UYXRSK2012-02Throwbot XT

©2012 ReconRobotics 17 Warranty The Manufacturer’s Warranty documentation is enclos ed with all new product shipments and is available online at: http://www.reconrobotics.com/warranty Manual Translations This manual is available in several languages onlin e at: http://www.reconrobotics.com/service/recon-scout_us er_manuals.cfm To Request Service or Repairs Call or e-mail your ReconRobotics representative or reseller to describe the problem you are experiencing and request a Return M aterial Authorization (RMA) tracking number. In addition to your original sales receipt, you will need to provide the unit's serial number, your return shipping addr ess, email address and a daytime telephone number. ReconRobotics, Inc. 7620 West 78th Street Edina, MN 55439 USA 1-866-697-6267 or 952-935-5515 [email protected] Warranty and Service Warranty and Service Throwbot XT Throwbot XT User Manual User Manual Version 1.08 June 2012 R001108 Product Identification This manual applies to the ReconRobotics Throwbot® XT and OCUs. Notice: Changes or modifications not expressly approved by ReconRobotics could void the user’s warranty and could void the user's authority to ope rate the equipment. All materials contained in this document are propri etary and confidential. Reproduction and duplication, without specific writ ten permission, are strictly prohibited. Corporate Headquarters: ReconRobotics, Inc. 7620 West 78th Street Edina, MN 55439 USA Phone: 1-866-697-6267 or 952-935-5515 Fax: 952-935-5508 Email: [email protected] Website: www.reconrobotics.com The devices described within this manual are protec ted under US Patent Numbers 6,548,982, 6,806,346, 7,559,385 a nd other patents pending. Place Serial Number Sticker Here ©2012 ReconRobotics 16
Lithium Polymer batteries are volatile. Only charg e the robot and OCU with chargers provided by ReconRobotics. Failure to do so may cause fire, which could result in personal injury and/or property dam age.
By purchasing the Throwbot XT robot kit, the buyer assumes all risks associated with lithium polymer batteries. If you do not agre e with these conditions, please return the robot kit to ReconRobotics.
Do not attempt to disassemble or modify the robot o r OCU. This may cause an electric shock, fire or system failure.
Do not insert any foreign objects inside the robot or OCU . This may cause electric shock, fire or system failure.
Do not immerse the OCU or chargers into water or liquids. • If water or any liquid enters the inside of the OCU , immediately stop use to avoid electric shock, fire or system failure.
The following describes additional symptoms of a de vice that needs technical attention and should not be used: • After a full charge, the OCU display intermittently turns ON and OFF. • The OCU or charger has been dropped and is malfunct ioning. • There are exposed wires on a charger cable. • The robot , OCU or charger becomes too hot to touch. • There is an unusual sound emitted from any of the c omponents. • There is smoke emitted from any of the components. • There is a burning smell emitted from any of the co mponents. If you have questions or concerns regarding the use or operation of the robot or OCU, discontinue use and contact ReconRobotics or the vendor from whom you purchased your equipment. ©2012 ReconRobotics 15 Safety Information & Warnings Safety Information & Warnings Read these warnings before charging or using your T hrowbot XT robot or OCU. Failure to read and follow these ins tructions may result in fire, personal injury and/or damage to pr operty.
To reduce the risk of electric shock, do not remove the shell of the robot, Operator Control Unit (OCU) or the chargers. No use r-serviceable parts are inside. Refer servicing to qualified ReconRobotics service personnel.
To reduce the risk of injury or damage, keep these safety precautions in mind when setting up, using and maintaining your equipme nt.
Read all safety and operating instructions before o perating the robot or OCU.
Retain the safety and operating instructions for fu ture reference.
Follow all operating and usage instructions.
Do not attempt to service the robot or OCU yourself . Repairs or modifications not conducted by authorized personnel will result i n the voiding of warranty and/or Annual Maintenance Plans.
Keep loose clothing and hair away from the robot.
Considerations for charging: • Always charge the robot with the activation pin ins erted. • Always keep the OCU turned off while charging. • Always charge in a cool, ventilated, fire-safe area . • Do not leave system unattended while charging. • Always use a proper country-specific AC socket (120 -240 VAC) with the AC Dual DC Battery Charger. Do not force the plug i nto a socket. • Ensure the charger plug is inserted at the correct angle when connecting to the robot or OCU. • Ensure the barrel of the charging connector is not deformed, bent or otherwise damaged before inserting in the robot or OCU. FCC Guidelines and Logbook i-iv Throwbot XT Kit Inventory 1 Throwbot XT Robot Components 2 OCU Components 3 OCU Audio/Video-Out Capabilities 4 Quick Start Guide 5 Instructions for Use: Setup 6 Chargers 7 Field Maintenance: Robot 9 OCU 10 Frequently Asked Questions 11 Troubleshooting 12 Safety Information and Warnings 15 Warranty and Service 17 For applicable FCC guidelines, refer to your FCC logbook (US customers only). Table of Contents Table of Contents ©2012 ReconRobotics 1 Throwbot XT Kit Inventory Throwbot XT Kit Inventory Please inspect the contents of this package to ensu re that all materials are present. If any of the materials are missing, please contact [email protected]. Your Throwbot XT Kit includes:
One (1) Throwbot XT or Throwbot XT Audio Robot
One (1) Operator Control Unit (OCU) with lanyard
One (1) Throwbot XT & XT Audio 4-Pin AC Dual DC Bat tery Charger
One (1) Region-Specific AC Power Cable
One (1) Spare Activation Pin
One (1) Tether Kit
One (1)…

