* Please read this manual carefully before using * Caution :This product can be used only for 12V cigarette lighter socket power. Package Content Getting Started -1 Getting Started -2 Main Unit / Stereo cable / Additional fuse / User manual / Connector for iPod When you use SoundFly i with iPod & iPhone. 2. Turn on the radio and find a frequency that is not being used for broadcasting. Match the frequency of SoundFly i to your radio using up/down button. 3. Connect your iPod to SoundFly i by using the connector, then iPod is automa tically turned on and SoundFly i starts playing music from iPod. 4. Connect a portable audio device/music player to SoundFly i with stereo cable. 5. Turn on the audio device and press the play button. SoundFly i lets you listen to your portable audio devices such as iPod, MP3 player, CD player, portable DVD player & iPhone through any FM radio speaker. Safty precautions 1. This product should be used only for 12V cigarette lighter socket power. 2. Do not start your car being put a SoundFly i into the cigarette lighter socket because the fuse could be burnt out. 3. Operate the device while the car is stopped to avoid the car accident. 4. Do not expose it to direct sunshine. 5. Avoid using the device in strong magnetic field. 6. Do not subject the device to severe impact or dropping from high position. 7. Keep the device away from any liquids. 8. We are not responsible for the damages caused by misusing and repairing the device or battery replacement. 9. Pause SoundFly i when you stop the car or disconnect portable hard disk to avoid damage to SoundFly i or hard disk. Specifications Product Dimension Weight of the product Frequency range Input power Modulation USB Rated output power 63 * 31 * 18mm 50g 87.6 ~ 107.9MHz 12V Output power FM(F3E) 5V 500mA Conformity with FCC, CE, KCC - 7 - - 8 - Functions and Description -1 [Basic operation] ButtonPress with clicking Press & hold for about 2 sec. Play &Pause Display frequency & playing time Plays previous song Plays next song Moves to previous ALBUM Moves to next ALBUM Smart Scan Moves to previous / next frequency (intervals of 0.1MHz) MEM/SCAN MEM/SCAN Storing frequency Using stored frequency Stand by mode (power on/off) [Setting the frequency] 1. Press button. 2. Select frequency with , buttons. 3. Press button once again. 1. Press button, when you want to play or pause. 2. Move to previous or next song clicking , buttons, while music is palying. 3. Move to previous or next Album by pressing & holding , buttons for about 2 seconds while music is playing [Selecting the track and playback] Functions and Description -2 [Changing display mode] Press & hold button for about 2 seconds while music is playing, display mode is changed into 2 types as below. Press & hold , button for about 2 seconds, it moves to previous / next ALBUM. 1. Press MEM/SCAN button. 2. Press MEM/SCAN button again repeatedly until the memory address that you want is displayed. 3. Stop pressing the MEM/SCAN button, then it moves to selected frequency. Frequency Playing time [Moving to previous/next ALBUM] 1. Select the frequency you want by pressing button & , button. 2. Press MEM/SCAN button, then [-] is displayed on LCD as below. 3. Press , button, and select the desired memory address. 4. Press MEM/SCAN button to set the frequency, you can store up to 4 frequencies. [Storing frequencies] [Use of stored frequencies] Functions and Description -3 [iPod & iPhone Charging function] * SoundFly i can charge iPod & iPhone so that you can keep using your ipod & iPhone and It let you keep enjoying listening to music as much as you want. [ RDS Display ] * RDS stands for Radio Data System, it can display song information or musician’s name on the car stereo screen through ID3 tag of MP3 files. [ Adjusting Volume ] * Be noted that once you connect your ipod or iphone to SoundFly i to listen to music, you’re not able to adjust volume through your iPod & iphone. The volume is set at a defult level by itself. You can adjust volume by using your car radio volume up/down. [AUTO SCAN function] * SoundFly i has Auto scan & Auto follow-up function. SoundFly i detects the best signal and store them automatically. You do not need to match the frequency manually. FREQFREQ Functions of Remote control -1 Shuffle / IRP / All / NOR Move to next song Move to prevous song Move to previous frequency Move to next frequency Bookmarking Repeating the section between A and B [Detail operations] Please use the remote control after remove the protection sticker. [ Power on / off ] * Press button, you can power on and off SoundFly i . [ Selecting display mode] * Press button, display mode is changed into 2 types, frequency and playing time of music. Play & Pause Power on/off Fast rewind Fast forward Searching clear frequency Searching 4 of the clearest frequencies, and storing them seperately Move to previous ALBUM Frequency & playing time Move to next ALBUM Functions of Remote control -2 [ Selecting PLAY MODE ] * Press button, you can select PLAY MODE (NOR, 1RP, SHUFFLE,ALL) [ SMART SCAN ] * If you press button, then SoundFly i start searching FM band ranging from 87.6 MHz up to 107.9MHz to finds out 4 clearest frequencies. After it selects 4 clearest frequencies and store them automatically in 4 seperate memory address . [ SINGLE SCAN ] * If you press button, then SoundFly i detects the best signal automatically. Auto follow-up : Once SoundFly i finds out the best signal by SIGNLE SCAN, then Car radio automatically follows up and set the same frequency. [ Move to previous / next song ] * Press button to move previous song. * Press button to move next song. [ Fast forward & rewind ] * Press button to rewind as twice, quintuple and decuple. * Press button to play forward as 2×, 5×, 10×. [ Setting frequency ] * Press / button, frequency is moved to forward / back at 0.1MHz intervals. [ Quick move to stored frequency ] * Press button to move directly to stored frequency, and you can se…
