UGM-WBS700L-1Base station

WBS-700 Mhz Outdoor Wi-Fi Base Station Installation Guide Rev. 1 September 2010 Copyright Notice ©2010 Wavion, Inc. All rights reserved. Wavion is a registered trademark of Wavion in the United States and certain other jurisdictions. Specifications are subject to change without notice. FCC Notice to Users and Operators This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference, in which case the user will be required to correct the interference at his own expense. If this equipment does cause interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to correct the interference by using one of the following measures: • Reorient or relocate the receiving antenna. • Increase separation between the equipment and receiver. • Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician. Note This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. 3 Wavion Networks Contents Chapter 1 About This Guide....................................................................... 4 Preface .................................................................................................. 4 Conventions ........................................................................................... 4 Contacting Technical Support .................................................................. 5 Chapter 2 Introduction.............................................................................. 6 Chapter 3 Package Content ....................................................................... 7 Chapter 4 Installing the Wavion WBS-700 Metro Base Station ................ 9 Important Safety Instructions .................................................................10 Preparing for Installation ........................................................................11 Choosing a Location...............................................................................12 Preparing the Site..................................................................................12 Mounting Strategies ...............................................................................13 Using Hose Clamps ................................................................................13 Mounting on a Pole/Streetlight................................................................15 Metal/Wood/Streetlight Pole Mounting.....................................................15 Grounding the Data Protection Device.....................................................20 Connecting Antennas .............................................................................22 Antenna Sealing ....................................................................................25 Connecting Power and DATA ..................................................................26 Safety Information for the Wavion WBS-700............................................30 Service Instructions ...............................................................................30 Chapter 5 Product Specification WBS-700.............................................. 31 Chapter 6 Installation Accessories .......................................................... 33 Lightning Protection...............................................................................33 Power Over Ethernet..............................................................................33 Chapter 7 Wind Loading Considerations ................................................. 34 Chapter 8 Acronyms ................................................................................ 35 4 Wavion Networks Chapter 1 About This Guide Preface This guide details the Wavion WBS-700 installation procedures. The intended audience of this document is trained technical professionals. Conventions The exclamation point within a triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product. The lightning flash with an arrowhead symbol within a triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The notebook is intended to alert the user of a note containing further information. Installation Guide 5 Contacting Technical Support For technical support, contact Wavion using these methods: Address: Wavion Technical Support Wavion 5 Hamada Street, PO BOX 580 Yoqneam Illit, 20692 Israel Telephone: +972-4-9097343 Fax: +972-4-9097322 Email: [email protected] Web: www.wavionnetworks.com Introduction Installation Guide 6 Chapter 2 Introduction WBS-700 a high capacity, IP services oriented Broadband Wireless access system. WBS-700 is a new category of Broadband Wireless Base Station designed from the ground up for metro-Wi-Fi deployments. The system employs wireless packet switched data technology to support high-speed IP se…

Text truncated - open the document above for the full version.

