SuzhouHuiMiCommunicationTechnologyCo.,Ltd 1 ProjectName:Pointmobile_TR54_3IN1antennaDocument: Pointmobile_TR54_3IN1antennaApprovalSheet_A Date:2025-04-21Version:A SAMPLE&SPECIFICATIONFORAPPROVAL Customer:CooseaGroupCo.,Ltd ModelNO:TR54 CustomerP/N: Version:V1.0 SpecificationDescribe:TR54-3IN1ANTENNA(Carrier+FPC) VendorP/N: Date:2025-04-21 Address:Room301,Building12No.1001,YuyangRoad,YushanTown,Kunshan City,JiangsuProvince Sampleanddatasheetmustbeapprovedfor5PCS. NoCustomerappointedMaterialAssignPart R&DQESales DepartmentMDHW Qualityand Eng.Dep.Sale&Marketing CheckedBy LIXULiShengHuaLiWeiWeiLiMin ApprovedBy LIXueQinWangJinhuiYeLingYiQin FinalJudgment LiLinHuaLiLinHuaLiLinHuaLiLinHua Remark SuzhouHuiMiCommunicationTechnologyCo.,Ltd 2 ProjectName:Pointmobile_TR54_3IN1antennaDocument: Pointmobile_TR54_3IN1antennaApprovalSheet_A Date:2025-04-21Version:A SuzhouHuiMiCommunicationTechnologyCo.,Ltd AntennaApprovalSheet CustomerPointMobileCo.,Ltd CustomerP/N ModelTR54 P/N DescriptionTR54-3IN1ANTENNA(Carrier+FPC) Frequency Bluetooth:2402MHz-2480MHz WIFI: 2.4G:2412MHz-2472MHz 5G:5180MHz-5700MHz、5745MHz-5825MHz 6G:5955MHz-7115MHz GPS/Galileo:1559MHz-1610MHz InitialDate2025-04-21 RevisionA Author RFEngineerME WangJinhuiSunQuan Tel.1801546768813405120400 Approval R&DPMQE CustomerSignature SuzhouHuiMiCommunicationTechnologyCo.,Ltd 3 ProjectName:Pointmobile_TR54_3IN1antennaDocument: Pointmobile_TR54_3IN1antennaApprovalSheet_A Date:2025-04-21Version:A Catalog 1.Summary ........................................................................................................................................... 4 3.DeviceConditions ....................................................................................................................... 4 4.TestEnvironment ....................................................................................................................... 5 5.AntennaTestResults ............................................................................................................... 5 5.1AntennaPhotos ................................................................................................................... 5 5.2MatchingNetwork ............................................................................................................... 6 5.3VSWR(S11) ....................................................................................................................... 6 5.4Efficiency&PeakGain ......................................................................................................... 7 5.5RadiationPattern ................................................................................................................. 8 6.MechanicalDrawings ................................................................................................................. 9 7.DimensionReport ..................................................................................................................... 10 8.ReliabilityTestReport ...................................................................................................... 11 9.PackingMethod ......................................................................................................................... 12 10．RoHS ........................................................................................................................................... 13 11.Shippinginspectioncriterion .................................................................................................... 14 12.QCProcessChart ........................................................................................................................ 15 13.StorageManagementMethod ................................................................................................. 16 SuzhouHuiMiCommunicationTechnologyCo.,Ltd 4 ProjectName:Pointmobile_TR54_3IN1antennaDocument: Pointmobile_TR54_3IN1antennaApprovalSheet_A Date:2025-04-21Version:A 1.Summary Thisisthe3IN1antennaapprovalsheet. Workingband: Bluetooth:2402MHz-2480MHz WIFI: 2.4G:2412MHz-2472MHz 5G:5180MHz-5700MHz、5745MHz-5825MHz 6G:5955MHz-7115MHz GPS/Galileo:1559MHz-1610MHz 2.Antenna Structure Carrier+FPC 3.Device Conditions Picture1 TR54Mobilephonephoto SuzhouHuiMiCommunicationTechnologyCo.,Ltd 5 ProjectName:Pointmobile_TR54_3IN1antennaDocument: Pointmobile_TR54_3IN1antennaApprovalSheet_A Date:2025-04-21Version:A 4.TestEnvironment Picture2TestEnvironmentphoto 5.AntennaTestResults 5.1AntennaPhotos Picture33IN1antennaphoto SuzhouHuiMiCommunicationTechnologyCo.,Ltd 6 ProjectName:Pointmobile_TR54_3IN1antennaDocument: Pointmobile_TR54_3IN1antennaApprovalSheet_A Date:2025-04-21Version:A 5.2MatchingNetwork Picture4Matchingnetworkof3IN1antenna 5.3VSWR(S11) Frequency(MHz)VSWR 15752.03 24001.1 25001.89 51502.63 71251.79 Picture5VSWRof3IN1antenna SuzhouHuiMiCommunicationTechnologyCo.,Ltd 7 ProjectName:Pointmobile_TR54_3IN1antennaDocument: Pointmobile_TR54_3IN1antennaApprovalSheet_A Date:2025-04-21Version:A 5.4Efficiency&PeakGain Suz hou HuiMi CommunicationTechnologyCo.,Ltd 8 Project Name:Pointmobile_TR54 _3IN1 antennaDocument: Pointmobile_TR54 _3IN1 antenna Approval Sheet_A Date :2025-04-21Ver si on: A 5. 5RadiationPattern

DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.705B Page: 1 of 24 Test report No: 2540846R.705B FCC TEST REPORT Product Name Tablet PC Model and /or type reference TR54,GT40 Trademark N/A FCC ID V2X-TR54 Applicant ́s name / address Point Mobile Co., LTD. A-26F, Building Gasan Publik 178, Digital-ro, Geumcheon-gu Seoul, 08513 Republic of Korea Test method requested, standard 47 CFR FCC Part 15 (Section 15.407) Verdict Summary IN COMPLIANCE Tested By (name / position & signature) Jun Xu/ Project Engineer Approved by (name / position & signature) Frank He/Technical Manager Date of issue 2025-09-01 Report Version V1.0 Report template No Template_FCC Part 15E-RF-V1.0 DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.705B Page: 2 of 24 INDEX page Competences and Guarantees ......................................................................................................................................... 3 General conditions ............................................................................................................................................................ 3 Environmental conditions .................................................................................................................................................. 3 Possible test case verdicts ................................................................................................................................................ 4 Abbreviations..................................................................................................................................................................... 4 Document History .............................................................................................................................................................. 5 Remarks and Comments .................................................................................................................................................. 5 Used Equipment ................................................................................................................................................................ 6 Uncertainty ........................................................................................................................................................................ 7 1 General Information ................................................................................................................................................. 8 1.1 General Description of the Item(s) ................................................................................................................. 8 1.2 Channel List ................................................................................................................................................... 9 1.3 Test Facility .................................................................................................................................................. 10 2 UNII Device Description ......................................................................................................................................... 11 3 Test description ...................................................................................................................................................... 12 3.1 Test Setup .............................................................................................................................................................. 12 3.2 Limits ...................................................................................................................................................................... 13 3.3 Client Device requreiment...................................................................................................................................... 19 3.4 Radar Waveform Calibration.................................................................................................................................. 20 3.5 Radar Waveform Calibration Result ...................................................................................................................... 21 4 Channel Move Time ,Channel Closing Transmission Time and Non-Occupancy Period ..................................... 22 4.1 Test Procedure ...................................................................................................................................................... 22 4.2 Test Requirement .................................................................................................................................................. 22 4.3 Test Result of Channel Move Time ,Channel Closing Transmission Time and Non-Occupancy Period ............. 23 Channel Move Time and Channel Closing Transmission Time: ............................................................................ 23 DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.705B Page: 3 of 24 COMPETENCES AND GUARANTEES DEKRA is a testing laboratory competent to carry out the tests described in this report. In order to assure the traceability to other national and international laboratories, DEKRA has a calibration and maintenance program for its measurement equipment. DEKRA guarantees the reliability of the data presented in this report, which is the result of the measurements and the tests performed to the item under test on the date and under the conditions stated in the report and it is based on the knowledge and technical facilities available at DEKRA at the time of performanc…

Text truncated - open the document above for the full version.

DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 435 / 478 Mode1:Transmit at 5320MHz by 802.11ax(20MHz) with RU26-8 Test Graph Data List NO . Frequenc y [MHz] Reading [dBμV] Level [dBμV/m] Factor [dB/m] Limit [dBμV/m] Margin [dB] Det Pol Verdi ct 1 5350.00 32.04 47.75 15.71 74.00 26.25 PK Horizo ntal PASS 2 5357.68 36.81 52.51 15.70 74.00 21.49 PK Horizo ntal PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 436 / 478 Mode1:Transmit at 5320MHz by 802.11ax(20MHz) with RU26-8 Test Graph Data List NO . Frequenc y [MHz] Reading [dBμV] Level [dBμV/m] Factor [dB/m] Limit [dBμV/m] Margin [dB] Det Pol Verdi ct 1 5350.00 25.69 41.40 15.71 54.00 12.60 AV Horizo ntal PASS 2 5372.38 27.22 42.90 15.68 54.00 11.10 AV Horizo ntal PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 437 / 478 Mode1:Transmit at 5320MHz by 802.11ax(20MHz) with RU26-8 Test Graph Data List NO . Frequenc y [MHz] Reading [dBμV] Level [dBμV/m] Factor [dB/m] Limit [dBμV/m] Margin [dB] Det Pol Verdi ct 1 5350.00 32.71 48.42 15.71 74.00 25.58 PK Vertic al PASS 2 5365.63 36.64 52.33 15.69 74.00 21.67 PK Vertic al PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 438 / 478 Mode1:Transmit at 5320MHz by 802.11ax(20MHz) with RU26-8 Test Graph Data List NO . Frequenc y [MHz] Reading [dBμV] Level [dBμV/m] Factor [dB/m] Limit [dBμV/m] Margin [dB] Det Pol Verdi ct 1 5350.00 26.17 41.88 15.71 54.00 12.12 AV Vertic al PASS 2 5379.56 27.05 42.72 15.67 54.00 11.28 AV Vertic al PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 439 / 478 Mode1:Transmit at 5180MHz by 802.11ax(20MHz) with RU52-37 Test Graph Data List NO . Frequenc y [MHz] Reading [dBμV] Level [dBμV/m] Factor [dB/m] Limit [dBμV/m] Margin [dB] Det Pol Verdi ct 1 5129.63 38.41 53.40 14.99 74.00 20.60 PK Horizo ntal PASS 2 5150.00 35.55 50.66 15.11 74.00 23.34 PK Horizo ntal PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 440 / 478 Mode1:Transmit at 5180MHz by 802.11ax(20MHz) with RU52-37 Test Graph Data List NO . Frequenc y [MHz] Reading [dBμV] Level [dBμV/m] Factor [dB/m] Limit [dBμV/m] Margin [dB] Det Pol Verdi ct 1 5142.74 28.71 43.78 15.07 54.00 10.22 AV Horizo ntal PASS 2 5150.00 28.01 43.12 15.11 54.00 10.88 AV Horizo ntal PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 441 / 478 Mode1:Transmit at 5180MHz by 802.11ax(20MHz) with RU52-37 Test Graph Data List NO . Frequenc y [MHz] Reading [dBμV] Level [dBμV/m] Factor [dB/m] Limit [dBμV/m] Margin [dB] Det Pol Verdi ct 1 5118.93 38.77 53.70 14.93 74.00 20.30 PK Vertic al PASS 2 5150.00 36.04 51.15 15.11 74.00 22.85 PK Vertic al PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 442 / 478 Mode1:Transmit at 5180MHz by 802.11ax(20MHz) with RU52-37 Test Graph Data List NO . Frequenc y [MHz] Reading [dBμV] Level [dBμV/m] Factor [dB/m] Limit [dBμV/m] Margin [dB] Det Pol Verdi ct 1 5129.19 28.95 43.94 14.99 54.00 10.06 AV Vertic al PASS 2 5150.00 28.00 43.11 15.11 54.00 10.89 AV Vertic al PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 443 / 478 Mode1:Transmit at 5500MHz by 802.11ax(20MHz) with RU52-37 Test Graph Data List NO . Frequenc y [MHz] Reading [dBμV] Level [dBμV/m] Factor [dB/m] Limit [dBμV/m] Margin [dB] Det Pol Verdi ct 1 5460.00 38.03 54.37 16.34 68.30 13.93 PK Horizo ntal PASS 2 5468.83 39.66 56.10 16.44 68.30 12.20 PK Horizo ntal PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 444 / 478 Mode1:Transmit at 5500MHz by 802.11ax(20MHz) with RU52-37 Test Graph Data List NO . Frequenc y [MHz] Reading [dBμV] Level [dBμV/m] Factor [dB/m] Limit [dBμV/m] Margin [dB] Det Pol Verdi ct 1 5457.16 28.47 44.78 16.31 54.00 9.22 AV Horizo ntal PASS 2 5460.00 28.30 44.64 16.34 54.00 9.36 AV Horizo ntal PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 445 / 478 Mode1:Transmit at 5500MHz by 802.11ax(20MHz) with RU52-37 Test Graph Data List NO . Frequenc y [MHz] Reading [dBμV] Level [dBμV/m] Factor [dB/m] Limit [dBμV/m] Margin [dB] Det Pol Verdi ct 1 5460.00 38.71 55.05 16.34 68.30 13.25 PK Vertic al PASS 2 5466.11 40.19 56.60 16.41 68.30 11.70 PK Vertic al PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 446 / 478 Mode1:Transmit at 5500MHz by 802.11ax(20MHz) with RU52-37 Test Graph Da…

