attached power cord into cigarette lighter directly, then activate the receiver. 4.1 Operation mode illustration SC-T8000 series provides various operating mode to set different parameter, under normal condition, please follow the above illustration Key4Exitfor 0.5 second into different operating modes in order to make use of different functions and parameter sets. 4.2 Preset ID Under normal condition presscheck the first installed tire ID is righr or not, and then press Enter , check tire ID 2, 3, and 4. If the sensors ID are all correctly located, then you can ignore the next steps. (Section 4.3). 4.3 ID search and set under normal conditiondo as the followings: ‡ Press(for 0.5 second) ‡ Press twice ‡ Press into ID search Make sure the sensor is consistent with the main engine geared position then press Key1 (Enter), SC-T8000 Fast Installation Guide follow step 3 to install the next sensor installation, after finishing press Key4 (Exit). *attention: Finished installing, LED shows “red “, If you set different sensor ID in the same place, the LED will disappear, at this moment you must reset the sensor. Signal 1. Normal: When tires operate in normal condition, LED shows “green” light. Every 8 sec., the “orange” light takes turn to show each tire’s condition. 2. Abnormal: When tire is in over-heated, over-pressured, or under-pressured condition, LED shows “red” light, locks on the position of over-heated tire with “beep” sound. NOTETwo tires are abnormal at the same time, it will be fixed on the abnormal status. 3. Receiver did not receive Data: If receiver can not receive updated tire messages over 10 mins., LED shows abnormal indication. Example: Left-front tire didn’t receive data, shows “ t l ----”. Right-front tire didn’t receive data, shows “ t2 ----”. Left-rear tire didn’t receive data, shows “ t3 ----”. Right-rear tire didn’t receive data, shows “ t4 ----”. *attention: The abnormal signal will be disappear after once messages received. If long time no new information, please check your sensor. FCC Notice The changes or modifications not expressly approved by the party responsible for compliance could void the users authority to operate the equipment. THIS DEVICE COMPLIES WITH PART 15 OF THE FCCRULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. Caution: Any changes or modifications in construction of this device which are not expressly approved by the party responsible for compliance could void the users authority to operate the equipment. 910805 2 FCC Notice: Notice : The changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. IMPORTANT NOTE: To comply with the FCC RF exposure compliance requirements, no change to the antenna or the device is permitted. Any change to the antenna or the device could result in the device exceeding the RF exposure requirements and void user’s authority to operate the device. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

1 Lucy Tsai From:Iris Lin [[email protected]] Sent:Sunday, January 20, 2008 6:58 PM To:Lucy Tsai Subject:Re: WIESON Technologies CO., LTD., FCC ID: U27TPMS-8500, Assessment NO.: AN08T7500, Notice#1 Attachments:Exhibit-C-Test_Report rev.pdf Dear Lucy, Please refer to the updated report as attachment for your questions as below. ELECTRONICS TESTING CENTER, TAIWAN IRIS LIN (???) TEL: 886-2-26023052 ext.10 FAX: 886-2-26010910 ----- Original Message ----- From: "Lucy Tsai" <[email protected]> To: "Iris Lin" <[email protected]> Sent: Tuesday, January 15, 2008 3:35 AM Subject: FW: WIESON Technologies CO., LTD., FCC ID: U27TPMS-8500, Assessment NO.: AN08T7500, Notice#1 Dear Iris, Please address following issues. Q#1: FCC ID and model no. listed in test report page 1-2 and page 4 are up side down, please revise. Besides, the model no listed on the test report is different from the user manual, please clarify. Q#2: Please confirm the version of ANSI C63.4 is followed and specify it into the test report. Q#3: For devices operated under 15.231(e) shall be provided with a means for automatically limiting operation so that the duration of each transmission shall not be greater than one second and the silent period between transmissions shall be at least 30 times the duration of the transmission but in no case less than 10 seconds. Please provide test data to demonstrate the compliance. Q#4: Test result of20dB BW shown in page 18 of test report shall be 61 but not 83kHz, please revise. Best Regards, Lucy The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 30 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender.

