Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
WaveNet Radio Network 3065 Published January 2007 WaveNet Radio Network 3065 Page 2 1.0 Important Information ................................................................... 4 2.0 Introduction ................................................................................... 5 3.0 Transmission media...................................................................... 5 4.0 Usable radio wavelengths............................................................ 6 5.0 What are the factors to be aware of? .......................................... 6 6.0 Secure message transmission..................................................... 7 7.0 WaveNet System 3065 Network components ............................. 7 7.1 Computers ............................................................................................. 8 7.2 Router Nodes (general) ........................................................................ 8 7.3 Router Nodes (special versions) ......................................................... 9 7.4 Lock Nodes .......................................................................................... 11 8.0 Network structure........................................................................ 13 9.0 Security ........................................................................................ 15 9.1 Secure communication between the WaveNet network nodes ..... 15 9.2 Automatic testing of individual system components ..................... 15 9.3 Alarms .................................................................................................. 15 10.0 Battery warning ........................................................................... 15 9.1. Changing the Lock Node batteries.................................................... 15 WaveNet Radio Network 3065 Page 3 11.0 Installing WaveNet Lock Nodes................................................. 16 12.0 Technical specifications............................................................. 16 12.1 WaveNet power supply....................................................................... 16 12.2 WaveNet Central Node RS232 connection cable............................. 16 12.3 WaveNet Central Node with integrated RS485 port ........................ 17 12.4 WaveNet Central Node with 915 MHz radio module ........................ 17 12.5 WaveNet Router Node as RS 485 Repeater...................................... 18 12.6 WaveNet Router Node as 915 MHz Repeater ................................... 19 12.7 WaveNet Router Node with RS 485 / 915 MHz Converter ............... 19 12.8 WaveNet Router Node with 915 MHz / RS-485 Converter ............... 20 12.9 WaveNet Lock Node............................................................................ 20 © Copyright 2007 SimonsVoss Technologies, Inc. All rights reserved This work contains information supplied by SimonsVoss Technologies, Inc., and all such information is supplied without liability for errors or omissions. No part may be reproduced or used except with the express written permission of SimonsVoss Technologies, Inc.. The copyright and the aforementioned restriction on reproduction and use extend to all media in which the information may be used. WaveNet Radio Network 3065 Page 4 1.0 Important Information Safety remark: Caution! – Incorrect handling of the batteries and storage batteries used in this product can result in the risk of fire or burns. Do not charge, open or burn these batteries or heat them to more than 100 °C (212 °F). Installation of a SimonsVoss RF Lock requires knowledge in the areas of door mechanics, door certifications, installation of electronics and the use of the SimonsVoss software. For this reason, only trained and authorized personnel should install the unit. Compliance Statement (Part 15.19) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Warning (Part 15.21) Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC Interference Statement (Part 15.105 (b)) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Industry Canada Statement per Section 4.0 of RSP-100 The term "IC:" before the certification / registration number only signifies that the Industry Canada technical specifications were met. Section 7.1.5 of RSS-GEN Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. SimonsVoss Technologies Inc. will not accept any liability for damages caused by incorrect installation. WaveNet Radio Network 3065 Page 5 2.0 Introduction In this document, the components of the Sy…
Text truncated - open the document above for the full version.
10125 South 52 nd Street Franklin WI 53132 Toll Free: 866.785.6259 Phone: 414.421.2481 FAX: 414.421.2496 www.simons-voss.us Date: January 11, 2007 Time: 11:00 To: FCC Authorization & Evaluation Division 7435 Oakland Mills Road Columbia, MD 21045-0429 From: Warren Simonsen Phone: 414-855-1076 VP Marketing and Operations Fax: 414-421-2496 Applicant: SimonsVoss Technologies, Inc. E-Mail: [email protected] ____________________________________________________________________________________ Subject: Request for Non disclosure for FCC ID: UUC-05. To Whom It May Concern: Pursuant to 47 CFR Section 0.459, SimonsVoss Technologies, Inc. hereby requests non disclosure and confidential treatment of the following materials submitted in support of FCC certification application for FCC ID # UUC-05 a. Schematic Diagrams b. Operational Description c. Block Diagram Above materials contain trade secrets, proprietary and technical information which would customarily be guarded from competitors and those seeking to compromise the security of the system under 47 CFR section 0.457(d)(2). Disclosure or publication of any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors and may assist those seeking to compromise the security of the system. SimonsVoss Technologies, Inc understands that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before, during and after the date of the grant. Sincerely yours, By: Warren Simonsen Title: VP Marketing and Operations SimonsVoss Technologies, Inc.
