UXX-MBR1400Mobile Broadband Router

Business Continuity for Network Failover setup guide P A C K A G E I n c l u d e sBusiness Wireless Router Wall Charger (12v)Ethernet Cable (5-feet)Mounting Hardware (2x)Setup Guide The CradlePoint Business Wireless Router(MBR1400) is built to work in tandem withour Business Modem and provides a network connection effortlessly from its source to your network.You can also connect additional USB andExpressCard modems.Designed for small businesses, branch offices, and retail locations, the MBR1400 provides primary connection via 4G/3G wireless broadband networks as well as traditional wired networks.With features like failover/fail back, secureVPN, multiple encryption modes, dual bandWiFi broadcast (2.4 GHz and 5 GHz), andWiFi as WAN, your primary business routerhas never been so flex ible and affordable. NOTE: MBR1400 itself does not build in WiMAX radio inside. Warning:Read me before plug in your mo dem card in to MBR1400W device System can not activate more than two ports at a time.System can enable one EC port and one USB port at a time. ** Tested 3G dongle (FCC ID:N7NAC880E) and Ex press card (FCC ID:QISE219) can be used with the MBR1400. Other dongle(s)/card(s) have not b een verified and may not comply with FCC relevant rule(s). Federal Communication Commission Interference StatementThis equipment has been tested and found to comply wi th the limits for a Cl ass B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential inst allation. This equipment generates, uses and can radiate radio frequency e nergy and, if not installe d and used in accordance with the instructions, may cause harmful interference to radio communications . However, there is no guarantee that interference will not occur in a particular installati on. If this equipm ent does cause harmful interference to radio or television reception, wh ich can be determined by turning the equipment off and on, the user is enc ouraged to try to correct th e interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation betwee n the equipment and receiver. - Connect the equipment into an outlet on a circuit diff erent from that to which the receiver is connected.- Consult the dealer or an experienc ed radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void th e user's author ity to operate th is equipment. For operation within 5.15 ~ 5.25 GHz frequency range, it is rest ricted to in door environment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This devi ce may not cause harmful in terference, and (2) this device must accept any interference received, includi ng interference that ma y cause undesired operation. IMPORTANT NOTE:FCC Radiation Exposure Statement:This equipment complies with FCC radiation ex posure limits set fort h for an uncontrolled environment. This equipment s hould be installed and operated with minimum distance 20cm between the radia tor & your body. This transmitter must not be co -located or operating in conjunc tion with any other antenna or transmitter.The availability of some s pecific channels and/o r operational frequenc y bands are country dependent and are firmw are programmed at the fact ory to match the int ended destination. The firmware setting is not acce ssible by the end user. Industry Cana da statement This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interf erence, and (2) this device must accept any interference received, including interferen ce that may cause undesired operation. Ce dispositif est conforme à la norme CNR-210 d'Industrie Canada app licable aux appareils radio exempts de licence. Son fonctionnement est sujet aux deux conditions suivantes: (1) le dispositif ne do it pas produire de brouillage préjudiciable, et (2) ce di spositif doit accepter tout brouillage reçu, y compris un brouillage susceptible de provoquer un fonctionnement indésirable. IMPORTANT NOTE:Radiation Exposure Statement:This equipment complies with IC ra diation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimu m distance 20cm between the radiator & your body. NOTE IMPORTANTE: (Pour l'utilis ation de dispositifs mobiles) Déclaration d'exposition aux radiations:Cet équipement est conforme aux lim ites d'exposition aux rayonnements IC établies pour un environnement non contrôlé. Cet é quipement doit être installé et utilisé avec un mi nimum de 20 cm de di stance entre la source de rayonnement et votre corps. Caution:The device for the band 5150-5250 MHz is only for indoor usage to reduce potential for harmful interference to co-channel mobile satellite systems. Le dispositif fonctionnant dans la ba nde 5150-5250 MHz est réservé uniquement pour une utilisat ion à l'intérieur afin de réduire les risques de brouillage préjudiciable aux systèmes de satellites mobiles utilisant les mêmes canaux Under Industry Canada regulations, this radio transmit ter may only operate using an antenna of a type and maximum (or lesser) gain ap proved for the transmitter by Industry Canada. To reduce po tential radio interference to other users, the antenna ty pe and its gain shou ld be so chosen that the equi valent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication. Conformement a la reglementat ion d'Industrie Canada, le present emetteur radio peut fonctionner avec une anten ne d'un type et d'un gain ma ximal (ou inferieur) approuve pour l'emetteur par Industrie Canada. Dans le but de reduir e les risques de brouillage radioelectrique a l'intentio n des autres utilisateurs, il faut choisir le type d'anten n…

