UXX-S5A103A5G Adapter

W2000 Series Indoor 5G Wideband Adapter Quick Start Guide Introduction This document provides a brief overview of the W2000 indoor 5G Wideband adapter, discusses what's inside the box, and provides basic set up and install instructions. Intended Audience This article is intended for general Cradlepoint hardware users. It provides a basic knowledge for setting up the W2000 indoor 5G Wideband adapter. Due to the unique nature of each installation, potential for RF exposure, and enhanced separation requirements, customers must have a professional install their 5G hardware. Refer to the Professional Installer Network section of this document for assistance in locating a professional installer. Professional Installer Network Email our Professional Installer Network for assistance in locating a professional installer in your service area at <TBD>@cradlepoint.com. Navigation Use the following links to quickly navigate through this quick start guide. Introduction ....................................................................................................................................... 1 Intended Audience ............................................................................................................................ 1 Professional Installer Network ......................................................................................................... 1 W2000 Indoor 5G Wideband Adapter Models................................................................................. 2 Before You Begin .............................................................................................................................. 3 Location Considerations....................................................................................................................................... 3 Ethernet Cable Considerations ............................................................................................................................. 3 SIM Card Setup for Wireless Connectivity .......................................................................................................... 3 Check Box for Contents .................................................................................................................... 3 Activate the Adapter Through NetCloud Manager ......................................................................... 4 Understanding LEDs ......................................................................................................................... 4 Troubleshooting ................................................................................................................................ 7 Resources ........................................................................................................................................... 7 Help and Support .............................................................................................................................. 7 Terms of Service ................................................................................................................................ 7 W2000 Indoor 5G Wideband Adapter Models This guide applies to the following products: CRADLEPOINT W2000-5GA MODEL: S5A010A CRADLEPOINT W2000-5GB MODEL: S5A103A Before You Begin Read the following before setting up your W2000 indoor 5G Wideband adapter. Location Considerations The W2000 Indoor 5G Wideband adapter is purpose-built for indoor mounting and should be installed by a professional. The following includes considerations when identifying a location for mounting. • Ensure that the mounting surface is flat and clear of any obstructions or objects that may interfere with the antennas, signal reception, or cables. • Position the endpoint for optimal cellular and Wi-Fi signal reception. • Avoid mounting in direct sunlight or in locations where it may be exposed to the weather. • Ensure plenty of airflow for ventilation. • Mount in locations compliant with the Safety, Regulatory, and Warranty guide, included in the product shipping box. IMPORTANT: The W2000 indoor 5G Wideband adapter requires increased separation distances in relation to other networking hardware. Therefore, Cradlepoint requires that all 5G adapters be installed by a professional. For assistance with installation or in locating a professional installer, contact Cradlepoint Sales and Support. Ethernet Cable Considerations Cradlepoint recommends shielded, twisted-pair (S/FTP) Ethernet network cabling and connectors (Cat5/Cat6/Cat6a/Cat7a) for optimal wired network performance. SIM Card Setup for Wireless Connectivity A wireless broadband data plan must be added to your Cradlepoint W2000 for wireless broadband connectivity. Network providers, such as AT&T, Verizon, and Telstra, must provision a SIM to provide wireless broadband data plans compatible for use with the Cradlepoint W2000 indoor 5G Wideband adapter endpoints. Contact your network provider for further details. Check Box for Contents Prior to having the W2000 indoor 5G Wideband adapter installed, open the boxes and ensure that all items are present. You should have received the following: • Box 1 - Hardware Only: o [1] W2000 indoor 5G Wideband adapter hardware • Box 2 - Accessories Kit: o [1] 90 W PoE Injector o [4] Cellular antennas o [1] Indoor mounting kit o [1] Screw pack o [1] Safety, Regulatory, and Warranty guide o [1] Quick Start reference sheet Once you ensure all required hardware is present, have a professional install your W2000 indoor 5G Wideband adapter. Activate the Adapter Through NetCloud Manager Once the adapter is installed, it will need to be activated in NetCloud Manager (NCM). Your endpoint is packaged with NetCloud services and activation requires that you log into your NetCloud account. Refer to Getting Started with NetCloud Manager for more information. Understanding LEDs Refer to the following for information about the LED indicators on the Cradlepoint W2000 indoor 5G …

Text truncated - open the document above for the full version.

