UXX-PHS2000WTableRock

Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designedto provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different fromthat to which the receiver is connected. •Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation issubject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Caution: Any changes or modifications not expressly approvedby the party responsible for compliance could void the user's authority to operate this equipment. IEEE 802.11b or 802.11g operation of this product in the U.S.A. is firmware-limited to channels 1 through 11. IMPORTANT NOTE: FCC Radiation Exposure Statement: The product comply with the US portable RF exposure limit set forth for an uncontrolled environment and are safe for intended operation as described in this manual. The further RF exposure reduction can be achieved if the product can be kept asfar as possible from the user body or reduce output power if it doesn't affect the transmission/receiving quality. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Due to the essential high output power natural of WiMAXdevice, use of this device with other transmitter at the same time may exceed the FCC RF exposure limit and such usage must be prohibited (unless such co-transmission has been approved by FCC in the future).

805 W. Franklin Street
Boise, ID
83702 F C C G E N E R A L D E C L A R A T I O N FCC ID: UXX-PHS2000W Date: 01.13.2011 To whom it may concern: We, CradlePoint, Inc., declare the PHS2000 does not have “Ad Hoc on non-US frequencies” and/or “on DFS frequencies” Sincerely, __________________________________ Steven T. Wood / Vice President of R&D CradlePoint, Inc. Telephone: (208) 424-5054 Facsimile: (208) 429-6852 Email: [email protected]

805 W. Franklin Street
Boise, ID
83702 Date: 01.17.2011 To whom it may concern: We CradlePoint, Inc. declare that Product: Battery-Powered WiFi/WiMAX Router Brand: CradlePoint Model Name: PHS2000W By FCC ID: UXX-PHS2000W hardware configuration, the maximum ratio of DL:UL is 29:18. That means it cannot support the higher ratio than 29:18, for example, 26:21. The ratio cannot be modified to higher ratio than 29:18 by any method. Sincerely, __________________________________ Steven T. Wood / Vice President of R&D CradlePoint, Inc. Telephone: (208) 424-5054 Facsimile: (208) 429-6852 Email: [email protected]

805 W. Franklin Street
Boise, ID
83703 Date: 02.17.2011 ATTESTATION LETTER To whom it may concern: The product, FCC ID: UXX-PHS2000W, is designed and limited in the firmware such that the built-in WiMAX cannot co-transmit at same time as an attached, external 3G dongle device. Only one modem/radio can be enabled at a time as described in page 11 of the u ser manual. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely, __________________________________ Steven T. Wood / Vice President of R&D CradlePoint, Inc. TEL(208) 424-5054 Facsimile(208) 429-6852 Email: [email protected]

805 W. Franklin Street
Boise, ID
83702 2011/1/17 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request FCC ID: UXX-PHS2000W Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Block Diagram Schematics Operational Description Parts list Tune up procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Steven T. Wood / Vice President of R&D CradlePoint, Inc. TEL: (208) 424-5054 Facsimile: (208) 429-6852 Email: [email protected]

805 W. Franklin Street
Boise, ID
83702 P O W E R O F A T T O R N E Y 01.17.2011 To whom it may concern: We, the undersigned Cradlepoint, Inc. hereby authorize Bureau Veritas Consumer Product Service (Hong Kong) Limited, Taoyuan Branch of Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 27M & Part 15C approval and any communication needed with the national authority. Any and all acts carried out by Bureau Veritas Consumer Product Service (Hong Kong) Limited, Taoyuan Branch on our behalf shall have the same effects as acts of our own. This authorization is limited to the following products： FCC ID: UXX-PHS2000W If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely, __________ _ Steven T. Wood / Vice President of R&D CradlePoint, Inc. TEL: (208) 424-5054 Facsimile: (208) 429-6852 Email: [email protected]

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 3 Page 4 Page 5

(Fig.1) FCC ID: UXX-PHS2000W FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. Back Side : LABEL

SSID: PHS2000W-38c Password: e002e38c Made in Taiwan FCC ID:UXX-PHS2000W RoHS 5V with some n features WiMAX MAC Address : 003044009B4E P/N : PHS2000W Model: PHS2000W MFG DATE: NOV 2010 H/W: 1.0 S/N : MM100092800003 Tablerock product label without IC ID

Page 6 Page 7 Page 8 Page 9 Page 10 Page 11 Page 12 Page 13 Page 14 Page 15 Page 16

APPENDIX D: SYSTEM CERTIFICATE & CALIBRATION D1: PHANTOM D2: DOSIMETRIC E-FIELD PROBE

D4: SYSTEM VALIDATION DIPOLE

1 PHOTOGRAPHS OF THE TEST CONFIGURATION (SAR Test Set Up Photos) Back edge Front edge Top Bottom Right edge Left edge 2 Antenna Location Test Set Up

香港商立德國際商品試驗有限公司桃園分公司 Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch No simultaneous SAR justification for FCC ID: UXX-PHS2000W The device has WiFi and WiMAX function and supports external 3G dongle. Simultaneous transmission mode for the device is as below 1. WiFi + WiMAX 2. WiFi + external dongle WiMAX and external dongle can Not work at the same time. WIFI and WiMAX Simultaneous Transmission Configurations WiFi Max. SAR (W/Kg ) (1g) WiMAX Max. Scaled SAR (W/Kg ) (1g)    all SAR 1g (W/Kg ) (1g) 1 WiFi antenna 1+ WiMAX antenna 1 0.038 0.213 0.251 2 WiFi antenna 1+ WiMAX antenna 2 0.038 0.370 0.408 3 WiFi antenna 2+ WiMAX antenna 1 0.015 0.213 0.228 4 WiFi antenna 2+ WiMAX antenna 2 0.015 0.370 0.385 Since the sum of SAR value is less than 1.6 W/kg, therefore simultaneous Transmission SAR for WiFi and WiMAX is not required WIFI and external dongle Simultaneous Transmission Configurations WiFi SAR (W/Kg )(1g) External dongle (W/Kg ) (1g) Separation distance(cm) SPLSR xy 5 WiFi antenna 1+ External dongle 0.038 1.6 11.4* 0.14 6 WiFi antenna 2+ External dongle 0.015 1.6 12.1* 0.13 *Please check plots of P2 Since the SPLSR xy is less than 0.3, therefore simultaneous Transmission SAR for WiFi and external dongle is not required 香港商立德國際商品試驗有限公司桃園分公司 Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch WiFi antenna 1 test plot WiFi antenna 2 test plot Combined test plot
