UX2T955WWireless Zoning Starter Package

Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Company name: BELLMATE HOLDINGS LTD. FCC ID: UX2T955W FCC Part 15 Certification Gentlemen, In accordance with DA 00-1407 – 26 th Jun 2000 “Part 15 Unlicensed Modular Transmitter Approval”, BELLMATE HOLDINGS LTD. believes it has met all of the requirements set out in the document for the granting of modular approval. 1. The modular transmitter must have its own RF shielding. It is not fulfilled The module does not have its own shielding. Therefore, this device will be limited to end-products which can supply the necessary shielding function. 2. The modular transmitter must have buffered modulation/data inputs. It is fulfilled .The modular have buffered modulation (ASK Modulation) 3. The modular transmitter must have its own power supply regulation. It is fulfilled .The modular have its own DC 3.3V power supply regulation. 4. The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). It is fulfilled. The modular comply with antenna requirements. Please see the Internal photos. 5. The modular transmitter must be tested in a stand-alone configuration, It is not fulfilled, The modular transmitter tested with final product. 6. The modular transmitter must be labeled with its own FCC ID number. It is fulfilled. The label has been noted. 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. It is fulfilled. The operation description and user manual provide this detail. 8. The modular transmitter must comply with any applicable RF exposure requirements. It is fulfilled. The modular is exempted due to it is low field strength. Signature Name Jimmy Title General Manager Company BELLMATE HOLDINGS LTD.

Letter of Authorization Company: BELLMATE HOLDINGS LTD Address: UNIT206,STERLING CENTRE,11 CHEUNG YUE STREET,CHEUNG SHA WAN， KOWLOON.HONG KONG. Product Name: Wireless Controller Model Number: Z955W/RZ251W/ZDA250W/Z260W/Z270W/RZ250W/T955WH/R251W B270WH/R250W/T955W/B270W We authorize MiCOM Labs, 440 Boulder Court, Suite 200, Pleasanton, CA 94566, USA, to act on our behalf on all matters concerning the above named equipment. This shall include the following: - Testing - Approval applications and procedures - Payment of approval fees We declare that MiCOM Labs, 440 Boulder Court, Suite 200, Pleasanton, CA 94566, USA, is allowed to forward all information related to the approval project to the applied notified body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own.

Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Request for Confidentiality Company name: BELLMATE HOLDINGS LTD FCC ID: UX2Z955W FCC Part 15 Certification Gentlemen, In accordance with 0.45 9 of CFR 47,BELLMATE HOLDINGS LTD. hereby requests confidentiality of the following documents for the subject application: • Block diagram • Schematics • Operation description • BOM List These documents contain detailed system and equipment description and related information about the product which BELLMATE HOLDINGS LTD. considers to be proprietary, confidential and a custom design and otherwise would not release to the general public. Since the design is a basis from which future technological products will evolve, BELLMATE HOLDINGS LTD. considers that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market.

