U6ZUW005CATC5K UWB Analyzer/Exerciser

For Software Version 3.0 August 2007 PROTOCOL SOLUTIONS GROUP 3385 SCOTT BLVD SANTA CLARA, CA 95054 LeCroy UWBTracer™/Trainer ™ Ultra-Wideband Protocol Analyzer User Manual Manual Version 3.0 UWBTracer/Trainer User Manual LeCroy Corporation Document Disclaimer The information in this document has been carefully checked and is believed to be reliable. However, no responsibility can be assumed for inaccuracies that may not have been detected. LeCroy reserves the right to revise the information in this document without notice or penalty. Trademarks and Servicemarks LeCroy, UWBTrainer, UWBTracer, UWBTracer MPI, CATC Trace, and BusEngine are trademarks of LeCroy. Microsoft and Windows are registered trademarks of Microsoft Inc. Intel and Pentium are registered trademarks of Intel Corporation. AMD Duron and AMD Athlon are trademarks of Advanced Micro Devices, Inc. All other trademarks are property of their respective companies. Copyright Copyright © 2007, LeCroy Corporation. All Rights Reserved. This document may be printed and reproduced without additional permission, but all copies should contain this copyright notice. FCC Conformance Statement Compliance with 47 CFR 15.519 (a)(1) This device complied with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Rule 47 CFR 15.519 (a)(1) states that “A UWB device operating under the provisions of this section shall transmit only when it is sending information to an associated receiver. The UWB intentional radiator shall cease transmission within 10 seconds unless it receives an acknowledgement from the associated receiver that its transmission is being received. An acknowledgement of reception must continue to be received by the UWB intentional radiator at least every 10 seconds or the UWB device must cease transmitting. “ This equipment may only be operated indoors. Operation outdoors is in violation of 47 U.S.C. 301 and could subject the operator to serious legal penalties. Note: This device must be installed in a location that is not accessible to the general public. Install the device so that the antenna is more than 20 cm from unsuspecting personnel. Failure to install this device as described will result in a failure to comply with FCC rules for RF exposure and is discouraged. Only antennas approved with the device may be used. This device may not be co-located with other transmitters without further approval by the FCC. Caution: Changes or modifications not expressly approved by the party responsible for compliance could void the operator’s authority to operate the equipment. UWBTracer/Trainer User Manual LeCroy Corporation EU Declaration of Conformity This equipment including all its options is in conformity with the provisions of the following EC directives(s), including all the latest amendments: 73/23/EEC Low Voltage Directive 89/336/EEC EMC Directive Conformity with Council Directive 73/23/EEC is based on: EN 61010-1:2001 Safety requirements for electrical equipment for measurement, control and laboratory use Conformity with Council Directive 89/336/EEC is based on: EN 61326/A3: 2003 EMC requirements for electrical equipment for measurement control and laboratory use Emissions EN 55011/A2:2002 (Conducted and Radiated Emissions) EN 61000-3-2/A2:2005 (Harmonic Current Emissions) EN 61000-3-3/A2:2005 (Voltage Fluctuations and Flicker) ImmunityEN 61000-4-2/A2:2001 (Electrostatic Discharge) EN 61000-4-3/A1:2003 (RF Radiated Electromagnetic Field) EN 61000-4-4:2004 (Electrical Fast Transient/Burst) EN 61000-4-5/A1:2001 (Surge) EN 61000-4-6/A1:2001 (RF Conducted Electromagnetic Field) EN 61000-4-11:2004 (Mains Dips