UQLWLX2007Wireless USB HUB reference design

WLX-2007 User Guide Document Number: E-PR-2006-0162 Version:0.3 Author: Jerod Meacham WLX-2007 For FCC Certification Testing © 2006 Staccato Communications, Inc. All rights reserved. Information provided in this document is provided in connection with Staccato products. All information contained in this document is subject to change without notice. Nothing in this document shall operate as an express or implied license or indemnity under the intel- lectual property rights of Staccato or third parties. Except as provided in Staccato’s Terms and Conditions of Sale for such products, Staccato assumes no liability whatsoever, and Staccato disclaims any express or implied warranty, relating to sale and/or use of Stac- cato products including liability or warranties relating for a particular purpose, merchantability, or infringement of any patent, copyright or other intellectual property right. Staccato’s products are not authorized for use in life-support or safety critical applications. Use in such applications is done at the sole discretion of the customer. Staccato will not warrant the use of its devices in such applications. While the information contained herein is believed to be accurate, such information is preliminary, and should not be relied upon for accuracy or completeness, and no representations or warranties of accuracy or completeness are made. THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROVIDED ON AN “AS IS” BASIS. In no event shall Staccato be liable for damages arising directly or indirectly from any use of the information contained in this document. All trademarks listed in this document are the property of their respective holders. Contact your Staccato sales representative to obtain the latest specifications before placing your product order. Staccato Communications, Inc. 6195 Lusk Boulevard, Suite 200 San Diego, CA 92121 Phone: 858.812.1000 Fax: 858.812.1001 www.staccatocommunications.com Regulatory Notices The device is compliant with 47 CFR 15.519(a)(1): "A UWB device operating under the provisions of this section shall transmit only when it is sending information to an associated receiver. The UWB intentional radiator shall cease transmission within 10 seconds unless it receives an acknowledgement from the associated receiver that its transmission is being received. An acknowledgement of reception must continue to be received by the UWB intentional radiator at least every 10 seconds or the UWB device must cease transmitting." Note: Any intentional or unintentional modifications not expressly approved by Staccato Communications or the FCC will void the warranty of the device and the authority of the user to operate the device. Revision History DateRevisionDescription 11/2/060.3Initial release. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. THIS DEVICE MUST BE INSTALLED IN A LOCATION THAT IS NOT ACCESSIBLE TO THE GENERAL PUBLIC. INSTALL THE DEVICE SO THAT THE ANTENNA IS MORE THAN 20 CM FROM UNSUSPECTING PERSONNEL. FAILURE TO INSTALL THIS DEVICE AS DESCRIBED WILL RESULT IN A FAILURE TO COMPLY WITH FCC RULES FOR RF EXPOSURE AND IS DISCOURAGED. ONLY ANTENNAS APPROVED WITH THE DEVICE MAY BE USED. THIS DEVICE MAY NOT BE CO- LOCATED WITH OTHER TRANSMITTERS WITHOUT FURTHER APPROVAL BY THE FCC. WLX-2007 User GuidePage i Doc. No. E-PR-2006-0162 v0.3Staccato Communications Contents 1.0Introduction ........................................................................................................... 1 1.1 Purpose........................................................................................................... 1 1.2 Intended Audience .......................................................................................... 1 1.3 Conventions .................................................................................................... 1 1.4 Document Structure and Use.......................................................................... 1 1.5 Technical Support ........................................................................................... 1 2.0Overview ................................................................................................................ 2 2.1 System Requirements..................................................................................... 3 3.0Installation ............................................................................................................. 4 3.1 Software Installation........................................................................................ 4 3.2 Hardware/Driver Installation............................................................................ 9 4.0Operation ............................................................................................................. 14 Acronyms and Definitions .................................................................................. 17 Document References ........................................................................................ 18 Contact Information ............................................................................................ 19 WLX-2007 User GuidePage ii Doc. No. E-PR-2006-0162 v0.3Staccato Communications List of Figures Figure 2-1 WLX-2007 .................................................................................................. 2 Figure 2-2 WLX-2007 Back ......................................................................................... 3 Figure 3-1 Staccato_FCC.exe ..................................................................................... 4 Figure 3-2 .Net Framework Installation ....................................................................... 4 Figure 3-3 .Net Framework Installation ......................................................…

Text truncated - open the document above for the full version.