Text truncated - open the document above for the full version.

Federal Communications Commission DA 11-675 Before the Federal Communications Commission Washington, D.C. 20554 In the Matter of RECONROBOTICS, INC. Request for Waiver of Part 90 of the Commission’s Rules Petitions for Reconsideration ) ) ) ) ) ) ) ) WP Docket No. 08-63 ORDER ON RECONSIDERATION Adopted: April 13, 2011 Released: April 15, 2011 By the Chief, Wireless Telecommunications Bureau, Chief, Public Safety and Homeland Security Bureau, and Chief, Office of Engineering and Technology: 1.Introduction. This Order on Reconsideration addresses three petitions for reconsideration of an Order by the Wireless Telecommunications Bureau and the Public Safety and Homeland Security Bureau (the Bureaus). 1 The Order granted a request filed by ReconRobotics, Inc. (ReconRobotics) for a waiver of the Commission’s Part 90 rules to permit certification and use of the Recon Scout, a remote-controlled, maneuverable surveillance robot operating in the 420-450 MHz band. W. Lee McVey, 2 Kristopher Kirby, 3 and the American Radio Relay League, Inc. (ARRL) 4 filed petitions for reconsideration. 5 These petitions largely raise issues that were adequately addressed in the original Order. For this and other reasons set forth below, we deny the McVey and Kirby petitions, and deny in part the ARRL petition, but grant ARRL’s request for a modified labeling requirement. 2.Background. In 2008, ReconRobotics filed a request for waiver of Sections 90.101, 90.207 and 90.209 of the Commission’s Rules 6 to permit equipment authorization and customer licensing 1 See ReconRobotics, Inc., Order, WP Docket No. 08-63, 25 FCC Rcd 1782 (WTB/PSHSB 2010) (Order). 2 Petition for Reconsideration of Waiver Grant to ReconRobotics, Inc. (filed Mar. 6, 2010) (McVey Petition). 3 Letter from Kristopher Kirby to Federal Communications Commission (filed Mar. 10, 2010) (Kirby Petition). 4 Petition for Reconsideration (filed Mar. 24, 2010) (ARRL Petition). ARRL also requested that we stay the Order, to prevent the marketing and deployment of the Recon Scout pending the resolution of the petitions for reconsideration. Id. at 1 n.1. Because no applications to authorize operations pursuant to the Order have been granted, seenote 17, infra, we deny the stay request. 5 In addition, James Edwin Whedbee filed a motion to set the Order aside, and related pleadings. Motion to Set Aside, Vacate, or Correct Order by Cancellation of the Waiver Order, Construing the Application Therefor as a Petition for Rulemaking, and Reinstating Proceedings as a Notice of Proposed Rulemaking Consistent with 5 U.S.C. Section 553 (filed Aug. 19, 2010) (Motion). Although Whedbee did not caption his Motion as a petition for reconsideration, we will treat it as such because it clearly seeks review of the Order.See Nevada Ready Mix Corp., Order on Reconsideration and Order Proposing Modification, 24 FCC Rcd 4648, 4649 ¶ 7 (WTB MD 2009) (citing Jack Gerritsen, Memorandum Opinion and Order, 20 FCC Rcd 4273, 4273 n.3 (EB 2005); Redlands Municipal Airport, Order on Reconsideration, 20 FCC Rcd 14782, 14782 ¶ 4 (WTB PSCID 2005)). The Order was released on February 23, 2010, so petitions for reconsideration were due thirty days later, on March 25, 2010. See 47 C.F.R. § 1.106(f). We therefore agree with ReconRobotics that the Motion should be dismissed as untimely. See Opposition to Motion to Set Aside at 1 (filed Aug. 20, 2010). 