1 INTERTEK TESTING SERVICES RF Exposure The equipment under test (EUT) is a VEX 123 Robot with Bluetooth function operating in 2402-2480MHz. The EUT is powered by DC 3.2V by rechargeable battery or DC 5V by USB port. For more detail information pls. refer to the user manual. Antenna Type: Integral antenna Modulation Type: GFSK Antenna Gain: 0dBi Bluetooth Version: 5.1 BLE (Single Mode) The normal radiated output power (e.i.r.p) is: -13.0dBm (tolerance: +/- 3dB). The normal conducted output power is -13.0dBm (tolerance: +/- 3dB). According to the KDB 447498: T he Maximum peak radiated emission for the EUT is 82.5 dBμV/m at 3m in the frequency 2402MHz The EIRP = [(FS*D) ^2 / 30] mW = -12.73dBm which is within the production variation. The Minimum peak radiated emission for the EUT is 80.5 dBμV/ m at 3m in the frequency 2480MHz The EIRP = [(FS*D) ^2 / 30] mW = -14.73dBm which is within the production variation. The maximum conducted output power specified is -10dBm= 0.100 mW The source- based time-averaging conducted output power =0.100* Duty cycle mW =0.100 mW(Duty cycle =100%) The SAR Exclusion Threshold Level: = 3.0 * (min. test separation distance, mm) / sqrt(freq. in GHz) = 3.0 * 5 / sqrt (2.480) mW = 9.53 mW Since the source-based time-averaging conducted output power is well below the SAR low threshold level, so the EUT is considered to comply with SAR requirement without testing. FCC ID: UKU-RAD16

Page 1 of 2 Radiated Photos Up to 1GHz (The EUT placed at the center of the turntable) Page 2 of 2 Above 1GHz (The EUT placed at the center of the turntable)

Page 1 of 1 Conducted photos
