V2S-TV4LNRemote controller

LED Open Sign Instructions CAUTION To reduce the risk of fire, electric shock or injury to persons: • This product is for indoor use only. Do not use in damp or wet locations. • Not for use with light dimmer circuits. • To reduce the likelihood of injury or damage mount only on a surface that is mechanically sound. • Do not use extension cords or outlets with inadequate current carrying capacity. • It is recommended to use a surge protector. Power surges ARE NOT covered under warranty for this product. • Only use 120VAC input, 60Hz, 18VDC, 1500mA output adaptor. • Do not handle adapter or sign with wet hands. • Disconnect power before handling or cleaning. • Do not use liquid cleaners or aerosol cleaners. Use a dry cloth for cleaning. • This product is fully assembled and ready to use. Do not attempt to disassemble or service. • Do not alter the plug or power supply cord in any way. Installation 1. Remove “S” hooks and chains from the parts bag located within the packaging. 2. Install the two “S” hooks through the hanger tabs located on the top of the open sign. 3. Attach the chains to the “S” hooks. [FIGURE A] 4. Attach the two chains to the ceiling using the appropriate hanging hardware. 5. Insert barrel plug into power input and plug adaptor into the electrical outlet. 6. Remove battery tab on remote. Power Input Volts: 120VAC Hertz: 60Hz Output Amps: 1500mA Output Volts: 18VDC Flash/Remote - Power Switch Switch MUST be positioned to Flash/Remote for remote to function Control Panel on back of sign – [FIGURE C] Item No. 283158 Model No. AA-04-RC FIGURE C Remote [FIGURE B] WARNING: Flash/Remote – Static Switch on control panel MUST be positioned to Flash/Remote for remote to function. Includes one 27A battery. ON / OFF FLASH / STATIC FLASH SPEED Remote range: 32′ with antenna up 12′ with antenna down REPLACEMENT REMOTES: • Only $9.00 each • Free Shipping • Easy to program • To order call 1-877-264-5625 FIGURE B Remove Battery Tab before use Flash Speed Control Push to change speeds (eight speed options) LED Open Sign LIMITED 3 YEAR WARRANTY Model Number : AA-04-RC Part Number: 283158 C-M Glo, LLC warrants that this product will be free from defect due to material and work- manship under normal use for a period of three (3) years from the date of purchase. Please retain receipt for proof of purchase. Proof of purchase is required for any warranty claim. Warranty is void if product is abused, disassembled, or exposed to atmosphere or conditions other than stated within instructions. If product fails within the specified time, return the product to the store where it was purchased or return sign with all accessories, original packing material and a copy of the sales receipt to C-M Glo, LLC. Your sign will be repaired or replaced within six weeks of receipt of your unit. Please ship your sign to: C-M Glo, LLC 1201 N. 4th Street Watertown, WI 53098 (920) 261-1000 DISCLAIMER OF WARRANTY Warranty is invalid if purchaser fails to properly operate and/or maintain the product. This Warranty is not transferable to third parties. There is no warranty for fitness for a particular purpose. This Warranty is in lieu of all other warranties expressed or implied. No representa- tive or any other person is authorized or permitted to make any Warranty changes or assume on behalf of C-M Glo, LLC any liability not strictly in accordance with this Warranty. C-M Glo, LLC shall not be liable for special or consequential loss or damages, direct or indirect, such as, but not limited to, damage or loss of property or equipment, loss of profit or revenue, loss of use of the product, cost or replacement of the product, or claims for service interruptions. Tampering, accident, abuse, negligence, unauthorized repairs, or other causes unrelated to defective materials or workmanship will void this Warranty. This warranty does not cover costs associated with shipping the product to the manufacturer. This warranty does not cover replacement of remote battery. changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. FCC ID: V2S-TV4LN This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

C-M GLO，LLC ____________________________________________________ SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 Revised wording (current) 1.0 2.0 Sept–25-2007 C-M GLO，LLC ____________________________________________________ SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 (September 29, 2010) To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, C-M GLO，LLC hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): (Product description, model name) FCC ID: V2S-TV4LN Product name: remote controller Model: tv4ln We affirm that between SIEMIC and C-M GLO，LLC, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Signature John D. Martin / President Title: President Telephone: 920-261-1000 Email: [email protected] Date: September 29, 2010

To p Vi e w To p Vi e w Bottom View Front View Left View Rear View Right View

FCC ID: V2S-TV4LN

Label Location

Top View Top View ANTENNA Bottom View

The operation of the remote control: 1：Working voltage:DC12V(23A battery,amount:one) 2: Working current:≤10MA 3: Working frequency: 315MHz 4: Encoding type: study code 5: Dimension: 63*26*15MM Operation description: Pull out antenna of handheld remote control and toward controlled device, according to the button instruction, press the button. Now, remote control’s indicating lamp on and send encoding wireless control signal. Free the button, remote control stops working.

