ULP-24IQ588 Button Remote

OEM MANUAL Refer to Freescale MC13213 operations manuals for complete descriptions. Microcontroller Features • Low voltage MCU with 40 MHz low power HCS08 CPU core • Up to 60K flash memory with block protection and security and 4K RAM — MC13211: 16KB Flash, 1KB RAM — MC13212: 32KB Flash, 2KB RAM — MC13213: 60KB Flash, 4KB RAM • Low power modes (Wait plus three Stop modes) • Dedicated serial peripheral interface (SPI) connected internally to 802.15.4 modem • One external 4-channel (5-channel internal) 16-bit timer/pulse width modulator (TPM) module and one external 1-channel (3-channel internal) 16-bit timer/pulse width modulator module, each with selectable input capture, output capture, and PWM capability. • 8-bit port keyboard interrupt (KBI) • 8-channel 8-10-bit ADC • Two independent serial communication interfaces (SCI) • Multiple clock source options — Internal clock generator (ICG) with 243 kHz oscillator that has +/-0.2% trimming Resolution and +/-0.5% deviation across voltage. — Start-up oscillator of approximately 8 MHz — External crystal or resonator — External source from modem clock for very high accuracy source or system low-cost option • Inter-integrated circuit (IIC) interface with 100 kbps operation • In-circuit debug and flash programming available via on-chip background debug module (BDM) — Two comparator and 9 trigger modes — Eight deep FIFO for storing change-of-flow addresses and event-only data — Tag and force breakpoints — In-circuit debugging with single breakpoint • System protection features — Programmable low voltage interrupt (LVI) — Optional watchdog timer (COP) — Illegal opcode detection • Up to 32 MCU GPIO with programmable pull-ups RF Modem Features • Fully compliant 802.15.4 Standard transceiver supports 250 kbps O-QPSK data in 5.0 MHz channels and full spread-spectrum encode and decode • Operates on one of 16 selectable channels in the 2.4 GHz ISM band • -1 to 0 dBm nominal output power, programmable from -27 dBm to +3 dBm typical • Receive sensitivity of <-92 dBm (typical) at 1% PER, 20-byte packet, much better than the 802.15.4 Standard of -85 dBm • Integrated transmit/receive switch VOLTAGE INFORMATION: CHANNEL NUMBER TO FREQUENCY RANGE: * Channel number (0-15) * Channel frequencies : * 0 : 2.405GHz * 1 : 2.410GHz * 2 : 2.415GHz * 3 : 2.420GHz * 4 : 2.425GHz * 5 : 2.430GHz * 6 : 2.435GHz * 7 : 2.440GHz * 8 : 2.445GHz * 9 : 2.450GHz * 10: 2.455GHz * 11: 2.460GHz * 12: 2.465GHz * 13: 2.470GHz * 14: 2.475GHz * 15: 2.480GHz FCC STATEMENT • This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: — This device may not cause harmful interference. — This device must accept any interference received, including interference that may cause undesired operation. • Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. RF warning statement: The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 Interactive Technologies, Inc. ______________________________________________________________________________ 2015.07.01 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, _____Interactive Technologies, Inc. _____hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product description: 8 Button Remote model name: 2.4IQ58 FCC ID: ULP-24IQ58 Sincerely, Client’s signature: Client’s name / title : Rob Dorrell/President Contact information / address : Interactive Technologies, Inc. 15655 S. Mahaffie Street Olathe, KS 66062

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (current) 3.0 4.0 March-26-2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 4.0 Interactive Technologies, Inc. ______________________________________________________________________________ 2015.07.01 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: ULP-24IQ58 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature: Client’s name / title : Rob Dorrell/President Contact information / address : Interactive Technologies, Inc. 15655 S. Mahaffie Street Olathe, KS 66062

Test Report No. 15020559-FCC-R1 Page 24 of 34 Annex B. EUT And Test Setup Photographs Annex B.i. Photograph EUT Internal Photo Front View of EUT Rear View of EUT Test Report No. 15020559-FCC-R1 Page 25 of 34 Top View of EUT Bottom View of EUT Test Report No. 15020559-FCC-R1 Page 26 of 34 Left View of EUT Right View of EUT

Test Report No. 15020559-FCC-R1 Page 27 of 34 Annex B.ii. Photograph EUT Internal Photo EUT Uncover - Front View EUT Uncover - Rear View Test Report No. 15020559-FCC-R1 Page 28 of 34 EUT PCBA - Front View EUT PCBA - Rear View Antenna