W2000 Series Indoor 5G Wideband Adapter Professional Installation Guide Introduction This document provides a brief overview of the W2000 indoor 5G Wideband adapter, discusses what's inside the box, and provides basic set up and install instructions. Disclaimer Cradlepoint, Inc. (“Cradlepoint”) does not warrant that the hardware will work properly in all environments or applications, and makes no warranty or representation, either implied or expressed, with respect to the quality, performance, merchantability, or fitness for a particular purpose of the W2000 indoor 5G Wideband adapter even when installed in accordance with this Professional Installation Guide. This Professional Installation Guide is provided “AS IS,” without any warranty of any kind. Without limiting the foregoing, to the maximum extent permitted by applicable law Cradlepoint expressly disclaims all representations, warranties and conditions, whether express, implied, statutory, or otherwise, with respect to this Professional Installation Guide, including without limitation any warranty of title, non-infringement, merchantability or fitness for a particular purpose. While Cradlepoint has made every effort to ensure this Professional Installation Guide is accurate, Cradlepoint disclaims liability for any inaccuracies or omissions that may have occurred and shall not be liable for any adverse results caused, in whole or in part, by the installer’s reliance upon the instructions in this Professional Installation Guide. Information in this Professional Installation Guide is subject to change without notice and does not represent a commitment on the part of Cradlepoint. Cradlepoint assumes no responsibility for any inaccuracies that may be contained in this Professional Installation Guide. Cradlepoint makes no commitment to update or keep current the information in this Professional Installation Guide and reserves the right to make improvements to this Professional Installation Guide and/or to the products described in this Professional Installation Guide, at any time without notice. If you find information in this Professional Installation Guide that is incorrect, misleading, or incomplete, we would appreciate your comments and suggestions. Intended Audience This article is intended for professional networking hardware installers. It provides basic knowledge and should be used only as a reference guide for installing the W2000 indoor 5G Wideband adapter. Due to the unique nature of each installation, potential for RF exposure, and enhanced separation requirements, customers must have a professional install their 5G hardware. This document is a reference guide and is intended only to provide best practices. Installer Responsibility Cradlepoint hereby disclaims any liability for failure of the installer to install the hardware properly and for any other acts and omissions of the installer. By using this Professional Installation Guide, you agree to indemnify and hold Cradlepoint harmless from and against any and all, liabilities, losses, damages, costs and expenses (including without limitation attorneys’ fees and costs) incurred by Cradlepoint arising out of or in connection with any installation work that is done other than in accordance with the instructions in this Professional Installation Guide. Limitation of Liability TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT WILL CRADLEPOINT BE LIABLE TO YOU OR TO ANYONE CLAIMING THROUGH OR UNDER YOU FOR ANY LOST PROFITS, EQUIPMENT DOWNTIME, OR LOSS OF DATA OR BUSINESS OPPORTUNITY, OR FOR ANY INDIRECT, SPECIAL, EXEMPLARY, INCIDENTAL, CONSEQUENTIAL OR PUNITIVE DAMAGES, HOWEVER CAUSED AND UNDER ANY THEORY OF LIABILITY, ARISING IN ANY WAY IN CONNECTION WITH YOUR INSTALLATION ACTIVITIES, EVEN IF CRADLEPOINT HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. SOME JURISDICTIONS (SUCH AS THE STATE OF NEW JERSEY) DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE EXCLUSION OR LIMITATION MAY NOT APPLY TO YOU. IN NO EVENT SHALL THE AGGREGATE LIABILITY OF CRADLEPOINT AND/OR ITS AFFILIATES ARISING UNDER OR IN CONNECTION WITH THE PRODUCT, HOWEVER ARISING, REGARDLESS OF THE NUMBER OF EVENTS, OCCURRENCES, OR CLAIMS GIVING RISE TO LIABILITY, EXCEED THE PRICE PAID BY THE ORIGINAL PURCHASER OF THE PRODUCT. THE FOREGOING LIMITATIONS WILL APPLY EVEN IF THE ABOVE STATED REMEDY FAILS OF ITS ESSENTIAL PURPOSE. Professional Installer Network Email our Professional Installer Network for assistance in locating a professional installer in your service area at <TBD>@cradlepoint.com. Navigation Use the following links to quickly navigate through this quick start guide. Introduction ....................................................................................................................................... 1 Disclaimer ............................................................................................................................................................ 1 Intended Audience ............................................................................................................................................... 2 Installer Responsibility......................................................................................................................................... 2 Limitation of Liability .......................................................................................................................................... 2 Professional Installer Network ............................................................................................................................. 2 W2000 Indoor 5G Wideband Adapter Models................................................................................. 3 Before You Begin .............................................................................................................................. 4 Location Considerations.........................................…

Text truncated - open the document above for the full version.