123456 A B C D 654321 D C B A Title NumberRevisionSize B Date:24-Sep-2010Sheet of File:C:\Users\admin\Desktop\上海维柏电子科技有限公司\pcb版图\大山电器\subway和鸭蛋open\SUBWAY\控制器和遥控器 PCB\openDrawn By: 315MHZ CRYSTAL L1 PCB INDUCTOR L2 4.5T Q3 S8050 Q1 S8550 SPD F/S R2 10k Q2 2SC3356 VCC 12V VCC 12V C1 5p C2 7p R4 27k R3 47k E1 ANTENNA D1 LED R5 6.2k 1 2 3 45 6 7 8 U1 ZX1527 R6 220K R7 150 C3 0.1UF ON/OFF PDF created with pdfFactory Pro trial version www.pdffactory.com

Shenzhen Certification Technologh Service Co., Ltd 3F, Bldg27,Area A, Tanglang Industrial Zone, Xili Town, Nanshan District, ShenZhen, Guang dong, P.R. China. FCCID: V2S-TV4LN Page 1 of 31 TEST REPORT FCC ID: V2S-TV4LN Applicant : C-M GLO，LLC Address : 1201 North 4 th Street, Watertown, WI 53098 USA Equipment under Test (EUT): Name : remote controller Model : tv4ln Standards : FCC PART 15, SUBPART C : 2008 (Section 15.231) Report No. : STE100927756 Date of Test : October 6-9, 2010 Date of Issue : October 10, 2010 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above Authorized Signature (Mark Zhu) General Manager The manufacture should ensure that all the products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of Shenzhen Certification Technology Service Co., Ltd. Or test done by Shenzhen Certification Technology Service Co., Ltd. Approvals in connection with, distribution or use of the product described in this report must be approved by Shenzhen Certification Technology Service Co., Ltd. Approvals in writing. Report No.:STE100927756 FCCID: V2S-TV4LN Page 2 of 31 TABLE OF CONTENT Description Page 1 General Information------------------------------------------------------------------------------------- 3 1.1 Description of Device (EUT)---------------------------------------------------------------------3 1.2 Description of Test Facility -----------------------------------------------------------------------4 2 EMC Equipment List --------------------------------------------------------------------------------- 4 3 Test Procedure ------------------------------------------------------------------------------------------- 5 4 Summary of Measurement ------------------------------------------------------------------------- 6 Occupied bandwidth -------------------------------------------------------------------------------------- 6 5 Radiation Emission----------------------------------------------------------------------------------- 7 5.1 Duty cycle------------------------------------------------------------------------------------------7 5.2 Radiation Emission Limits(15.209&231)------------------------------------------------- 13 5.3 Test Setup--------------------------------------------------------------------------------------- 13 5.4 Test Procedure--------------------------------------------------------------------------------- 15 5.5 Test Equipment Setting For emission test.est Result--------------------------------- 16 5.6 Test Condition---------------------------------------------------------------------------------- 16 5.7 Test Result-------------------------------------------------------------------------------------- 16 6 Occupied bandwidth -------------------------------------------------------------------------------- 20 6.1 Test limit------------------------------------------------------------------------------------------ 20 6.2 Method of measurement--------------------------------------------------------------------- 20 6.3 Test Setup--------------------------------------------------------------------------------------- 20 6.4 Test Results------------------------------------------------------------------------------------- 20 7 Transmission time ----------------------------------------------------------------------------------- 22 7.1 Test limit------------------------------------------------------------------------------------------ 22 7.2 Method of measurement--------------------------------------------------------------------- 22 7.3 Test Setup--------------------------------------------------------------------------------------- 22 7.4 Test Results------------------------------------------------------------------------------------- 22 8 Band Edge Check------------------------------------------------------------------------------------ 24 8.1 Test limit------------------------------------------------------------------------------------------ 24 Please refer section15.231 and section 15.205.----------------------------------------------- 24 8.2 Test Procedure--------------------------------------------------------------------------------- 24 8.3 Test Setup--------------------------------------------------------------------------------------- 24 8.4 Test Result-------------------------------------------------------------------------------------- 24 9 Antenna Requirement ------------------------------------------------------------------------------ 25 9.1 Standard Requirement----------------------------------------------------------------------- 25 9.2 Antenna Connected Construction---------------------------------------------------------- 25 9.3 Result--------------------------------------------------------------------------------------------- 25 10 Photographs of Test Setup ----------------------------------------------------------------------- 26 11 Photographs of EUT--------------------------------------------------------------------------------- 27 Report No.:STE100927756 FCCID: V2S-TV4LN Page 3 of 31 1 General Information 1.1 Description of Device (EUT) Trade Name : N/A EUT : remote controller Model No. : tv4ln Type of Antenna : Integral Antenna Operation Frequency : 315 MHZ Channel number : 1 Modulation type : ASK Power Supply : DC 12V Supply by battery Rated PF output Power 76.29 dBuV (PK detector) Applicant : C-M GLO，LLC Address : 1201 North 4 th Street, Watertown, WI 53098 USA Manufacturer : Shanghai VIBO Electronics Technology Co., Ltd Address : NO. 6459, PuWei Road, FenXian District, ShangHai PRC Report No.:STE100927756 FCCID: V2S-TV4LN Page 4 of 31 1.2 Description of Test Facility Shenzhen Certification Technology Service Co.,Ltd. 3F, Bldg.27, Area A, Tanglang Industrial Zone, Xili Town,…
