V4NM893CDMA 800/1900 CELL-PCS MODULE(1xRTT/1xEV-DO)

CDMA 1X EV-DO Module M893 User’s Guide YISO Wireless Co., Ltd 0Propretary & Confidential M893 User’s Guide YISO Wireless CO., LTD. 4F, Gold, 217, Yangjae-dong, Seocho-Gu, Seoul, Korea, 137-894 Tel : 070-7019-8461 www.yisowireless.com CDMA 1X EV-DO Module M893 User’s Guide YISO Wireless Co., Ltd 2Propretary & Confidential 1. A Summary 1.1 Document Contents This document is a summary of M893(one of YISO’s wireless modem)’s hardware and software specifications. Contents are as followings. zProduct summary and features : Describes about the M893’s main features and provide pictures of product. zSpecification : Describes about the Environment specifications, Hardware, Software and Mechanism specifications. zModem Interface : Describes about the 100 pins for interface. 1.2 Revision History Initial ReleaseDecember 28, 2007V1.0 DescriptionsDateVersion 1.3 Pictures of Product zM893 Module [Top][Bottom] RF Test Cable Connector MM8430-2600 RA1(murata) Antenna Cable Connector MM9329-2700(murata) CDMA 1X EV-DO Module M893 User’s Guide YISO Wireless Co., Ltd 4Propretary & Confidential 3. Specifications 3.1 General Specifications 3.1.1 Environmental zRelative Humidity : 5%~95% zStorage Temperature : -30 °C ~ 60 °C zOperation Temperature : -20 °C ~ +50 °C zVibration Stability : 1.5G peak 5 to 500Hz 3.1.2 Hardware zCDMA Protocol : CDMA 1x-EVDO zPower Consumption : 3.6V/700mA (Max Power) zIF Receiving Chip : RFL6000, RFR6000 zIF Transfer Chip : RFT6100 zChipset : Qualcomm MSM6500 zInterface ™Interface Connector(100 Pins) 3.1.3 Software zData Service : IS-878P1,P2 and IS-835-B zBaud Rate ™DM : Default 230,400bps (variable) zTransmitting ™Forward-2.4Mbps ™Reverse-153.6kbps zSMS (IS-637) : MO,MT Support zNAM : 5 NAM zProduct Support Tool : PST zDM : Qualcomm CAIT CDMA 1X EV-DO Module M893 User’s Guide YISO Wireless Co., Ltd 5Propretary & Confidential 3.2 Electronic Specifications 3.2.1 Transmitter zType of Multiplexing : Duplexer zNormal Output Power : . zFrequency Range : 824. ∼ 848.3MHz (Cellular) 1851.25 ~ 1908.75MHz (USPCS) zFrequency Stability : Under defined Freq. ±300Hz(Cellualr), ±150Hz(USPCS) zChannel : 20ch(Cellular) , 42ch(USPCS) zChannel Spacing : 1.23MHz(Cellular), 1.25MHz(USPCS) zOccupied Frequency Bandwidth : Below 1.25MHz zOscillation Method : PLL SYNTHESIZER zLocal Oscillation Frequency : 954 ∼ 980MHz(Cellular) 1720.87 ~ 1778.37MHz(USPCS) zAntenna Impedance : 50 ohm 3.2.2 Receive Specifications zReceive Method : Zero IF zFrequency Range : 869. ~ 893.3MHz (Cellular) 1931.25 ~ 1988.75MHz(USPCS) zChannel : 20 ch(Cellular) , 42ch(USPCS) zChannel Spacing : 1.23MHz(Cellular), 1.25MHz(USPCS) zOccupied Frequency Bandwidth : Below 1.25MHz zOscillation Method : PLL SYNTHESIZER zLocal Oscillation Frequency : 954 ~ 980MHz (Cellular) 1720.87 ~ 1778.37MHz (USPCS) zAntenna Impedance : 50Ω CDMA 1X EV-DO Module M893 User’s Guide YISO Wireless Co., Ltd 6Propretary & Confidential 3.3 Mechanical zDimension : 30 X 45 X 5 (mm) zMechanical Drawing ™TOP CDMA 1X EV-DO Module M893 User’s Guide YISO Wireless Co., Ltd 7Propretary & Confidential ™Bottom CDMA 1X EV-DO Module M893 User’s Guide YISO Wireless Co., Ltd 8Propretary & Confidential 3.4 Interface Connector(100 Pins) Specifications ÆJIG or Interface partPart No. AXK5F20545YMATSUSHITA CDMA 1X EV-DO Module M893 User’s Guide YISO Wireless Co., Ltd 9Propretary & Confidential ÆM893 Module partPart No. AXK6F20345YMATSUSHITA CDMA 1X EV-DO Module M893 User’s Guide YISO Wireless Co., Ltd 10Propretary & Confidential 4. Modem Interface 4.1 Pin Assignments CDMA 1X EV-DO Module M893 User’s Guide YISO Wireless Co., Ltd 11Propretary & Confidential 4.2 Pin descriptions CDMA 1X EV-DO Module M893 User’s Guide YISO Wireless Co., Ltd 12Propretary & Confidential CDMA 1X EV-DO Module User’s Guide YISO Wireless Co., LtdPropretary& Confidential .1 WARNING! Read this information before use Caution• Modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC Compliance Information• This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2)This device must accept any interference received. Including interference that may cause undesired operation. Information to User• This equipment has been tested and found to comply with the limits for a ClassB digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and canradiate radio frequency energy and,ifnot installed and used in accordance withthe instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which canbe determined byturning the equipment off and on, the user is encouraged to try to correct the interference by oneor more of the following measures: -Reorient or relocate the receiving antenna.-Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/ tvtechnician for help.