Text truncated - open the document above for the full version.

805 W. Franklin Street
Boise, ID
83703 FCC Declaration letter FCC ID: UXX-MBR1400 Date: 12.09.2010 To whom it may concern: We, the undersigned, declare that the MBR1400 doesn’t have“Ad Hoc on non-US frequencies” and/or “on DFS frequencies” Sincerely, __________________________________ Steven T. Wood / Vice President of R&D CradlePoint, Inc. TEL(208) 424-5054 Facsimile(208) 429-6852 Email: [email protected]

805 W. Franklin Street
Boise, ID
83703 A G E N C Y A U T H O R I Z A T I O N L E T T E R FCC ID: UXX-MBR1400 Date: 12.09.2010 To whom it may concern: We, the undersigned, hereby authorize Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan) of Taiwan to act on our behalf, as our agent, in the following matters related to the FCC approval of our products: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by BV CPS Taoyuan within the scope of this authorization shall have the same effects as our own. This authorization shall expire 6 months from original date. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you. Sincerely, __________ _ Steven T. Wood / Vice President of R&D CradlePoint, Inc. TEL(208) 424-5054 Facsimile(208) 429-6852 Email: [email protected]

Page 1 CONSTRUCTION PHOTOS OF EUT EUT with 2.4G antenna Page 2 EUT with 5.0GHz antenna Page 3 Page 4 Page 5 Page 6

CradlePoint MBR1400 PRODUCT LABEL Made in Taiwan RoHS Model No.: MBR1400 Part No.: MBR1400 www.cradlepoint.com H/W ver.: 1.0 12V 1.5A MAC Address : 0030440c1fc1 Serial No.: MM100167900418 MFG DATE: NOV 2010 R01 FCC ID:UXX-MBR1400 IC: 6921A-MBR1400 Default Password : 440c1fc1 SSID: MBR1400-fc1

Label Location

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 3 Page 4 Page 5 Page 6 Page 7

FCC ID: UXX-MBR1400 Report No.: RF 991209C18 Operational Description This device is a Mobile Broadband Router, which operates in both of the 2.4GHz and 5GHz bands; the maximum data rate could be up to 450Mbps which OFDM technique. If the signal to noise radio is too poor which could not support 450Mbps, the 11Mbps data rate with DSSS technique will be applied. The transmitter of the EUT is powered by adapter. The antenna is Dipole antennas with R-SMA antenna connector. For more detailed instruction, please take a look at the user’s manual. FCC 15.407(c) states: The device shall automatically discontinue transmission in case of either absence of information to transmit or operational failure. These provisions are not intended to preclude the transmission of control or signaling information or the use of repetitive codes used by certain digital technologies to complete frame or burst intervals. Applicants shall include in their application for equipment authorization a description of how this requirement is met” Data transmission is always initiated by software, which is then pass down through the MAC, through the digital and analog baseband, and finally to the RF chip. Several special packets (ACKs, CTS, PSPoll, etc...) are initiated by the MAC. There are the only ways the digital baseband portion will turn on the RF transmitter, which it then turns off at the end of the packet. Therefore, the transmitter will be on only while one of the aforementioned packets are being transmitted.

