U99EWLAN2802.11abgn Module

Integration Information FCC ID: U99EWLAN2 IC: 4019A-EWLAN2 Page 1 of 9 EWLAN2 integration manual The EWLAN2 Module is a 3x3 3-stream IEEE 802.11 a/b/g/n wireless LAN module in PCI express mini card form factor, designed to deliver high-reliable radio performance for a variety of bandwidth-intensive wireless applications. Outer Appearance Top view with Samtec connector (PCI express): Rear view with antenna connectors: Dimensions: 34 mm (w) x 54mm (l) x 10 mm (h) Integration Information FCC ID: U99EWLAN2 IC: 4019A-EWLAN2 Page 2 of 9 General requirements: This module is designed exclusively for usage in Hirschmann (Belden) host equipment. A regulated power supply via the dedicated interface to the WLAN module is required. This RF module is approved only for use in products operating as fixed or mobile transmitting device where the antennas are at least 50 cm away from any persons during normal operating conditions. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. The integrator is still responsible for the FCC compliance requirement of the end product, which integrates this module. Appropriate measurements (e.g. 15 B compliance) and if applicable additional equipment authorizations (e.g. Verification , Doc) of the host device to be addressed by the integrator/manufacturer. Hardware Integration EWLAN2 supports the PCI express standard from the electrical power supply and signaling point of view. To enhance connection reliability in harsh environments between EWLAN2 and the host equipment, Samtec interface connectors have been selected. Integration Information FCC ID: U99EWLAN2 IC: 4019A-EWLAN2 Page 3 of 9 EWLAN2 is equipped with Samtec connector QRM8 The host equipment has to be equipped with Samtec connector QRF8-026-05.0-L-D-A-GP Pin assignment of QRF8-026-05.0-L-D-A-GP Integration Information FCC ID: U99EWLAN2 IC: 4019A-EWLAN2 Page 4 of 9 Data Interface Pin definition Pin Signal Comment Pin Signal Comment 1 GND ground 2 GND ground 3 Res open 4 Res open 5 GND ground 6 Res open 7 Res open 8 Res open 9 GND ground 10 Res open 11 Res open 12 GPIO10 GPIO-Interface 13 Res open 14 GPIO7 GPIO-Interface 15 GND ground 16 GND ground 17 Res open 18 PERST_L /Reset 19 GND ground 20 GND ground 21 VCC3.3 3.3V ±5% 22 VCC3.3 3.3V ±5% 23 VCC3.3 3.3V ±5% 24 VCC3.3 3.3V ±5% 25 GND ground 26 GND ground 27 Res open 28 PETp0 PCIe Tx+ 29 GND ground 30 PETn0 PCIe Tx- 31 Res open 32 GND ground 33 Res open 34 PERp0 PCIe Rx+ 35 GND ground 36 PERn0 PCIe Rx- 37 GND ground 38 GND ground Integration Information FCC ID: U99EWLAN2 IC: 4019A-EWLAN2 Page 5 of 9 39 VCC1.2 1.2V ±5% 40 REFCLK+ PCIe Ref Clock+ 41 VCC1.2 1.2V ±5% 42 REFCLK- PCIe Ref Clock- 43 GND ground 44 GND ground 45 GND ground 46 GND ground 47 Res open 48 CLKreq_L /Clock request 49 Res open 50 WAKE_L /PCIe awake 51 GND ground 52 GND ground Integration Information FCC ID: U99EWLAN2 IC: 4019A-EWLAN2 Page 6 of 9 Power Requirements EWLAN2 has to be powered as follows: 3.3VDC at VCC3.3 1.28VDC at VCC1.2 Antenna Connectors The antenna connectors of EWLAN2 are micro miniature coaxial types (MMCX). Antennas (USA/Canada) The usage of the antennas for products shipped to North America (USA and Canada) is restricted to the models and bands below: Antennas operating with this device model (Hirschmann model names) Permitted band of operation 2.4 GHz Band 5.15-5.25 GHz Band 5.725-5.825 GHz Band BAT-ANT-RSMA-2AGN-R (1) Yes Yes Yes BAT-ANT-N-3AGN-IP67 Yes Yes Yes BAT-ANT-N-MiMoDB-5N-IP65 Yes Yes Yes BAT-ANT-N-MiMo5-9N-IP65 No Yes Yes BAT-ANT-N-8G-DS-IP65 Yes No No BAT-ANT-N-MiMo-18N-IP65 (2) No No Yes Note (1): When using three antennas of the type BAT-ANT-RSMA-2AGN-R, each antenna has to be aligned into a separate spatial direction (x-y-z), where one antenna is perpendicular to the device and the other two are at right angles to each other. Note (2): Antenna BAT-ANT-N-MiMo-18N-IP65 has to be connected to the WLAN main unit as below: Antenna port “Ver” to WLAN antenna port 1 Antenna port “+45” to WLAN antenna port 2 Antenna port “-45” to WLAN antenna port 3 Other connection combinations are not permitted. Integration Information FCC ID: U99EWLAN2 IC: 4019A-EWLAN2 Page 7 of 9 SW Integration EWLAN2 is designed for usage with Hirschmann host equipment (motherboards) running the HiLCOS operating system 8.60.x or higher versions. Only HiLCOS versions with fixed (non-adjustable) radio parameters for USA/Canada are allowed for products intended for the North American market. Regulatory Requirements (FCC/IC) If intended for the North American market the following regulatory requirements apply: 1) ELWAN1 needs to be labeled with the FCC ID and Canada number: FCC ID: U99EWLAN2 IC: 4019A-EWLAN2 2) The host product need to be labeled as below: 3) The user guide of the host equipment shall contain the following information: FCC note: This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
This device may not cause harmful interference, and
This device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, This device complies with Part 15 of the FCC Rules and Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAN ICES-3 (B)/NMB-3(B) Contains Transmitter Module FCC ID: U99EWLAN2 IC: 4019A-EWLAN2 Integration Information FCC ID: U99EWLAN2 IC: 4019A-EWLAN2 Page 8 of 9 uses and can radiate radio frequency …

