UTT2715Pitchback

Franklin Pitchback Operating Instructions (for FCC approval process) 10/31/06 Power Unit Battery Installation 1. On the power unit, unscrew the battery door to access the battery compartment 2. Insert 8 'D' size batteries. Follow the polarity indications inside the compartment and be sure to install batteries as indicated. 3. Replace battery door and tighten the screw. NOTE: A DC jack is located on the main power unit for operating the unit with optional DC adapter. Remote Control Battery Installation 1. Unscrew the screw on the back of the remote . 2. Placing a coin between the slot provided on the side of remote control and twist to open the remote control. 3. Insert 3 pieces of CR-2016 battery. Remote Control Synchronization 1. The frequency between main unit and remote controller has been synchronized at the factory. However, if the remote does not work properly, please perform the following: 2. Install fresh batteries in the remote and power unit. 3. Press the Power button on the main unit so it is ON. The LED indicator will light. 4. PRESS and HOLD both Manual Up & Down buttons on the power unit simultaneously. While holding those buttons, PRESS either the Manual Up or Down button on the remote controller. 5. Release all buttons. 6. This procedure should synchronize the remote and the power unit. Operating the Unit NOTE: The unit can be operated either with the control buttons located on the side of the power unit or with the remote control. 1. Press the On/Off Power button on the power unit once. The LED indicator will light. 2. Press either Manual Up or Down button. The unit will move up, or down in 5 pre-programmed sections. 3. NOTE: The unit is equipped with an eight hour auto shut off timer; the unit will shut off automatically after eight hours in standby mode to conserve battery life. Auto/Random Mode 1. If the Auto/Random Mode button is pressed, the unit will automatically move up and down at random intervals approximately every 15 seconds. To stop the Auto/Random mode, press the Auto/Random button again. NOTE: The unit has a power save feature that automatically stops the Auto/Random mode after one hour of play and goes into standby mode. Simply press the Auto/Random button on the power unit or on the remote control if you wish to continue to use Auto/Random Mode. Operating the Unit with Remote Controller Press the On/Off Power button on the power unit once. The LED indicator will light. Using the remote, press either Manual Up or Down buttons on the remote to control to adjust the angle of the pitchback manually. Press the Auto/Random button on the remote control once to activate the Auto/Random mode. To stop the Auto/Random mode, press the Auto/Random button again. NOTE: When finished playing, remember to turn off the main unit by pressing the On/Off Power button on the main unit. User manual: Transmitter part: This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ---Reorient or relocate the receiving antenna. ---Increase the separation between the equipment and receiver. ---Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ---Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation.

ABBA ELECTRONICS CO., LTD _ FLAT C, 4th FLOOR, BLOCK 1, CAMELPAINT BUILDING, 62 HOI YUEN RD., KWUN TONG, KOWLOON, HK Date: 5 January 2007 Compliance Certification Services Certification Division 561F Monterey Road Morgan Hill, CA 95037 To whom it may concern: We, the undersigned, hereby authorize the Shenzhen office of Compliance Engineering Services, Inc., d.b.a. Compliance Certification Services and hereafter referred to as CCS SZ, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by CCS SZ on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing CCS SZ as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us.

ABBA ELECTRONICS CO., LTD _ FLAT C, 4th FLOOR, BLOCK 1, CAMELPAINT BUILDING, 62 HOI YUEN RD., KWUN TONG, KOWLOON, HK Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: UTT2715 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Theory of Operation Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market.

CHECKED APPROVED MODEL No. DRAWING No. REVISION SHEET OF 2 2 DRAWN DATE DATE DATE FR-001(FRANKLIN) FR001-UFCC-061114-01(PITCHBACK) AARONE ENGINEERING PRODUCTS CO.LTD (R&D) FOR CLIENT SIGN OFF FOR PRE-PRO SAMPLE FOR PMC MODEL #.: 2715 FCC ID:UTT2715 DC: CR2016 BATTERIES x 3 MADE IN CHINA FRANKLIN

