E3000‐C18B Branch Router Quick Start Guide ‐ DRAFT Introduction This document provides a brief overview of the E3000‐C18B Branch Router, discusses what's inside the box, and provides basic setup and install instructions. Navigation What's in the Box Hardware Accessories Required Tools Before You Begin Location Considerations SIM Card for Wireless Connectivity Installing an External Modem Setup Understanding LEDs Connecting to NetCloud Troubleshooting Resources Help and Support E300 Branch Router Models What's in the Box  One router with built‐in WiFi and embedded LTE modem  Four LTE universal modem antennas (SMA)  Four (4) external dual‐band, high‐gain WiFi antennas (RP‐SMA)  An AC/DC power adapter  One MC400 modem door screw  Four rubber feet for desk mounting  Screw Pack for wa ll mounting  One LTE Antenna Alignment tool  Two rack mount brackets  Antenna Alignment instructions/Wall Mount Template  Safety, Regulatory, and Warranty Guide Hardware Hardware specifications vary by model type. Accessories To enable cellular connectivity, you will also need at least one activated 2FF‐sized SIM card with an active cellular data plan. Required Tools #0 Philips‐head screwdriver (for LTE modem door cover) Before You Begin Read the following before setting up the E3000‐C18B Branch Router. Location Considerations To ensure the E3000‐C18B operates efficiently, do the following:  Ensure the device is positioned to receive optimal signal. Avoid positioning near concrete walls, metal or reflective surfaces, or any other objects that may interfere with RF reception.  Ensure plenty of ventilation. Avoid installing the device in enclosed spaces.  Do no t install the device in direct exposure to the elements. Extreme heat or cold can and will impact the router's performance.  Refer to the E3000‐C18B Safety, Regulatory, and Warranty Guide (included with your hardware) for more information about location considerations. SIM Card for Wireless Connectivity A wireless broadband data plan must be added to your Cradlepoint E3000‐C18B for wireless broadband connectivity. Wireless broadband data plans are available from wireless carriers such as Verizon, AT&T, Sprint, and T‐Mobile. The SIM card must be activated and provisioned by the carrier. Contact your carrier for details about selectin g a data plan and about the process for provisioning your SIM. Installing an External Modem The E3000‐C18B includes a slot for an additional MC400 LTE modem. This enhanced capability allows for redundancy, advanced configuration, failover, and upgradability. The E3000‐C18B supports both the MC400‐600M or the MC400‐1200M. Refer to the following for more information: Insert Optional MC400 External Modem MC400 Webpage MC400 Spec Sheet MC400 Quick Start Guide Setup Read through the following to set up your E3000‐C18B Branch Router. 1. Insert an Activated SIM. a. If setting up cellular connectivity, do the following: b. Remove the modem door covering the SIM slots. c. Insert an activated 2FF‐sized SIM card with metal contacts face up and notch in, into the SIM 1 slot. It will click into place. Depress again to remove, if necessary. d. Insert a secondary/backup, activated SIM card into the SIM 2 slot, if desired. e. Replace the modem door an d secure with the modem door screw. NOTE: The modem door cover must be on the device or the embedded modem will not power on. 2. Insert Optional External MC400 Modem. The E3000‐C18B has a slot for second, removable modem (MC400). Before the E3000‐C18B can be set up, the additi onal modem must be installed. To install this modem, do the following: a. Insert an activated 2FF‐sized SIM card into the MC400 modem, metal contacts down, notch end first. b. Remove the modem door on the E3000‐C18B device. c. Slide the MC400 modem into the available modem slot, US B plug first, with the Cradlepoint logo facing up. d. Replace the MC400 modem door cover. NOTE: Remove the plastic SMA covers from the modem door cover for the additional antenna ports on the modem. e. Secure with the door cover screw. 3. Attach the Antennas. Attach the cellular modem antennas ( included) to the connectors. a. Hold the antenna straight and twist the base of the antenna to connect to the device, folding the joint if needed. NOTE: Do not over‐tighten. The maximum recommended torque is 4 in‐lbs. b. Angle the antennas for optimal signal reception. 4. Connect the Po wer Source a. Connect the power supply to the router and then plug the provided power supply into an electrical outlet. b. Switch the device to ON (O = OFF, – = ON). The LED lights will begin lighting up. Once the E3000‐C18B is powered on, log into your Ne tCloud account and configure the device. Refer to the Connecting to NetCloud section of this document for more information. Understanding LEDs INDICATOR BEHAVIOR POWER: The Cradlepoint E3000‐C18B must be powered using an approved 54 VDC power source.  Green = Powered On.  No Light = Not receiving power. Check the power switch and the power source connection.  Amber = Attention. Open the administration pages and check the router status. VPN VPN: Indicates status of VPN connection.  Blue = Connected to an active VPN.  Green = Router is connected to remote modem via WAN (captive modem) REMOVABLE MODEM: Indicates the status of removable LTE modem(s).  Green = Modem has established an active connection.  Blinking Green = Modem is connecting.  Blinking Amber = Data connection error. No modem connection possible.  Blinking Red = Modem is in the process of resetting. WiFi BROADCAST: Indicates activity on the WiFi broadcast for both 2.4 GHz and 5 GHz bands.  Blue = WiFi is on and operating normally.  No Light = WiFi is not operating. SIGNAL STRENGTH: LED bars indicate the active modem’s signal strength (only for embedded and removable modems). When the embedded modem is active, the bars will be blue. When the removable modem is active, the bars will be green. When the remote (captive) modem is active, the…