W2005 Outdoor 5G Wideband Adapter Quick Start Guide Introduction This document provides a brief overview of the W2005 outdoor 5G Wideband adapter, discusses what's inside the box, and provides basic set up and install instructions. Intended Audience This article is intended for general Cradlepoint hardware users. It provides a basic knowledge for setting up the W2005 outdoor 5G Wideband adapter. Due to the unique nature of each installation, potential for RF exposure, and enhanced separation requirements, customers must have a professional install their 5G hardware. Refer to the Professional Installer Network section of this document for assistance in locating a professional installer. Professional Installer Network Email our Professional Installer Network for assistance in locating a professional installer in your service area at <TBD>@cradlepoint.com. Navigation Use the following links to quickly navigate through this quick start guide. Introduction ....................................................................................................................................... 1 Intended Audience ............................................................................................................................ 1 Professional Installer Network ......................................................................................................... 1 W2005 Outdoor 5G Wideband Adapter Models .............................................................................. 2 Before You Begin .............................................................................................................................. 3 Location Considerations....................................................................................................................................... 3 Ethernet Cable Considerations ............................................................................................................................. 3 SIM Card Setup for Wireless Connectivity .......................................................................................................... 3 Check Box for Contents .................................................................................................................... 4 Activate the Adapter Through NetCloud Manager ......................................................................... 4 Connecting Additional Interfaces ..................................................................................................... 4 Understanding LEDs ......................................................................................................................... 5 Troubleshooting ................................................................................................................................ 6 Resources ........................................................................................................................................... 7 Help and Support .............................................................................................................................. 7 Terms of Service ................................................................................................................................ 7 W2005 Outdoor 5G Wideband Adapter Models This guide applies to the following products: CRADLEPOINT W2005-5GA MODEL: S5A009A CRADLEPOINT W2005-5GB MODEL: S5A108A Before You Begin Read the following before setting up your W2005 outdoor 5G Wideband adapter. Location Considerations The W2005 outdoor 5G Wideband adapter is purpose-built for exterior mounting and should be installed by a professional. The following includes considerations when identifying a location for mounting. • Ensure that the mounting surface clear of any obstructions or objects that may interfere with the antennas, signal reception, or cables. • Position the device for optimal signal reception. • Ensure plenty of airflow for ventilation. • For the W2005 to maintain its rating against hurricane force winds (up to 137mph sustained); the following must be met when pole mounted o The pole on which the W2005 is to be mounted must be metal, hollow, and between 3-10 inches in diameter o From the base of the pole to where the W2005 is mounted can be no higher than 10 feet. • Mount in locations compliant with the Safety, Regulatory, and Warranty guide, included in the product shipping box IMPORTANT: The W2005 outdoor 5G Wideband adapter requires increased separation distances in relation to other networking hardware. Therefore, Cradlepoint requires that all 5G adapters be installed by a professional. For assistance with installation or in locating a professional installer, contact Cradlepoint Sales and Support. Ethernet Cable Considerations Cradlepoint recommends shielded twisted-pair (S/FTP) Ethernet cabling and connectors (Cat6a/Cat7a) for optimal wired network performance. SIM Card Setup for Wireless Connectivity A wireless broadband data plan must be added to your Cradlepoint W2005 for wireless broadband connectivity. Network providers, such as AT&T, Verizon, and Telstra, must provision a SIM to provide wireless broadband data plans compatible for use with the Cradlepoint W2000 and W2005 Branch 5G adapter endpoints. Contact your network provider for further details. The following instructions are intended for network hardware installers. Read through the following to set up your W2005 outdoor 5G Wideband adapter or use the Verify mobile installation app. Check Box for Contents Prior to having the W2005 outdoor 5G Wideband adapter installed, open the boxes and ensure that all items are present. You should have received the following: • Box 1 - Hardware Only: o [1] W2005 Branch Outdoor 5G adapter hardware • Box 2 - Accessories Kit: o [1] 90 W PoE Injector o [4] Outdoor Sub 6 GHz 5G/LTE antennas o [1] Outdoor mounting assembly o [1] Outdoor mounting plate o [3] Pole mount clamps o [4] Plate to assembly mounting screws o [4] Plate …

Text truncated - open the document above for the full version.

