MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR ASN-700FCC-N, FCC ID: URK-ASNBTSLG2 RE: CONFIDENTIALITY REQUEST FOR ASN-800FCC-N, FCC ID: URK-ASNBTSLG2 To Whom It May Concern: This letter serves as an official request for confidentiality under FCC Rule Section 0.459. We have requested that the following documents required to be submitted with this application be withheld from public review. - Block diagram - Schematics diagram - Technical description of link products - Pictures of internal electronics PCB and RF boards of the product - Parts list and BOM of the product The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Please contact me if there is any information you may need. Sincerely, November 17 th , 2006 Ari Maunuksela Director of Product Management Airspan Networks (Finland) Oy Valkjärventie 7 C 02130 Espoo Finland Tel. +358-0-4392 1070 Fax +358-9-4126 762 [email protected]

MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize MET Laboratories, Inc. to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, November 17 th , 2006 Ari Maunuksela Director of Product Management Airspan Networks (Finland) Oy Valkjärventie 7 C 02130 Espoo Finland Tel. +358-0-4392 1070 Fax +358-9-4126 762 [email protected]

1 Jennifer Sanchez From: Jennifer Sanchez Sent: Wednesday, December 20, 2006 11:15 AM To: Liming Xu Cc: Joyce Holton; Amber Manganello; Shawn McMillen; Kevin Mehaffey; Marie Confroy; Tony Permsombut; Jennifer Sanchez Subject: RE: 20952 - Airspan Communications - METrak Mail From: Jennifer Sanchez Hi Liming, The report & MPE Calculation have been corrected to state the correct RF Power. Please refer to files EMCS20952-FCC247_rev1.pdf & 20952-MPE Calculation_Rev1.pdf. I have archived the original report and MPE calculation files. Please proceed with your Technical Review and let me know if you need any further information from me. Thanks! Jennifer Sanchez 408-213-2359 MET Laboratories, Santa Clara CA -----Original Message----- From: Liming Xu Sent: Tuesday, December 19, 2006 9:03 PM To: Jennifer Sanchez Cc: Joyce Holton; Amber Manganello; Shawn McMillen; Kevin Mehaffey; Marie Confroy; Jennifer Sanchez; Tony Permsombut Subject: RE: 20952 - Airspan Communications - METrak Mail From: Jennifer Sanchez Hi All, Please explain: In this FCC/TCB application, Conducted RF power is measured as 27.6 dBm (0.575 Watts) But in original grant (FCC ID: SWX-SR5) is 25.7 dBm (0.372 Watts) If this is true, you can not use the original grant (FCC ID:SWX-SR5) As a module approval for your application BR Liming -----Original Message----- From: Jennifer Sanchez [mailto:[email protected]] Sent: Tuesday, December 19, 2006 1:16 PM To: Liming Xu Cc: Joyce Holton; Amber Manganello; Shawn McMillen; Kevin Mehaffey; Marie Confroy; Jennifer Sanchez; Tony Permsombut Subject: 20952 - Airspan Communications - METrak Mail From: Jennifer Sanchez Importance: High Job Number: 20952 Model Desc: New Product with Ubiquiti SR5 Radio Customer Name: Airspan Communications Customer Code: AIR15 ----------------------------------------------------- Task Number: 322850 Task Description: FCC TCB Application Task Status: In Progress Hi Liming, Please accomplish technical review for the FCC TCB this project with the following information: 2 H:\METrak_Job_Folders\2006\A\Airspan Communications - AIR15\20952\TCB\Customer Info\FCC TCB Please keep in mind that our turn around time for technical review is twenty-four to forty-eight hours. Let me know if I should provide you anything else, or if there may be any delays you may foresee in reviewing. Thanks! Best Regards, Jennifer Sanchez TCB Administrator/Technical Writer MET Laboratories Santa Clara, CA 408-213-2359 http://www.metlabs.com

AirSpan Networks Model ASN-700FCC-N External Photographs AirSpan Networks Model ASN-700FCC-N AirSpan Networks Model ASN-700FCC-N AirSpan Networks Model ASN-700FCC-N

AirSpan Networks Model ASN-800FCC-N External Photographs AirSpan Networks Model ASN-800FCC-N AirSpan Networks Model ASN-800FCC-N AirSpan Networks Model ASN-800FCC-N

