UCVHSTNH-F17C

Hon Hai Precision Ind. Co., Ltd.

WLAN/BT HANDHELD PDA

Click to zoom

Application Details

Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Date of Grant: Oct 24, 2007
Application Purpose: Original Equipment
Date of Application: Oct 21, 2007
Equipment Note: WLAN/BT HANDHELD PDA
Frequency Range: 2402.00000000 - 2480.00000000
Company: Hon Hai Precision Ind. Co., Ltd.
Country: Taiwan

Documents & Files

Select a file to view

Users Manual

Cover Letter(s)

External Photos

ID Label/Location Info

Internal Photos

RF Exposure Info

Test Report

Test Setup Photos

Document Text Content (12 documents)

Cover Letter(s)

REPORT NO: 07U11062-2 DATE: JULY 12, 2007 EUT: WIRELESS MODEM FCC ID: N7NMC8780U Page 31 of 36 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of CCS. 8. SETUP PHOTOS RADIATED RF MEASUREMENT SETUP FOR PORTABLE CONFIGURATION X-AXIS FRONT PHOTO REPORT NO: 07U11062-2 DATE: JULY 12, 2007 EUT: WIRELESS MODEM FCC ID: N7NMC8780U Page 32 of 36 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of CCS. X-AXIS BACK PHOTO REPORT NO: 07U11062-2 DATE: JULY 12, 2007 EUT: WIRELESS MODEM FCC ID: N7NMC8780U Page 33 of 36 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of CCS. Y-AXIS FRONT PHOTO REPORT NO: 07U11062-2 DATE: JULY 12, 2007 EUT: WIRELESS MODEM FCC ID: N7NMC8780U Page 34 of 36 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of CCS. Y-AXIS BACK PHOTO REPORT NO: 07U11062-2 DATE: JULY 12, 2007 EUT: WIRELESS MODEM FCC ID: N7NMC8780U Page 35 of 36 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of CCS. Y-AXIS WITH CRADLE FRONT PHOTO REPORT NO: 07U11062-2 DATE: JULY 12, 2007 EUT: WIRELESS MODEM FCC ID: N7NMC8780U Page 36 of 36 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 47173 BENICIA STREET, FREMONT, CA ...

Cover Letter(s)

REPORT NO: 07U11062-4B DATE: July 17, 2007 FCC ID: N7NMC8780U COMPLIANCE CERTIFICATION SERVICES Page: 19 of 37 This report shall not be reproduced except in full, without the written approval of CCS. 8 SAR MEASURMENT RESULTS 8.1 CELL BAND The following modes were chosen based on conducted output power measurement results and previous CCS project # 07U11027. 8.1.1 PANASONIC CF-29 8.1.1.1 POSITION 1 Measured SAR Power Drift Extrapolated 1) SAR 1 g (mW/g)(dB)1g (mW/g) 128824.20 192837.000.5020.0000.502 251848.80 WCDMA Measured SAR Power Drift Extrapolated 1) SAR 1 g (mW/g)(dB)1g (mW/g) 4132826.40 4182836.400.262-0.0870.267 4233846.60 GPRS 2 Slots Channelf (MHz) Channelf (MHz) Notes: 1) The exact method of extrapolation is Measured SAR x 10^(-drift/10). The SAR reported at the end of the measurement process by the DASY4 system can be scaled up by the Power drift to determine the SAR at the beginning of the measurement process. 2) The SAR measured at the middle channel for this configuration is at least 3 dB lower (0.8 mW/g) than SAR limit (1.6 mW/g), thus testing at low & high channel is optional. 3) The battery was fully charged in accordance with manufacture’s instructions prior to SAR measurements. 4) Please see attachments for the detailed measurement data and plots showing the maximum SAR location of the EUT. 7 mm REPORT NO: 07U11062-4B DATE: July 17, 2007 FCC ID: N7NMC8780U COMPLIANCE CERTIFICATION SERVICES Page: 20 of 37 This report shall not be reproduced except in full, without the written approval of CCS. 8.1.1.2 POSITION 2 Measured SAR Power Drift Extrapolated 1) SAR 1 g (mW/g)(dB)1g (mW/g) 128824.20 192837.000.5540.0000.554 251848.80 WCDMA Measured SAR Power Drift Extra polated 1) SAR 1 g (mW/g)(dB)1g (mW/g) 4132826.40 4182836.400.4250.0000.425 4233846.60 GPRS 2 Slots Channelf (MHz) Channelf (MHz) Notes: 1) The exact method of extrapolation is Measured SAR x 10^(-drift/10). The SAR reported at the end of the measurement process by the DASY4 system can be sca...

Contact Information

Applicant

Wilson Huang(Product Safety/EMC Manager)

[email protected]886 2 2268 3466Fax: 886 2 2267 1190

Test Firm

Sporton International IncKathy Lin

[email protected]886-2-26962468Fax: 886-2-26962255

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.40 GHz - 2.48 GHz	2.00 mW

Confidentiality

Long Term

Grant Notes

Power listed is conducted. The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter, except as evaluated in this composite filing. End-users must be provided with transmitter operating conditions for satisfying RF exposure compliance.