MTI WIRELESS EDGE LTD. MT-221024/NV REV-D SCALE: NONE DOC NO. RD42863700C SHEET 1 OF 4 Specification for MT-/221024 NV OMNI Directional Antenna 698-746 MHz, 6.0 dBi THIS DOCUMENT AND THE INFORMATION CONTAINED IN IT ARE PROPRIETARY AND CONFIDENTIAL TO MTI. NO PERSON IS ALLOWED TO COPY REPRINT REPRODUCE OR PUBLISH ANY PART OF THIS DOCUMENT NOR DISCLOSE ITS CONTENTS TO OTHERS NOR MAKE ANY USE OF IT NOR ALLOW OR ASSIST OTHERS TO MAKE ANY USE OF IT, UNLESS BY THE PRIOR WRITTEN EXPRESS AUTHORIZATION OF MTI AND THEN ONLY TO THE EXTENT AUTHORIZED. (C) COPYRIGHT –MTI WIRELESS EDGE LTD. MTI WIRELESS EDGE LTD. Specification for MT-221024/NV OMNI Directional Antenna DOC NO. RD42863700C 698-746 MHz, 6.0 dBi SCALE: NONE CLASSIFICATION: NONE REV-D SHEET 2 OF 4 REVISION RECORD REV ECO DESCRIPTION APVD DATE 01 UPDATESPEC YAEL H. 17.3.10 02 DELETE MOUNTING KIT YAEL H. 22.3.10 A DC31 RELEASED YAEL H. 26.4.10 B 4588 UPDATE HEIGHT OF ANTENNA FROM 1100 TO 1115 YAELH. 2.5.10 C 4606 UPDATE HEIGHT OF ANTENNA FROM 1115 TO 1120 YAEL H. 20.5.10 D 4675 UPDATE SPEC YAEL H. 14.7.10 SHEET 43 44 45 46 47 48 49 50 51 52 53 54 55 56 REV SHEET 29 30 31 32 33 34 35 36 37 38 39 40 41 42 REV SHEET 15 16 17 18 19 20 21 22 23 24 25 26 27 28 REV SHEET 1 2 3 4 5 6 7 8 9 10 11 12 13 14 REV D D D D PRODUCT STATUS: PROPOSAL IN DEVELOPMENT PREPRODUCTION PRODUCTION CONTRACT NO ACTION NAME SIGN DATE PREP YAEL YAEL 17.03.10 CHKD DANIEL ZERAH D.Z 26.4.10 CHKD CHKD DSGN MAURICE DADOUN M.D 21.4.10 PROJ MOTI ROSTMY M.R 19.4.10 MFG QA MOTI MOTOVICH MOTI 22.4.10 MARK. DROR REISS D.R 22.4.10 MTI WIRELESS EDGE LTD. Specification for MT-221024/NV OMNI Directional Antenna DOC NO. RD42863700C 698-746 MHz, 6.0 dBi SCALE: NONE CLASSIFICATION: NONE REV-D SHEET 3 OF 4 SPECIFICATION OMNI Directional Antenna MTI PART NUMBER MT-221024/NV Regulatory Compliance RoHS , CE 0682 ELECTRICAL. 1 Frequency Range 698 – 746 MHz VSWR <1.6 : 1 Gain at Horizon* 6.0 dBi (typ) ; 5.2dBi (min. over freq. range and azimuth ripple) Azimuth Beam width 360° Azimuth Ripple ±0.5 dB (max) Beam Squint (Elevation) ±4.5º ; ( 709 – 735MHz: ±2.5º ) E-Plane Beam width 1 8.5° ±1.5º Elevation Side-Lobes -12dB typ., -9dB max. Cross Polarization -15dB (max) Polarization Linear Vertical Input Impedance 50 (ohms) Power 10 W (max) Lightning ProtectionDC Grounded MECHANICAL. 2 Dimensions : Diameter Height 45 mm (max) 1120 mm (max) Weight 0.5 kg (max) Connector N- type Female Radome Plastic Outline Drawing RD42999000C *Gain reflects impact of beam squint, Ripple and Radome. MTI WIRELESS EDGE LTD. Specification for MT-221024/NV OMNI Directional Antenna DOC NO. RD42863700C 698-746 MHz, 6.0 dBi SCALE: NONE CLASSIFICATION: NONE REV-D SHEET 4 OF 4 3. ENVIRONMENTAL TEST STANDARD DURATION TEMPERTURE NOTES Low Temperature IEC 68-2-1 72 h -55°C - High Temperature IEC 68-2-2 72 h +71°C - Temp. Cycling IEC 68-2-14 1 h -45°C +70°C 3 Cycles Vibration IEC 60721-3-4 30 min/axis - Random 4M5 Shock Mechanical IEC 60721-3-4 - - 4M5 Humidity ETSI EN300-2-4 T4.1E 144 h - 95% Water Tightness IEC 529 - - IP67 Solar Radiation ASTM G 154 1000 h - - Flammability UL 94 - - Class HB Salt Spray IEC 68-2-11 Ka 500 h - - Ice And Snow - - - 25mm Radial Wind Speed Survival Operation - - - - - - 220 Km/h 160 Km/h

Declaration of Authorization We Name: Wavion Ltd. Address: 5 Hamada street, P.O.B. 580 City: Yokneam 20692 Country: Israel ........................................................................... . Declare that: Name Representative of agent: ............. (1) Agent Company name: Hermon Laboratories Ltd. Address: Harakevet Industrial Zone City: Binyamina 30500 Country Israel is authorized to apply for Certification of the following product(s): Product description: ... Base station ...... . Type designation: ...WBS-700-L................... Trademark: ... WAVION WIRELESS NETWORKS on our behalf. Date: September 16, 2010 Name: Oren Niv Function: Engineering Director Signature: Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

FCC, Request for non-disclosure Date: 16-Jul-10 RF_501, Issue 6 Page 1 of 1 Company Name: Wavion Ltd. Address : 5 Hamada street, P.O.B. 580 City: Yokneam 20692 Country: Israel To: Telefication B.V., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: UGM-WBS700L-1 Reference number: ###### Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, a pplicant hereby requests Short-Term Confidential treatment of the following materials (note 1): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: Public disclosure of the above document is harmful to our company. The above material contains trade secrets and proprietary design which would customarily be guarded from competitors Planned Release Date STC: 180 days after grant day (notes 2, 3, 4, 5) Date: August 29,2010 Name and signature of applicant: Oren Niv Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period

September 20, 2010 To: Telefication B.V. Attn: Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Application for certification of a base station radio operating in 698-746 MHz band, FCC ID:UGM-WBS700L-1 Dear Gentlemen, Please find attached our application for certification of a base station radio operating in 698-746 MHz band, model name WBS-700-L, FCC ID:UGM-WBS700L-1, prepared in accordance with FCC Rules, parts 2 and 27. The product testing and this application for certification were performed by Hermon Laboratories, which is listed by FCC (Registration Numbers 90623, 90624). Hermon Labs responsible person is Mr. Michael Nikishin, tel: 011 972 4626 8440, fax:011 972 4628 8277, e-mail: [email protected]. We hope this application satisfies your requirements. Please send an invoice to Hermon Labs. Sincerely, Oren Niv, Engineering Director

