DATA RADIO MANUAL HLD-100V2 PAGE - 1 SPECIFICATIONS GENERAL Equipment Type..........................................Data radio Band..........................................................VHF Channel Spacings.........................................25kHz, 12.5kHz programmable RF Output Power..........................................5/1 watt Modulation Type...........................................F3D, D3E Intermediate Frequency.................................45.1MHz & 455KHz Number of Channels.....................................16 Frequency Source.........................................Synthesizer Power Supply................................................Power Supply (12 VDC Nominal Voltage) Temperature Range Storage.....................................................from -40 to + 80 Operating..................................................from -30 to + 60 Current Consumption Standby (Muted).........................................< 65mA Transmit 5 Watts RF Power..........................< 2.0A Transmit 1 Watts RF Power..........................< 1.0A Frequency Bands RX TX VHF V2 148.000 – 174.000 MHz 148.000 – 174.000 MHz PAGE - 2 TRANSMITTER Carrier Power.................................................................Nom. Max Min Hi..............................................................................5W < 6W > 4.5W Low...........................................................................1W < 1.5W > 0.8W Sustained Transmission..................................................Nominal conditions Time : 5 10 30 Sec. Power : >90% >85% >80% Frequency.....................................................................< 0.5 kHz Nominal condition for VHF ±5.0 ppm Extreme condition for VHF Frequency Deviation 25 kHz Channel Spacing...............................................Peak ±5.0, Min. ±3.8 12.5 kHz Channel Spacing.............................................Peak ±2.5, Min. ±1.9 Audio Frequency Response.............................................Within+1/-3dB of 6dB octave ＠ 300 Hz to 2.55 kHz for 12.5 kHz C.S ＠ 300 Hz to 3.0 kHz for 25 kHz C.S Adjacent Channel Power 25 kHz........................................................................< 70 dBc ＠ Nominal Condition < 65 dBc ＠ Extreme Condition 12.5 kHz......................................................................< 60 dBc ＠ Nominal Condition < 55 dBc ＠ Extreme Condition Conducted Spurious Emission.........................................< -57 dBc Modulation Sensitivity...................................100mV RMS ＠60% Peak Dev. Hum & Noise : 25 kHz Channel Spacing...............................> 40 dB 12.5 kHz Channel Spacing............................> 34 dB Modulation Symmetry...................................< 10% Peak Dev ＠ 1kHz input for nominal dev +20dB Load Stability................................................No osc at ≥ 10:1 VSWR all phase angles and suitable antenna No destroy at ≥ 20:1 all phase angle Peak Deviation Range Adjustment ＠ kHz, Nom. Dev +20dB : 25 kHz Channel Spacing...............................> Min. 3.5, Max. 6.0 12.5 kHz Channel Spacing............................> Min. 1.5, Max. 4.0 PAGE - 3 RECEIVER Sensitivity (12dB Sinad),................................. VHF<-118dBm @ Nom. Condition VHF<-116dBm @ Extreme Condition Amplitude Characteristic.................................< ±3dB Adjacent Channel Selectivity : 25 kHz Channel Spacing.............................> 60dB @ Nom., > 55dB @ Extreme Condition 12.5 kHz Channel Spacing............................> 50dB @ Nom., > 45dB @ Extreme Condition Spurious Response Rejection..........................70dB (100kHz-4 GHz) Image Response.............................................> 70 IF Response...................................................> 70 Others...........................................................> 70 Intermodulation Response Rejection : ±25 kHz / 50 kHz.........................................65 dB ±50 kHz / 100 kHz.......................................65 dB Conducted Spurious Emission @ Nominal Conditions : 9 kHz – 1 GHz.............................................> -57 dBm 1 GHz – 4 GHz............................................> -47 dBm Rx Spurious Emissions (Radiated) @ Nominal Conditions 9 kHz – 1 GHz.............................................> -57 dBm 1 GHz – 12.75 GHz.......................................> -47 dBm AF Distortion..................................................5% @ Nom., < 10% @ Extreme condition Rx Hum & Noise : 25.0 kHz CP................................................< 40 dB No PSOPH 12.5 kHz CP................................................< 35 dB with PSOPH Receiver Response Time.................................< 16 mS Squelch Opening Range...................................RF level for 6 to 14 dB Sinad Squelch Closing Range (Hysteresis):................ 0-6 dB Sinad @ Nominal Condition Squelch Decay Time : Rf Level at Threshold...................................< 40mS Rf Level at Threshold + 20dB........................< 30mS Squelch Decay Time........................................5 mS Min., 20mS Max. PAGE - 4 Antenna Socket Input Match.............................> 10dB Return Loss L.O.Frequency Temperature Stability.................1 st <5 ppm, 2 nd <15 ppm from -30 to 60 L.O.Frequency Aging Rate................................±2ppm/yeat REFERENCY CRYSTAL Frequency......................................................14.4 MHz Holder Type.....................................................HC-18 Temperature Characteristic...............................±5.0 ppm from -30 to 60 Aging Rate.......................................................< 2 ppm /year in 1 st year < 1 ppm/ year thereafter Lock time........................................................< 10mS TX to RX..........................................................< 20 (No Power Saving) RX to TX..........................................................< 20 PAGE - 5 INTRODUCTION The HEADLINE HLD-1…