and Interruptions) Warning: This is a Class A product. In a domestic environment this product may cause radio interference, in which case the user may be required to take adequate measures. UWBTracer/Trainer User Manual LeCroy Corporation WEEE Program Part number: 730-0077-00 This electronic product is subject to disposal and recycling regulations that vary by country and region. Many countries prohibit the disposal of waste electronic equipment in standard waste receptacles. For more information about proper disposal and recycling of your LeCroy product, please visit www.lecroy.com/recycle. UWBTracer/Trainer User ManualSection 1 LeCroy Corporation 1 Section 1. General Section 1UWBTracer/Trainer User Manual 2LeCroy Corporation [blank page] UWBTracer/Trainer User ManualChapter 1: Overview LeCroy Corporation 3 Chapter 1: Overview This chapter describes the UWBTracer/Trainer™ product and Ultra-Wideband technology in general. 1.1 UWBTracer/Trainer Ultra-Wideband Analyzers The LeCroy UWBTracer/Trainer is a portable Ultra-Wideband (UWB) test and debug platform that combines non-intrusive recording with extensive decoding features. The RF (wireless) recording functionality is designed to record non-intrusively off-the-air WiMedia UWB traffic from one or more devices, while the MPI recording functionality is designed to connect to the specification-defined MAC-PHY Interface (MPI) bus between the MAC and the PHY subsystems in WiMedia-compliant devices and to capture the traffic between them. The WiNet protocol uses the MUX sublayer and services of the WiMedia MAC for data networking. By leveraging years of experience in protocol analysis tools for emerging markets, UWBTracer/Trainer blends sophisticated functionality with practical features to allow designers and validation engineers to easily specify multi-level, conditional trigger scenarios to pinpoint intermittent problems in the UWB connection. System-level validation requires non-intrusive monitoring. UWBTracer/Trainer ensures accurate data collection by providing transparent electrical taps. At the heart of UWBTracer/Trainer is the CATC BusEngine™ protocol processor that features a re…

Text truncated - open the document above for the full version.

MODEL: UW005MGA-XFCC ID: U6ZUW005 CHECKEDBY:DRAWNBY: REV.: APP’VDBY: UNLESS OTHERWISESPECIFIED, ALLDIMENSIONS AREIN INCHES. 1:1 NOTICE: This design is the sole property of LeCroy Corporation. It contains proprietary informationand is furnished with the understanding that it is not to be used, disclosed or reproduced in anymanner without the approval of LeCroy Corporation. PART NUMBER :TITLE:SCALE: SHEET OF MFR ENGBY: TOLERANCES ARE:INCHE S = ± 0.01 in Corporation DRAWING NUMBER : DESCRIPTION DATE REV ECO # JEREMY EMS 915402 1 MARKETINGBY: A UWB FCC ID LABEL TRAINER 915402-00 TEXT COLOR: PANTONE 426CBACKGROUND COLOR: PETER LACKE VPMP00003 OR APPROVED EQUIVALENTMATERIAL: VELVET POLYCARBONATE, FINE GRAIN P35, 0.25 mm THICKADHESIVE: SCOTCH 3M 467MP OR APPROVED EQUIVALENT ® R 0.100 in 1.60 in 0.60 in 1 20-SEP-07 PRODUCTION RELEASE PRODUCTION RELEASE 12314 A

0 Enlarge Your World with Wireless ACON Antenna Product Specification DOC. No.:WPS06003 Rev.2 Page: 1/6 Approved/Date Checked/Date Written/Date UWB Antenna Ultra wide band Allen 06/29/06’ Chiao 06/29/06’ Angel 06/29/06’ ADVANCED-CONNECTEK INC. B1. NO.205, Sec.3, Bei-Hsin Rd., Hsin-Tien Taipei, Taiwan TEL: 886-2-8913-1939 UWB Antenna 3.1~4.9GHz Wideband for UWB Application Technical Information: Center Frequency 3.1~4.9 GHz Bandwidth (VSWR:2 max.) >2 GHz Peak Gain 2.46 dBi Efficiency > 60% Polarization Linear Impedance 50 ohm Weight 11 g Dimension 108 ×φ10mm