10125 South 52 nd Street Franklin WI 53132 Toll Free: 866.785.6259 Phone: 414.421.2481 FAX: 414.421.2496 www.simons-voss.us FCC A U T H O R I Z A T I O N Date: January 25, 2007 Time: 10:00 am To: FCC Authorization & Evaluation Division 7435 Oakland Mills Road Columbia, MD 21045-0429 From: Warren Simonsen Phone: 414-855-1076 VP Marketing and Operations Fax: 414-421-2481 Applicant: SimonsVoss Technologies, Inc. E-Mail: [email protected] ______________________________________________________________________________________ Dear Ladies and/or Gentlemen: I appoint Kenneth L. Boston, James Blaha and Teresa White of LS Research, LLC, to act as an agent in the preparation of applications under Part 15 of the rules and regulations of the Federal Communications Commission. I certify that the exhibitions properly describe the device being submitted under this application and will implement any changes described in the test report. The labels described will be affixed to each item. The following statement is required by the Federal Communications Commission: By checking Yes, the applicant certifies that, in the case of an individual applicant, he or she is not subject to a denial of federal benefits, that included FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C 853(a), or, in the case of a non-individual applicant (e.g. corporation, partnership, or other unincorporated association), no party to the application is subject to a denial of federal benefits, that includes FCC benefits, pursuant to that section. ___X___Yes _______No By: Warren Simonsen Title: VP Marketing and Operations SimonsVoss Technologies, Inc.
10125 South 52 nd Street Franklin WI 53132 Toll Free: 866.785.6259 Phone: 414.421.2481 FAX: 414.421.2496 www.simons-voss.us March 14, 2007 Teresa White LS Compliance W66 N220 Commerce Ct. Cedarburg, WI 53012 RE: FCC ID UUC-05 certification request Dear Ms. White, The SimonsVoss WaveNet network system is a wireless network designed to allow a personal computer to configure, monitor, and control a system of electronic locks produced by SimonsVoss Technologies. Starting at the lock, the Lock Node routes messages from the lock either directly to a central node or through a series of routers to the central node. The routers may just repeat the signal (to achieve greater distances) or convert the signal to other media (from 915 MHz to RS485). The Central Node then communicates to the personal computer through RS-232 or TCP/IP protocols. Each node in the WaveNet network, including the Lock Node, Routers, and Central Node must be programmed with its proper address and frequency at our factory before installation. This means that an installing dealer must conduct a site survey, prepare the proper installation plan, and convey this to the factory with the purchase order. The system is then shipped to the installing dealer for installation. SimonsVoss will sell the WaveNet network only to qualified dealers and integrators. SimonsVoss does not sell any products direct to end users. The second paragraph of section 1.0 of the WaveNet manual reads “Installation of a SimonsVoss RF Lock requires knowledge in the areas of door mechanics, door certifications, installation of electronics and the use of the SimonsVoss software. For this reason, only trained and authorized personnel should install the unit.” I trust that this answers the question about installation, but feel free to contact me if there are any remaining questions. Best regards, Warren Simonsen VP Marketing and Operations SimonsVoss Technologies, Inc.