Report No.: SA991206C18 Report Format Version 4.0.0 1 RF EXPOSURE REPORT REPORT NO.: SA991206C18 MODEL NO.: MBR1400 FCC ID: UXX-MBR1400 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: Cradlepoint, Inc. ADDRESS: 1199 Shoreline Lane, Suite 301 Boise, ID 83702 ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien 244, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. Report No.: SA991206C18 Report Format Version 4.0.0 2 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED Original release N/A Dec. 24, 2010 Report No.: SA991206C18 Report Format Version 4.0.0 3 1. RF EXPOSURE LIMIT LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 2. MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r2) where Pd = power density in mW/cm2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 3. CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA991206C18 Report Format Version 4.0.0 4 4. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER For FCC ID: UXX-MBR1400 MODULATION MODE FREQUENCY BAND (MHz) MAX CONDUCTED POWER (dBm) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 802.11b 2412-2462 25.3 9.77 20 0.640 1 802.11g 2412-2462 25.3 9.77 20 0.640 1 802.11n (20MHz) 2412-2462 26.1 5 20 0.256 1 802.11n (40MHz) 2422-2452 26.0 5 20 0.251 1 802.11a 5180-5240 12.2 9.77 20 0.031 1 802.11n (20MHz) 5180-5240 16.5 5 20 0.028 1 802.11n (40MHz) 5180-5240 16.7 5 20 0.029 1 802.11a 5745-5825 25.3 9.77 20 0.640 1 802.11n (20MHz) 5745-5825 25.5 5 20 0.223 1 802.11n (40MHz) 5745-5825 25.0 5 20 0.199 1 NOTE: (802.11 b/g/a): Directional gain =5dBi+10log(3)=9.77dBi Report No.: SA991206C18 Report Format Version 4.0.0 5 For FCC ID: N7NAC880E (3G dongle) 850 Band MODE ERP(dBm) EIRP(dBm) SOURCE TIME AVERAGE POWER (dBm) MPE LIMIT GPRS 28.8 30.95 27.95 0.12 0.55 EGPRS 26.8 28.95 25.95 0.08 0.55 WCDMA 25.9 28.05 25.05 0.06 0.55 HSDPA 26.0 28.15 25.15 0.07 0.55 1900 Band MODE EIRP(dBm) SOURCE TIME AVERAGE POWER (dBm) MPE LIMIT GPRS 29.3 26.3 0.08 1 EGPRS 27.0 24.0 0.05 1 WCDMA 27.1 24.1 0.05 1 HSDPA 27.6 24.6 0.06 1 For FCC ID: QISE219 (Express Card) 1900 Band MODE EIRP(dBm) SOURCE TIME AVERAGE POWER (dBm) MPE LIMIT GPRS 31.05 28.05 0.13 1 EGPRS 27.12 24.12 0.05 1 CONCULSION: The Product has 3 USB ports and 2 express slot to connect 3G device to support 3G function. Only 1 usb port and 1 express slot can work at the same time. Therefore, transmit simultaneously is evaluated for this product + 1 usb dongle + 1 express card. The formula of calculated the MPE is: CPD1 / LPD1 + CPD2 / LPD2 + ......etc. < 1 CPD = Calculation power density LPD = Limit of power density 1. WLAN 2.4GHz + 850 band of 3G dongle + 1900 band of Express card = 0.640 / 1 + 0.12 / 0.55 + 0.13 / 1 = 0.988 2. WLAN 2.4GHz + 1900 band of 3G dongle + 1900 band of Express card = 0.640 / 1 + 0.08 / 1 + 0.13 / 1 = 0.850 3. WLAN 5GHz + 850 band of 3G dongle + 1900 band of Express card = 0.640 / 1 + 0.12 / 0.55 + 0.13 / 1 = 0.988 4. WLAN 5GHz + 1900 band of 3G dongle + 1900 band of Express card = 0.640 / 1 + 0.08 / 1 + 0.13 / 1 = 0.850 Therefore, the maximum calculation of this situation is 0.988, which is less than the “1” limit.