YISO Wireless Co., Ltd. Date: February , 20, 2008 Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize Kyu Chul, Shin /Application Examiner of CTK Co., Ltd.and hereafter referred to as CTK Co., Ltd., to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Kyu Chul, Shin of CTK Co., Ltd.on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing CCS as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Tae Hun Shin / Manager YISO Wireless Co., Ltd.

Suite 407,Gold, 217 Yangjiae-dong,Seocho-gu, Seoul,Korea Tel No : +82-70-7019-8520 Fax No : +82-2059-8164 February 20, 2008 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re : YISO Wireless Co., Ltd. FCC ID : V4 NM893 Request for Confidentiality Gentlemen: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Schematics, Parts List. Block diagram and Operational description. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, __________________________ Tae H u n S h i n /Manager

Suite 407,Gold, 217 Yangjiae-dong,Seocho-gu, Seoul,Korea Tel No : +82-70-7019-8520 Fax No : +82-2059-8164 February 22, 2008 The CDMA Dual band module ( model: M893 ), FCC ID : V4 NM893 , is seeking FCC Authorization as a modular transmitter. The EUT meets the requirements for modular approval as detailed in FCC public Notice DA00-1407. Compliance to each of the requirements is described below: Questions are: 1. “The modular transmitter must have its own RF shielding.” - The radio portion of the CDMA wireless module has its own RF shielding. The shielding is installed at the factory. 2. “The modular transmitter must have buffered modulation/data inputs.” - Please see Appendix 1 for schematics of the module. 3. “The modular transmitter must have its own power supply regulation.” - The EUT has its own AC/DC power adapter. It insures compliance with part 15 supplying the module from the host unit. 4. “The modular transmitter must comply with the antenna requirements of section 15.203 and 15.204(c).” - The EUT meets the FCC antenna requirements. 5. “The modular transmitter must be tested in a stand-alone configuration.” - The EUT was tested in a stand-alone configuration. 6. “The modular transmitter must be labeled with its own FCC ID number.” - The EUT is labeled with its own FCC ID number. 7. “The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacture must provide adequate instruction along with the module to explain any such requirements.” - The EUT is compliant with all applicable FCC rules. 8. “The modular transmitter must comply with any applicable RF exposure requirements.” – The EUT fully complies with RF exposure requirements.