SimonsVoss Router FCC ID#: UUC-05 Photo One – External Bottom View, Showing FCC ID Label SimonsVoss Router FCC ID#: UUC-05 Photo Two – External Close-Up of FCC ID Label SimonsVoss Router FCC ID#: UUC-05 Photo Three – External Side View SimonsVoss Router FCC ID#: UUC-05 Photo Four – External Top View of Router SimonsVoss Router FCC ID#: UUC-05 Photo Five – External View of Connection
Technical Datasheet PE 231 Product Description Labels for thermal transfer printers Material Foil Polyester foil, surface printable Thickness: 0.05 mm Color: white matt Adhesive: Heat-stabilized acrylate adhesive Suitable for food-related applications Adhesive Force Measurements made following 72 hours of contact High-grade steel 605 N/m Acrylic 495 N/m Glass 550 N/m Temperature Range When applying: +10 °C to +40 °C After application: -40 °C to +150 °C Stability Excellent ruggedness against solvent, water, humidity, oil alcohol, household cleaner and industrial chemicals. Characteristics Excellent ruggedness against abrasion, heat and aging; not shrinking, stable under UV light, electrically conductive. Electrical Dielectric strength 3.8 kV/m Characteristics Surface resistance 3.2 x 10 14 Ohm Printability Thermal transfer printers Smear Resistance Resistant to water, oil and gasoline Specification For interior and exterior application, UL listed MH 16635 Shelf-Life 2 years with 23 °C and 50% relative humidity; without direct exposure to the sun Tyco Electronics idento GmbH Paul-Ehrlich-Strasse 23 D-63322 Rodermark Tel: 06074 / 8908-0
SimonsVoss Router FCC ID#: UUC-05 Photo One – Internal Open for Inspection I SimonsVoss Router FCC ID#: UUC-05 Photo Two – Internal Back of RF Board SimonsVoss Router FCC ID#: UUC-05 Photo Three – Internal Open for Inspection II SimonsVoss Router FCC ID#: UUC-05 Photo Four – Internal Close-Up of Backside – RF Board SimonsVoss Router FCC ID#: UUC-05 Photo Five – Internal RF Section SimonsVoss Router FCC ID#: UUC-05 Photo Six – Internal Close-Up of RF Section SimonsVoss Router FCC ID#: UUC-05 Photo Seven – Internal RF Section - Shielded SimonsVoss Router FCC ID#: UUC-05 Photo Eight – Internal Bottom View of RF Board SimonsVoss Router FCC ID#: UUC-05 Photo Nine – Internal Close-Up of RF Section – Shield Removed
Antennas • Locknode antenna is a PCB antenna designed for the frequency bands 868MHz .. 870 MHz and 902 MHz .. 928 MHz. It max. gain is about – 15 dBi. • Routernodes and Centralnodes use a „Whip Antenna“ (1/4-wavelength), which has the following characteristics: Impedance: 50 Ohm VSWR: 1.5 max. at Resonance Gain: 0 dBi max. Radiation: Omni Polarisation: Vertical Connector: SMA Male Total Length: 104 mm Antenna Cover: TPEE
Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Note: The test data of this report is related only to the individual item which has been tested. This report shall not be reproduced except in full extent without the written approval of the testing laboratory. Test Report No. 51971-060823-1 (Edition 1) Page 1 of 41 Pages Straubing, 07 December 2006 T E S T - R E P O R T No. 51971-060823-1 (Edition 1) for WaveNET Router Node Transceiver for Electronic Lock Applicant: SimonsVoss Technologies AG Test Specifications: FCC Code of Federal Regulations, CFR 47, Part 15, Sections 15.107, 15.109, 15.205, 15.207, 15.215 and 15.249 Industry Canada Radio Standards Specifications RSS-Gen Issue 1, Sections 7.2.2, 7.2.3 and RSS-210 Issue 6, Sections 2.2, A2.9 (Category I Equipment) Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 51971-060823-1 (Edition 1) Page 2 of 41 Pages Table of Contents 1 Description of the Equipment Under Test (EUT) ........................................................ 3 2 Administrative Data..................................................................................................... 4 3 Identification of the Test Laboratory ........................................................................... 5 4 Summary .................................................................................................................... 6 5 Operation Mode and Configuration of EUT................................................................. 7 6 Measurement Procedures........................................................................................... 8 6.1 Conducted Output Power ..................................................................................... 8 6.2 Bandwidth Measurements .................................................................................. 10 6.3 Conducted AC Powerline Emission .................................................................... 