U6DAL170A1LCD TV Monitor

FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F07-0309 1/1 ATTACHMENT E. - USER’S MANUAL -1 -  Foreword Caution......................................................................2 Important.Safety.Instructions.....................................3 Precaution.................................................................4 Overview Viewing.the.Control.Panel.........................................7. Viewing.the.Connecting.Panel...................................8 Viewing.the.Remote.Control.....................................10 ....Button.Description................................................10 Installation Table.Stand.Installation.(optional)............................12 Wall.Mount.Installation.(optional).............................12 Connections Connecting.the.TV.Cable.........................................13 Connecting.the.VCR.................................................14 Connecting.the.DVD.................................................15 Connecting.the.Set.Top.Box.....................................17 Connecting.the.PC.[.D-Sub.&.DVI.]..........................18 Displayable TV Specification....................................19 Channel Control Basic.Operation........................................................20 OSD.Menu.Structurenels.........................................21 Tuning.Band.............................................................22 Auto.Ch.Search........................................................22 Channel.Edit.............................................................23 Menu.Language.......................................................24 DTV.Signal...............................................................24 Picture Control Contrast/Brightness/Sharpness/Color/Tint...............25 Backlight...................................................................27 Aspect.Ratio.............................................................27 Screen.Aspect.Description.......................................28 Others Control Audio.Language.......................................................29 Bass/Treble/Balance................................................30 Digital.Audio.Output..................................................30 Time Setting Time.Set...................................................................31 ....Time.Set.Menu.....................................................31 Sleep.Timer..............................................................31 Advanced.Video.Menu.............................................32 Password.Set...........................................................33 Parental.Control.......................................................34 ....Parental.Control.Menu.US...................................34 ....Parental.Control.Menu.Canadian.........................35 ....Advanced.Rating.(TBD)........................................35 Close.Caption.Options.............................................36 PC.Set......................................................................37 ...PC.Setting.Menu...................................................37 ...Auto.Adjust............................................................38 Troubleshooting Troubleshooting........................................................39 Specification Specification-17.1 Inch LCD.....................................40 Contents  Caution Always be careful when using your the TV. To reduce the risk of fire, electrical shock, and other injuries, keep these safety precautions in mind when installing, using, and maintaining your machine. ► Read all safety and operating instructions before operating your the TV. ► Keep the safety and operating instructions for future reference. ► Heed all warnings on the TV and in the operating instructions. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK), . .NO.USER-SERVICE.ABLE.PARTS.INSIDE... REFER SERVICING TO QUALIFIED SERVICE .PERSONNEL. RISK OF ELECTRIC SHOCK . DO.NOT.OPEN CAUTION This.symbol.is.intended.to.alert.the.user.to.the.. presence.of.uninsulated.“dangerous.voltage”.. within.the.product’s.enclosure.thatmay.be.of.. sufficient magnitude to constitute a risk of . electric.shock.to.persons. This.symbol.is.intended.to.alert.the.user.to.the.. presence.of.important.operating.and.. maintenance.(servicing).instructions.in.the.. literature.accompanying.the.appliance. CAUTION - TO PREVENT DAMAGE WHICH MAY RESULT IN FIRE OR . SHOCK HAZARD. - DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. - SHOCK HAZARD DO NOT OPEN. CAUTION These servicing instructions are for use by qualified service.personnel.only..To.reduce.the.risk.of.electric. shock, do not perform any servicing other than that contained.in.the.operating.instructions.unless.you. are qualified to do so. CAUTION The.stand.intended.for.use.only.with.this.TV... Use.with.other.apparatus.is.capable.of.resulting.in. instability.causing.possible.injury.. - Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, . ...shall.be.placed.on.the.apparatus. -..This.is.Class.B.product..In.a.domestic.environment.this.product.may.cause.radio.interference.in.which.case.. ...the.user.may.be.required.to.take.adequate.measures. - To reduce the risk of fire and electric shock, do not expose this product to rain or moisture. This device has been tested and found to comply with the limits for a Class B device, pursuant to Part 15 of . the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in home environment as well as in a commercial, industrial or business environment. This equipment can . generate, use and radiate radio frequency energy and, if not installed and used in accordance with the . instruction, may cause harmful interference to radio communications. Howeve…

Text truncated - open the document above for the full version.

FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F07-0309 1/1 ATTACHMENT E. - USER’S MANUAL -2 - 0 Basic Operation Turning the TV On/Off Press.the.Power.button.on.the.remote.control..The.TV.will.turn.on.and.you.will.be.ready.to.use.its. features. You can also use the Power button on the front panel. Select Source Press.INPUT.button.on.the.remote.control..Then.you.can.see.the.current.source.menu.shown.as. below. TV Program Selection 1 Connect.the.signal.source.(TV.antenna).to.TV.input..Press.INPUT.button.on.the.remote.control.. .and.select.TV.on.the.source.. 2 Use CH+, CH- button or numeric button to change TV programme you want. 3 Press Pre.CH button on the remote control to watch the previous programme. 4 Also, you can tune the cable service, provided programmes while using the cable box. . For further information regarding cable TV service, contact your TV service provider(s). Volume Control Use.VOL/VOL.button.on.the.remote.control.to.adjust.the.volume.level. Press.MUTE.button.on.the.remote.control.when.you.need.to.cut.the.sound.temporarily. Ch 6 - 1 SBS Video 1 Composite Video 2 PC Video 3 HDMI Video 4 S-Video  OSD Menu Structure •.OSD.(On.Screen.Display).allows.users.to.control.or.adjust.various.features.and.settings.in. ..accordance..with.his/her.preferences.. •.Press.the..Menu.button.on.the.remote.control.to.see.the.main.OSD.menu. Example of OSD Menu 1 Main Menu Press.Menu.button.on.the.remote.control.to.enter.the.main.OSD.menu. First, select Main menu item you need with .&..button. To select a main menu items, just press .or..button.on.the.Remote.Control. 2 Sub Menu Each.menu.item.has.its.own.sub.menu.items.to.set. 3 Sub Menu items A : If there is a empty space part, the item has an sub menu. You can enter the under menu and adjust an item you need. .......Select.sub-menu.item.with. buttons on the remote control and press OK button to .......enter.the.submenu. .B : If there is a item part, you can set the item by selecting buttons... Press OK button to set. SetupVideoAudioFeature MoveSelectExit Tuning Band Air OK DTV Signal OK Auto Ch Search OK Channel Edit Air OK Menu Language English OK B 1 2 A ◄► Part  Tuning Band Before your television can begin memorizing the available channels, you must specify the type of signal source that is connected to the TV. (i.e., an antenna, a standard cable system) Auto Ch Search 1 Press.Menu.button.on.the.remote.control.to.. .display.the.main.OSD.menu. 2 Select.The.Setup.main.menu.with.button.. .on.the.remote.control. 3 Press..to.enter.the.sub.menu. 4 Select.Tuning Band.menu.. 5 Select.the.Band by press OK button and press Exit or Menu button. You can select Air or .CABLE. •.Auto.Ch.Search.scan.first.analog.channel.after.then.digital.channel. •.Add.On.Ch.Search.scan.new.channel.except.pre-scan.channel.. Notes ATSC Channel 20 Not Found Analog Channel Found 6 Digital Channel Found 5 Progress (%) 62 AutoProgram Menu (DTV Scan) NTSC Channel 22 Not Found Analog Channel Found 6 Digital Channel Found 0 Progress (%) 17 AutoProgram Menu (ATV Scan) Setup 1 Press.Menu.button.to.display.the.main.OSD.. .menu. 2 Select.The.Setup.menu.with..button.on.. .the.remote.control. 