YISO Wireless Co., Ltd., FCC ID: V4NM893, Assessment NO.: AN08T7742, Notice#1 Inbox X Immediate X from [email protected] to [email protected], cc [email protected], [email protected], date Thu, Mar 27, 2008 at 4:25 PM subject YISO Wireless Co., Ltd., FCC ID: V4NM893, Assessment NO.: AN08T7742, Notice#1 hide details Mar 27 (11 days ago) Reply Dear Shin Kyu Chul, Review of this application is complete. Please reply to the following items. If you have questions, please ask and I will try to explain. Q1: Test setup photos show only radiated setup. Please provide test setup photos to include conducted setups. Q2: No power line conducted or radiated emissions test data < 1GHz is included in the test report as referenced in 3.1.7 and 3.1.8. As this device is considered a "peripheral device" according to FCC rules, and the FCC Declaration of Conformity labeling is used, please confirm that this device has been shown to comply with the requirements of FCC Part 15 for power line conducted and radiated emissions using the Declaration of Conformity procedure. Q3: Antenna specifications were not included in the filing. Please provide an antenna specification exhibit for the antenna used for the measurements. Q4: The ERP and EIRP values and antenna gains used for MPE calculations on pages 78 and 79 of the test report do not agree with results reported on pages 9-11. Please provide revised data or additional explanation in the MPE calculations. The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 30 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender. Best regards, Tim Dwyer Technical Reviewer Reply Reply to all Forward to tim.dwyer show details Apr 1 (7 days ago) Reply Hi Tim Dwyer Q1: Test setup photos show only radiated setup. Please provide test setup photos to include conducted setups. >Attach setup photo > Q2: No power line conducted or radiated emissions test data < 1GHz is included in the test report as referenced in 3.1.7 and 3.1.8. As this device is considered a "peripheral device" according to FCC rules, and the FCC Declaration of Conformity labeling is used, please confirm that this device has been shown to comply with the requirements of FCC Part 15 for power line conducted and radiated emissions using the Declaration of Conformity procedure. > Attach labeling > Q3: Antenna specifications were not included in the filing. Please provide an antenna specification exhibit for the antenna used for the measurements. > Attach antenna specification > Q4: The ERP and EIRP values and antenna gains used for MPE calculations on pages 78 and 79 of the test report do not agree with results reported on pages 9-11. Please provide revised data or additional explanation in the MPE calculations. > Sorry Test mistake Test again and attaches atresults > Best regards, - Show quoted text - 4 attachments — Download all attachments http://mail.google.com/mail/?ui=2&view=bsp&ver=ymdfwq781tpu http://mail.google.com/mail/?ui=2&view=bsp&ver=ymdfwq781tpu (1 of 5)4/7/2008 9:51:37 PM http://mail.google.com/mail/?ui=2&view=bsp&ver=ymdfwq781tpu [M893] Op Discription1.pdf 2623K View as HTML Download [M893] Test report.pdf 2357K View as HTML Download [M893] Test Setup photos.pdf 198K View as HTML Download [M893] Label and Location.pdf 142K View as HTML Download Reply Reply to all Forward from Tim Dwyer <[email protected]> to <[email protected]>, date Tue, Apr 1, 2008 at 8:08 PM subject Re: YISO Wireless Co., Ltd., FCC ID: V4NM893, Assessment NO.: AN08T7742, Notice#1 mailed-by gmail.com hide details Apr 1 (6 days ago) Reply Hi Shin Kyu Chul, After reviewing your reply, items Q1, Q3, and Q4 are complete. To complete item Q2, since this device is considered a "peripheral device" according to FCC rules, it must comply with the radiated and conducted requirements in Part 15.107 and 15.109. This compliance can be by the DoC procedure or by the Certification procedure. Your laboratory as listed at FCC (Reg. 805871) is acceptable for DoC test. If the DoC procedure will be used, we need minimum your statement confirming that this product complies with Class B radiated and conducted limits of part 15 when tested in a typical host configuration. We also need the name and address of the laboratory who made the test. If DoC procedure will be used, we will use the label submitted initially. The other possibility is to use the Certification procedure. To use the certification procedure, you would need to submit a composite application with exhibits and test report for the composite JBP equipment code. Best regards, Tim Dwyer Technical Reviewer - Show quoted text - Reply Forward from <[email protected]> to Tim Dwyer <[email protected]>, date Tue, Apr 1, 2008 at 9:49 PM subject Re: YISO Wireless Co., Ltd., FCC ID: V4NM893, Assessment NO.: AN08T7742, Notice#1 hide details Apr 1 (6 days ago) Reply Hi Tim Dwyer I do not understand http://mail.google.com/mail/?ui=2&view=bsp&ver=ymdfwq781tpu (2 of 5)4/7/2008 9:51:37 PM http://mail.google.com/mail/?ui=2&view=bsp&ver=ymdfwq781tpu This device is CDMA modeule , By the way, why are this devices a peripheral device? Attaches eut photo and Test zig Need not this devices to do doc? Best regards Thanks - Show quoted text - 2 attachments — Download all attachments eut photo.pdf 115K View as HTML Download [M893] Label and Location.pdf 142K View as HTML Download Reply Forward from Tim Dwyer <[email protected]> to <[email protected]>, cc Mike Kuo <[email protected]>, date Thu, Apr 3, 2008 at 11:52 AM subject Re: YISO Wireless Co., Ltd., FCC ID: V4NM893, Assessment NO.: AN08T7742, Notice#1 maile…

Text truncated - open the document above for the full version.

