UNK-FW02AIR PRESSURE TRANSMITTER

Air pressure transmitter (Starting Equipment) User’s Manual Version. 2.0(25.5.2010) THE YOKOHAMA RUBBER CO., LTD. INDUSTRIAL PRODUCTS TECHNICAL DEPARTMENT Notice: This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of this device. Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. 1 1. Introduction This manual covers the composition and the operation, boot and halt, of the air pressure transmitter (FW02). 2. Transmitter 2.1 Composition of the transmitter The air pressure transmitter consists of a battery section and an antenna section, and is covered with plastic. The features and the composition of the transmitter are shown in Fig 1. (a) Features (b) Composition Fig. 1 Features and composition of the transmitter 1V Transmitter MPU Matching Circuit Antenna HF Antenna (433MHz) RF signal X1X’tal (10MHz) GND HF Pressure Te m p e r a t ure Sensor 2 3. Operation 3.1 Staring equipment The air pressure transmitter is controlled by using the starting equipment as shown in Fig 2. (a) Feature of starting equipment (b) Operation panel of the starting equipment Fig 2 Starting equipment Boot Area Operation Panel 3 3.2 Boot & Halt Put the transmitter on the boot area of the starting equipment, and then boot up and halt the transmitter according to the procedure as below. FW02 FW02

FCC ID: UNK-FW02 Copyright ○ c 2010, LTA Co., Ltd. Page 1 of 4 FCC ID: UNK-FW02 Copyright ○ c 2010, LTA Co., Ltd. Page 2 of 4 FCC ID: UNK-FW02 Copyright ○ c 2010, LTA Co., Ltd. Page 3 of 4 FCC ID: UNK-FW02 Copyright ○ c 2010, LTA Co., Ltd. Page 4 of 4

FCC ID: UNK-FW02 Copyright Ⓒ 2010, LTA Co., Ltd. SAMPLE LABEL & LOCATION FCC ID:UNK-FW02 M/N: FW02 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Made in KOREA