Product Name: Mater Model: A dditional Model 列名型号 Figure 外观 Component 元件 Color 颜 色 PCB 线路板 Structure 结构 others 其他 T955WH same same same same same T955W same same same same same R251W same same same same same R250W same same same same same B270WH same same same same same B270W same same same same same Differences Among These Models ( 产品差异说明 ) Wireless controller Z955W / RZ251W / ZDA250W /RZ250W / Z270W / Z260W

FCC ID: UX2T955W IC: 11070A-T955W Copyright of this report is owned by Centre of Testing Service and may not be reproduced other than in full except with the written approval of the issuing Company. CTS (Ningbo) Testing Service Technology Co., Ltd. 2/F., South Tower, Huoju Building, No.181, Canghai Road, Jiangdong Science and Technology Park, Ningbo, Zhejiang, China Tel：+86-20-85543113 (32 lines) Fax：+86-20-38780406 Complaint line：+86-20-85533471 E-mail：[email protected] See Reverse For Terms And Conditions of Service Report No.: CGZ3130402-00239-EFI Page 1 of 13 1. External Photos of the EUT External view Z955W External view 1 Z955W External view 2 FCC ID: UX2T955W IC: 11070A-T955W Copyright of this report is owned by Centre of Testing Service and may not be reproduced other than in full except with the written approval of the issuing Company. CTS (Ningbo) Testing Service Technology Co., Ltd. 2/F., South Tower, Huoju Building, No.181, Canghai Road, Jiangdong Science and Technology Park, Ningbo, Zhejiang, China Tel：+86-20-85543113 (32 lines) Fax：+86-20-38780406 Complaint line：+86-20-85533471 E-mail：[email protected] See Reverse For Terms And Conditions of Service Report No.: CGZ3130402-00239-EFI Page 2 of 13 Z955W External view 3 Z955W External view 4 Z955W External view 5 FCC ID: UX2T955W IC: 11070A-T955W Copyright of this report is owned by Centre of Testing Service and may not be reproduced other than in full except with the written approval of the issuing Company. CTS (Ningbo) Testing Service Technology Co., Ltd. 2/F., South Tower, Huoju Building, No.181, Canghai Road, Jiangdong Science and Technology Park, Ningbo, Zhejiang, China Tel：+86-20-85543113 (32 lines) Fax：+86-20-38780406 Complaint line：+86-20-85533471 E-mail：[email protected] See Reverse For Terms And Conditions of Service Report No.: CGZ3130402-00239-EFI Page 3 of 13 Z955W External view 6 RZ251W External view 1 RZ251W External view 2 FCC ID: UX2T955W IC: 11070A-T955W Copyright of this report is owned by Centre of Testing Service and may not be reproduced other than in full except with the written approval of the issuing Company. CTS (Ningbo) Testing Service Technology Co., Ltd. 2/F., South Tower, Huoju Building, No.181, Canghai Road, Jiangdong Science and Technology Park, Ningbo, Zhejiang, China Tel：+86-20-85543113 (32 lines) Fax：+86-20-38780406 Complaint line：+86-20-85533471 E-mail：[email protected] See Reverse For Terms And Conditions of Service Report No.: CGZ3130402-00239-EFI Page 4 of 13 RZ251W External view 3 RZ251W External view 4 RZ251W External view 5 FCC ID: UX2T955W IC: 11070A-T955W Copyright of this report is owned by Centre of Testing Service and may not be reproduced other than in full except with the written approval of the issuing Company. CTS (Ningbo) Testing Service Technology Co., Ltd. 2/F., South Tower, Huoju Building, No.181, Canghai Road, Jiangdong Science and Technology Park, Ningbo, Zhejiang, China Tel：+86-20-85543113 (32 lines) Fax：+86-20-38780406 Complaint line：+86-20-85533471 E-mail：[email protected] See Reverse For Terms And Conditions of Service Report No.: CGZ3130402-00239-EFI Page 5 of 13 RZ251W External view 6 ZDA250W External view 1 ZDA250W External view 2 FCC ID: UX2T955W IC: 11070A-T955W Copyright of this report is owned by Centre of Testing Service