6 See47 C.F.R. §§ 90.101 (limiting Part 90 use of 420-450 MHz to radiolocation), 90.207 (modulation), 90.209 (bandwidth). Federal Communications Commission DA 11-675 2 for the Recon Scout, and its use by state and local public safety agencies, and security personnel in critical infrastructure industries. The Recon Scout can be thrown, dropped, or launched into potentially hazardous areas, and transmits real-time video surveillance data back to the operator on frequencies on one of three channels: 430-436 MHz, 436-442 MHz, and 442-448 MHz. 7 A waiver was required to permit the device to transmit surveillance data in the 420-450 MHz band, which is allocated to the federal radiolocation service on a primary basis, and to the amateur service and certain non-federal radiolocation systems on a secondary basis. 8 3.The Bureaus sought comment on the waiver request. 9 In response, over seventy comments were filed. Generally, public safety and law enforcement entities commented in support of the waiver request, and amateur radio commenters (including ARRL, but not the other petitioners) opposed it. 10 4.After consideration of the record, the Bureaus granted the request pursuant to Section 1.925(b)(3)(i) of the Commission’s rules, which provides authority to grant a waiver if the underlying purpose of the rule(s) would not be served or would be frustrated by application to the instant case, and grant of the requested waiver would be in the public interest. 11 The Bureaus concluded that the underlying purpose of the rules would not be served by strict application because the Recon Scout was not likely to cause interference to other services, and ReconRobotics acknowledged that the Recon Scout would operate on a secondary basis to other users. 12 The Bureaus held that grant of the request would be in the public interest because it would improve officer safety in many high-risk situations with a likelihood of death or serious harm. 13 They acknowledged commenters’ concerns that interference to the Recon Scout from higher power sources could impair its reliability, but concluded that the possibility of such interference in some instances was not a reason to prohibit its use in all instances. 14 5.Consequently, the Bureaus granted the waiver request, subject to certain conditions. 15 The number of units to be sold was limited to 2,000 during the first year following equipment approval, and 8,000 during the second year. The first unit to be sold to a responding organization must operate on 436-442 MHz, with the 442-448 MHz version being sold only to entities that already…

Text truncated - open the document above for the full version.