Text truncated - open the document above for the full version.

Ersteller: D. Brandhorst Revision: 00 Erstelldatum: 02.01.2012 Datum: 00.00.0000 Seite 1 von 1 Long/Short-term Confidentiality Request PHOENIX TESTLAB GmbH Date: 24 January 2014 Product Certification Königswinkel 10 D 32825 Blomberg FCC ID: U99EWLAN2 To Whom it may concerns, Pursuant to sections 0.457(d) and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, we hereby requests long-term confidential treatment of information accompanying this application as outlined below: Schematics Parts List Block Diagram Tune-Up Info Operational Description In addition we hereby request the following exhibits contained in this application to be temporarily (short-term confidentilality) withheld from the public disclosure for an initial period of days until: not applicable External Photos Test Setup Photos Internal Photos Users Manual The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to rule 0.457(d), disclosure of this application and all accompanying documentation will not be made before the date of the GRANT for this application. Thank you for your attention in this matter. Applicant’s Company address : Signature : ____________________________ Job Title and Dept. : Uwe Dollitz PHOENIX TESTLAB GmbH Graduated Certification Specialist International Radio Type Approval Koenigswinkel 10, 32825 Blomberg, Germany

Attn: Reviewing Engineer RE: PART 15 UNLICENSED LIMITED MODULAR TRANSMITTER APPROVAL To Whom It May Concern: We, Hirschamnn, hereby requests for part 15 unlicensed limited modular transmitter approval of our device, described as follows: Model name: EWLAN2 FCC ID: U99EWLAN2 In FCC Public Notice DA 00-1407 released June 26,2000 there are eight numbered requirements that our device complies with: 1. The modular transmitter has its own shielding, refer to external photos 2. The modular transmitter has its own buffered modulation/data inputs 3. The modular transmitter is limited to 3.3 VDC and 1.28 VDC 4. The modular transmitter must complies with the antenna requirements of Section 15.203 and 15.204c 5. The modular transmitter was tested in a stand-alone configuration, refer to Test Setup Photos 6. The modular transmitter is labelled with its own FCC ID number accrodng to the Integration Manual 7. The modular transmitter complies with 15.247 and 15.407 and the manufacturer provides adequate instructions with the integration manual 8. The modular transmitter complies with any applicable RF exposure requirements.