and may not be reproduced other than in full except with the written approval of the issuing Company. CTS (Ningbo) Testing Service Technology Co., Ltd. 2/F., South Tower, Huoju Building, No.181, Canghai Road, Jiangdong Science and Technology Park, Ningbo, Zhejiang, China Tel：+86-20-85543113 (32 lines) Fax：+86-20-38780406 Complaint line：+86-20-85533471 E-mail：[email protected] See Reverse For Terms And Conditions of Service Report No.: CGZ3130402-00239-EFI Page 6 of 13 ZDA250W External view 3 ZDA250W External view 4 ZDA250W External view 5 FCC ID: UX2T955W IC: 11070A-T955W Copyright of this report is owned by Centre of Testing Service and may not be reproduced other than in full except with the written approval of the issuing Company. CTS (Ningbo) Testing Service Technology Co., Ltd. 2/F., South Tower, Huoju Building, No.181, Canghai Road, Jiangdong Science and Technology Park, Ningbo, Zhejiang, China Tel：+86-20-85543113 (32 lines) Fax：+86-20-38780406 Complaint line：+86-20-85533471 E-mail：[email protected] See Reverse For Terms And Conditions of Service Report No.: CGZ3130402-00239-EFI Page 7 of 13 ZDA250W External view 6 RZ250W External view 1 RZ250W External view 2 FCC ID: UX2T955W IC: 11070A-T955W Copyright of this report is owned by Centre of Testing Service and may not be reproduced other than in full except with the written approval of the issuing Company. CTS (Ningbo) Testing Service Technology Co., Ltd. 2/F., South Tower, Huoju Building, No.181, Canghai Road, Jiangdong Science and Technology Park, Ningbo, Zhejiang, China Tel：+86-20-85543113 (32 lines) Fax：+86-20-38780406 Complaint line：+86-20-85533471 E-mail：[email protected] See Reverse For Terms And Conditions of Service Report No.: CGZ3130402-00239-EFI Page 8 of 13 RZ250W External view 3 RZ250W External view 4 RZ250W External view 5 FCC ID: UX2T955W IC: 11070A-T955W Copyright of this report is owned by Centre of Testing Service and may not be reproduced other than in full except with the written approval of the issuing Company. CTS (Ningbo) Testing Service Technology Co., Ltd. 2/F., South Tower, Huoju Building, No.181, Canghai Road, Jiangdong Science and Technology Park, Ningbo, Zhejiang, China Tel：+86-20-85543113 (32 lines) Fax：+86-20-38780406 Complaint line：+86-20-85533471 E-mail：[email protected] See Reverse For Terms And Conditions of Service Report No.: CGZ3130402-00239-EFI Page 9 of 13 RZ250W External view 6 Z260W External view 1 Z260W External view 2 FCC ID: UX2T955W IC: 11070A-T955W Copyright of this report is owned by Centre of Testing Service and may not be reproduced other than in full except with the written approval of the issuing Company. CTS (Ningbo) Testing S…

Text truncated - open the document above for the full version.

FCC ID:UX2T955W IC:11070A-T955W Copyright of this report is owned by Centre of Testing Service and may not be reproduced other than in full except with the written approval of the issuing Company. CTS (Ningbo) Testing Service Technology Co., Ltd. 2/F., South Tower, Huoju Building, No.181, Canghai Road, Jiangdong Science and Technology Park, Ningbo, Zhejiang, China Tel：+86-20-85543113 (32 lines) Fax：+86-20-38780406 Complaint line：+86-20-85533471 E-mail：[email protected] See Reverse For Terms And Conditions of Service Report No.: CGZ3130402-00239-EFI Page 1 of 6 LABEL PHOTOGRAPHS Label Location Z955W Label Loaction 30mm 20mm FCC ID:UX2T955W IC:11070A-T955W Copyright of this report is owned by Centre of Testing Service and may not be reproduced other than in full except with the written approval of the issuing Company. CTS (Ningbo) Testing Service Technology Co., Ltd. 2/F., South Tower, Huoju Building, No.181, Canghai Road, Jiangdong Science and Technology