Text truncated - open the document above for the full version.

DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 326 / 478 11AX20SISO-Ant1-5500-106Tone-RU53-PASS 11AX20SISO-Ant1-5500-106Tone-RU54-PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 327 / 478 11AX20SISO-Ant1-5580-26Tone-RU0-PASS 11AX20SISO-Ant1-5580-26Tone-RU8-PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 328 / 478 11AX20SISO-Ant1-5580-52Tone-RU37-PASS 11AX20SISO-Ant1-5580-52Tone-RU40-PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 329 / 478 11AX20SISO-Ant1-5580-106Tone-RU53-PASS 11AX20SISO-Ant1-5580-106Tone-RU54-PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 330 / 478 11AX20SISO-Ant1-5700-26Tone-RU0-PASS 11AX20SISO-Ant1-5700-26Tone-RU8-PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 331 / 478 11AX20SISO-Ant1-5700-52Tone-RU37-PASS 11AX20SISO-Ant1-5700-52Tone-RU40-PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 332 / 478 11AX20SISO-Ant1-5700-106Tone-RU53-PASS 11AX20SISO-Ant1-5700-106Tone-RU54-PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 333 / 478 11AX20SISO-Ant1-5745-26Tone-RU0-PASS 11AX20SISO-Ant1-5745-26Tone-RU8-PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 334 / 478 11AX20SISO-Ant1-5745-52Tone-RU37-PASS 11AX20SISO-Ant1-5745-52Tone-RU40-PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 335 / 478 11AX20SISO-Ant1-5745-106Tone-RU53-PASS 11AX20SISO-Ant1-5745-106Tone-RU54-PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 336 / 478 11AX20SISO-Ant1-5785-26Tone-RU0-PASS 11AX20SISO-Ant1-5785-26Tone-RU8-PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 337 / 478 11AX20SISO-Ant1-5785-52Tone-RU37-PASS 11AX20SISO-Ant1-5785-52Tone-RU40-PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 338 / 478 11AX20SISO-Ant1-5785-106Tone-RU53-PASS 11AX20SISO-Ant1-5785-106Tone-RU54-PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 339 / 478 11AX20SISO-Ant1-5825-26Tone-RU0-PASS 11AX20SISO-Ant1-5825-26Tone-RU8-PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 340 / 478 11AX20SISO-Ant1-5825-52Tone-RU37-PASS 11AX20SISO-Ant1-5825-52Tone-RU40-PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 341 / 478 11AX20SISO-Ant1-5825-106Tone-RU53-PASS 11AX20SISO-Ant1-5825-106Tone-RU54-PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 342 / 478 DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 343 / 478 Appendix H: Radiated Emission Band Edge Mode1:Transmit at 5180MHz by 802.11a Test Graph Data List NO . Frequenc y [MHz] Reading [dBμV] Level [dBμV/m] Factor [dB/m] Limit [dBμV/m] Margin [dB] Det Pol Verdi ct 1 5143.68 38.42 53.49 15.07 74.00 20.51 PK Horizo ntal PASS 2 5150.00 35.47 50.58 15.11 74.00 23.42 PK Horizo ntal PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 344 / 478 Mode1:Transmit at 5180MHz by 802.11a Test Graph Data List NO . Frequenc y [MHz] Reading [dBμV] Level [dBμV/m] Factor [dB/m] Limit [dBμV/m] Margin [dB] Det Pol Verdi ct 1 5138.51 28.85 43.89 15.04 54.00 10.11 AV Horizo ntal PASS 2 5150.00 27.70 42.81 15.11 54.00 11.19 AV Horizo ntal PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, C…

