FCC ID: U6DAL260V1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F07-0503 1/1 ATTACHMENT E. - USER’S MANUAL - Setting the Picture 31 Your the TV has 3 automatic factory preset picture settings (Standard,VividandMild). You can choose Standard,VividorMildby pressing Picture button on the remote control (or by making a selection from the menu). Or you can select Userwhich automatically recalls your personalized picture settings. Press Menu/Set button to display the main OSD menu. Select the Picture main menu. Press Menu/Set button to enter the sub menu. SelectModeand press Menu/Set button to enter the sub menu. Then the picture sub mode appear. Select the picture mode and press Menu/Set button. You will see the picture setting bars. Just press Exit button on the remote control. You can adjust each values of the picture setting, but the changed values are stored as in Usermode. You can change the Contrast,Brightness,Color,SharpnessandTintaccording to personal preference in Usermode. (The function for Tint adjustment is activated when NTSC signal is input.) Select the item to adjust with button. Press Menu/Set button. Adjust the item with button. To cancel all adjust, select Recalland press Menu/Set button. Notes Alternative method: Just press the Picture button on the remote control. Each time it is pressed, different mode is selected. Changing the Picture Mode 1 2 3 4 1 2 3 4 5 6 User mode require more settings. It has an under menu. For a more detailed description of these settings, see the next page. Adjusting the User Mode Select User Mode Picture Mode Temperature Color Enhancer Video NR Screen Form Black Enhancer Wide Mode Standard Normal On On 16:9 On On ¥ ¥ ¥ ¥ ¥ ¥  ¥ Š Š Š Š Š Š Š Move Enter Exit Mode Standard Vivid Mild User Move Select Exit User Contrast Brightness Color Sharpness Tint Recall 50 50 50 50 0 ¥ ¥ ¥  ¥ ¥ Š Š Š Š Š Move Adjust Exit User Contrast Brightness Color Sharpness Tint Recall 50 50 50 50 0 ¥ ¥ ¥  ¥ ¥ Š Š Š Š Š Move Adjust Exit Setting the Picture 32 Adjust brightness difference between bright part of the screen and dark part. Adjust brightness of the screen. Adjust deep and light color of the screen. Adjust vividness of the screen. Adjust the balance between green and yellow. Contrast Brightness Color Sharpness Tint Distinct¥ ŠVague Dark¥ ŠBright Decrease¥ ŠIncrease Less sharp ¥ ŠSharp Green color is deeper ¥ ŠRed color is deeper Setting the Picture 33 Your TV has 5 screen temperatures (color settings). Press Menu/Set button to display the main OSD menu. Select the Picture main menu. Press button to enter the picture menu. SelectTemperatureand press Menu/Set button to enter the sub menu. Then the picture-temperature under menu appear. Select the Temperature mode with button and press Menu/Set button. Press Exit button to return. Screen seems cool: Strong Blue. Normal: Factory default. Screen seems warm: Strong Red. This function will enhance the color level. Green, Blue and Skin color on the picture will enhance, while others areas remain unchanged. Press Menu/Set button to display the main OSD menu. Select the Picture main menu item. Press button to enter the sub menu. SelectColor Enhancer. Then the cursor moves into the ¥Šparts. Turn on or off Film Mode function with button and press Exit button. Changing the Color Temperature Changing the Color Enhancer 1 2 3 4 5 6 1 2 3 4 5 Cool 1, 2 Normal Warm 1, 2 Picture Mode Temperature