W2005 Outdoor 5G Wideband Adapter Professional Installation Guide Introduction This document provides a brief overview of the W2005 outdoor 5G Wideband adapter, discusses what's inside the box, and provides basic set up and install instructions. Disclaimer Cradlepoint, Inc. (“Cradlepoint”) does not warrant that the hardware will work properly in all environments or applications, and makes no warranty or representation, either implied or expressed, with respect to the quality, performance, merchantability, or fitness for a particular purpose of the W2005 outdoor 5G Wideband adapter even when installed in accordance with this Professional Installation Guide. This Professional Installation Guide is provided “AS IS,” without any warranty of any kind. Without limiting the foregoing, to the maximum extent permitted by applicable law Cradlepoint expressly disclaims all representations, warranties and conditions, whether express, implied, statutory, or otherwise, with respect to this Professional Installation Guide, including without limitation any warranty of title, non-infringement, merchantability or fitness for a particular purpose. While Cradlepoint has made every effort to ensure this Professional Installation Guide is accurate, Cradlepoint disclaims liability for any inaccuracies or omissions that may have occurred and shall not be liable for any adverse results caused, in whole or in part, by the installer’s reliance upon the instructions in this Professional Installation Guide. Information in this Professional Installation Guide is subject to change without notice and does not represent a commitment on the part of Cradlepoint. Cradlepoint assumes no responsibility for any inaccuracies that may be contained in this Professional Installation Guide. Cradlepoint makes no commitment to update or keep current the information in this Professional Installation Guide and reserves the right to make improvements to this Professional Installation Guide and/or to the products described in this Professional Installation Guide, at any time without notice. If you find information in this Professional Installation Guide that is incorrect, misleading, or incomplete, we would appreciate your comments and suggestions. Intended Audience This article is intended for professional networking hardware installers. It provides basic knowledge and should be used only as a reference guide for installing the W2005 outdoor 5G Wideband adapter. Due to the unique nature of each installation, potential for RF exposure, and enhanced separation requirements, customers must have a professional install their 5G hardware. This document is a reference guide and is intended only to provide best practices. Installer Responsibility Cradlepoint hereby disclaims any liability for failure of the installer to install the hardware properly and for any other acts and omissions of the installer. By using this Professional Installation Guide, you agree to indemnify and hold Cradlepoint harmless from and against any and all, liabilities, losses, damages, costs and expenses (including without limitation attorneys’ fees and costs) incurred by Cradlepoint arising out of or in connection with any installation work that is done other than in accordance with the instructions in this Professional Installation Guide. Limitation of Liability TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT WILL CRADLEPOINT BE LIABLE TO YOU OR TO ANYONE CLAIMING THROUGH OR UNDER YOU FOR ANY LOST PROFITS, EQUIPMENT DOWNTIME, OR LOSS OF DATA OR BUSINESS OPPORTUNITY, OR FOR ANY INDIRECT, SPECIAL, EXEMPLARY, INCIDENTAL, CONSEQUENTIAL OR PUNITIVE DAMAGES, HOWEVER CAUSED AND UNDER ANY THEORY OF LIABILITY, ARISING IN ANY WAY IN CONNECTION WITH YOUR INSTALLATION ACTIVITIES, EVEN IF CRADLEPOINT HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. SOME JURISDICTIONS (SUCH AS THE STATE OF NEW JERSEY) DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE EXCLUSION OR LIMITATION MAY NOT APPLY TO YOU. THE FOREGOING LIMITATIONS WILL APPLY EVEN IF THE ABOVE STATED REMEDY FAILS OF ITS ESSENTIAL PURPOSE. Professional Installer Network Email our Professional Installer Network for assistance in locating a professional installer in your service area at <TBD>@cradlepoint.com. Navigation Use the following links to quickly navigate through this quick start guide. Introduction ....................................................................................................................................... 1 Intended Audience ......................................................................................... 錯誤! 尚未定義書籤。 Professional Installer Network ...................................................................... 錯誤! 尚未定義書籤。 W2005 Outdoor 5G Wideband Adapter Models .............................................................................. 4 Before You Begin .............................................................................................................................. 4 Location Considerations....................................................................................................................................... 4 Ethernet Cable Considerations ............................................................................................................................. 5 SIM Card Setup for Wireless Connectivity .......................................................................................................... 5 Setup .................................................................................................................................................. 5 STEP 1: Check box contents. ............................................................................................................................... 5 STEP 2: Insert an Activated 2FF-Sized SIM. ...................................................................................................... 6 STEP 3: Attach anten…