Request for Confidentiality C S ommunications taccato 6195 Lusk Blvd, Suite 200 San Diego, CA 92121 858-812-1000 www.staccatocommunications.com Staccato Communications 6195 Lusk Blvd, Suite 200 San Diego, CA 92121 Chief, Authorizations Branch Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 November 3, 2006 Subject: Staccato Communications FCC certification application for WLX-2007 FCC ID: UQLWLX2007 To Whom It May Concern: Staccato Communications hereby requests that the following documents are to be held as confidential and not posted in any public forum. • Block Diagram • Schematic • Bill of Materials • Internal Photos of device These documents contain proprietary and confidential information. Thank you. Sincerely, Roberto Aiello Chief Technical Officer/Founder Staccato Communications

TDK Test Services Authorization C S ommunications taccato 6195 Lusk Blvd, Suite 200 San Diego, CA 92121 858-812-1000 www.staccatocommunications.com Staccato Communications 6195 Lusk Blvd, Suite 200 San Diego, CA 92121 Chief, Authorizations Branch Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 November 3, 2006 Subject: Authorization of TDK Test Services for Staccato Communications FCC ID: UQLWLX2007 To Whom It May Concern: Please be advised that TDK Test Services is authorized to act on behalf of Staccato Communications with regards to FCC submission and certification of the WLX-2007 Wireless Hub. Thank you. Sincerely, Roberto Aiello Chief Technical Officer/Founder Staccato Communications

Model: WLX-2007 FCC ID: UQLWLX2007

WLX-2007 Theory of Operation Document No. E-AP-2006-0161 v1.0 C S ommunications taccato 6195 Lusk Blvd, Suite 200 San Diego, CA 92121 858-812-1000 www.staccatocommunications.com WLX-2007 – Wireless 4-port hub based upon Certified Wireless USB From inception, California headquartered Staccato Communications has dedicated itself to the UWB market by driving global standards activities, creating industry momentum, and engaging in cutting-edge technological development. Staccato™ is recognized for being the leader in single-chip, all CMOS complete solutions based on the WiMedia Common Radio Platform for Certified Wireless USB. Staccato’s 110nm highly-integrated digital CMOS silicon includes RF, Digital Baseband, Media Access Controller (MAC), Memory, 32-bit RISC Processor, Encryption Engine and various I/O including USB 2.0 Host, USB 2.0 Device and SDIO 1.1 Device. Staccato is enabling the personal computer, consumer electronic and mobile device industries with high-speed wireless personal area network (WPAN) solutions optimized for cost, power consumption and form-factor. The WLX-2007 product incorporates Staccato’s Ripcord™ SC3500P series silicon with pin-out for Certified Wireless USB Device Wire Adapter (DWA) and has been built by Taiwanese-based Original Design Manufacturer (ODM) innovator Cameo Communications. This product is to be used with a Certified Wireless USB Host Wire Adapter (HWA) or native Host and enables legacy USB devices (such as printers, hard-disk drivers, digital still cameras, and personal media players) to be accessed wirelessly at data rates of up to 480Mbps, according to the specifications defined by the USB Implementers Forum. WLX-2007 is compliant to WiMedia PHY specification v1.1, and operates in the 3168-4752MHz spectrum. The SC3500P series silicon also supports Certified Wireless USB HWA products including external adapters and MiniCards that get embedded into notebooks. The spirit of wire adapters is to enable fast deployment of Certified Wireless USB by allowing minimal software/firmware modifications, primarily to the host PC; in fact, a DWA such as the WLX-2007 enables up to four legacy devices to be connected to a single unit without any software or firmware changes. Staccato’s numerous reference design kits include working hardware samples, schematics, PCB Gerber layout files, bill-of-materials, design guides, production test guides, HWA and DWA Windows XP drivers and utilities, and a sample end user manual in order to accelerate time to market. The reference designs are supplemented by Staccato’s UWB University and Team Staccato Partner Program. UWB University offers a free online educational review of the most relevant industry topics for engineers and business executives in the Certified Wireless USB, Bluetooth 3.0 and IP-over-UWB arenas. The Team Staccato partner program provides customers with total solutions through alliances with industry leaders throughout the value chain, including suppliers of UWB components, software, test equipment and services, and design services. Staccato’s Ripcord SC3500P series silicon transmits WiMedia UWB signals that have instantaneous bandwidth (BW) greater than 500MHz or fractional occupied BW greater than 20 percent as defined by the FCC Report and Order for UWB Communications. Band Group 1 is divided into 3 individual bands, each 528MHz wide, with center frequencies of 3432MHz, 3960MHz and 4488MHz. Staccato’s silicon transmits either by band switching between the 3 bands or remaining stationary in each band, known as TFI or FFI respectively. Staccato’s silicon occupies approximately 1584MHz while band switching in TFI mode (528MHz instantaneously) and the average transmitted power is approximately -9.3dBm (or - 14dBm when stationary operating in FFI mode). FCC Part 15 regulation in Subpart F, Section 15.517 and 15.519 specifies maximum average Equivalent Iso-tropically Radiated Power (EIRP) of – 41.3dBm (53.9dBuV/m) measured using a resolution bandwidth of 1MHz. EIRP in dBm coverts to a field strength, in dBuV/m at 3 meters, by adding 95.2dB. One hundred twenty two modulated Orthogonal Frequency Division Multiplexed (OFDM) sub-carriers comprise the 528MHz wide signal of each band.