Federal Communications Commission Washington, D.C. 20554 February 6, 2012 DA 12-138 Mitchell Lazarus Fletcher, Heald & Hildreth, PLC 1300 North 17th Street, 11th floor Arlington, VA 22209 Dear Mr. Lazarus: This letter responds to your January 11, 2012 request 1 on behalf of ReconRobotics, Inc. (ReconRobotics)regarding the limit on sales of the Recon Scout, a surveillance robot that uses the 430- 448 MHz segment of the 420-450 MHz band. For the reasons set forth below, we grant the request to the extent indicated. In 2010, the Wireless Telecommunications Bureau and Public Safety and Homeland Security Bureau (the Bureaus) granted ReconRobotics a waiver to permit equipment authorization and customer licensing of the Recon Scout. 2 The Bureaus limited sales to 2,000 units during the first year following equipment approval and 8,000 units during the second year, and indicated that they would consider limits for later years upon a subsequent request from ReconRobotics. 3 ReconRobotics, which obtained equipment authorization for the Recon Scout on April 22, 2010, 4 now requests that it be permitted to sell up to 8,000 units during the third and fourth years following equipment authorization, with unused limits from prior years carried forward to any subsequent year. Applications for customer licensing of the Recon Scoutremain pending, but ReconRobotics states that it has received no complaints of verified interference from operation of Recon Scouts pursuant to an experimental license. 5 We conclude that we need not revisit the Recon Scout sales limit every two years. Consequently, we now establish an annual limit of 8,000 units, with a rollover of unused sales. 6 All other conditions of the waiver continue to apply. Accordingly, IT IS ORDERED that the request of ReconRobotics, Inc., dated January 11, 2012, IS GRANTED to the extent indicated. 1 Letter dated Jan. 11, 2012 from Mitchell Lazarus, counsel for ReconRobotics, Inc. to Rick Kaplan, Chief, Wireless Telecommunications Bureau, and James Arden Barnett, Jr., Chief, Public Safety and Homeland Security Bureau. 2 See ReconRobotics, Inc., Order, 25 FCC Rcd 1782 (WTB/PSHSB 2010), aff’d, 26 FCC Rcd 5895 (WTB/PSHSB/OET 2011). 3 Id.at 1787 ¶ 11. 4 FCC ID URXYSK2010-01. ReconRobotics obtained equipment authorization for another version of the Recon Scout on October 19, 2011. FCC ID URXYSK2011-01. The sales limit applies to overall sales of all versions of the Recon Scout. 5 Call Sign WE2XCL. 6 If ReconRobotics later finds this to be insufficient, it may request that the limit be increased or eliminated. Page 2 This action is taken under delegated authority pursuant to Sections 0.131 and 0.331 of the Commission’s Rules, 47 C.F.R. §§ 0.131, 0.331. FEDERAL COMMUNICATIONS COMMISSION Scot Stone Deputy Chief, Mobility Division Wireless Telecommunications Bureau