Park, Ningbo, Zhejiang, China Tel：+86-20-85543113 (32 lines) Fax：+86-20-38780406 Complaint line：+86-20-85533471 E-mail：[email protected] See Reverse For Terms And Conditions of Service Report No.: CGZ3130402-00239-EFI Page 2 of 6 LABEL PHOTOGRAPHS Label Location RZ251W Label Loaction 30mm 20mm FCC ID:UX2T955W IC:11070A-T955W Copyright of this report is owned by Centre of Testing Service and may not be reproduced other than in full except with the written approval of the issuing Company. CTS (Ningbo) Testing Service Technology Co., Ltd. 2/F., South Tower, Huoju Building, No.181, Canghai Road, Jiangdong Science and Technology Park, Ningbo, Zhejiang, China Tel：+86-20-85543113 (32 lines) Fax：+86-20-38780406 Complaint line：+86-20-85533471 E-mail：[email protected] See Reverse For Terms And Conditions of Service Report No.: CGZ3130402-00239-EFI Page 3 of 6 LABEL PHOTOGRAPHS Label Location ZDA250W Label Loaction 30mm 20mm FCC ID:UX2T955W IC:11070A-T955W Copyright of this report is owned by Centre of Testing Service and may not be reproduced other than in full except with the written approval of the issuing Company. CTS (Ningbo) Testing Service Technology Co., Ltd. 2/F., South Tower, Huoju Building, No.181, Canghai Road, Jiangdong Science and Technology Park, Ningbo, Zhejiang, China Tel：+86-20-85543113 (32 lines) Fax：+86-20-38780406 Complaint line：+86-20-85533471 E-mail：[email protected] See Reverse For Terms And Conditions of Service Report No.: CGZ3130402-00239-EFI Page 4 of 6 LABEL PHOTOGRAPHS Label Location RZ250W Label Loaction 30mm 20mm FCC ID:UX2T955W IC:11070A-T955W Copyright of this report is owned by Centre of Testing Service and may not be reproduced other than in full except with the written approval of the issuing Company. CTS (Ningbo) Testing Service Technology Co., Ltd. 2/F., South Tower, Huoju Building, No.181, Canghai Road, Jiangdong Science and Technology Park, Ningbo, Zhejiang, China Tel：+86-20-85543113 (32 lines) Fax：+86-20-38780406 Complaint line：+86-20-85533471 E-mail：[email protected] See Reverse For Terms And Conditions of Service Report No.: CGZ3130402-00239-EFI Page 5 of 6 LABEL PHOTOGRAPHS Label Location Z260W Label Loaction 30mm 20mm FCC ID:UX2T955W IC:11070A-T955W Copyright of this report is owned by Centre of Testing Service and may not be reproduced other than in full except with the written approval of the issuing Company. CTS (Ningbo) Testing Service Technology Co., Ltd. 2/F., South Tower, Huoju Building, No.181, Canghai Road, Jiangdong Science and Technology Park, Ningbo, Zhejiang, China Tel：+86-20-85543113 (32 lines) Fax：+86-20-38780406 Complaint line：+86-20-85533471 E-mail：[email protected] See Reverse For Terms And Conditions of Service Report No.: CGZ3130402-00239-EFI Page 6 of 6 LABEL PHOTOGRAPHS Label Location Z270W Label Loaction 30mm 20mm

FCC ID: UX2T955W IC: 11070A-T955W Copyright of this report is owned by Centre of Testing Service and may not be reproduced other than in full except with the written approval of the issuing Company. CTS (Ningbo) Testing Service Technology Co., Ltd. 2/F., South Tower, Huoju Building, No.181, Canghai Road, Jiangdong Science and Technology Park, Ningbo, Zhejiang, China Tel：+86-20-85543113 (32 lines) Fax：+86-20-38780406 Complaint line：+86-20-85533471 E-mail：[email protected] See Reverse For Terms And Conditions of Service Report No.: CGZ3130402-00239-EFI Page 1 of 14 1. External Photos of the EUT Z955W Internal view Z955W PCB side1 Z955W PCB side2 FCC ID: UX2T955W IC: 11070A-T955W Copyright of this report is owned by Centre of Testing Service and may not be reproduced other than in full except with the written approval of the issuing Company. CTS (Ningbo) Testing Service Technology Co., Ltd. 2/F., South