UVIBS10R11BServer for Bridge score input device

Bridgemate Pro Scoring system Manual © 2004-2007 Bridge Systems BV All information contained in this document is subject to change without prior warning. Unless stated otherwise, all persons and details mentioned in this document are fictitious. No part of this publication may be reproduced and/or published, by print, photoprint, microfilm or otherwise, or stored in a retrieval system, without prior written permission from Bridge Systems BV. © Copyright 2004-2007 Bridge Systems BV. All rights reserved. Bridgemate, Bridgemate Pro and the Bridgemate logo are trademarks and/or registered trademarks of Bridge Systems BV in the Netherlands and other countries. Microsoft and Microsoft Windows are trademarks and/or registered trademarks of the Microsoft Corporation in the United States and other countries. Table of contents LIMITED WARRANTY 1 SAFETY INSTRUCTIONS 5 INTRODUCTION 9 CHAPTER 1: DESCRIPTION BRIDGEMATE PRO SCORING SYSTEM 11 DESCRIPTION OF COMPONENTS 11 PROCEDURE 13 CHAPTER 2: HARDWARE CONFIGURATION 15 SYSTEM REQUIREMENTS 15 INSTALLING BRIDGEMATE PRO CONTROL SOFTWARE 15 INSTALLING THE SERVER 15 POWER SUPPLY 15 CONNECTING THE SERVER TO THE PC 16 SETTING THE REGION 16 CONFIGURING THE BRIDGEMATES 16 SETTING THE CHANNEL 17 OPERATING INSTRUCTIONS 17 CHAPTER 3: BRIDGEMATE PRO CONTROL SOFTWARE 19 LAUNCHING BRIDGEMATE PRO CONTROL 19 LOGGING IN AND LOGGING OFF BRIDGEMATES 20 LOGGING IN BRIDGEMATE 20 LOGGING OFF BRIDGEMATE 21 BOARD RESULTS 21 READING FROM THE SERVER 21 VIEWING AND FILTERING OR SORTING SCORES 22 CHANGING AND DELETING SCORES 22 PROCESSING SCORES IN THE SCORING PROGRAM 23 OPENING AND CLOSING RESULT FILES 23 ADDING A CLIENT TO THE RESULT FILE 23 MANAGING TABLES 23 SERVER CONTROL 24 ACTIVATING THE SERVER 24 ADDING TABLES 24 REMOVING TABLES 24 SYNCHRONIZING THE SERVER AND CLIENT 24 RECOVERING THE SERVER 26 UPDATING MOVEMENT IN THE SERVER 26 SETTINGS 26 CHAPTER 4: SERVER FUNCTIONS 29 OVERVIEW OF TABLES 29 OVERVIEW OF ENTERED SCORES 29 RESTARTING BRIDGEMATE NETWORK 29 RESETTING THE SERVER 30 SETTING THE REGION 30 SETTING THE CHANNEL 30 SYSTEM FUNCTIONS 31 CHAPTER 5: USE OF THE BRIDGEMATE ® PRO SCORING DEVICES 33 EXPLORING THE BRIDGEMATE 33 ACTIVATING THE BRIDGEMATE 34 ENTERING SCORES WITH THE BRIDGEMATE 35 READING BRIDGEMATE PRO SCORES 39 TD MENU 40 CHAPTER 6: ADDITIONAL BRIDGEMATE FUNCTIONS 42 READING SCORES MANUALLY IN BRIDGEMATE 42 BRIDGEMATE SETTINGS 42 SYSTEM FUNCTIONS 44 CHAPTER 7: TIPS FOR USE 47 REPLACING BRIDGEMATE 47 RECOVERING THE SERVER 47 PROCEDURE IN THE EVENT OF DATA LOSS 47 MULTIPLE BRIDGE CLUBS PLAYING SIMULTANEOUSLY 49 LARGE TOURNAMENTS 49 DECLARATION OF CONFORMITY 51 Limited warranty 1 Limited warranty IMPORTANT—PLEASE READ THIS LIMITED WARRANTY CAREFULLY TO UNDERSTAND YOUR RIGHTS AND OBLIGATIONS! The term “Hardware Device” means the Bridge Systems hardware product. The term “You” means either an individual or a single legal entity who will be referred to in this Limited Warranty as “You” and “Your”. A. WARRANTIES. 1. Express Warranty. Subject to the terms and conditions of this Limited Warranty and in lieu of any other (if any) express warranties, Bridge Systems warrants that under normal use and service, on the date of acquisition as shown on Your receipt or similar proof of payment and for the period of time stated below for the applicable Hardware Device (hereafter each defined as the “Warranty Period”), that the Hardware Device will substantially conform with the accompanying Bridge Systems packaging and documentation. As to any defects discovered after the Warranty Period, there is no warranty or condition of any kind. Warranty Period: For all hardware parts of the Bridgemate Pro scoring system: one (1) year. This Limited Warranty does not cover, and no warranty of any kind is provided with respect to any subjective or aesthetic aspects of the Hardware Device. The express warranty stated above is the only express warranty made to You and is provided in lieu of all other express or implied warranties and conditions (except for any nondisclaimable implied warranties that exist), including any created by any other documentation or packaging. No information or suggestions (oral or in a record) given by Bridge Systems, its distributors, agents, affiliates or suppliers or its or their employees or agents, shall create a warranty or condition or expand the scope of this Limited Warranty. 2. Limitation on Duration of Implied Warranties. If you are a consumer, You may also have an implied warranty and/or condition under the laws of some jurisdictions, which is hereby limited to the duration of the Warranty Period. Some jurisdictions do not allow limitations on how long an implied warranty or condition lasts, so the foregoing limitation may not apply to You. B. EXCLUSIVE REMEDY. Subject to applicable law and the following, and provided that You return the Hardware Device to Your place of acquisition (or, if that place will not accept the return, to Bridge Systems) with a copy of Your receipt or other bona fide proof of payment during the Warranty Period, Bridge Systems will, at its option and as Your exclusive remedy for breach of this Limited Warranty and any implied warranties: repair or replace the defective Hardware Device; or make payment to You for the allowable damages that You incurred in reasonable reliance, but only up to the amount You paid (if any) for the Hardware Device less reasonable depreciation based on actual use. The above remedy is subject to the following: Any repaired or replaced Hardware Device will be new or refurbished or serviceably used, comparable in function and performance to the original Hardware Device, and may include third party items; Any Hardware Device repaired or replaced under this Limited Warranty will be warranted for the remainder of the original Warranty Period or 30 days from the date of shipment of the item back to You, whichever is longer. Except as otherwise required by legislation in Your jurisdiction, costs associated with…