Copyright © Airspan Networks. 2006 FlexNET product labels and locations 2 1 Label 1: barcode xxxxxxxxxxxxxxxxxxxxxxx FCC ID: URK-ASNBTSLG2 IC Canada: 4548D-ASNBTSLG Model: ASN-700FCC-N 5.725 – 5.850 GHz HW type: ASN-GTT1 HW revision: 1.0.0 Input: 12...24 VDC, max. 33W Designed in Finland Airspan Networks (Finland) Label 2: Integrated antenna: Frequency range: 5.725-5.850 GHz Polarization: Vertical Gain: 23dBi Beam width: 10 deg Page 1 of 2 Copyright © Airspan Networks. 2006 FlexNET product labels and locations 3 Label 3: This device complies with part 15 of FCC Rules. Operation is subjected to the following conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received including interference that cause undesired operation. 3. Warning! Electromagnetic radiation. Please keep this device at a distance 20 cm from human body Page 2 of 2

AirSpan Networks Models: ASN-700FCC-N & ASN-800FCC-N MPE CALCULATION MPE Limit Calculation: EUT’s operating frequencies @ 5725 - 5850 MHz ; highest conducted power = 24.7dBm (peak) therefore, Limit for Uncontrolled exposure: 1 mW/cm 2 or 10 W/m 2 Power Density Determination: S = PG / 4πR 2 or R = √(PG / 4πS) where, S = Power Density (1 mW/cm 2 ) P = Linear Power Input to antenna G = Numerical Antenna Gain R = Radius Model 800 Antenna Model Gain (dBi) Power Density @ 20cm or Distance to meet limit ARC Wireless Solutions (Parabolic) 30 153.3cm separation distance required for 1 mW/cm 2 PlainAir HiperLink (15 0 Sector) 22 61.0cm separation distance required for 1 mW/cm 2 PlainAir HiperAccess (90 0 Sector) 14 24.3cm separation distance required for 1 mW/cm 2 MTI Wireless Edge (60 0 Sector) 17 34.3cm separation distance required for 1 mW/cm 2 MTI Wireless Edge (120 0 Sector) 15 27.2cm separation distance required for 1 mW/cm 2 MTI Wireless Edge (Omni) 9 0.46 mW/cm 2 @ 20cm separation distance Model 700 Antenna Model Gain (dBi) Power Density @ 20cm or Distance to meet limit ARC Wireless Solutions (Panel) 23 68.5cm separation distance required for 1 mW/cm 2