All services undertaken are subject to the following general policy. Reports are submitted for exclusive use of the client to whom they are addressed. Their significance is subject to the adequacy and representative character of the samples and to the comprehensiveness of the tests, examinations or surveys made. This report shall not be reproduced except in full, without written consent of TDK R&D Corporation. This report must not be used to claim product endorsement by A2LA, NVLAP nor any other agency of the US Government. Compliance report of WLX2007 reference design Customer: Staccato Communications Date: November 10, 2006 TDK Report: TTS-TR-T111-101 Test performed by: TDK R&D Corporation 1101 Cypress Creek Rd Cedar Park, TX 78613 Technician Checked by Radiated 30 MHz to 40 GHz A. Medina K. Yata Conducted 150 KHz to 30 MHz A. Medina K. Yata AC conducted A. Medina K. Yata Report A. Medina K. Yata This document contains confidential information and cannot be disclosed outside of Staccato or any affiliated company in whole or in part without the express written permission of TDK R&D Corporation. Staccato Communications, WLX2007 reference design page 2 of 49 1. Executive Summary An EMC evaluation to determine compliance of the WLX2007 reference design with requirements of FCC 47 CFR Part 15, Subpart F Section 15.519 was conducted. All references are to the most current version of the Code of Federal Regulations 47 that are currently in effect. In accordance with §2.1033, the following data is presented in support of the Certification of the WLX2007 reference design. The client should retain a copy of this document on file for at least 5 years after the manufacturing of the product has been discontinued. Test Description FCC 47 CFR Section Compliance Operational Limitations 15.519(a) The client has been notified of these limitations. In normal operating mode the transmitter will only send data when associated with a receiver. See section 5 for detail UWB Bandwidth 15.519(b) Yes Radiated Emissions 15.519(c), 15.209 Yes Radiated Emissions in GPS Bands 15.519(d) Yes Peak Emissions within a 50 MHz Bandwidth 15.519(e) Yes Labelling Requirements 15.519(f) Yes Page 3 of 49 2. Task Description 2.1. Scope Reference FCC ET Docket No. 98-153, FCC 02-48 First R&O; FCC 47 CFR, Part 15, Subpart A; FCC 47 CFR, Part 15, Subpart B; FCC 47 CFR, Part 15, Subpart C; FCC 47 CFR, Part 15, Subpart F FCC ET Docket No. 04-352, Petition for Waiver of the Part 15 UWB Regulations Filed by MBOA-SIG (Adopted: March 10, 2005) Title Revision of Part 15 of the Commission’s Rules Regarding Ultra-Wideband Transmissions Systems; Code of Federal Regulations, Part 15 Subpart A: General Code of Federal Regulations, Part 15 Subpart B: Unintentional Radiators ode of Federal Regulations, Part 15 Subpart C: Intentional Radiators Code of Federal Regulations, Part 15 Subpart F: Ultra-Wideband Operation Purpose of Test To gain FCC Certification for technical