3 Press..to.enter.the.sub.menu. 4 Select.Auto Ch Search. Press OK Button on .the.remote.control..Then.the.tuning.bar.will.. .appear.and.scanning.will.start. SetupVideoAudioFeature MoveSelectExit Tuning Band Air OK DTV Signal OK Auto Ch Search OK Add On Ch Search OK Channel Edit Air OK Menu Language English OK SetupVideoAudioFeature MoveSelectExit Tuning Band Air OK DTV Signal OK Auto Ch Search OK Add On Ch Search OK Channel Edit Air OK Menu Language English OK  Setup Channel Edit You can add, erase or store of your favorite channels for each available input Band. Then, when you press the Favorite button on the remote control. 1 Press.Menu.button.on.the.remote.control.to.. .display.the.main.OSD.menu. 2 Select.the.Setup.main.menu.with..button.. .on.the.remote.control......................... 3 Press..button.to.enter.the.sub.menu.. 4 Select.Channel Edit.menu.. 5 Select the Viewable/Not Viewable/Favorite with OK button and press Exit button. You Can select Viewable, Not Viewable or Favorite. • Only scanned channels can be stored as Favorite programmes. Notes You can Viewable, Not viewable or Favorite .the.current.channel.by.the.remote.control. .CH ADD/DEL. .The.current.channel.into.the.scanned.channel.. .list. Ch 6-1 SBS Viewable Ch 7-1 KBS D-2 Viewable Ch 9-1 KBS D-1 Favorite Ch 10-1 EBS Viewable Ch 11-1 MBC Viewable Ch 2-0 Not Viewable Ch 6-0 Viewable Ch 7-0 Viewable Ch 9-0 Viewable Ch 11-0 Viewable Ch 13-0 Viewable Channel Edit Menu MoveSelectExit SetupVideoAudioFeature MoveSelectExit Tuning Band Air OK DTV Signal OK Auto Ch Search OK Add On Ch Search OK Channel Edit Air OK Menu Language English OK  Setup Menu Language You can select of your favorite language for display OSD menu. DTV Signal You can see digital signal level of current channel. 1 Press.Menu.button.on.the.remote.control.to.. .display.the.main.OSD.menu. 2 Select.the.Setup.main.menu.with.button.. .on.the.remote.control......................... 3 Press..button.to.enter.the.sub.menu.. 4 Select.Menu Language.menu.. 5 Select the English/Spanish/French with OK .button.and.press.Exit.button.. •.DTV.Signal.level.activate.on.DTV. Notes 1 Press.Menu.button.on.the.remote.control.to.. .display.the.main.OSD.menu. 2 Select.the.Setup.main.menu.with.button.. .on.the.remote.control......................... 3 Press..button.to.enter.the.sub.menu.. 4 Select.DTV Signal.menu.. 5 To see signal level, press OK.button.. SetupVideoAudioFeature MoveSelectExit Tuning Band Air OK DTV Signal OK Auto Ch Search OK Channel Edit Air OK Menu Language English OK SetupVideoAudioFeature MoveSelectExit Tuning Band Air OK DTV Signal OK Auto Ch Search OK Channel Edit Air OK Menu Language English …