RF EXPOSURE REPORT Report No.: 15020559-FCC-H1 Supersede Report No.: N/A Applicant Interactive Technologies, Inc. Product Name 8 Button Remote Main Model 2.4IQ58 Test Standard FCC 2.1093 Test Date June 24 to June 29, 2015 Issue Date June 29, 2015 Test Result Pass Fail Equipment complied with the specification Equipment did not comply with the specification William Long Test Engineer Herve Idoko Checked By This test report may be reproduced in full only Test result presented in this test report is applicable to the tested sample only Issued by: SIEMIC (Nanjing-China) Laboratories 2-1 Longcang Avenue Yuhua Economic and Technology Development Park, Nanjing, China Tel:+86(25)86730128/86730129 Fax:+86(25)86730127 Email: [email protected] Test Report No. 15020559-FCC-H1 Page 2 of 7 Laboratories Introduction SIEMIC, headquartered in the heart of Silicon Valley, with superior facilities in US and Asia, is one of the leading independent testing and certification facilities providing customers with one-stop shop services for Compliance Testing and Global Certifications. In addition to testing and certification, SIEMIC provides initial design reviews and compliance management throughout a project. Our extensive experience with China, Asia Pacific, North America, European, and International compliance requirements, assures the fastest, most cost effective way to attain regulatory compliance for the global markets. Accreditations for Conformity Assessment Country/Region Scope USA EMC, RF/Wireless, SAR, Telecom Canada EMC, RF/Wireless, SAR, Telecom Taiwan EMC, RF, Telecom, SAR, Safety Hong Kong RF/Wireless, SAR, Telecom Australia EMC, RF, Telecom, SAR, Safety Korea EMI, EMS, RF, SAR, Telecom, Safety Japan EMI, RF/Wireless, SAR, Telecom Singapore EMC, RF, SAR, Telecom Europe EMC, RF, SAR, Telecom, Safety Test Report No. 15020559-FCC-H1 Page 3 of 7 This page has been left blank intentionally. Test Report No. 15020559-FCC-H1 Page 4 of 7 CONTENTS 1 REPORT REVISION HISTORY ....................................................................................................................................... 5 2 CUSTOMER INFORMATION ......................................................................................................................................... 5 3 TEST SITE INFORMATION ............................................................................................................................................ 5 4 EQUIPMENT UNDER TEST (EUT) INFORMATION ......................................................................................................... 6 5 FCC §2.1093 - RF EXPOSURE ...................................................................................................................................... 7 Test Report No. 15020559-FCC-H1 Page 5 of 7 1 Report Revision History Report No. Report Version Description Issue Date 15020559-FCC-H1 NONE Original June 29, 2015 2 Customer information Applicant Name Interactive Technologies, Inc. Applicant Add 15655 S. Mahaffie Street, Olathe KS 66062 Manufacturer Beijing Jia An Electronics Technology Co,.Ltd. Manufacturer Add No.19 GuCheng West Street,Shi Jing Shan District,Beijing 100043,CHINA 3 Test site information Lab performing tests SIEMIC (Nanjing-China) Laboratories Lab Address 2-1 Longcang Avenue Yuhua Economic and Technology Development Park, Nanjing, China FCC Test Site No. 986914 IC Test Site No. 4842B-1 Test Software Labview of SIEMIC version 1.0 Test Report No. 15020559-FCC-H1 Page 6 of 7 4 Equipment under Test (EUT) Information Description of EUT: 8 Button Remote Main Model: 2.4IQ58 Serial Model: N/A Date EUT received: June 15, 20145 Test Date(s): June 24 to June 29, 2015 Antenna Gain: 1 dBi Type of Modulation: O-QPSK RF Operating Frequency (ies): 2405-2480 MHz(TX/RX) Number of Channels: 16CH Port: N/A Input Power: DC 3V Trade Name : N/A FCC ID: ULP-24IQ58 Test Report No. 15020559-FCC-H1 Page 7 of 7 5 FCC §2.1093 - RF Exposure Standard Requirement: According to §15.247 (i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Routine SAR evaluation refers to that specifically required by § 2.1093, using measurements or computer simulation. When routine SAR evaluation is not required, portable transmitters with output power greater than the applicable low threshold require SAR evaluation to qualify for TCB approval. Test Result: Type Test mode CH Freq (MHz) Conducted Power (dBm) Tune Up Power (dBm) Output power 2.4G Low 2405 -17.165 -18.0±1 Mid 2440 -17.421 High 2480 -18.358 One antenna is available for the EUT. 2.4G Mode: The maximum output power(turn-up power) in low channel of 2.4G is -17.0 dBm=0.02 mW The calculation results= 0.02/5*√2.405= 0.006< 3 The maximum output power(turn-up power) in middle channel of 2.4G is -17.0 dBm=0.02mW The calculation results= 0.02/5*√2.440= 0.006< 3 The maximum output power(turn-up power) in high channel of 2.4G is -17.0 dBm=0.02 mW The calculation results=0.02/5*√2.480= 0.006< 3 Test Result: Pass

