YCHME0X Operational Description The YCHME0X is a Network camera provides the ability to view the cameras monitored through PC or mobile phone as a live video stream, it supports the telecommunications standard of 3GPP streaming format. All 3G enabled mobile devices and most 2G phones that support the streaming standard of 3GPP are compatible. The U2 on OT207OV77252VA board is a CMOS image sensor, it captures the image data and the data is send to U on OTIPCAMCORE1VD board in ITU656 format. The U3 on OT2267GM812X1VB board is an ARM MCU including a H264/MPEG4 CODEC, it implements all the control and TCP/IP protocol in the same time it will encode the image data come from U4. While the encoding is complete, the encoding data will be sent out in two ways. While the RJ45 is pluged, YCHME0X will send the compress image data by the CAT5 wire. While the RJ45 is unplugging, YCHME0X will send the compress image data by the WLAN Module using Wireless way. The U1 include a MAC, U1 sent compress image data directly to Ethernet. The camera allows live the H264/MPEG-4 and Motion JPEG streams simultaneously. The camera features H264/MPEG4 compression which compresses the video to make transmission faster and more efficient. The H264/MPEG4 and MJPEG image can be transmitted at 30 frames per second. Because of its high-compression ratios, users can monitor high-quality moving images with low delay even at low bandwidths. The image size can be selected according to the network environment and application requirements. Image size can be selected from three modes: 640 x 480, 320 x 240, and 160 x 120.

RF Exposure Requirements Product Description: Bluetooth Headset Model No.: YCHME0x FCC ID: V4FYCHME61 Acorrding to the KDB-447498, the following RF exposure evaluation shall to demonstrate RF exposure compliance. Tx frequency range: 2412~2462MHz Device category: Fixed Device Maximum Conducted Output Power: 9.10 mW (9.59 dBm) Maximum Antenna Gain: 2.0 dBi Maximum EIRP Output Power: 14.42 mW (11.59 dBm) Limit: 60/f(GHz) mW = 24.88 mW Source-based time-averaged EIRP output power is 14.42 mW =< 60/f So the transmitter complies with the RF exposure requirements and the SAR is not required.