Tower, Huoju Building, No.181, Canghai Road, Jiangdong Science and Technology Park, Ningbo, Zhejiang, China Tel：+86-20-85543113 (32 lines) Fax：+86-20-38780406 Complaint line：+86-20-85533471 E-mail：[email protected] See Reverse For Terms And Conditions of Service Report No.: CGZ3130402-00239-EFI Page 2 of 14 Z955W Oscillation view 1 Z955W Oscillation view 2 Z955W Module side 1 FCC ID: UX2T955W IC: 11070A-T955W Copyright of this report is owned by Centre of Testing Service and may not be reproduced other than in full except with the written approval of the issuing Company. CTS (Ningbo) Testing Service Technology Co., Ltd. 2/F., South Tower, Huoju Building, No.181, Canghai Road, Jiangdong Science and Technology Park, Ningbo, Zhejiang, China Tel：+86-20-85543113 (32 lines) Fax：+86-20-38780406 Complaint line：+86-20-85533471 E-mail：[email protected] See Reverse For Terms And Conditions of Service Report No.: CGZ3130402-00239-EFI Page 3 of 14 Z955W side 2 RZ251W Internal view RZ251W PCB side 1 FCC ID: UX2T955W IC: 11070A-T955W Copyright of this report is owned by Centre of Testing Service and may not be reproduced other than in full except with the written approval of the issuing Company. CTS (Ningbo) Testing Service Technology Co., Ltd. 2/F., South Tower, Huoju Building, No.181, Canghai Road, Jiangdong Science and Technology Park, Ningbo, Zhejiang, China Tel：+86-20-85543113 (32 lines) Fax：+86-20-38780406 Complaint line：+86-20-85533471 E-mail：[email protected] See Reverse For Terms And Conditions of Service Report No.: CGZ3130402-00239-EFI Page 4 of 14 RZ251W PCB side 2 RZ251W Oscillation view 1 RZ251W Oscillation view 2 FCC ID: UX2T955W IC: 11070A-T955W Copyright of this report is owned by Centre of Testing Service and may not be reproduced other than in full except with the written approval of the issuing Company. CTS (Ningbo) Testing Service Technology Co., Ltd. 2/F., South Tower, Huoju Building, No.181, Canghai Road, Jiangdong Science and Technology Park, Ningbo, Zhejiang, China Tel：+86-20-85543113 (32 lines) Fax：+86-20-38780406 Complaint line：+86-20-85533471 E-mail：[email protected] See Reverse For Terms And Conditions of Service Report No.: CGZ3130402-00239-EFI Page 5 of 14 RZ251W Module side 1 RZ251W Module side 2 ZDA250W Internal view FCC ID: UX2T955W IC: 11070A-T955W Copyright of this report is owned by Centre of Testing Service and may not be reproduced other than in full except with the written approval of the issuing Company. CTS (Ningbo) Testing Service Technology Co., Ltd. 2/F., South Tower, Huoju Building, No.181, Canghai Road, Jiangdong Science and Technology Park, Ningbo, Zhejiang, China Tel：+86-20-85543113 (32 lines) Fax：+86-20-38780406 Complaint line：+86-20-85533471 E-mail：[email protected] See Reverse For Terms And Conditions of Service Report No.: CGZ3130402-00239-EFI Page 6 of 14 ZDA250W PCB side 1 ZDA250W PCB side 2 ZDA250W Oscillation view 1 FCC ID: UX2T955W IC: 11070A-T955W Copyright of this report is owned by Centre of Testing Service and may not be reproduced other than in full except with the written approval of the issuing Company. CTS (Ningbo) Testing Service Technology Co., Ltd. 2/F., South Tower, Huoju Building, No.181, Canghai Road, Jiangdong Science and Technology Park, Ningbo, Zhejiang, China Tel：+86-20-85543113 (32 lines) Fax：+86-20-38780406 Complaint line：+86-20-85533471 E-mail：[email protected] See Reverse For Terms And Conditions of Service Report No.: CGZ3130402-00239-EFI Page 7 of 14 ZDA250W Oscillation view 2 ZDA250W Module side 1 ZDA250W Module side 2 FCC ID: UX2T955W IC: 11070A-T955W Copyright of this report is owned by Centre of Testing Service and may not be reproduced other than in full except with the written approval