UXX-CTR350Cellular Travel Router

Cradlepoint, Inc.
Cellular Travel Router - FCC ID UXX-CTR350 - Cradlepoint, Inc.
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Feb 05, 2007
Application Purpose
Original Equipment
Date of Application
Feb 05, 2007
Equipment Note
Cellular Travel Router
Frequency Range
2412.00000000 - 2462.00000000
Company
Cradlepoint, Inc.
Country
United States

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

CTR Cellular Travel Router User’s Manual 1 Contents Getting Acquainted 2 Compliance Notes 3 Introduction 4 CTR at a Glance 5 Using the Controls 6 Getting on the Internet Configuring Your Wi reless Netwo rk 7 Welcome to the Help and Setup Pages 8 Navigating the Help and Setup Pages 12 The Wizards 16 Factory Default Reset Tips and Troubleshooting 17 The Error Pages “Data Service Not Available” “Phone Not Available” “Unable to Connect to WAN” 18 “Handset Error” “DNS Poisoning” “Maximum Number of Users Connected” 19 Security Notes 20 Care a nd Mainten ance 21 Indicators (LE Ds) 22 Glossary and Setup De tails 2 Com pliance Not es FCC No tic e: This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Caution: The user is cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the warranty and users’ authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. IMP ORTA NT N OT E: FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. Caution: To comply with the FCC RF exposure compliance requirements, this device must not be co-located or operating in conjunction with any other antenna or transmitter. Indus try Cana da No tic e: Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. The term “IC:” before the radio certification number only signifies that Industry Canada technical specifications were met. This product meets the applicable Industry Canada technical specifications of the RSS210. This class B device complies with Canadian ICES-003. Cet appareil numérique de la classe B est confome à la norme NMB-003 du Canada. FCC COMPLIANCE STATEMENT Property of CradlePoint, Inc For Internal Use Only. Unauthorized reproduction and/or distribution is strictly prohibited. This product is protected under copyright law and trade secret law as an unpublished work. Copyright (C) 2007 CradlePoint, Inc All rights reserved. 3 Introduction WEL C OM E The CradlePoint CTR (Cellular Tra vel Router) is a high-performance Bro adband Cellular Ga te way designed to pro vide fast a nd con venient Inte rne t access while connected to a Cellular mode m o r handset. The CTR pro vides a straightforwa rd and porta ble Interne t connection leve raging adva nces from C radlePoint Tech nologies, Inc. The CTR includes the following featu res:  Establishes shared network connection via standard WAN PPP when connecting DSL, Cable Modem, or other uplink to Ethernet port  Establishes shared network connection via Cellular when connecting Cellular Phone or Cellular Modem to USB port  Designed to work with all 3G cellular service provider networks  Supports up to 128-bit WEP and WPA encryption for data-security  Supports Virtual Private Network (VPN) pass-through  Supports 1 Wired LAN connection  Rugged but compact design is perfect for fixed or mobile applications  Software algorithms boost efficiency, performance, and improve perceived network speed  Auto-Upgrade Notification helps keep user updated with latest system CTR software revision  GUI-based device management from any standard web Browser PACKA GE CO NT ENTS  CradlePoint CTR Cellular Travel Router  Power Adapter (5V/2.5A)  CD-ROM with Manual  Quick Installation Guide  Carrying Case Note: Us ing a po wer supp ly wi th a differe nt vol ta ge t ha n t he one i ncl uded w ith your produ ct w ill ca use d am ag e a nd void the warra nty for thi s produc t. If any of the above items are missing, please contact your reseller. OV ERVI EW OF F EA TURES  Instantly creates a personal WiFi Hotspot anywhere within the Cellular Service Providers' network.  No software to install: Follows simplicity of 802. 11 wireless standards  Supports multiple simultaneous wireless LAN clients  Includes advanced wireless router features: o NAT/NAPT Firewall o DHCP Server o Security - MAC Address Filtering or WPA or WEP Encryption o Web-based Configuration and User Interface  Automatic firmware upgrades  Bridges from Cellular phone/modem connection to wired Ethernet for a no-software secure Internet connection  Recharges the handset battery and CTR internal battery when connected to an external power source.  Windows, Macintosh and Linux support. 4 A B B C D D E F G H I A. LED 0 - USB Status B. LED 1 - LAN Status C. LED 2 - WLAN Status D. LED 3 - Power Status E. Ventilation Slots F. CAT 5 (Ethernet) Port G. Power Connecto…