Connector SMA Male Reverse Connector DOC. No.:WPS06003 Rev.2 Page: 2/6 Approved/Date Checked/Date Written/Date UWB Antenna Ultra wide band Allen 06/29/06’ Chiao 06/29/06’ Angel 06/29/06’ ADVANCED-CONNECTEK INC. B1. NO.205, Sec.3, Bei-Hsin Rd., Hsin-Tien Taipei, Taiwan TEL: 886-2-8913-1939 Return Loss VSWR DOC. No.:WPS06003 Rev.2 Page: 3/6 Approved/Date Checked/Date Written/Date UWB Antenna Ultra wide band Allen 06/29/06’ Chiao 06/29/06’ Angel 06/29/06’ ADVANCED-CONNECTEK INC. B1. NO.205, Sec.3, Bei-Hsin Rd., Hsin-Tien Taipei, Taiwan TEL: 886-2-8913-1939 Radiation pattern 3200MHZ 3500MHz DOC. No.:WPS06003 Rev.2 Page: 4/6 Approved/Date Checked/Date Written/Date UWB Antenna Ultra wide band Allen 06/29/06’ Chiao 06/29/06’ Angel 06/29/06’ ADVANCED-CONNECTEK INC. B1. NO.205, Sec.3, Bei-Hsin Rd., Hsin-Tien Taipei, Taiwan TEL: 886-2-8913-1939 4000MHz 4500MHz DOC. No.:WPS06003 Rev.2 Page: 5/6 Approved/Date Checked/Date Written/Date UWB Antenna Ultra wide band Allen 06/29/06’ Chiao 06/29/06’ Angel 06/29/06’ ADVANCED-CONNECTEK INC. B1. NO.205, Sec.3, Bei-Hsin Rd., Hsin-Tien Taipei, Taiwan TEL: 886-2-8913-1939 4800MHz DOC. No.:WPS06003 Rev.2 Page: 6/6 Approved/Date Checked/Date Written/Date UWB Antenna Ultra wide band Allen 06/29/06’ Chiao 06/29/06’ Angel 06/29/06’ ADVANCED-CONNECTEK INC. B1. NO.205, Sec.3, Bei-Hsin Rd., Hsin-Tien Taipei, Taiwan TEL: 886-2-8913-1939 Mechanical dimensions

Compliance report of CATC5K UWB Analyzer/Exerciser Customer: LeCroy Corporation Date: September 10, 2007 TDK Report: TTS-TR-T12-121 Test performed by: TDK R&D Corporation 1101 Cypress Creek Rd Cedar Park, TX 78613 Technician Checked by Radiated 30 MHz to 40 GHz A. Medina K. Yata Report A. Medina P. Carson/K. Yata All services undertaken are subject to the following general policy. Reports are submitted for exclusive use of the client to whom they are addressed. Their significance is subject to the adequacy and representative character of the samples and to the comprehensiveness of the tests, examinations or surveys made. This report shall not be reproduced except in full, without written consent of TDK RF Systems Inc. This report must not be used to claim product endorsement by A2LA, NVLAP nor any other agency of the US Government 1. Executive Summary An EMC evaluation to determine compliance of the CATC5k UWB Analyzer/Exercise with requirements of FCC 47 CFR Part 15, Subpart F Section 15.517 was conducted. All references are to the most current version of the Code of Federal Regulations 47 that are currently in effect. In accordance with §2.1033, the following data is presented in support of the Certification of the CATC5K UWB Analyzer/Exerciser. The client should retain a copy of this document on file for at least 5 years after the manufacturing of the product has been discontinued. Test Description FCC 47 CFR Section Compliance Operational Limitations 15.517(a) The client has been notified of these limitations. In normal operating mode the transmitter will only send data when associated with a receiver. See section 5 for detail UWB Bandwidth 15.517(b) Yes Radiated Emissions 15.517(c), 15.209 Yes Radiated Emissions in GPS Bands 15.517(d) Yes Peak Emissions within a 50 MHz Bandwidth 15.517(e) Yes Labelling Requirements 15.517(f) Yes Report prepared by Approved by Armando Medina Kunio Yata September 10, 2007 October 1, 2007 This document contains confidential information and cannot be disclosed outside of LeCroy or any affiliated company in whole or in part without the express written permission of TDK R&D Corporation. TTS-TR-T112-121 page 2 of 50 2. Task Description 2.1. Scope Reference FCC ET Docket No. 98-153, FCC 02-48 First