requirements for Handheld UWB Systems operating between 3.1 GHz and 10.6 GHz. Test Procedures The tests were conducted in accordance with the following documents: FCC ET Docket 98-153, FCC 02-48 First R&O ANSI C63.4: 2001: Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz FCC Code of Federal Regulations 47, Part 15 Subpart A: General FCC ET Docket No. 04-352, Petition for Waiver of the Part 15 UWB Regulations Filed by MBOA-SIG (Adopted: March 10, 2005) General Procedures FCC Code of Federal Regulations 47, Part 2 Frequency Allocations and Radio Treaty Matter: General Rules and Regulations Classification of EUT Hand Held Ultra-Wideband System Page 4 of 49 2.2. Related Submittal(s)/Grant(s) None 2.3. Test Plan Reference Publication Year Title FCC 47 CFR, Part 15, Subpart A 10/2004 Code of Federal Regulations, Part 15 Subpart A: General FCC 47 CFR, Part 15, Subpart B 10/2004 Code of Federal Regulations, Part 15 Subpart B: Unintentional Radiators FCC 47 CFR, Part 15, Subpart C 10/2004 Code of Federal Regulations, Part 15 Subpart C: Intentional Radiators FCC 47 CFR, Part 15, Subpart F 10/2004 Code of Federal Regulations, Part 15 Subpart F: Ultra-Wideband Operation FCC ET Docket 98-153, FCC 02-48 First R&O 04/2002 Revision of Part 15 of the Commission’s Rules Regarding Ultra- Wideband Transmissions Systems: First Report & Order ANSI C63.4 01/2001 Methods of Measurement of Radio- Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz FCC ET Docket No. 04- 352 3/2005 Petition for Waiver of the Part 15 UWB Regulations Filed by MBOA-SIG 2.4. Client Information APPLICANT Name: Staccato Communications Address: 6195 Lusk Blvd., Suite 200, San Diego, CA 92121 Contact Person: Jerod Meacham MANUFACTURER Name: Staccato Communications Address: 6195 Lusk Blvd., Suite 200, San Diego, CA 92121 Contact Person: Jerod Meacham Page 5 of 49 2.5. Equipment Under Test (EUT) The following information (with the exception of the date information) has been supplied by the applicant. The test results in this report pertain only to the item tested. General Brand Name Ultra-Wideband reference design Product Name Ultra-Wideband reference design Model Name or Number WLX2007 Serial Number None Type of Equipment Wireless USB HUB Input Power Supply Type External power adaptor Classification Hand held Ultra-Wideband system Technical Power Supply Requirements AC main, 100 – 240 Vac, 47 – 63 Hz RF Output Rating -42 dBm EIRP @ 3 meters Operating Frequency Range 3100 MHz to 4800 MHz RF Output Impedance 50 Ω Channel Spacing N/A Pulse Width N/A Pulse Repetition Frequency N/A 10 dB Bandwidth >500 MHz Modulation/Constellation Multiband OFDM Oscillators’ Frequencies 12, 26, 66, 264, 528, 1056MHz EUT Ports 5V DC and USB Antenna Connector Type Internal Antenna Description Omni directional linear polarized planar Logistics EUT Receive Date October 31, 2006 EUT Receive Condition Good Test Start Date October…

Text truncated - open the document above for the full version.
