Application Details
- Equipment Class
- DSS - Part 15 Spread Spectrum Transmitter
- Date of Grant
- Oct 27, 2007
- Application Purpose
- Original Equipment
- Date of Application
- Oct 27, 2007
- Equipment Note
- Viking Z Seven SCBA
- Frequency Range
- 2405.00000000 - 2480.00000000
- Country
- United States
Documents & Files
Select a file to view
Users Manual
Cover Letter(s)
External Photos
ID Label/Location Info
Internal Photos
RF Exposure Info
Test Report
Test Setup Photos
Document Text Content (2 documents)
Test Setup Photos
Quatitée # Description #Pièce Manufacturier 1 Ic 1 MICRO MCHC908QT2CDWE FREESCALE 1 IC 2 RF DEVICES T5754-6AQ ATMEL 1 IC3 RF AMPLI. SGA-2286Z SIRENZA 1 IC4 V. REF. 1.2V LM285D-1-2 TEXAS INS. 1 D1 DIODE H.S. 1N4148W-TP M.C.C. 1 R SW REED SW CM5-2319 SRC DEVICE 1 XTAL 13.56 MHZ -40C CS10-13.560MABJ-UT CITIZEN 1 C1 150 μF TANT. B45197A1157K409 EPCOS 1 C2 22 PF. CER. ECJ-OEC1H220D PANASONIC 2 C3,C6 68 NF. CER ECJ-0EB1A683K ‘’ 1 C4 12 PF. CER ECJ-0EC1H120J `` 1 C5 33 PF. CER ECJ-0EC1H330J `` 2 C7,C8 220 PF. CER. ECJ-0EC1H221J `` 1 C9 100 PF. CER. ECJ-0EC1H101J `` 1 C10 1000 PF. CER ECJ-0EB1H102K `` 1 C11 1 μF. CER . ECJ-1VF1A105Z `` 1 R1 100K RESIST. MCR10EZHF1003 ROHM 1 R2 3 K `` MCR10EZHF3001 `` 1 R3 10 K `` MCR10EZHF1002 `` 1 R4 10 ohm `` MCR10EZHF10R0 `` 2 L1,L2 68 NH. INDUCT. ELJ-RF68NGFB PANASONIC 1 BAT 2400 MAH. 3.6V TL-5903/P TADIRAN 1 CON. .1’’ R. ANGLE 22-28-8021 MOLEX/WAL. revision 01-06 2007 C2 de 8 Pf remplacé par capacitor de 22 pf
Users Manual
file://///Nemko01/Shares/projects/YR7/Johny%20Tiedown/NEX-86202%20-%2010971/Submissions/Pieces%20pour%20Com-Usb.txt Pieces pour Com-Usb johnytiedown ver. Smt Quantitée Ident. Description #Pièce Manufacturier 1 ic 1 MCU MC908JB8JDWE FREESCALE 1 ic 2 Radio 433.92 TH71102ENE MELEXIS 1 IC 3 RTC CLOCK DS1302ZN+ DALLAS 1 IC 4 32X8 EEPROM 25LC256-i/Sn MICROCHIP 1 T 1 LNA TRANS. BFP420E6327 INFINEON 1 D1 DIODE SIGNAL IN4148TPMSCT MICRO-COMMERCIAL 1 X1 XTAL 23.51222MHZ ECS-235.122-CDX-0378 ECS 1 X2 XTAL 6.00 MHZ ECS-60-32-5PXDN-TR ECS 1 X3 XTAL 32768 HZ CMJ206T32.768KDZB-UT CITIZEN 1 SAW SAW FILTER B39431B3760Z810 EPCOS 1 CERFIL FILTRE 110KHZ SFECV10M7KA00-R0 MURATA 1 CERDIS DISCRIMINATEUR CDSCB10M7GA135-R0 MURATA 1 BUZZER BUZZER 2.73 KHZ ST-04BH SOBERTON 2 C1,C8 CAP 27PF NPO ECJ-1VC1H270J PANASONIC 1 C2 Cap 100μf tan. B5197A3107K409 Kemet 4 C3,C10,C11,C17 CAP 1NF NPO ECJ-1VC1H102J PANASONIC 1 C4 CAP 10 NF X7R ECJ-1VB1E103K '' 1 C6 CAP 4.7PF NPO GRM1885C1H4R7CZ01D MURATA 1 C7,C12 CAP 2.2PF NPO GRM1885C1H2R2CZ01D '' 1 C9 CAP 33PF NPO ECJ-1VC1H330J PANASONIC 1 C13 CAP 7PF NPO ECJ-1VC1H070D '' 3 C15,C19,C22 CAP 390 PF NPO ECJ-1VC1H391J '' 1 C16 CAP 1,5NF X7R ECJ-1VB1H152K '' 1 C18 CAP 2,7PF NPO GRM1885C1H2R7CZ01D MURATA 2 C29,C21 CAP 15PF NPO ECJ-1VC1H150J PANASONIC 2 C23,C24 CAP 20PF NPO GRM1885C1H200JA01D MURATA 1 C25 Cap 10μf X5R ECJ-1VB0J106M Panasonic 1 C26 CAP .1μF Y5V ECJ-1VF1C104Z '' 7 CB1,2,3,4,5,7,8 CAP 330PF NPO ECJ-1VC1H331J '' 2 CB6,CB9 CAP 33NF X7R ECJ-1VB1E333K '' 1 L1 INDUCT 33 NH ELJ-RE33NJFA '' 1 L2 INDUCT 22 NH ELJ-RE22NJFA '' 2 L3,L4 INDUCT 68 NH ELJ-RE68NJFA '' 1 L5 INDUCT 15 NH ELJ-RE15NJFA '' 2 L6,L7 INDUCT 100 NH ELJ-RER10JFA '' 1 R1 RES. 10 MG MCR10EZHJ106 ROHM 1 R2 RES 560 OHM MCR10EZHF5600 ROHM file://///Nemko01/Shares/projects/YR7/Johny%20Tiedown...2%20-%2010971/Submissions/Pieces%20pour%20Com-Usb.txt (1 of 2)6/5/2007 9:37:45 AM file://///Nemko01/Shares/projects/YR7/Johny%20Tiedown/NEX-86202%20-%2010971/Submissions/Pieces%20pour%20Com-Usb.txt 1 R3 RE...
Contact Information
Applicant
John Baker(Engineering Tech)
Technical Contact
International Safety Instruments, IncJohn Baker
[email protected]770-962-2552
Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | 100.00 µW |