R&O; FCC 47 CFR, Part 15, Subpart A; FCC 47 CFR, Part 15, Subpart B; FCC 47 CFR, Part 15, Subpart C; FCC 47 CFR, Part 15, Subpart F FCC ET Docket No. 04-352, Petition for Waiver of the Part 15 UWB Regulations Filed by MBOA-SIG (Adopted: March 10, 2005) Title Revision of Part 15 of the Commission’s Rules Regarding Ultra-Wideband Transmissions Systems; Code of Federal Regulations, Part 15 Subpart A: General Code of Federal Regulations, Part 15 Subpart B: Unintentional Radiators Code of Federal Regulations, Part 15 Subpart C: Intentional Radiators Code of Federal Regulations, Part 15 Subpart F: Ultra-Wideband Operation Purpose of Test To gain FCC Certification for technical requirements for Handheld UWB Systems operating between 3.1 GHz and 10.6 GHz. Test Procedures The tests were conducted in accordance with the following documents: FCC ET Docket 98-153, FCC 02-48 First R&O ANSI C63.4: 2003: Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz FCC Code of Federal Regulations 47, Part 15 Subpart A: General FCC ET Docket No. 04-352, Petition for Waiver of the Part 15 UWB Regulations Filed by MBOA-SIG (Adopted: March 10, 2005) General Procedures FCC Code of Federal Regulations 47, Part 2 Frequency Allocations and Radio Treaty Matter: General Rules and Regulations Classification of EUT Indoor Ultra-Wideband System Page 3 of 50 2.2. Related Submittal(s)/Grant(s) None 2.3. Test Plan Reference Publication Year Title FCC 47 CFR, Part 15, Subpart A 10/2004 Code of Federal Regulations, Part 15 Subpart A: General FCC 47 CFR, Part 15, Subpart B 10/2004 Code of Federal Regulations, Part 15 Subpart B: Unintentional Radiators FCC 47 CFR, Part 15, Subpart C 10/2004 Code of Federal Regulations, Part 15 Subpart C: Intentional Radiators FCC 47 CFR, Part 15, Subpart F 10/2004 Code of Federal Regulations, Part 15 Subpart F: Ultra-Wideband Operation FCC ET Docket 98-153, FCC 02-48 First R&O 04/2002 Revision of Part 15 of the Commission’s Rules Regarding Ultra- Wideband Transmissions Systems: First Report & Order ANSI C63.4 01/2004 Methods of Measurement of Radio- Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz FCC ET Docket No. 04- 352 3/2005 Petition for Waiver of the Part 15 UWB Regulations Filed by MBOA-SIG 2.4. Client Information APPLICANT Name: LeCroy Corporation Address: 700 Chestnut Ridge Rd, Chestnut Ridge, NY 10977 Contact Person: Ravi Kalyandrug MANUFACTURER Name: LeCroy Corporation Address: 700 Chestnut Ridge Rd, Chestnut Ridge, NY, 10977 Contact Person: Ravi Kalyandrug Page 4 of 50 2.5. Equipment Under Test (EUT) The following information (with the exception of the date information) has been supplied by the applicant. The test results in this report pertain only to the item tested. General Brand Name LeCroy Product Name CATC5K UWB Analyzer/Exercise Model Name or Number UW005MGA-X Serial Number 00000399 Type of Equipment UWB Analyzer Input Power Supply Type Public utility AC power Classification Indoor Ultra-Wideband system Technical Power Supply Requirements 12Vdc RF Output Rating -42 dBm EIRP @ 3 meters Operating Frequency Range 3100 MHz to 4800 MHz RF Output Impedance 50 Ω Channel Spacing N/A Pulse Width N/A Pulse Repetition Frequency N/A 10 dB Bandwidth >500 MHz Modulation/Constellation Multiband OFDM Oscillators’ Frequencies 24M, 30M, 33.333M, 66M, 100M & 200MHz EUT Ports USB, EXT Data, Sync. In & Out, MPI Adapter, Aux Antenna Connector Type Reverse SMA Antenna Description Linear polarized planar Logistics EUT Receive Date July 13, 2007 EUT Receive Condition Good Test Start Date July 16, 2007 Test Completion Date August 25, 2007 Page 5 of 5…

Text truncated - open the document above for the full version.