Text truncated - open the document above for the full version.

10 December 2020 Document Part: 500044-000 DRAFT SAFETY, REGULATORY, AND WARRANTY GUIDE Cradlepoint W2000-5GB MODEL: S5A103A Cradlepoint W2005-5GB Model: S5A108A This important Safety, Regulatory, and Warranty Guide contains safety, handling, disposal, regulatory, trademark, copyright, and software licensing information. Read all safety information below and operating instructions before using the device to avoid injury. FEDERAL COMMUNICATION COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: • Reorient or relocate the receiving antenna. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Increase the separation between the equipment and receiver. • Consult the dealer or an experienced radio/TV technician for help. Professional installation is required for this device. FCC CAUTION Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Statement For product available in the USA/Canada market, only channel 1-11 can be operated. Selection of other channels is not possible. For W2000-5GB (Model S5A103A) Operation on the 5150-5250 MHz WiFi radios is restricted to indoor use only. For W2005-5GB (Model S5A108A) Because this device is intended to be used outdoors, operation on the 5150- 5250 MHz WiFi radio is permanently disabled. FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance of 38 cm between the radiator and your body. This device and its antennas(s) must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance with FCC multi-transmitter product procedures. To comply with FCC regulations limiting both maximum RF output power and human exposure to RF radiation, the maximum cellular antenna gain must not exceed as below: except when transmit operation in Band 30 is not disabled. (See “FCC LTE Band 30 Notice for installers in USA section in the online user manual at www.cradlepoint.com) Professional installation instruction 1. Installation personal This product is designed for specific application and needs to be installed by a qualified personal who has RF and related rule knowledge. The general user shall not attempt to install or change the setting. 2. Installation location The product shall be installed at a location where the radiating antenna can be kept 38cm (FOR FCC) / 45cm (FOR Canada) from nearby person in normal operation condition to meet regulatory RF exposure requirement. 3. External antenna Use only the antennas which have been approved by the applicant. The non- approved antenna(s) may produce unwanted spurious or excessive RF transmitting power which may lead to the violation of FCC/ISED limit and is prohibited. 4. Installation procedure Please refer to installation manual for the detail. 5. Warning Please carefully select the installation position and make sure that the final output power does not exceed the limit set force in relevant rules. The violation of the rule could lead to serious federal penalty. Instructions d'installation professionnelle 1. Installation : Ce produit est destine a un usage specifique et doit etre installe par un personnel qualifie maitrisant les radiofrequences et les regles s'y rapportant. L'installation et les reglages ne doivent pas etre modifies par l'utilisateur final. 2. Emplacement d'installation : En usage normal, afin de respecter les exigences reglementaires concernant l'exposition aux radiofrequences, ce produit doit etre installe de facon a respecter une distance de 38cm(FOR FCC)/45cm(FOR IC)entre l'antenne emettrice et les personnes. 3. Antenn externe.: Utiliser uniiquement les antennes approuvees par le fabricant. L'utilisation d'autres antennes peut conduire a un niveau de rayonnement essentiel ou non essentiel depassant les niveaux limites definis par FCC/ISED, ce qui est interdit. 4. Procedure d'installation : Consulter le manuel d'utilisation. 5. Avertissement : Choisir avec soin la position d'installation et s'assurer que la puissance de sortie ne depasse pas les limites en vigueur. La violation de cette regle peut conduire a de serieuses penalites federales. INDUSTRY CANADA STATEMENT For indoor use only This device complies with Industry Canada license-exempt RSS standards. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. For product available in the USA/Canada market, only channel 1-11 can be operated. Selection of other channels is not possible. (i)the device for operation in the band 5150-5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mob…

Text truncated - open the document above for the full version.