Federal Communications CommissionDA 10-291 Before the Federal Communications Commission Washington, D.C. 20554 In the Matter of RECONROBOTICS, INC. Request for Waiver of Part 90 of the Commission’s Rules ) ) ) ) ) ) WP Docket No. 08-63 ORDER Adopted: February 22, 2010Released: February 23, 2010 By the Deputy Chief, Wireless Telecommunications Bureau, and Deputy Chief, Public Safety and Homeland Security Bureau: I. INTRODUCTION 1.We have before us a request filed by ReconRobotics, Inc. (ReconRobotics) for waiver of Sections 90.101, 90.207, and 90.209 of the Commission’s Rules to permit equipment authorization and customer licensing under Part 90 of the Commission's Rules 1 for the Recon Scout, which is a remote- controlled, maneuverable surveillance robot designed for use in areas that may be too hazardous for human entry. 2 For the reasons set forth below, we grant the waiver request subject to the conditions specified herein. A waiver is required to permit the device to transmit surveillance data in the 430-448 MHz segment of the 420-450 MHz band, which is allocated to the Federal Radiolocation service on a primary basis, and to the amateur service and certain non-Federal radiolocation systems on a secondary basis. 3 II. BACKGROUND 2.ReconRobotics seeks awaiver to permit equipment certification for the Recon Scout, and its use by state and local law enforcement and firefighting agencies, and security personnel in critical infrastructure industries. 4 The Recon Scout can be thrown, dropped, or launched into potentially hazardous areas and can provide real-time video to an operator located a safe distance away. 5 Typical applications will include checking a building prior to forced entry; searching vehicle undercarriages for explosives; locating hostages, hostiles, officers, and bystanders before a rescue attempt; and searching for survivors in a burning 1 See 47 C.F.R. §§ 90.101 (limiting Part 90 use of 420-450 MHz to radiolocation), 90.207 (modulation), 90.209 (bandwidth). 2 SeeRequest for Waiver (filed Jan. 11, 2008) (Request). 3 See47 C.F.R. §§ 2.106, 90.103(c)(21), 97.303(f). Non-Federal radiolocation stations are secondary to both Federal radiolocation stations and amateur stations. 4 SeeRequest at 1. 5 See id.at 2. ReconRobotics plans to add optional sensors foraudio, biological, chemical, heat, radiation, or other needed data. Federal Communications CommissionDA 10-291 2 building. 6 The Recon Scout is used overseas by the U.S. armed forces, and is credited with saving lives. 7 3.The Recon Scout transmits the analog video signalto the operator on one of three six- megahertz channels:430-436 MHz, 436-442 MHz, and 442-448 MHz. 8 ReconRobotics states that multiple channels are necessary in order to avoid interference during incidents where multiple Recon Scouts are in use, but that such situations should be rare. 9 Itproposes that the first unit sold to a responding organization would operate on 442-448 MHz, with the 436-442 MHz version being sold only to entities that already own the 442-448 MHz version, and the 430-436 MHz version being sold only to entities that already own the 442-448 MHz and 436-442 MHz versions. 10 4.ReconRobotics proposes to limit eligibility to state and local police and firefighters; and security personnel in critical infrastructure industries for use only in areas that are hazardous for entry by human personnel due to nuclear, chemical, or other environmental toxins. 11 Italso proposes other conditions on the waiver to minimize potential interference: use would be limited to actual emergencies involving threats to safety of life, and necessary training related to such operations; and the number of units to be sold would be limited to 2,000 during the first year following equipment approval, and 8,000 during the second year. 12 Italso suggests that the Commission, in collaboration with the National Telecommunications and Information Administration (NTIA), could deny license applications in particular areas as necessary to protect Federal radiolocation facilities. 13 5.Over seventy comments were received in response to the public notice seeking comment on the waiver request. 14 The commenters generally consist of public safety and law enforcement entities 6 Id.at 2, 14. 7 Id.at 2, 6. The military version of the Recon Scout operates in the 430-436 MHz band. See File No. 0056-EX- PL-2007, Section 5.63 Supplementary Statement at 1, Request for Expedited Consideration at 2 n.2. 8 See Request at 3, 10. ReconRobotics states that analog operation is required because a device with a digital transmitter would not be small and light enough to throw; digital video is prone to sudden cut-off at the end of its range, while a weak analog signal is still useful; and use of digital technology would render the device too expensive for many public safety entities. Id.at 4 n.4. 9 Id.at 12. 10 Id.at 3, 12, 15. ReconRobotics proposes to proceed in this sequence in order to provide maximum protection to amateur satellite downlinks in the 435-438 MHz segment. See id.at 3. 11 See id.at 15. Any offer for sale or lease of the device would state these eligibility limits. Id. 12 Id.at 15-16. 13 SeeLetter dated July 30, 2008 from Mitchell Lazarus, Counsel for ReconRobotics, to Marlene H. Dortch, Secretary, Federal Communications Commission, Attachment: Spectrum Analysis for the “Recon Scout” Robot Device at 1. 14 SeeWireless Telecommunications Bureau andPublic Safety and Homeland Security BureauSeek Comment on Request for Waiver by ReconRobotics, Inc. to Allow Certification and Use of Remote-Controlled Surveillance Robot Operating at 430-448 MHz, Public Notice, WP Docket No. 08-63, 23 FCC Rcd 7437 (WTB/PSHSB 2008). In addition, because the 420-450 MHz band is allocated to the Federal Radiolocation service on a primary basis, we have coordinated ReconRobotics’s waiver request with NTIA, which administers authorizations for Federal stations. NTIA’s comments have been placed into the record …

Text truncated - open the document above for the full version.