Compliance report of LeCroy CATC5K UWB Analyzer/Exerciser with ACON Antennas Customer: LeCroy Corporation Date: November 27, 2007 TDK Report: TTS-TR-T112-127 Test performed by: TDK R&D Corporation 1101 Cypress Creek Rd Cedar Park, TX 78613 Technician Checked by Radiated 30 MHz to 40 GHz A. Medina K. Yata Report A. Medina P. Carson/K. Yata All services undertaken are subject to the following general policy. Reports are submitted for exclusive use of the client to whom they are addressed. Their significance is subject to the adequacy and representative character of the samples and to the comprehensiveness of the tests, examinations or surveys made. This report shall not be reproduced except in full, without written consent of TDK RF Systems Inc. This report must not be used to claim product endorsement by A2LA, NVLAP nor any other agency of the US Government 1. Executive Summary An EMC evaluation to determine compliance of the LeCroy CATC5K UWB Analyzer/Exerciser with requirements of FCC 47 CFR Part 15, Subpart F Section 15.517 was conducted. All references are to the most current version of the Code of Federal Regulations 47 that are currently in effect. In accordance with §2.1033, the following data is presented in support of the Certification of the CATC5K UWB Analyzer/Exerciser. The client should retain a copy of this document on file for at least 5 years after the manufacturing of the product has been discontinued. Test Description FCC 47 CFR Section Compliance Operational Limitations 15.517(a) The client has been notified of these limitations. In normal operating mode the transmitter will only send data when associated with a receiver. See section 5 for detail UWB Bandwidth 15.517(b) Yes Radiated Emissions 15.517(c), 15.209 Yes Radiated Emissions in GPS Bands 15.517(d) Yes Peak Emissions within a 50 MHz Bandwidth 15.517(e) Yes Labelling Requirements 15.517(f) Yes Report prepared by Approved by Armando Medina Kunio Yata November 27, 2007 November 29, 2007 This document contains confidential information and cannot be disclosed outside of LeCroy or any affiliated company in whole or in part without the express written permission of TDK R&D Corporation. TTS-TR-T112-127 page 2 of 51 2. Task Description 2.1. Scope Reference FCC ET Docket No. 98-153, FCC 02-48 First R&O; FCC 47 CFR, Part 15, Subpart A; FCC 47 CFR, Part 15, Subpart B; FCC 47 CFR, Part 15, Subpart C; FCC 47 CFR, Part 15, Subpart F FCC ET Docket No. 04-352, Petition for Waiver of the Part 15 UWB Regulations Filed by MBOA-SIG (Adopted: March 10, 2005) Title Revision of Part 15 of the Commission’s Rules Regarding Ultra-Wideband Transmissions Systems; Code of Federal Regulations, Part 15 Subpart A: General Code of Federal Regulations, Part 15 Subpart B: Unintentional Radiators Code of Federal Regulations, Part 15 Subpart C: Intentional Radiators Code of Federal Regulations, Part 15 Subpart F: Ultra-Wideband Operation Purpose of Test To gain FCC Certification for technical requirements for Handheld UWB Systems operating between 3.1 GHz and 10.6 GHz. Test Procedures The tests were conducted in accordance with the following documents: FCC ET Docket 98-153, FCC 02-48 First R&O ANSI C63.4: 2003: Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz FCC Code of Federal Regulations 47, Part 15 Subpart A: General FCC ET Docket No. 04-352, Petition for Waiver of the Part 15 UWB Regulations Filed by MBOA-SIG (Adopted: March 10, 2005) General Procedures FCC Code of Federal Regulations 47, Part 2 Frequency Allocations and Radio Treaty Matter: General Rules and Regulations Classification of EUT Indoor Ultra-Wideband System Page 3 of 51 2.2. Related Submittal(s)/Grant(s) None 2.3. Test Plan Reference Publication Year Title FCC 47 CFR, Part 15, Subpart A 10/2004 Code of Federal Regulations, Part 15 Subpart A: General FCC 47 CFR, Part 15, Subpart B 10/2004 Code of Federal Regulations, Part 15 Subpart B: Unintentional Radiators FCC 47 CFR, Part 