Text truncated - open the document above for the full version.

DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 262 / 478 11A-Ant1-5580-PASS 11A-Ant1-5700-PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 263 / 478 11A-Ant1-5745-PASS 11A-Ant1-5785-PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 264 / 478 11A-Ant1-5825-PASS 11N20SISO-Ant1-5180-PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 265 / 478 11N20SISO-Ant1-5200-PASS 11N20SISO-Ant1-5240-PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 266 / 478 11N20SISO-Ant1-5260-PASS 11N20SISO-Ant1-5280-PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 267 / 478 11N20SISO-Ant1-5320-PASS 11N20SISO-Ant1-5500-PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 268 / 478 11N20SISO-Ant1-5580-PASS 11N20SISO-Ant1-5700-PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 269 / 478 11N20SISO-Ant1-5745-PASS 11N20SISO-Ant1-5785-PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 270 / 478 11N20SISO-Ant1-5825-PASS 11N40SISO-Ant1-5190-PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 271 / 478 11N40SISO-Ant1-5230-PASS 11N40SISO-Ant1-5270-PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 272 / 478 11N40SISO-Ant1-5310-PASS 11N40SISO-Ant1-5510-PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 273 / 478 11N40SISO-Ant1-5590-PASS 11N40SISO-Ant1-5670-PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 274 / 478 11N40SISO-Ant1-5755-PASS 11N40SISO-Ant1-5795-PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 275 / 478 11AC20SISO-Ant1-5180-PASS 11AC20SISO-Ant1-5200-PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 276 / 478 11AC20SISO-Ant1-5240-PASS 11AC20SISO-Ant1-5260-PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 277 / 478 11AC20SISO-Ant1-5280-PASS 11AC20SISO-Ant1-5320-PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 278 / 478 11AC20SISO-Ant1-5500-PASS 11AC20SISO-Ant1-5580-PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 279 / 478 11AC20SISO-Ant1-5700-PASS 11AC20SISO-Ant1-5745-PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 280 / 478 11AC20SISO-Ant1-5785-PASS 11AC20SISO-Ant1-5825-PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 281 / 478 11AC40SISO-Ant1-5190-PASS 11AC40SISO-Ant1-5230-PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 282 / 478 11AC40SISO-Ant1-5270-PASS 11AC40SISO-Ant1-5310-PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 283 / 478 11AC40SISO-Ant1-5510-PASS 11AC40SISO-Ant1-5590-PASS DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 284 / 478 11AC40SISO-An…

Text truncated - open the document above for the full version.

DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 211 / 478 NTNV-11A-Ant1-5320 NTNV-11A-Ant1-5500 DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 212 / 478 NTNV-11A-Ant1-5580 NTNV-11A-Ant1-5700 DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2540846R.704B Page 213 / 478 NTNV-11A-Ant1-5745 NTNV-11A-Ant1-5785 DEKRA Testing and Certifi…