KBC Networks Limited Date: 2012-9-21 Federal Communications Commission Authorization and Evaluation Division FCC ID: OLXWLM200N5-49 Statement Letter This modular is not able to connect to PC directly for data transmission. Due to above reasons, this device needn’t perform Part 15B DOC testing, and FCC logo shouldn’t be on the label. Your understanding will be highly appreciated. Sincerely, Dwayne Smith /Manager KBC Networks Limited

Throwbot XT External Photos Figure 1: Front View Figure 2: Side View Figure 3: Bottom View FCC Label Goes Here Figure 4: Rear View Figure 5: Top View

(1) EUT Photo (2) EUT Photo (3) EUT Photo (4) EUT Photo (5) EUT Photo (6) EUT Photo (7) EUT Photo (8) EUT Photo (9) EUT Photo

Proposed FCC ID Label Format and Location Applicant: ReconRobotics Model No: Throwbot XT FCC ID: UYXRSK2012-02 Materials: Top Layer: 3.0 MIL VELVET LEXAN OVERLAMINATE W/ PERMANENT ADHESIVE Bottom Layer: 2.0 MIL WHITE-GLOSS POLYESTER W/ PERMANENT ADHESIVE Adhesive: TLP STOCK#606 TRANSFER ADHESIVE W/ PERMANENT ADHESIVE Figure 1: Sample Label Location FCC ID: UYXRSK2012-02 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device does not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device may not interfere with Federal or non-federal stations operating in the 420-450 MHz band and must accept any interference received. FCC ID: UYXRSK2012-02 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device does not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device may not interfere with Federal or non-federal stations operating in the 420-450 MHz band and must accept any interference received.

Recon Scout Circuit Board Photos Figure 1: Video Transmitter (Top) Figure 2: Video Transmitter (Bottom) Figure 3: Blister (Top) Figure 4: Blister (Bottom) Figure 5: Blister In Housing (Top) Figure 6: Blister In Housing (Bottom) Figure 7: FrontBoard (Top) Figure 8: FrontBoard (Bottom) Figure 9: Command Receiver (COTS Product, Top) Figure 10: Command Receiver (COTS Product, Bottom) Figure 11: Main Board (Top) Figure 6: Main Board stacked with COTS Command Receiver

Recon Scout Construction and Components Photos Figure 1: Chassis Back Figure 2: Chassis Front