15, Subpart C 10/2004 Code of Federal Regulations, Part 15 Subpart C: Intentional Radiators FCC 47 CFR, Part 15, Subpart F 10/2004 Code of Federal Regulations, Part 15 Subpart F: Ultra-Wideband Operation FCC ET Docket 98-153, FCC 02-48 First R&O 04/2002 Revision of Part 15 of the Commission’s Rules Regarding Ultra- Wideband Transmissions Systems: First Report & Order ANSI C63.4 01/2004 Methods of Measurement of Radio- Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz FCC ET Docket No. 04- 352 3/2005 Petition for Waiver of the Part 15 UWB Regulations Filed by MBOA-SIG 2.4. Client Information APPLICANT Name: LeCroy Corporation Address: 3385 Scott Blvd., Santa Clara, CA 95054 Contact Person: Daniel Jacobs MANUFACTURER Name: LeCroy Corporation Address: 3385 Scott Blvd., Santa Clara, CA 95054 Contact Person: Daniel Jacobs Page 4 of 51 2.5. Equipment Under Test (EUT) The following information (with the exception of the date information) has been supplied by the applicant. The test results in this report pertain only to the item tested. General Brand Name LeCroy Product Name CATC5K UWB Analyzer/Exerciser Model Name or Number UW005MGA-X Serial Number 00000399 Type of Equipment UWB Analyzer Input Power Supply Type Public utility AC power Classification Indoor Ultra-Wideband system Technical Power Supply Requirements 12Vdc RF Output Rating -42 dBm EIRP @ 3 meters Operating Frequency Range 3100 MHz to 4800 MHz RF Output Impedance 50 Ω Channel Spacing N/A Pulse Width N/A Pulse Repetition Frequency N/A 10 dB Bandwidth >500 MHz Modulation/Constellation Multiband OFDM Oscillators’ Frequencies 24M, 30M, 33.333M, 66M, 100M & 200MHz EUT Ports USB, EXT Data, Sync. In & Out, MPI Adapter, Aux Antenna Connector Type Reverse SMA Antenna Description Linear polarized monopole bar Logistics EUT Receive Date August 31, 2007 EUT Receive Condition Good Test Start Date November 6, 2007 Test Completion Date N…

Text truncated - open the document above for the full version.

Compliance report of CATC5K UWB Analyzer/Exerciser Customer: LeCroy Corporation Date: November 29, 2007 TDK Report: TTS-TR-T112-128 Test performed by: TDK R&D Corporation 1101 Cypress Creek Rd Cedar Park, TX 78613 Technician Checked by Radiated 30 MHz to 40 GHz A. Medina K. Yata Report A. Medina P. Carson/K. Yata All services undertaken are subject to the following general policy. Reports are submitted for exclusive use of the client to whom they are addressed. Their significance is subject to the adequacy and representative character of the samples and to the comprehensiveness of the tests, examinations or surveys made. This report shall not be reproduced except in full, without written consent of TDK RF Systems Inc. This report must not be used to claim product endorsement by A2LA, NVLAP nor any other agency of the US Government 1. Executive Summary An EMC evaluation to determine compliance of the CATC5k UWB Analyzer/Exercise with requirements of FCC 47 CFR Part 15, Subpart F Section 15.517 was conducted. All references are to the most current version of the Code of Federal Regulations 47 that are currently in effect. In accordance with §2.1033, the following data is presented in support of the Certification of the CATC5K UWB Analyzer/Exerciser. The client should retain a copy of this document on file for at least 5 years after the manufacturing of the product has been discontinued. Test Description FCC 47 CFR Section Compliance Operational Limitations 15.517(a) The client has been notified of these limitations. In normal operating mode the transmitter will only send data when associated with a receiver. See section 5 for detail UWB Bandwidth 15.517(b) Yes Radiated Emissions 15.517(c), 15.209 Yes Radiated Emissions in GPS Bands 15.517(d) Yes Peak Emissions within a 50 MHz Bandwidth 15.517(e) Yes Labelling Requirements 15.517(f) Yes Report prepared by Approved by Armando Medina Kunio Yata November 29, 2007 November 29, 2007 This document contains