ANNEX B: EXTERNAL PHOTOGRAPHS Examiner: Paul NEUFELD Test Report No.: F134981E1 Date of issue: 24 January 2014 Order No.: 13-114981 page 1 of 3 134981_4.JPG: EUT + Ancillary Device, 3D view 1 ANNEX B: EXTERNAL PHOTOGRAPHS Examiner: Paul NEUFELD Test Report No.: F134981E1 Date of issue: 24 January 2014 Order No.: 13-114981 page 2 of 3 134981_5.JPG: EUT + Ancillary Device, 3D view 2 ANNEX B: EXTERNAL PHOTOGRAPHS Examiner: Paul NEUFELD Test Report No.: F134981E1 Date of issue: 24 January 2014 Order No.: 13-114981 page 3 of 3 134981_6.JPG: Adapter board for test purposes

ANNEX B: EXTERNAL PHOTOGRAPHS Examiner: Paul NEUFELD Test Report No.: F133448E3 Date of issue: 24 January 2014 Order No.: 13-114981 page 1 of 3 133448_08.JPG: EUT + Ancillary Device, 3D view 1 ANNEX B: EXTERNAL PHOTOGRAPHS Examiner: Paul NEUFELD Test Report No.: F133448E3 Date of issue: 24 January 2014 Order No.: 13-114981 page 2 of 3 133448_09.JPG: EUT + Ancillary Device, 3D view 1 ANNEX B: EXTERNAL PHOTOGRAPHS Examiner: Paul NEUFELD Test Report No.: F133448E3 Date of issue: 24 January 2014 Order No.: 13-114981 page 3 of 3 133448_10.JPG: Adapter board for test purposes

FCC ID: U99EWLAN2 IC: 4019A-EWLAN2 Page 1 of 2 Label: FCC ID: U99EWLAN2 Model: EWLAN2 IC: 4019A-EWLAN2 Label Position: Label location Alternative location FCC ID: U99EWLAN2 IC: 4019A-EWLAN2 Page 2 of 2 Label information for host device: This device complies with Part 15 of the FCC Rules and Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAN ICES-3 (B)/NMB-3(B) Contains Transmitter Module FCC ID: U99EWLAN2 IC: 4019A-EWLAN2

ANNEX C: INTERNAL PHOTOGRAPHS Examiner: Paul NEUFELD Test Report No.: F134981E1 Date of issue: 24 January 2014 Order No.: 13-114981 page 1 of 3 134981_7.JPG: EUT - top view, with shielding ANNEX C: INTERNAL PHOTOGRAPHS Examiner: Paul NEUFELD Test Report No.: F134981E1 Date of issue: 24 January 2014 Order No.: 13-114981 page 2 of 3 134981_9.JPG: EUT - top view, shielding removed ANNEX C: INTERNAL PHOTOGRAPHS Examiner: Paul NEUFELD Test Report No.: F134981E1 Date of issue: 24 January 2014 Order No.: 13-114981 page 3 of 3 134981_8.JPG: EUT – bottom view

ANNEX C: INTERNAL PHOTOGRAPHS Examiner: Paul NEUFELD Test Report No.: F133448E3 Date of issue: 24 January 2014 Order No.: 13-114981 page 1 of 3 133448_13.JPG: EUT - top view, with shielding ANNEX C: INTERNAL PHOTOGRAPHS Examiner: Paul NEUFELD Test Report No.: F133448E3 Date of issue: 24 January 2014 Order No.: 13-114981 page 2 of 3 133448_16.JPG: EUT - top view, shielding removed ANNEX C: INTERNAL PHOTOGRAPHS Examiner: Paul NEUFELD Test Report No.: F133448E3 Date of issue: 24 January 2014 Order No.: 13-114981 page 3 of 3 133448_14.JPG: EUT – bottom view

Calculation: RF-Exposure for 5 GHz transmitter Type identification: EWLAN2 In accordance to the CFR Part 47, §1.1310 S: Limit for power density according to CFR Part 47, §1.1310: 10 W/m 2 P: 12.6 mW (averaged over 30 min) G: 21 dBi = 125.9 D: Duty cycle: 100 % = 1 R: Distance in what the limit of S has to be reached: 0.5 m 222 51.0 )5.0(4 19.1250126.0 4m W m W S R DGP S ˜˜ ˜˜ Ÿ ˜˜ ˜˜ SS The value for the “General population / Uncontrolled Exposure” of the power density is below the limit of CFR Part 47, §1.1310.

Calculation: RF-Exposure for 2.4 GHz transmitter Type identification: EWLAN2 In accordance to the CFR Part 47, §1.1310 S: Limit for power density according to CFR Part 47, §1.1310: 10 W/m 2 P: 44 mW (averaged over 30 min) G: 8.3 dBi = 6.8 D: Duty cycle: 100 % = 1 R: Distance in what the limit of S has to be reached: 0.5 m 222 12.0 )5.0(4 16.8044.0 4m W m W S R DGP S ˜˜ ˜˜ Ÿ ˜˜ ˜˜ SS The value for the “General population / Uncontrolled Exposure” of the power density is below the limit of CFR Part 47, §1.1310.