Compliance Certification Services (Shenzhen) Inc. Report No: SZ061211B02-RP FCC ID: UTT2715 Date of Issue: December 27, 2006 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 Total Page: 1 Rev. 00 FCC 47 CFR PART 15 SUBPART C TEST REPORT For pitchback Model: FR-001, 2715 Trade Name: Franklin Sports Prepared for ABBA ELECTRONICS CO. LTD FLAT C, 4 TH FLOOR, BLOCK 1, CAMELPAINT BUILDING, 62 HOI YUEN ROAD, KWUN TONG, KOWLOON, HONG KONG Prepared by COMPLIANCE CERTIFICATION SERVICES (SHENZHEN) INC. NO. 5, JINAO INDUSTRIAL PARK, NO. 35 JUKENG ROAD, DASHUIKENG VILLAGE, GUANLAN TOWN, BAOAN DISTRICT, SHENZHEN, CHINA TEL: 86-755-28055000 FAX: 86-755-28055221 LAB CODE:200577-0 Compliance Certification Services (Shenzhen) Inc. Report No: SZ061211B02-RP FCC ID: UTT2715 Date of Issue: December 27, 2006 Page 2 Rev. 00 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION............................................................................................. 3 2. EUT DESCRIPTION .................................................................................................................... 4 3. TEST METHODOLOGY ............................................................................................................. 5 3.1 EUT CONFIGURATION .............................................................................................................. 5 3.2 EUT EXERCISE......................................................................................................................... 5 3.3 GENERAL TEST PROCEDURES .................................................................................................. 5 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS ............................................. 6 3.5 DESCRIPTION OF TEST MODES................................................................................................. 6 4. INSTRUMENT CALIBRATION................................................................................................. 7 5. FACILITIES AND ACCREDITATIONS ................................................................................... 8 5.1 FACILITIES .............................................................................................................................. 8 5.2 EQUIPMENT............................................................................................................................. 8 5.3 LABORATORY ACCREDITATIONS AND LISTING....................................................................... 8 6. SETUP OF EQUIPMENT UNDER TEST .................................................................................. 9 6.1 SETUP CONFIGURATION OF EUT.............................................................................................. 9 6.2 SUPPORT EQUIPMENT .............................................................................................................. 9 7. FCC PART 15.231 REQUIREMENTS...................................................................................... 10 7.1 20 DB BANDWIDTH .......................................................................................................... 10 7.2 LIMIT OF TRANSMISSION TIME.............................................................................................. 12 7.3 DUTY CYCLE..................................................................................................................... 14 7.4 RADIATED EMISSIONS ........................................................................................................... 18 7.5 POWERLINE CONDUCTED EMISSIONS.................................................................................... 23 Compliance Certification Services (Shenzhen) Inc. Report No: SZ061211B02-RP FCC ID: UTT2715 Date of Issue: December 27, 2006 Page 3 Rev. 00 1. TEST RESULT CERTIFICATION Applicant: ABBA ELECTRONICS CO. LTD FLAT C, 4TH FLOOR, BLOCK 1, CAMELPAINT BUILDING, 62 HOI YUEN ROAD, KWUN TONG, KOWLOON, HONG KONG Equipment Under Test: pitchback Tra d e N a m e: Franklin Sports Model: FR-001, 2715 Date of Test: December 11-27, 2006 APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C No non-compliance noted We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.207, 15.209 and Part 15.231. The test results of this report relate only to the tested sample identified in this report. Approved by: Tested By: Henry Ding Reviewed By : Clinton Kao/ Manager Eric Wong / Assistant manager COMPLIANCE CERTIFICATION COMPLIANCE CERTIFICATION SERVICES (SHENZHEN) INC. SERVICES (SHENZHEN) INC. Compliance Certification Services (Shenzhen) Inc. Report No: SZ061211B02-RP FCC ID: UTT2715 Date of Issue: December 27, 2006 Page 4 Rev. 00 2. EUT DESCRIPTION Product pitchback Tra d e N a m e Franklin Sports Model Number FR-001, 2715 Model Difference All the models are identical in electronic level, different model designation applies due to marketing purpose. Power Supply DC 9V powered by lithium battery Frequency Range 315 MHz Antenna Designation PCB Antenna Remark: This submittal(s) (test report) is intended for FCC ID: UTT2715 filing to comply with Section 15.207, 15.209 and 15.231 of the FCC Part 15, Subpart C Rules. Compliance Certification Services (Shenzhen) Inc. Report No: SZ061211B02-RP FCC ID: UTT2715 Date of Issue: December 27, 2006 Page 5 Rev. 00 3. TEST METHODOLOGY The tests documented in this report were performed in acco…

Text truncated - open the document above for the full version.

Compliance Certification Services (Shenzhen) Inc. Report No: SZ061211B02-RP FCC ID: UTT2715 Date of Issue: December 27, 2006 Page 24 Rev. 00 APPENDIX 1 PHOTOGRAPHS OF TEST SETUP Radiated Emission Set up Photos