Wavion Ltd. FCC ID:UGM-WBS700L-1 Page 1 of 4 EXTERNAL PHOTOGRAPHS This document contains 3 photographs Wavion Ltd. FCC ID:UGM-WBS700L-1 Page 2 of 4 Photograph No.1 WBS-700-L base station general view Wavion Ltd. FCC ID:UGM-WBS700L-1 Page 3 of 4 Photograph No.2 WBS-700-L base station rear panel view Wavion Ltd. FCC ID:UGM-WBS700L-1 Page 4 of 4 Photograph No.3 WBS-700-L base station connectors view

Wavion Ltd. FCC ID:UGM-WBS700L-1 Page 1 of 2 LABELS The labels are affixed on the bottom of the base radio unit as shown below. The label material is PVC with a permanent adhesive. A label with FCC ID:UGM-WBS700L-1 will be located here. A label with P/N will be located here A label with FCC statement will be located here Type 4 Type 4 Type 4 Type 4 enclosure enclosureenclosure enclosure Model: WBS-700L Consult the installation Guide before applying power POE Input: 55VDC WARNING: P/N: 10706ASD Product: WBS-700L-AAA-DDD S/N: YYWWMCCCCCCCC MAC: ##.##.##.##.##.## PKGXXXXX-XXNN.LL This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID : UGM-WBS700L-1

Wavion Ltd. FCC ID:UGM-WBS700L-1 Page 1 of 12 INTERNAL PHOTOGRAPHS This document contains 11 photographs Wavion Ltd. FCC ID:UGM-WBS700L-1 Page 2 of 12 Photograph No.1 WBS-700-L base station internal view Wavion Ltd. FCC ID:UGM-WBS700L-1 Page 3 of 12 Photograph No.2 WBS-700-L base station internal view Wavion Ltd. FCC ID:UGM-WBS700L-1 Page 4 of 12 Photograph No.3 WBS-700-L base station internal view without RF heads Wavion Ltd. FCC ID:UGM-WBS700L-1 Page 5 of 12 Photograph No.4 WBS-700-L base station chassis Wavion Ltd. FCC ID:UGM-WBS700L-1 Page 6 of 12 Photograph No.5 WBS-700-L digital PCB front view Wavion Ltd. FCC ID:UGM-WBS700L-1 Page 7 of 12 Photograph No.6 WBS-700-L digital PCB second side view Wavion Ltd. FCC ID:UGM-WBS700L-1 Page 8 of 12 Photograph No.7 WBS-700-L communication PCB front view Wavion Ltd. FCC ID:UGM-WBS700L-1 Page 9 of 12 Photograph No.8 WBS-700-L communication PCB second side view Wavion Ltd. FCC ID:UGM-WBS700L-1 Page 10 of 12 Photograph No.9 RF module PCB front view Wavion Ltd. FCC ID:UGM-WBS700L-1 Page 11 of 12 Photograph No.10 RF module PCB second side view Wavion Ltd. FCC ID:UGM-WBS700L-1 Page 12 of 12 Photograph No.11 RF module PCB front view without shield

Wavion Ltd. FCC ID:UGM-WBS700L-1 RF_Env_evaluation_21071_rev2.doc Page 1 of 1 Environmental evaluation and exposure limit according to FCC CFR 47part 1, §1.1307, §1.1310 To confirm compliance with a safe distance for base station unit the following calculation was done: Limit for power density for general population/uncontrolled exposure is 1 mW/cm 2 for 1500 -100000 MHz frequency range: The power density P (mW/cm 2 ) = P T / 4 π r 2 , where P T is the transmitted power, which is equal to the peak transmitter output power plus maximum antenna gain. Our approach for output power and EIRP calculations for systems utilizing the Smart Antenna System (SAS): 1. The output power was summed across channels within the band - a device can transmit simultaneously on the same or different channels. Signal combiners should be avoided because it can produce anomalous results if the summed signals exhibit any correlation. The measured output power per chain shall be summed in linear units and converted back into decibels. Alternatively Output power=Tx power per chain+10log(# of Tx chains), however this option is less preferred. 2. All modes that drive multiple antenna elements with coherent signal, including legacy modes for communicating with non-MIMO devices Directional gain = gain of antenna element + 10 log(# of TX antenna elements) 3. 10 log(# of TX chains) in item 1 above represents power sum across RF spectrum and all Tx chains and 10 log(# of TX antenna elements) in item 2 represents the beamforming gain of antenna 4. Based on the above the total EIRP shall be calculated as follows: EIRP= Total power + Directional gain EIRP=Tx power per chain+10log(# of Tx chains)+gain of antenna+10log(# of ant elements) For our case the max value is: EIRP= 30.55 dBm + 6 dBi + 7.8 dB = 44.33 dBm, which is equal to 27102 mW. The minimum safe distance “r”, where RF exposure does not exceed FCC permissible limit, is r = sqrt { P T / (Px4π)} = sqrt {27101 / 12.56} = 46 cm << 2 m . General public cannot be exposed to dangerous RF level.