ETC Report No.: 07-10-RBF-093-04 FCC ID.: U27TPMS-8500 Rev. No 1.0 CONSTRUCTED PHOTOS of EUT Top View of EUT Side View of EUT ETC Report No.: 07-10-RBF-093-04 FCC ID.: U27TPMS-8500 Rev. No 1.0 CONSTRUCTED PHOTOS of EUT Front View of EUT Side View of EUT

TPMS-8500 Model : TPMS-8500 FCC ID : U27TPMS-8500 15mm 9mm

ETC Report No.: 07-10-RBF-093-04 FCC ID.: U27TPMS-8500 Rev. No 1.0 CONSTRUCTED PHOTOS of EUT Component View of Main PCB Solder View of Main PCB

Rev. No 1.0 FCC Part 15 EMI TEST REPORT of E.U.T. : Tire Pressure Monitoring System FCC ID. : U27TPMS-8500 Model : TPMS-8500 Series Working Frequency : 433.920 MHz for APPLICANT : Wieson Technologies Co., Ltd. ADDRESS : 7F, No. 276, Sec. 1, Datong Rd., Si jhih City, Taipei Country 221, Taiwan, R.O.C. Test Performed by ELECTRONICS TESTING CENTER, TAIWAN NO. 34. LIN 5. DINGFU TSUEN, LINKOU SHIANG TAIPEI COUNTY, TAIWAN, 24442, R.O.C. Tel : (02)26023052 Fax : (02)26010910 http://www.etc.org.tw ; e-mail: [email protected] Report Number : 07-10-RBF-093-04 ETC Report No.:07-10-RBF-093-04 FCC ID.: U27TPMS-8500 Rev. No 1.0 TEST REPORT CERTIFICATION Applicant : Wieson Technologies Co., Ltd. 7F, No. 276, Sec. 1, Datong Rd., Si jhih City, Taipei Country 221, Taiwan, R.O.C. Manufacturer DongGuan Huaguo Electronic Co., Ltd. Huaguo Gang, Houjie Town, Dong Guan City, Guang Dong, China. Description of EUT : a) Type of EUT : Tire Pressure Monitoring System b) Trade Name : WIESON c) FCC ID : U27TPMS-8500 d) Model No. : TPMS-8500 Series e) Working Frequency : 433.920 MHz f) Power Supply : DC 3V Battery Regulation Applied : FCC Rules and Regulations Part 15 Subpart C (2007) I HEREBY CERTIFY THAT; The data shown in this report were made in accordance with the procedures given in ANSI C63.4 and the energy emitted by the device was founded to be within the limits applicable. I assume full responsibility for accuracy and completeness of these data. Note : 1. The results of the testing report relate only to the items tested. 2. The testing report shall not be reproduced except in full, without the written approval of ETC. Issued Date : Jan. 09, 2008 Test Engineer : ( falcon Shi ) Approve & Authorized Signer : Will Yauo, Manager EMC Dept. II of ELECTRONICS TESTING CENTER, TAIWAN ETC Report No.:07-10-RBF-093-04 FCC ID.: U27TPMS-8500 Rev. No 1.0 Table of Contents Page 1. GENERAL INFORMATION.....................................................................................................................................................1 1.1 PRODUCT DESCRIPTION..................................................................................................................................................1 1.2 CHARACTERISTICS OF DEVICE:...............................................................................................................................................1 1.3 TEST METHODOLOGY..............................................................................................................................................................1 1.4 TEST FACILITY..........................................................................................................................................................................1 2. DEFINITION AND LIMITS.......................................................................................................................................................2 2.1 DEFINITION................................................................................................................................................................................2 2.2 RESTRICTED BANDS OF OPERATION.....................................................................................................................................2 2.3 LIMITATION...............................................................................................................................................................................2 2.4 LABELING REQUIREMENT.......................................................................................................................................................5 2.5 USER INFORMATION.................................................................................................................................................................5 3 SYSTEM TEST CONFIGURATION.........................................................................................................................................6 3.1 JUSTIFICATION..........................................................................................................................................................................6 3.2 DEVICES FOR TESTED SYSTEM...............................................................................................................................................6 4. RADIATED EMISSION MEASUREMENT.............................................................................................................................7 4.1 APPLICABLE STANDARD.........................................................................................................................................................7 4.2 MEASUREMENT PROCEDURE..................................................................................................................................................7 4.3 TEST DATA.................................................................................................................................................................................9 4.4 FIELD STRENGTH CALCULATION........................................................................................................................................11 4.5 ACTIVATE TIME......................................................................................................................................................................11 4.6 CALCULATION OF DUTY FACTOR.......................................................................................................................................11 4.7 RADIATED TEST EQUIPMENT...............................................................................................................................................14 4.8 MEASURING INSTRUMENT SETUP.......................................................................................................................................14 4.9 RADIATED MEASUREMENT PHOTOS.............................…