Certificates and reports shall not be reproduced except in full, without the written permission of Washington Labs, Limited. Maximum Permissible Exposure Evaluation For the Recon Robotics Inc. Recon Scout Throwbot XT FCC ID: UYKSK2012-02 September 17, 2012 WLL Report: 12650-MPE Prepared for: RECON ROBOTICS INC. 7620 W. 78TH STREET E DINA, MN 55439 Prepared by: WASHINGTON LABORATORIES, LTD. 7560 LINDBERGH DRIVE G AITHERSBURG, MARYLAND 20879 Testing Certificate AT-1448 Recon Robotics Inc. Recon Scout Throwbot XT RF Exposure Test Report September, 2012 WLL Report #12650-MPE - ii - © 2012 Washington Laboratories, Ltd. Maximum Permissible Exposure Evaluation For the Recon Robotics Inc. Recon Scout Throwbot XT September 17, 2012 WLL Report # 12650-MPE Prepared by: James Ritter EMC Lab Manager Reviewed by: Steven D. Koster Vice President Recon Robotics Inc. Recon Scout Throwbot XT RF Exposure Test Report September, 2012 Abstract This report has been prepared on behalf of Recon Robotics Inc. Recon Scout Throwbot XT to document the findings of the maximum permissible exposure evaluation on the Recon Robotics Inc. Recon Scout Throwbot XT. The purpose of this evaluation is to establish a minimum safe distance as per the RF exposure requirements as defined in FCC §1.1307 & §1.1310. This report documents the results of testing to the requirements of:  CFR Title 47 Volume 1 Practice and Procedure; (1.1307) Environmental Assessments The Evaluation was performed by Washington Laboratories, Ltd, 7560 Lindbergh Drive, Gaithersburg, MD 20879. Washington Laboratories, Ltd. has been accepted as an EMC Conformity Assessment Body (CAB) under the United States/European Union Memorandum of Agreement. Washington Laboratories, Ltd. is accredited by ACLASS under Testing Certificate AT-1448. Revision History Reason Date Rev 0 Initial Release September 17 , 2012 Recon Robotics Inc. Recon Scout Throwbot XT RF Exposure Test Report September, 2012 Table of Contents Abstract .................................................................................................................................................................... ii 1 Introduction ................................................................................................................................................ 1 2 Requirements .............................................................................................................................................. 1 2.1 Transmitter Categories ............................................................................................................................. 1 2.2 Exposure Categories ................................................................................................................................ 1 3 Device Summary ......................................................................................................................................... 3 4 Radio Frequency Radiation Exposure Evaluation .................................................................................. 3 List of Tables Table 1: MPE Limits ..................................................................................................................................................2 Table 2: Device Summary of the Recon Scout Throwbot XT ....................................................................................3 Table 3: Transmitter MPE Calculation Summary ......................................................................................................3 Recon Robotics Inc. Recon Scout Throwbot XT RF Exposure Test Report September, 2012 WLL Report #12650-MPE - Page 1 of 4 - © 2012 Washington Laboratories, Ltd. 1 Introduction This report has been prepared on behalf of Recon Robotics Inc. Recon Scout Throwbot XT Transmitter to show compliance with the RF exposure requirements as defined in FCC §1.1307. Testing supporting this evaluation was performed at Washington Laboratories, Ltd, 7560 Lindbergh Drive, Gaithersburg, MD 20879. Washington Laboratories, Ltd. has been accepted as an EMC Conformity Assessment Body (CAB) under the United States/European Union Memorandum of Agreement. Washington Laboratories, Ltd. is accredited with ACLASS under Testing Certificate AT-1448. 2 Requirements Three different categories of transmitters are defined by the FCC in OET Bulletin 65. These categories are fixed installation, mobile, and portable. Additionally, the FCC categorizes the use of the devices based on the user’s awareness and the ability to exercise control over his or her exposure. The two categories are defined as Occupational/Controlled Exposure and General Population/Uncontrolled Exposure. 2.1 Transmitter Categories 2.1.1 Fixed Installations A fixed location means that the device, including its antenna, is physically secured at a permanent location and is not able to be easily moved to another location. Additionally, distance to humans from the antenna is maintained to at least 2 meters. 2.1.2 Mobile Devices A mobile device is defined as a transmitting device designed to be used in other than fixed locations and to be generally used in such a way that a separation distance of at least 20 centimeters is normally maintained between the transmitter's radiating structures and the body of the user or nearby persons. Transmitters designed to be used by consumers or workers that can be easily re-located, such as a wireless modem operating in a laptop computer, are considered mobile devices if they meet the 20 centimeter separation requirement. The FCC rules for evaluating mobile devices for RF compliance are found in 47 CFR §2.1091. 2.1.3 Portable Devices A portable device is defined as a transmitting device designed to be used so that the radiating structure(s) of the device is/are within 20 centimeters of the body of the user. Portable device requirements are found in Section 2.1093 of the FCC's Rules (47 CFR§2.1093). 2.2 Exposure Categories The limits for exposure are determi…

Text truncated - open the document above for the full version.

Certificates and reports shall not be reproduced except in full, without the written permission of Washington Laboratories, Ltd. FCC Certification Test Report For the ReconRobotics Inc. Recon Scout Throwbot XT FCC ID: UYXRSK2012-02 WLL Report# 12650-01 Rev 1 September 17, 2012 Prepared for: ReconRobotics Inc. 7620 W. 78th Street Edina, MN 55439 Prepared By: Washington Laboratories, Ltd. 7560 Lindbergh Drive Gaithersburg, Maryland 20879 Testing Certificate AT-1448 ReconRobotics Inc. Recon Scout FCC Certification Test Report August 2012 WLL Report #12650-01 Rev 0 -Page ii - © 2012 Washington Laboratories, Ltd. FCC Certification Test Report For the…