confidential information and cannot be disclosed outside of LeCroy or any affiliated company in whole or in part without the express written permission of TDK R&D Corporation. TTS-TR-T112-128 page 2 of 51 2. Task Description 2.1. Scope Reference FCC ET Docket No. 98-153, FCC 02-48 First R&O; FCC 47 CFR, Part 15, Subpart A; FCC 47 CFR, Part 15, Subpart B; FCC 47 CFR, Part 15, Subpart C; FCC 47 CFR, Part 15, Subpart F FCC ET Docket No. 04-352, Petition for Waiver of the Part 15 UWB Regulations Filed by MBOA-SIG (Adopted: March 10, 2005) Title Revision of Part 15 of the Commission’s Rules Regarding Ultra-Wideband Transmissions Systems; Code of Federal Regulations, Part 15 Subpart A: General Code of Federal Regulations, Part 15 Subpart B: Unintentional Radiators Code of Federal Regulations, Part 15 Subpart C: Intentional Radiators Code of Federal Regulations, Part 15 Subpart F: Ultra-Wideband Operation Purpose of Test To gain FCC Certification for technical requirements for Handheld UWB Systems operating between 3.1 GHz and 10.6 GHz. Test Procedures The tests were conducted in accordance with the following documents: FCC ET Docket 98-153, FCC 02-48 First R&O ANSI C63.4: 2003: Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz FCC Code of Federal Regulations 47, Part 15 Subpart A: General FCC ET Docket No. 04-352, Petition for Waiver of the Part 15 UWB Regulations Filed by MBOA-SIG (Adopted: March 10, 2005) General Procedures FCC Code of Federal Regulations 47, Part 2 Frequency Allocations and Radio Treaty Matter: General Rules and Regulations Classification of EUT Indoor Ultra-Wideband System Page 3 of 51 2.2. Related Submittal(s)/Grant(s) None 2.3. Test Plan Reference Publication Year Title FCC 47 CFR, Part 15, Subpart A 10/2004 Code of Federal Regulations, Part 15 Subpart A: General FCC 47 CFR, Part 15, Subpart B 10/2004 Code of Federal Regulations, Part 15 Subpart B: Unintentional Radiators FCC 47 CFR, Part 15, Subpart C 10/2004 Code of Federal Regulations, Part 15 Subpart C: Intentional Radiators FCC 47 CFR, Part 15, Subpart F 10/2004 Code of Federal Regulations, Part 15 Subpart F: Ultra-Wideband Operation FCC ET Docket 98-153, FCC 02-48 First R&O 04/2002 Revision of Part 15 of the Commission’s Rules Regarding Ultra- Wideband Transmissions Systems: First Report & Order ANSI C63.4 01/2004 Methods of Measurement of Radio- Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz FCC ET Docket No. 04- 352 3/2005 Petition for Waiver of the Part 15 UWB Regulations Filed by MBOA-SIG 2.4. Client Information APPLICANT Name: LeCroy Corporation Address: 3385 Scott Blvd., Santa Clara, CA 95054 Contact Person: Daniel Jacobs MANUFACTURER Name: LeCroy Corporation Address: 3385 Scott Blvd., Santa Clara, CA 95054 Contact Person: Daniel Jacobs Page 4 of 51 2.5. Equipment Under Test (EUT) The following information (with the exception of the date information) has been supplied by the applicant. The test results in this report pertain only to the item tested. General Brand Name LeCroy Product Name CATC5K UWB Analyzer/Exercise Model Name or Number UW005MGA-X Serial Number 00000399 Type of Equipment UWB Analyzer Input Power Supply Type Public utility AC power Classification Indoor Ultra-Wideband system Technical Power Supply Requirements 12Vdc RF Output Rating -42 dBm EIRP @ 3 meters Operating Frequency Range 3100 MHz to 4800 MHz RF Output Impedance 50 Ω Channel Spacing N/A Pulse Width N/A Pulse Repetition Frequency N/A 10 dB Bandwidth >500 MHz Modulation/Constellation Multiband OFDM Oscillators’ Frequencies 24M, 30M, 33.333M, 66M, 100M & 200MHz EUT Ports USB, EXT Data, Sync. In & Out, MPI Adapter, Aux Antenna Connector Type Reverse SMA Antenna Description Linear polarized planar Logistics EUT Receive Date July 13, 2007 EUT Receive Condition Good Test Start Date July 16, 2007 Test Completion Date August 25, 2007 Page 5 of 51 2.5.1.Support Equi…

Text truncated - open the document above for the full version.