Text truncated - open the document above for the full version.

FCC, Request for non-disclosure Date: 21-07-05 RF_501, Issue 3 Page 1 of 1 Bridge Systems BV Bulgersteyn 7085 3011 AB Rotterdam The Netherlands To: Telefication B.V. Attn: Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID:UVIBS10R11B Reference number: conf2007-2 Dear FCC TCB, Persuant to 47 CFR Section 0.459(a) & (b), Bridge Systems BV hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application for FCC ID : UVIBS10R11B X Bill(s) of Material X Block Diagrams X Operational Description X Schematic Diagrams X Internal photos Above materials contain secrets, proprietary and technical information, which would customarily be quarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. Bridge Systems BV understands that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. March 14th, 2007 Rotterdam, The Netherlands R.F. Bouwland CEO, Bridge Systems BV

FCC, Request for non-disclosure Date: 21-07-05 RF_501, Issue 3 Page 1 of 1 Bridge Systems BV Bulgersteyn 7085 3011 AB Rotterdam The Netherlands To: Telefication B.V. Attn: Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID:UVIBS10R11B Reference number: conf2007-2 Dear FCC TCB, Persuant to 47 CFR Section 0.459(a) & (b), Bridge Systems BV hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application for FCC ID : UVIBS10R11B X Bill(s) of Material X Block Diagrams X Operational Description X Schematic Diagrams X Internal photos Above materials contain secrets, proprietary and technical information, which would customarily be quarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. Bridge Systems BV understands that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. March 14th, 2007 Rotterdam, The Netherlands R.F. Bouwland CEO, Bridge Systems BV

Telefication B.V. Office address: tel: +31 (0)316 583180 Chamber of commerce: 09076358 Edisonstraat 12 A fax: +31 (0)316 583189 ABN-AMRO: 41.15.67.926, Swift code: ABNANL2A 6902 PK Zevenaar Email: [email protected] Postbank: 610103, Swift code: INGBNL2A The Netherlands web-site: www.telefication.com VAT: NL 8013.41.164.B.01 To: FCC FCC ID: UVIBS10R11B -- -- Our reference Date 21 June 2007 Dear Sir/Madam, Please delete the Confidentiality Request letter uploaded on 19June2007. This letter included the request to keep Bill of Material confidential but such a Bill of Material was not delivered and not uploaded. I have already uploaded a corrected Confidentiality Request letter on 20 June 2007. Best regards, Bert Vos