RF TEST REPORT Report No.: 15020559-FCC-R1 Supersede Report No.: N/A Applicant Interactive Technologies, Inc. Product Name 8 Button Remote Main Model 2.4IQ58 Test Standard FCC Part 15.247: 2014, ANSI C63.10: 2013 Test Date June 24 to July 20, 2015 Issue Date July 20, 2015 Test Result Pass Fail Equipment complied with the specification Equipment did not comply with the specification William Long Test Engineer Herve Idoko Checked By This test report may be reproduced in full only Test result presented in this test report is applicable to the tested sample only Issued by: SIEMIC (Nanjing-China) Laboratories 2-1 Longcang Avenue Yuhua Economic and Technology Development Park, Nanjing, China Tel:+86(25)86730128/86730129 Fax:+86(25)86730127 Email: [email protected] Test Report No. 15020559-FCC-R1 Page 2 of 34 Laboratories Introduction SIEMIC, headquartered in the heart of Silicon Valley, with superior facilities in US and Asia, is one of the leading independent testing and certification facilities providing customers with one-stop shop services for Compliance Testing and Global Certifications. In addition to testing and certification, SIEMIC provides initial design reviews and compliance management throughout a project. Our extensive experience with China, Asia Pacific, North America, European, and International compliance requirements, assures the fastest, most cost effective way to attain regulatory compliance for the global markets. Accreditations for Conformity Assessment Country/Region Scope USA EMC, RF/Wireless, SAR, Telecom Canada EMC, RF/Wireless, SAR, Telecom Taiwan EMC, RF, Telecom, SAR, Safety Hong Kong RF/Wireless, SAR, Telecom Australia EMC, RF, Telecom, SAR, Safety Korea EMI, EMS, RF, SAR, Telecom, Safety Japan EMI, RF/Wireless, SAR, Telecom Singapore EMC, RF, SAR, Telecom Europe EMC, RF, SAR, Telecom, Safety Test Report No. 15020559-FCC-R1 Page 3 of 34 This page has been left blank intentionally. Test Report No. 15020559-FCC-R1 Page 4 of 34 CONTENTS 1. REPORT REVISION HISTORY ....................................................................................................................................... 5 2. CUSTOMER INFORMATION ......................................................................................................................................... 5 3. TEST SITE INFORMATION ............................................................................................................................................ 5 4. EQUIPMENT UNDER TEST (EUT) INFORMATION ......................................................................................................... 6 5. TEST SUMMARY .......................................................................................................................................................... 7 6. MEASUREMENTS, EXAMINATION AND DERIVED RESULTS ........................................................................................ 8 6.1 RF EXPOSURE ................................................................................................................................................................ 8 6.2 ANTENNA REQUIREMENT ............................................................................................................................................... 9 6.3 DTS CHANNEL BANDWIDTH .......................................................................................................................................... 10 6.4 MAXIMUM OUTPUT POWER .......................................................................................................................................... 12 6.5 POWER SPECTRAL DENSITY ........................................................................................................................................ 14 6.6 BAND-EDGE & UNWANTED EMISSIONS INTO NON-RESTRICTED FREQUENCY BANDS ................................................ 16 6.7 AC POWER LINE CONDUCTED EMISSIONS ................................................................................................................... 18 6.8 RADIATED SPURIOUS EMISSIONS ................................................................................................................................ 19 ANNEX A. TEST INSTRUMENT ........................................................................................................................................... 23 ANNEX B. EUT AND TEST SETUP PHOTOGRAPHS ........................................................................................................... 24 ANNEX C. TEST SETUP AND SUPPORTING EQUIPMENT ................................................................................................... 30 ANNEX D. USER MANUAL / BLOCK DIAGRAM / SCHEMATICS / PARTLIST ........................................................................ 33 ANNEX E. DECLARATION OF SIMILARITY ......................................................................................................................... 34 Test Report No. 15020559-FCC-R1 Page 5 of 34 1. Report Revision History Report No. Report Version Description Issue Date 15020559-FCC-R1 NONE Original July 20, 2015 2. Customer information Applicant Name Interactive Technologies, Inc. Applicant Add 15655 S. Mahaffie Street, Olathe KS 66062 Manufacturer Beijing Jia An Electronics Technology Co,.Ltd. Manufacturer Add No.19 GuCheng West Street,Shi Jing Shan District,Beijing 100043,CHINA 3. Test site information Lab performing tests SIEMIC (Nanjing-China) Laboratories Lab Address 2-1 Longcang Avenue Yuhua Economic and Technology Development Park, Nanjing, China FCC Test Site No. 986914 IC Test Site No. 4842B-1 Test Software Labview of SIEMIC version 1.0 Test Report No. 15020559-FCC-R1 Page 6 of 34 4. Equipment under Test (EUT) Information Description of EUT: 8 Button Remote Main Model: 2.4IQ58 Serial Model: N/A Date EUT received: June 15, 2015 Test Date(s): June 24 to July 20, 2015 Conducted Power (dBm) -17.165dBm Antenna Gain…

Text truncated - open the document above for the full version.

Test Report No. 15020559-FCC-R1 Page 29 of 34 Annex B.iii. Photograph: Test Setup Photo Radiated Spurious Emissions Test Setup Below 1GHz Radiated Spurious Emissions Test Setup Below 1GHz