Text truncated - open the document above for the full version.

FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F07-0309 1/1 ATTACHMENT C. - BLOCK DIAGRAM - Holly2 Block Diagram March 19, 2007 MP1 VSB Demodulator DC Voltage 1.8V 2.5V 3.3V 5.0V 12.0V 19V VCXO 27MHz RF Flash Memory (32Mbit) RS232 Driver 32bit/166MHz DTV Processor DDR SDRAM (256Mbx2) IFP/IFN/IF_AGC/SIF Decryption Processor Decrypted TP TP/Clock Video Switch MICOM 24.576MHz ATSC/NTSC HALF NIM TUNER Speaker Amplifier Encrypted TP TP/Clock Video ADC I2C0 I2C0 I2C0 I2C0 LVDS Connector PC Video Input PC Audio Input Composite/A-L/A-R S-Video HDMI SPDIF 25MHz DTV Service Audio ADC Audio Mux Video Driver Input Select Switch YPbPr YPbPr RGB Component Input (option) Y P b P r 8bit Y/C I2S LVDS HDMI SPDIF I2S T-Port Tx/Rx UART 10MHz MTI Data/CLK

FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr 1/3 March 30. 2007 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT : Aomni International FCC ID: U6DAL170A1 Gentlemen: Transmitted herewith, on behalf of Aomni International is an application for a FCC Part 15 Subpart B Certification of the following LCD TV MONITOR FCC ID : U6DAL170A1 MODEL : AL170A1 HL-1700XV Attached is the applicant’s Cover Letter, External/Internal Photos, Test Set-Up Photos, Manual, Label, Block Diagram and Test Report. Should you have any questions or comments concerning the above, please contact the undersigned. ______________ SANG JUN LEE EMC MANAGER cc: Mr. S.K. Jeung ------- R & D / MANAGER FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr 3/3 1. Attached the Gasket

Aomni International Date: March 30, 2007 Compliance Certification Services Certification Division 561F Monterey Road Morgan Hill, CA 95037 To whom it may concern: We, the undersigned, hereby authorize < HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD.>, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by < HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD.> on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing < HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD.> as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards;

FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F07-0309 1/5 ATTACHMENT B. - EXTERNAL PHOTOS - FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F07-0309 2/5 FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F07-0309 3/5 FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F07-0309 4/5 FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F07-0309 5/5

FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F07-0309 1/3 ATTACHMENT A. - ID LABEL INFORMATION AND LOCATION PHOTOS - FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F07-0309 2/3 1.1 ID Label Information Following is a copy of the label that will be placed on the rear side of the cabinet. Both the FCC ID and compliance statement are included in the product label Figure 3.1 PRODUCT LABEL FCC ID: Model No: EUT Type: Input power: Power Consumption: Serial No: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference , and (2) this device must accept any interference received, Includin g interference that may cause undesired operation. “ Product complies with DHHS Rules-21 CFR subchapter J-applicable at date of manufacture Aomni International (463-841) C-601 Inteli-G-2 Jeongja-Dong 24, Bundang-Gu Seongnam-Si, Gyeonggi-Do, Korea MADE IN KOREA U6DAL170A1 SAL170A1 HL-1700XV5-C LCD TV Monitor Input power: DC + 18 External Power Adaptor 54 Watt - FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F07-0309 3/3 1.2 Label Location Photos Label Location

FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F07-0309 1/30 ATTACHMENT F. - INTERNAL PHOTOS - FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F07-0309 2/30 FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F07-0309 3/30 FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F07-0309 4/30 FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F07-0309 5/30 FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F07-0309 6/30 FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F07-0309 7/30 FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F07-0309 8/30 FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F07-0309 9/30 FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F07-0309 10/30 FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F07-0309 11/30 FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F07-0309 12/30 FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F07-0309 13/30 FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F07-0309 14/30 FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F07-0309 15/30 FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F07-0309 16/30 FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F07-0309 17/30 FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F07-0309 18/30 FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F07-0309 19/30 FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F07-0309 20/30 FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F07-0309 21/30 FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F07-0309 22/30 FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F07-0309 23/30 FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F07-0309 24/30 FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F07-0309 25/30 FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL…

Text truncated - open the document above for the full version.

FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL: +82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No.: HCT-F07-0309 2/20 TABLE OF CONTENTS PAGE REPORT COVER 1 TABLE OF CONTENTS 2 1.1 SCOPE 3 2.1 INTRODUCTION (SITE DESCRIPTION ) 4 3.1 PRODUCTION INFORMATION 5 4.1 DESCRIPTION OF TESTS (CONDUCTED) 7 4.3 DESCRIPTION OF TESTS (RADIATED) 8 5.1 LIST OF SUPPORT EQUIPMENT 9 6.1 TEST DATA (CONDUCTED) 11 7.1 TEST DATA (RADIATED) 16 8.1 SAMPLE CALCULATIONS 17 9.1 TEST EQUIPMENT 18 10.1 TEST SOFTWARE USED 19 11.1 CONCLUSION 20 ATTACHMENT A: FCC ID LABEL & LOCATION ATTACHMENT B: EXTERNAL PHOTOGRAPHS ATTACHMENT C: BLOCK DIAGRAM ATTACHMENT D: TEST SETUP PHOTOGRAPHS ATTACHMENT E: USER’S MANUAL ATTACHMENT F: INTERNAL PHOTOGRAPHS FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL: +82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No.: HCT-F07-0309 3/20 MEASUREMENT REPORT 1.1 Scope Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. • FCC ID : U6DAL170A1 • Equipment Class: FCC Class B Peripheral Device (JBP) • EUT Type: LCD TV MONITOR • Model(s): AL170A1 HL-1700XV • Max input resolution: 1280 X 768 X 60 Hz • Input power: DC + 18 External power adaptor • Power consumption: 54 W • Rule Part(s): FCC Part 15 Subpart B • Test Procedure(s): ANSI C63.4 (2003) • Dates of Tests: March 27. 2007 ~ March 29. 2007 • Place of Tests: 254-1,MAEKOK-RI,HOBUP-MYUN,ICHON-SI,KYOUNGKI-DO,467-701,KOREA Applicant Name: Address: Aomni International 463-841) C-601 Inteli-G-2 Jeongja-Dong 24, Bundang-Gu Seongnam-Si, Gyeonggi-Do, Korea FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL: +82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No.: HCT-F07-0309 4/20 2.1 INTRODUCTION The measurement procedure described in American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9kHz to 40GHz (ANSIC63.4-2003) was used in determining radiated and conducted emissions emanating from Aomni International LCD TV MONITOR FCC ID: U6DAL170A1 The open area test site and conducted measurement facility used to collect the radiated data are located at the 254-1, MAEKOK-RI, HOBUP-MYUN, ICHON-SI, KYOUNGKI-DO, 467-701, KOREA. The site is constructed in conformance with the requirements of ANSI C63.4and CISPR Publication 22. Detailed description of test facility was submitted to the Commission and accepted dated July 23, 2003 (Confirmation Number: EA90661) FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL: +82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No.: HCT-F07-0309 5/20 3.1 PRODUCT INFORMATION 3.2 Equipment Description Equipment Under Test (EUT) is Aomni International LCD TV MONITOR (FCC ID: U6DAL170A1) EMI Suppression Devices: Modifications were made to the device. Please refer to the next page. FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL: +82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No.: HCT-F07-0309 6/20 1. Attached the Gasket FCC ID: U6DAL170A1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL: +82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No.: HCT-F07-0309 7/20 4.1 Description of Tests(Conducted) 4.2 Powerline Conducted RFI (150kHz- 30MHz) The power line conducted RFI measurements were performed according to ANSI C63.4 (2003). The EUT was placed on a non-conducting 1.0 by 1.5 meter table which is 0.8 meters in height and 0.40 meters away from the vertical wall of the shielded enclosure. Power to the EUT is provided through a Rohde & Schwarz 50 Ω / 50 uH Line Impedance Stabilization Network (LISN) and the support equipment through a separate Solar 50 Ω / 50 uH Line- Conducted Test Facility LISN. Sufficient time for the EUT, support equipment, and test equipment were allowed in order for them to warm up to their normal operating condition. The RF output of the LISN was connected to the spectrum analyzer to determine the frequency producing the maximum EME. The spectrum was scanned from 150kHz to 30 MHz. Each maximum EME was remeasured using an EMI receiver. The detector function of the receiver was set to CISPR quasi- peak and average mode with the bandwidth set to 9 kHz. Each emission was maximized consistent with the typical applications by varying the configuration of the test sample. Interface cables were connected to the available interface ports of the test unit. The effect of v…

Text truncated - open the document above for the full version.