12 6.4 Radiated Emission in Fully or Semi Anechoic Room.......................................... 14 6.5 Radiated Emission at Open Field Test Site........................................................ 16 7 Photographs Taken During Testing .......................................................................... 17 8 Test Results for Transmitter ..................................................................................... 22 8.1 Conducted Output Power ................................................................................... 24 8.2 Occupied Bandwidth........................................................................................... 25 8.3 Bandwidth of the Emission ................................................................................. 29 8.4 Designation of Emissions ................................................................................... 31 8.5 Restricted Bands of Operation ........................................................................... 32 8.6 Conducted Powerline Emission Measurement 150 kHz to 30 MHz................... 33 8.7 Radiated Emission Measurement 30 MHz to 10 GHz ....................................... 34 8.8 Exposure of Humans to RF Fields...................................................................... 36 9 Test Results for Receiver.......................................................................................... 38 9.1 Radiated Emission Measurement 30 MHz to 5 GHz ......................................... 39 10 Referenced Regulations ........................................................................................... 40 11 Charts taken during testing ....................................................................................... 41 Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 51971-060823-1 (Edition 1) Page 3 of 41 Pages 1 Description of the Equipment Under Test (EUT) General data of EUT Type designation 1 : WaveNET Router Node Parts 2 : Serial number(s): US-Band Manufacturer: SimonsVoss Technologies AG Type of equipment: Transceiver for Electronic Lock Version: As delivered FCC ID: Additional parts/accessories: Technical data of EUT Application frequency range: 902 - 928 MHz Frequency range: 915 MHz Operating frequency: 915 MHz Type of modulation: GFSK Pulse train: --- Pulse width: --- Number of RF-channels: 1 Channel spacing: Not applicable Designation of emissions 3 : 158kF1D Type of antenna: Monopole Size/length of antenna: 105 mm Connection of antenna: detachable not detachable Type of power supply: DC supply Specifications for power supply: nominal voltage: 6.0 V minimum voltage: 5.4 V maximum voltage: 6.6 V 1 Type designation of the system if EUT consists of more than one part. 2 Type designations of the parts of the system, if applicable. 3 Also known as "Class of Emission". Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 51971-060823-1 (Edition 1) Page 4 of 41 Pages 2 Administrative Data Application details Applicant (full address): SimonsVoss Technologies AG Feringastraße 4 85774 Unterföhring Germany Contact person: Mr. Ludger Voss Contract identification: --- Receipt of EUT: 19 September 2006 Date(s) of test: September - November 2006 Note(s): --- Report details Report number: 51971-060823-1 Edition: 1 Issue date: 07 December 2006 Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 51971-060823-1 (Edition 1) Page 5 of 41 Pages 3 Identification of the Test Laboratory Details of the Test Laboratory Company name: Senton GmbH EMI/EMC Test Center Address: Aeussere Fruehlingstrasse 45 D-94315 Straubing Germany Laboratory accreditation: DAR-Registration No. DAT-P-171/94-02 FCC test site registration number 90926 Industry Canada test site registration: IC 3050 Contact person: Mr. Johann Roidt Phone: (+49) (0)9421 5522-0 Fax: (+49) (0)9421 5522-99 Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 51971-060823-1 (Edition 1) Page 6 of 41 Pages 4 Summary Summar…
Text truncated - open the document above for the full version.
SimonsVoss Router FCC ID: UUC-05 Test Setup Photos Note: Testing was not performed at LS Research, LLC. Therefore, the test setup photos taken are located on pages 17-21 of the test report. Since the report states that it must be reprinted in full, with permission from the test lab, reference is made to the report, pages 17-21 for photos.
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 915 MHz - 915 MHz | - |

Door Lock
Equipment Class
DCD - Part 15 Low Power Transmitter Below 1705 kHz
Lock Switch
Equipment Class
DCD - Part 15 Low Power Transmitter Below 1705 kHz
Entry Transponder
Equipment Class
DCD - Part 15 Low Power Transmitter Below 1705 kHz
Lock Programmer
Equipment Class
DCD - Part 15 Low Power Transmitter Below 1705 kHz