Report No.: RF991206C18 1 Report Format Version 4.0.0 FCC TEST REPORT (15.247) REPORT NO.: RF991206C18 MODEL NO.: MBR1400 FCC ID: UXX-MBR1400 RECEIVED: Dec. 06, 2010 TESTED: Dec. 10 ~ Dec. 22, 2010 ISSUED: Dec. 24, 2010 APPLICANT: Cradlepoint, Inc. ADDRESS: 1199 Shoreline Lane, Suite 301 Boise, ID 83702 ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien 244, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 124 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval or endorsement by TAF or any government agency. The test results in the report only apply to the tested sample. Report No.: RF991206C18 2 Report Format Version 4.0.0 TABLE OF CONTENTS RELEASE CONTROL RECORD.............................................................................................. 5 1. CERTIFICATION........................................................................................................... 6 2. SUMMARY OF TEST RESULTS .................................................................................. 7 2.1 MEASUREMENT UNCERTAINTY................................................................................ 7 3. GENERAL INFORMATION ........................................................................................... 8 3.1 GENERAL DESCRIPTION OF EUT ............................................................................. 8 3.2 DESCRIPTION OF TEST MODES ............................................................................. 10 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST ........................................................ 11 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ............................. 12 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ............................................ 16 3.4 DESCRIPTION OF SUPPORT UNITS ....................................................................... 17 4. TEST TYPES AND RESULTS (FOR 2.4GHz BAND) ................................................. 18 4.1 RADIATED EMISSION MEASUREMENT .................................................................. 18 4.1.1 LIMITS OF RADIATED EMISSION MEASUREMENT................................................ 18 4.1.2 TEST INSTRUMENTS................................................................................................ 19 4.1.3 TEST PROCEDURES ................................................................................................ 20 4.1.4 DEVIATION FROM TEST STANDARD....................................................................... 20 4.1.5 TEST SETUP.............................................................................................................. 21 4.1.6 EUT OPERATING CONDITIONS ............................................................................... 21 4.1.7 TEST RESULTS ......................................................................................................... 22 4.2 CONDUCTED EMISSION MEASUREMENT ............................................................. 36 4.2.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT........................................... 36 4.2.2 TEST INSTRUMENTS................................................................................................ 36 4.2.3 TEST PROCEDURES ................................................................................................ 37 4.2.4 DEVIATION FROM TEST STANDARD....................................................................... 37 4.2.5 TEST SETUP.............................................................................................................. 38 4.2.6 EUT OPERATING CONDITIONS ............................................................................... 38 4.2.7 TEST RESULTS ......................................................................................................... 39 4.3 6dB BANDWIDTH MEASUREMENT.......................................................................... 43 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT ....................................................... 43 4.3.2 TEST INSTRUMENTS................................................................................................ 43 4.3.3 TEST PROCEDURE................................................................................................... 43 4.3.4 DEVIATION FROM TEST STANDARD....................................................................... 43 4.3.5 TEST SETUP.............................................................................................................. 44 4.3.6 EUT OPERATING CONDITIONS ............................................................................... 44 4.3.7 TEST RESULTS ......................................................................................................... 45 4.4 MAXIMUM OUTPUT POWER .................................................................................... 49 Report No.: RF991206C18 3 Report Format Version 4.0.0 4.4.1 LIMITS OF MAXIMUM OUTPUT POWER MEASUREMENT..................................... 49 4.4.2 INSTRUMENTS .......................................................................................................... 49 4.4.3 TEST PROCEDURES ................................................................................................ 49 4.4.4 DEVIATION FROM TEST STANDARD....................................................................... 50 4.4.5 TEST SETUP.............................................................................................................. 50 4.4.6 EUT OPERATING CONDITIONS ............................................................................... 50 4.4.…

Text truncated - open the document above for the full version.