Color Enhancer Video NR Screen Form Black Enhancer Standard Normal On On 16:9 On ¥ ¥ ¥ ¥ ¥ ¥  Š Š Š Š Š Š Move Enter Exit Temperature Cool2 Cool1 Normal Warm1 Warm2 Move Select Exit Picture Mode Temperature Color Enhancer Video NR Screen Form Black Enhancer User Normal On On 16:9 On ¥ ¥ ¥ ¥ ¥ ¥    Š Š Š Š Š Š Move Adjust Exit Setting the Picture 34 This function automatically filters out and reduces the image noise and improves picture quality where receiving weak signals. Press Menu/Set button to display the main OSD menu. Select the Picture main menu item. Press Menu/Set button to enter the sub menu. SelectVideo NR. Then the cursor moves into the¥Šparts. Turn on or off Video NR function with button and press Exit button. Your TV has four screen forms: 16:9,4:3,Panorama,Zoom1,Zoom2. (For more detail description for these modes, refer to the next page.) Press Menu/Set button to display the main OSD menu. Select the Picture main menu. Press button to enter the picture menu. SelectScreen Formand press button to enter the sub menu. Then the screen form under menu appear. Select the Screen Form you want and press button and Exit button. Video NR (Noise Reduction) Changing the Screen Form 1 2 3 4 5 1 2 3 4 5 Picture Mode Temperature Color Enhancer Video NR Screen Form Black Enhancer Standard Normal On On 16:9 On ¥ ¥ ¥ ¥ ¥ ¥  Š Š Š Š Š Š Move Adjust Exit Picture Mode Temperature Color Enhancer Video NR Screen Form Black Enhancer User Normal On On 16:9 On ¥ ¥ ¥ ¥ ¥ ¥  Š Š Š Š Š Š Move Enter Exit Screen Form 16:9 4:3 Panorama Zoom1 Zoom2 Move Select Exit Setting the Picture 35 16:9 16:9 video : No change. 4:3 video : Expands 4:3 video signal horizontally to fit the 16:9 screen. Panorama 16:9 video : No change. 4:3 video : Expands 4:3 video horizontally to fit the 16:9 screen and to minimize distortion, sides are expanded more than center. Zoom1 Expands 16:9 mode screen vertically. Zoom2 Expands Zoom 1 mode screen vertically. 4:3 16:9 video : The image is suppressed. 4:3 video : No expansion. There are gray areas besides the image. This will enhance the black level / the contrast of the picture. The dark regions of the picture are made darker, while bright areas remain unchanged. The advantage of this black-level expansion is that the black expansion is performed only if it is noticeable to the viewer. Screen Form Description Selecting the Black Enhancer Picture Mode Temperat…

Text truncated - open the document above for the full version.

FCC ID: U6DAL260V1 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F07-0503 1/1 ATTACHMENT C. - BLOCK DIAGRAM - U20 SVP-EX52 SCALER U27 MST3387M-110 ADC U19 LJU26901 LIP SYNC U1 SST39VF080A FRASH ROM U2 M16C M-MICOM U6 AT89C52 S-MICOM U28 MUX PI5V330W LVDS OUT(1.25mm/30P) U30 MUX PI5V330W U36 MUX PI5V330W PC RGB In Component In 1 U26 EEPROM U11 EEPROM U9 DS232A RS-232C U25 74HC125 BUFFER LVDS out(1mm/31P) PUMA Pro:Idiom X-tal 14.318M X-tal 10M X-tal 11.0592M X-tal 14.318M T1 M-TUNER U57 CXA2069Q AV MUX U56 MSP4650K U66 TA5112 AMP J19 MAIN POWER IN Front Key / IR 4 3 2 1 AV OUT AV1 J6 AUDIO OUT U18 53A3N9K AUDIO X-tal 18.432M J35 SPDIF+RS-232C U12 74HCT14 Vision System Block (AL260V1) PDP LCD DLP SPDIF AIR/CABLE DC-DC BLOCK J20 LCD CTL J9 LG PDP IN J40 HDTV POWER OUT J16 J1 J4 VISION VISION AUDIO IN(PC RGB) LINE OUT SVIDEO In/AV3 In HDMI In U13 K4D2623238F SRAM(DDR 128M) HDMI In DC-DC BLOCK U31 EEPROM U32 EEPROM DTV SERVICE MTI
