Coverletter: AKG Acoustics GmbH wants to get FCC-Certification for the following product: digital wireless microphone transmitter DHT800. The unit will get the following FCC-ID: V3TDHT800 List of documents: Exhibit Thema File Exhibit 01 Label and placement label_15-128.pdf Exhibit 02 Not needed -------------------- Exhibit 03 External Photos extern_15-128.pdf * Exhibit 04 Block Diagrams Block_DHT800.pdf * Exhibit 05 Schematic Diagrams 5042955_B_SV2_TÜV.pdf Exhibit 06 Testreport 15-128.pdf Exhibit 07 Test Set-up Photos setup_15-128.pdf Exhibit 08 User Manual 2015-02-19_DMS800QG_v12.pdf Exhibit 09 Internal Photos intern_15-128.pdf * Exhibit 10 Informations 5042955_B_BOMV2.pdf Exhibit 11 RF exposure RF exposure compliance issues.pdf * Exhibit 12 Operational Description DHT800 short description.pdf Exhibit 13 Cover letter Request for confidentiality This file 2655_001.pdf For the Exhibits marked with ‘*’ AKG Acoustics GmbH requested Confidentiality according to 47 CFR 0.457 and 0.459 of the FCC rules because these are sensitive parts owned by this company and include much of Know-How or sensitive data, it will not be provided to the public. The labelling on some photos maybe not the actual status. The correct labelling you can see on the label and placement photos in Exhibit 1.

RF exposure compliance issues: According to FCC Part 2.1093 this kind of transmitter is categorically excluded from routine SAR evaluation.