MET Laboratories, Inc. Safety Certification - EMI - Telecom Environmental Simulation 33439 WESTERN AVENUE ! UNION CITY, CALIFORNIA 94587 ! PHONE (510) 489-6300 ! FAX (510) 489-6372 The Nation’s First Licensed Nationally Recognized Testing Laboratory December 14, 2006 Airspan Networks (Finland) Oy Valkjärventie 7 C 02130 Espoo Finland Dear Ari Maunuksela, Enclosed is the EMC test report for compliance testing of the Airspan Networks (Finland) Oy, ASN-700FCC-N & ASN-800FCC-N as tested to the requirements of Title 47 of the CFR, Ch. 1 (10-1-03 ed.), Part 15, Subpart B for a Class A Digital Device and Subpart C for Intentional Radiators. Thank you for using the services of MET Laboratories, Inc. If you have any questions regarding these results or if MET can be of further service to you, please feel free to contact me. Sincerely yours, MET LABORATORIES, INC. Jennifer Sanchez Documentation Department Reference: (\Airspan Networks (Finland) Oy\EMCS20952-FCC247) Certificates and reports shall not be reproduced except in full, without the written permission of MET Laboratories, Inc. While use of the National Voluntary Laboratory Accreditation Program (NVLAP) letters or the NVLAP Logo, the Standards Council of Canada Logo, or the Nationally Recognized Testing Laboratory (NRTL) Letters in this report reflects MET Accreditation under these programs, these letters, logo, or statements do not claim product endorsement by NVLAP or any Agency of the U.S. Government. This letter of transmittal is not a part of the attached report. Electromagnetic Compatibility Airspan Networks (Finland) Oy Cover Page ASN-700FCC-N & ASN-800FCC-N CFR Title 47, Part 15, Subpart B & C MET Report: EMCS20952-FCC247 © 2007, MET Laboratories, Inc. Page ii of viii Electromagnetic Compatibility Criteria Test Report For the Airspan Networks (Finland) Oy Models ASN-700FCC-N & ASN-800FCC-N Verified under The FCC Certification Rules Contained in Title 47 of the CFR, Part 15 Subpart B & Part 15.247, Subpart C For Intentional Radiators MET Report: EMCS20952-FCC247 December 14, 2006 Prepared For: Airspan Networks (Finland) Oy C Valkjärventie 7 C 02130 Espoo Finland Prepared By: MET Laboratories, Inc. 4855 Patrick Henry Dr., Building 6 Santa Clara, CA 95054 Electromagnetic Compatibility Airspan Networks (Finland) Oy Cover Page ASN-700FCC-N & ASN-800FCC-N CFR Title 47, Part 15, Subpart B & C MET Report: EMCS20952-FCC247 © 2007, MET Laboratories, Inc. Page iii of viii Electromagnetic Compatibility Criteria Test Report For the Airspan Networks (Finland) Oy Models ASN-700FCC-N & ASN-800FCC-N Tested Under The FCC Certification Rules contained in Title 47 of the CFR, Part 15 Subpart B and Part 15.247, Subpart C For Intentional Radiators Shawn McMillen, Project Engineer Jennifer Sanchez Electromagnetic Compatibility Lab Documentation Department Engineering Statement: The measurements shown in this report were made in accordance with the procedures indicated, and the emissions from this equipment were found to be within the limits applicable. I assume full responsibility for the accuracy and completeness of these measurements, and for the qualifications of all persons taking them. It is further stated that upon the basis of the measurements made, the equipment tested is capable of operation in accordance with the requirements of Part 15 Subpart B and Part 15.247 Subpart C, of the FCC Rules under normal use and maintenance. Tony Permsombut, Manager Electromagnetic Compatibility Lab Electromagnetic Compatibility Airspan Networks (Finland) Oy Report Status ASN-700FCC-N & ASN-800FCC-N CFR Title 47, Part 15, Subpart B & C MET Report: EMCS20952-FCC247 © 2007, MET Laboratories, Inc. Page iv of viii Report Status Sheet Revision Report Date Reason for Revision ∅ December 14, 2006 Initial Issue. Electromagnetic Compatibility Airspan Networks (Finland) Oy Table of Contents ASN-700FCC-N & ASN-800FCC-N CFR Title 47, Part 15, Subpart B & C MET Report: EMCS20952-FCC247 © 2007, MET Laboratories, Inc. Page v of viii Table of Contents I. Executive Summary .................................................................................................................................................1 A. Purpose of Test ...................................................................................................................................................2 B. Executive Summary ............................................................................................................................................2 II. Equipment Configuration .......................................................................................................................................3 A. Overview.............................................................................................................................................................4 B. References...........................................................................................................................................................5 C. Test Site ..............................................................................................................................................................5 D. Description of Test Sample.................................................................................................................................6 E. Equipment Configuration..................................................................................................................................13 F. Support Equipment ...........................................................................................................................................13 G. Ports and Cabling Information ..........................................................................................................................14 H. Mode of Operation.................................................................................................................................…

Text truncated - open the document above for the full version.

AirSpan Networks Models: ASN-700FCC-N & ASN-800FCC-N TEST SETUP PHOTOGRAPHS ARC Wireless Parabolic Antenna AirSpan Networks Models: ASN-700FCC-N & ASN-800FCC-N MT-482016-N Antenna AirSpan Networks Models: ASN-700FCC-N & ASN-800FCC-N MT-484033-NV Antenna AirSpan Networks Models: ASN-700FCC-N & ASN-800FCC-N MT-484034-NV Antenna AirSpan Networks Models: ASN-700FCC-N & ASN-800FCC-N PlanAir HiperAccess 90 deg Antenna AirSpan Networks Models: ASN-700FCC-N & ASN-800FCC-N PlanAir HiperLink 15 deg Antenna