of the issuing Company. CTS (Ningbo) Testing Service Technology Co., Ltd. 2/F., South Tower, Huoju Building, No.181, Canghai Road, Jiangdong Science and Technology Park, Ningbo, Zhejiang, China Tel：+86-20-85543113 (32 lines) Fax：+86-20-38780406 Complaint line：+86-20-85533471 E-mail：[email protected] See Reverse For Terms And Conditions of Service Report No.: CGZ3130402-00239-EFI Page 8 of 14 RZ250W Internal view RZ250W PCB side 1 RZ250W PCB side 2 FCC ID: UX2T955W IC: 11070A-T955W Copyright of this report is owned by Centre of Testing Service and may not be reproduced other than in full except with the written approval of the issuing Company. CTS (Ningbo) Testing Service Technology Co., Ltd. 2/F., South Tower, Huoju Building, No.181, Canghai Road, Jiangdong Science and Technology Park, Ningbo, Zhejiang, China Tel：+86-20-85543113 (32 lines) Fax：+86-20-38780406 Complaint line：+86-20-85533471 E-mail：[email protected] See Reverse For Terms And Conditions of Service Report No.: CGZ3130402-00239-EFI Page 9 of 14 RZ250W Oscillation view 1 RZ250W Oscillation view 2 RZ250W Module side 1 FCC ID: UX2T955W IC: 11070A-T955W Copyright of this report is owned by Centre of Testing Service and may not be reproduced other than in full except with the written approval of the issuing Company. CTS (Ningbo) Testing Service Technology Co., Ltd. 2/F., So…

Text truncated - open the document above for the full version.

Function Description 1．RZ250W function Transmitter Frequency:916MHZ Modulation Mode: ASK Press “LEARN” key to learn code with Z955W. After learning code successfully, CPU chip transmit data to IC24C08 which will memorize the communication code. Then CPU chip will probe temperature. Measured data will be processed and transmitted to master Z955W. 2．RZ251W function Transmitter Frequency: 916MHZ Modulation Mode: ASK Press “LIGHT” key and touch screen keys to learn code with master T955WH. After learning code successfully, CPU chip transmit data to IC24C08 which will memorize the communication code. Then CPU enters into sleeping mode, IC will probe temperature and transmit data to CPU chip. CPU will process those data after received it, then transmit data to master Z955W. 3．ZDA250W function Transmitter Frequency: 916MHZ Modulation Mode: ASK Press operation keys to learn code with Z955W. After learning code successfully, CPU chip transmit data to IC24C08 which will memorize the communication code. Then CPU chip will probe temperature. Measured data will be processed and transmitted to master Z955W. 4．Z260W function Transmitter Frequency: 916MHZ Modulation Mode: ASK Press operation keys to learn code with Z955W. After learning code successfully, CPU chip transmit data to IC24C08 which will memorize the communication code. Then CPU chip will enter into receiving mode. Received data will be processed and apply to drive relevant load according to actual information. 5．Z955W function Transmitter Frequency :916MHZ Modulation Mode: ASK Use “LIGHT” key and touchscreen keys to set communication code and parameter, CPU chip will process those data and transmit to IC 24C64 to memorize, then CPU will enter into sleeping mode. When Z955W received data from RZ250W, RZ251W, Z260W and ZDA250W, CPU will be activated and process those data then transmit the data to Z270W. 6．Z270W function Transmitter Frequency: 916MHZ Modulation Mode: ASK By pressing “LIGHT” key, Z270W establishes communication with Z955W. CPU chip will process communication code, then send the data to IC 24C08 to memorize, after that it will enter into stand-by mode. When Z270W receives data from Z955W, CPU chip will start to working mode and process those data. It will drive relevant load according to actual information.