FCC ID: UNK-FW02 Copyright ○ c 2010, LTA Co., Ltd. Page 1 of 1

Ref. No.: LR500191005E Copyright ○ c 2010, LTA Co., Ltd. Page 1 of 17 243 Jubug-Ri,Yangji-Myeon, Yongin-Si, Gyeonggi-Do, Korea 449-822 Tel: +82-31-323-6008 Fax: +82-31-323-6010 http://www.ltalab.com Dates of Tests: May 17 ~ 24, 2010 Test Report S/N: LR500191005E Test Site : LTA CO., LTD. CERTIFICATION OF COMPLIANCE FCC ID APPLICANT TEST REPORT FCC Classification : Part 15 Security/Remote Control Transmitter Manufacturing Description : Air pressure transmitter Manufacturer : Fuji Electric Systems Co., Ltd. Model name : FW02 Test Device Serial No.: : Identification FCC Rule Part(s) : FCC Part 15 Subpart C ; ANSI C-63.4-2003 Frequency Range : 433.25 MHz Data of issue : May 25, 2010 This test report is issued under the authority of: The test was supervised by: Kyung-Taek LEE, Technical Manager Hyun-Chae You, Test Engineer This test result only responds to the tested sample. It is not allowed to copy this report even partly without the allowance of the test laboratory. This report must not be used by the applicant to claim product endorsement by any agency. NVLAP LAB Code.: 200723-0 UNK-FW02 The Yokohama Rubber Company, Limited Ref. No.: LR500191005E Copyright ○ c 2010, LTA Co., Ltd. Page 2 of 17 TABLE OF CONTENTS 1. GENERAL INFORMATION’S -------------------------------------------------------------------------- 2. INFORMATION’S ABOUT TEST ITEM ------------------------------------------------------------- 3. TEST REPORT 3.1 SUMMARY OF TESTS ------------------------------------------------------------------------------ 4. Field Strength of Fundamental ------------------------------------------------------------------------------ 5. Spurious Emission -------------------------------------------------------------------------------------------- 6. Bandwidth of Operation Frequency ------------------------------------------------------------------------ 7. Limit of Transmission Time ---------------------------------------------------------------------------------- APPENDIX APPENDIX 1 TEST EQUIPMENT USED FOR TESTS ------------------------------------------ 3 4 5 6 11 13 14 16 Ref. No.: LR500191005E Copyright ○ c 2010, LTA Co., Ltd. Page 3 of 17 1. General information’s 1-1 Test Performed Company name : LTA Co., Ltd. Address : 243, Jubug-ri,Yangji-Myeon,Youngin-Si, Kyunggi-Do, Korea. 449-822 Web site : http://www.ltalab.com E-mail : [email protected] Telephone : +82-31-323-6008 Facsimile +82-31-323-6010 Quality control in the testing laboratory is implemented as per ISO/IEC 17025 which is the “General requirements for the competents of calibration and testing laboratory”. 1-2 Accredited agencies LTA Co., Ltd. is approved to perform EMC testing by the following agencies: Agency Country Accreditation No. Validity Reference NVLAP U.S.A 200723-0 2010-09-30 ECT accredited Lab. RRL KOREA KR0049 2011-06-20 EMC accredited Lab. FCC U.S.A 610755 2011-04-22 FCC filing VCCI JAPAN R2133, C2307 2011-06-21 VCCI registration IC CANADA IC5799 2012-05-14 IC filing Ref. No.: LR500191005E Copyright ○ c 2010, LTA Co., Ltd. Page 4 of 17 2. Information’s about test item 2-1 Client & Manufacturer Company name : The Yokohama Rubber Company, Limited Address : 2-1 Oiwake, Hiratsuka Kanagawa 254-8601, Japan Telephone : +81-463-35-9701 2-2 Equipment Under Test (EUT) Trade name : Air pressure transmitter Model name : FW02 Serial number : Identification Date of receipt : May 17, 2010 EUT condition : Pre-production, not damaged Frequency Range : 433.25 MHz RF Output Power : Below 70dBuV/m Type of Modulation : FSK Power Source : DC 3V by Battery 2-3 Tested frequency Frequency TX RX Low - - Mid 433.25 MHz - High - - Note: Measurements were performed top and bottom location in the frequency range of operation according to the section 15.31(m) 2-4 Ancillary Equipment Equipment Model No. Serial No. Manufacturer - - - - - - - - Ref. No.: LR500191005E Copyright ○ c 2010, LTA Co., Ltd. Page 5 of 17 3. Test Report 3.1 Summary of tests FCC Part Section(s) Parameter Status (note 1) FCC Part 15.231(e)/209(a) Radiated emission, Spurious Emission and Field Strength of Fundamental C FCC Part 15.231 c) Bandwidth of Operation frequency C FCC Part 15.231 a) Transmission Time C FCC Part 15.231 e) Limit of Transmission Time C Note 1: C=Complies NC=Not Complies NT=Not Tested NA=Not Applicable Note 2: The data in this test report are traceable to the national or international standards. A sample calculation: COR. F (correction factor)= Antenna factor + Cable loss- Amp.gain- Distance correction Emission Level= meter reading + COR.F Ref. No.: LR500191005E Copyright ○ c 2010, LTA Co., Ltd. Page 6 of 17 4. Field Strength of Fundamental 4.1 Test Setup The diagram below shows the test setup that is utilized to make the measurements for emission from 9kHz to 30MHz Emissions. The diagram below shows the test setup that is utilized to make the measurements for emission from 30MHz to 1GHz Emissions. Ref. No.: LR500191005E Copyright ○ c 2010, LTA Co., Ltd. Page 7 of 17 The diagram below shows the test setup that is utilized to make the measurements for emission from 1GHz to 18GHz Emissions. Ref. No.: LR500191005E Copyright ○ c 2010, LTA Co., Ltd. Page 8 of 17 4.2 Limit 4.2.1. Radiated emission limits, general requirements Except as provided elsewhere in this Subpart, the emissions from an intentional radiator shall not exceed the field strength levels specified in the following table: Frequency (MHz) Field Strength (microvolts/meter) Measurement Distance (meter) 0.009 – 0.490 2400/F(kHz)300 0.490 – 1.705 2400/F(kHz)30 1.705 – 30.0 30 30 30 -88 100**3 88 -216 150**3 216 - 960 200**3 Above 960 5003 ** Except as provided in paragraph (g), fundamental emissions from intentional radiators operating under this Section shall not be located in the frequency bands 54-72 MHz, 76-88 MHz, 174-216 MHz or 470-806 MHz. However, operation within these frequency bands is permitted under other sections of this Part, e.g., Sections 15.231 and 15.241 4.2.2. Periodic operation in the ba…

Text truncated - open the document above for the full version.

FCC ID: UNK-FW02 Copyright ○ c 2010, LTA Co., Ltd. Page 1 of 1 Radiated Emission