Report No.: RF991206C18-1 1 Report Format Version 4.0.0 FCC TEST REPORT (15.407) REPORT NO.: RF991206C18-1 MODEL NO.: MBR1400 FCC ID: UXX-MBR1400 RECEIVED: Dec. 06, 2010 TESTED: Dec. 10 ~ Dec. 22, 2010 ISSUED: Dec. 24, 2010 APPLICANT: Cradlepoint, Inc. ADDRESS: 1199 Shoreline Lane, Suite 301 Boise, ID 83702 ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien 244, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 73 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval or endorsement by TAF or any government agency. The test results in the report only apply to the tested sample. Report No.: RF991206C18-1 2 Report Format Version 4.0.0 TABLE OF CONTENTS RELEASE CONTROL RECORD.............................................................................................. 4 1. CERTIFICATION........................................................................................................... 5 2. SUMMARY OF TEST RESULTS .................................................................................. 6 2.1 MEASUREMENT UNCERTAINTY................................................................................ 6 3. GENERAL INFORMATION ........................................................................................... 7 3.1 GENERAL DESCRIPTION OF EUT ............................................................................. 7 3.2 DESCRIPTION OF TEST MODES ............................................................................... 8 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST .......................................................... 9 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ............................. 10 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ............................................ 12 3.4 DESCRIPTION OF SUPPORT UNITS ....................................................................... 13 4. TEST TYPES AND RESULTS .................................................................................... 14 4.1 RADIATED EMISSION MEASUREMENT .................................................................. 14 4.1.1 LIMITS OF RADIATED EMISSION MEASUREMENT................................................ 14 4.1.2 LIMITS OF UNWANTED EMISSION OUT OF THE RESTRICTED BANDS .............. 14 4.1.3 TEST INSTRUMENTS................................................................................................ 15 4.1.4 TEST PROCEDURES ................................................................................................ 16 4.1.5 DEVIATION FROM TEST STANDARD....................................................................... 16 4.1.6 TEST SETUP.............................................................................................................. 17 4.1.7 EUT OPERATING CONDITION.................................................................................. 17 4.1.8 TEST RESULTS ......................................................................................................... 18 4.2 CONDUCTED EMISSION MEASUREMENT ............................................................. 28 4.2.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT........................................... 28 4.2.2 TEST INSTRUMENTS................................................................................................ 28 4.2.3 TEST PROCEDURES ................................................................................................ 29 4.2.4 DEVIATION FROM TEST STANDARD....................................................................... 29 4.2.5 TEST SETUP.............................................................................................................. 30 4.2.6 EUT OPERATING CONDITIONS ............................................................................... 30 4.2.7 TEST RESULTS ......................................................................................................... 31 4.3 PEAK TRANSMIT POWER MEASUREMENT ........................................................... 35 4.3.1 LIMITS OF PEAK TRANSMIT POWER MEASUREMENT ......................................... 35 4.3.2 TEST INSTRUMENTS................................................................................................ 35 4.3.3 TEST PROCEDURE................................................................................................... 36 4.3.4 DEVIATION FROM TEST STANDARD....................................................................... 36 4.3.5 TEST SETUP.............................................................................................................. 36 4.3.6 EUT OPERATING CONDITIONS ............................................................................... 36 4.3.7 TEST RESULTS ......................................................................................................... 37 Report No.: RF991206C18-1 3 Report Format Version 4.0.0 4.4 PEAK POWER EXCURSION MEASUREMENT ........................................................ 41 4.4.1 LIMITS OF PEAK POWER EXCURSION MEASUREMENT...................................... 41 4.4.2 TEST INSTRUMENTS................................................................................................ 41 4.4.3 TEST PROCEDURE................................................................................................... 41 4.4.4 DEVIATION FROM TEST STANDARD....................................................................... 42 4.4.5 TEST SETUP.............................................................................................................. 42 4.4.6 EUT OPERATING CONDITIONS ................…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION FOR 2.4GHz CONDUCTED EMISSION TEST TEST MODE A 2 CONDUCTED EMISSION TEST TEST MODE B 3 RADIATED EMISSION TEST TEST MODE A 4 RADIATED EMISSION TEST TEST MODE B 5 FOR 5.0GHz CONDUCTED EMISSION TEST TEST MODE A 6 CONDUCTED EMISSION TEST TEST MODE B 7 RADIATED EMISSION TEST TEST MODE A 8 RADIATED EMISSION TEST TEST MODE B