External photos IC ID : 6946A-BS10R11B Bottom Top

© Bridge Systems BV N14984 Tested to Comply With FCC Standards For Home or Office Use Input rating: 9~12V, 100mA P ro S erver P ro S erver Made in The Netherlands Polarity: Model No: BS10R11B FCC ID: UVIBS10R11B IC: 6946A-BS10R11B ®

Label location IC ID : 6946A-BS10R11B Label goes here

Radio test report 99833930 based on: - FCC Part 15 Subpart C, sections 15.209 and 15.247 (10-1-06 Edition) - RSS-210, Issue 6 (Sept. 2005 edition) Bridge scoring system Bridgemate BM11R11B; BS10R11B Report number: 99833930 Contents MAIN MODULE............................................................................................................................................3 1 I NTRODUCTION ....................................................................................................................................3 2 P RODUCT .............................................................................................................................................4 3 T EST SCHEDULE ...................................................................................................................................4 4 P RODUCT DOCUMENTATION .................................................................................................................5 5 O BSERVATIONS AND COMMENTS .........................................................................................................5 6 M ODIFICATIONS TO THE SAMPLE ..........................................................................................................6 7 S UMMARY ............................................................................................................................................6 8 C ONCLUSIONS ......................................................................................................................................7 TEST RESULTS MODULE .........................................................................................................................8 1 G ENERAL INFORMATION ......................................................................................................................8 1.1 Equipment information ...................................................................................................................8 1.2 Frequency test channels ..................................................................................................................8 2 T EST RESULTS ......................................................................................................................................9 2.1 Channel Separation.........................................................................................................................9 2.2 Number of hop frequencies ..........................................................................................................10 2.3 Bandwidth and Power Spectral Density .......................................................................................11 3 E MISSION TESTS .................................................................................................................................12 3.1 Peak power of intentional signal...................................................................................................12 3.2 Radiated Disturbance: Compliance Test (0.009 – 30 MHz).........................................................13 3.3 Field strength of unwanted emissions 30 - 1000 MHz .................................................................14 3.4 Field strength of unwanted emissions > 1000 MHz .....................................................................16 3.5 Emissions in the restricted bands..................................................................................................19 3.6 Conducted emissions on AC power line.......................................................................................23 USED TEST EQUIPMENT MODULE .....................................................................................................25 This report comprises of three modules. The total number of pages is: 28 Main module Page: 3 of 28 Report number: 99833930 Main module 1 Introduction This report contains the result of tests performed by: Telefication B.V. Edisonstraat 12a 6902 PK Zevenaar The Netherlands Telefication complies with the accreditation criteria for test laboratories as laid down in ISO/IEC 17025:2005. The accreditation covers the quality system of the laboratory as well as the specific activities as described in the authorized annex bearing the accreditation number L021 and is granted on 30 November 1990 by the Dutch Council For Accreditation (RvA: Raad voor Accreditatie). The contents of this test report, if reproduced, shall be copied in full, unless special consent in writing for reproduction in part is granted by Telefication. Copyright of this test report is reserved to Telefication. Ordering party: Company name : Bridge Systems BV Address : Bulgersteyn 7085 Zipcode : 3011 AB City/town : Rotterdam Country : The Netherlands Date of order : 11 January 2007 Main module Page: 4 of 28 Report number: 99833930 2 Product A sample of the following product was submitted for testing: Product description : Bridge scoring system Manufacturer : Bridge Systems BV Trade mark : Bridgemate Type designation : BM11R11B; BS10R11B FCC ID : UVIBM11R11B; UVIBS10R11B IC ID : -- Hardware version : -- Serial number : -- Software release : -- 3 Test schedule Tests are carried out in accordance with the specification detailed in chapter 7 “Summary” of this report. Tests are carried out at the following locations: • TNO Electronic Products & Services (EPS) B.V, Niekerk (radiated emissions) • Telefication, Zevenaar (all other measurements) The samples of the product were received on: • 16 March 2007 Tests are carried out between: • 20 March and 12 April 2007 Main module Page: 5 of 28 Report number: 99833930 4 Product documentation For production of this report the following product documentation is used: Description: Date: Identification: Manual 2004-2007 Bridgemate Pro Scoring System Circuit diagram Mar. 13, 2007 1014-2, CC1020-based RF modem Circuit diagram Jan 23, 2007 2217-01, BridgeMate Server Circuit diagram 30-07-2000 30072000-1-3, BridgeMate with r…