DECLARATION OF CONFORMITY According to FCC Part 15 Applicant Name : YISO Wireless Co., Ltd. Address : Suite 407,Gold, 217 Yangjiae-dong,Seocho-gu,Seoul,Korea Telephone : +82-70-7019-8520 Declares that Product : CDMA 800/1900 CELL-PCS MODULE (1xRTT/1xEV-DO) Model Name : M893 Report Number : 2008040009 This device complies with Part 15 of the FCC rules. Operations is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Test Laboratory: CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Designation Number : KR0025 Tel : +82-31-339-9970 Fax : +82-31-339-9855 Responsible Party: Company Name : Company Address : Phone : Fax : Name : Signature :

CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com FCC ID: V4NM893 Page 1 of 1 EUT External Photographs

CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com FCC ID: V4NM893 Page 1 of 1 FCC ID label and Location Label

CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com FCC ID: V4NM893 Page 1 of 2 EUT Internal Photographs CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com FCC ID: V4NM893 Page 2 of 2 EUT Test zig

CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Test Rep o r t No .: 2008030036 Date: March 17, 2008 Page 76 of 78 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 SubpartC(Rev.2) APPENDIX B – MPE CALCULATION CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Test Rep o r t No .: 2008030036 Date: March 17, 2008 Page 77 of 78 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 SubpartC(Rev.2) ** CDMA MPE Calculations ** The EUT will only be used with a separation of 20 centimeters or greater between the antenna and the body of the user. The MPE calculation for this exposure is shown below. The peak radiated output power (ERP) is calculated as follows: ERP = P + G ERP = 21.94 dBm Where, P = Power input to the antenna (mW) G = Power gain of the antenna (dBi) The numeric gain(G) of the antenna with a gain specified in dB is determined by: G = Log -1 (dB antenna gain / 10) G = Log -1 (-3.8/ 10) G = 0.42 Power density at the specific separation: S = PG/(4R 2 π) S = (374.97*0.42)/(4 * 20 2 * π) S = 0.0244 mW/cm 2 Where, S = Maximum power density (mW/cm 2 ) P = Power input to the antenna (mW) G = Numeric power gain of the antenna R = Distance to the center of the radiation of the antenna (20cm = limit for MPE) The Maximum permissible exposure (MPE) for the general population is 1 mW/cm 2 . The power density at 20cm does not exceed the 1 mW/cm 2 limit. Estimated safe separation: R = √(PG / 4π) R = √(374.97 * 0.42/ 4π) R = 3.12 cm Where, P = Power input to the antenna (mW) G = Numeric power gain of the antenna R = Distance to the center of the radiation of the antenna (20cm = limit for MPE) CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Test Rep o r t No .: 2008030036 Date: March 17, 2008 Page 78 of 78 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 SubpartC(Rev.2) ** PCS CDMA MPE Calculations ** The EUT will only be used with a separation of 20 centimeters or greater between the antenna and the body of the user. The MPE calculation for this exposure is shown below. The peak radiated output power (EIRP) is calculated as follows: EIRP = P + G + 2.15 EIRP = 31.72dBm Where, P = Power input to the antenna (mW) G = Power gain of the antenna (dBi) The numeric gain(G) of the antenna with a gain specified in dB is determined by: G = Log -1 (dB antenna gain / 10) G = Log -1 (4.9/ 10) G = 3.09 Power density at the specific separation: S = PG/(4R 2 π) S = (293.76*3.09)/(4 * 20 2 * π) S = 0.1807 mW/cm 2 Where, S = Maximum power density (mW/cm 2 ) P = Power input to the antenna (mW) G = Numeric power gain of the antenna R = Distance to the center of the radiation of the antenna (20cm = limit for MPE) The Maximum permissible exposure (MPE) for the general population is 1 mW/cm 2 . The power density at 20cm does not exceed the 1 mW/cm 2 limit. Estimated safe separation: R = √(PG / 4π) R = √(293.76 * 3.09/ 4π) R = 8.50 cm Where, P = Power input to the antenna (mW) G = Numeric power gain of the antenna R = Distance to the center of the radiation of the antenna (20cm = limit for MPE)

CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Test Rep o r t No .: 2008030036 Date: March 17, 2008 Page 1 of 78 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 SubpartC(Rev.2) TEST REPORT For FCC Test Report No. : 2008030036 Date of Issue : March 17, 2008 FCC ID : V4 NM893 Model/Type No. : M893 Classification : PCS licensed transmitter (PCB) Applicant : YISO Wireless Co., Ltd. Applicant Address : Suite 407,Gold, 217 Yangjiae-dong,Seocho-gu,Seoul,Korea Manufacturer : YISO Wireless Co., Ltd. Manufacturer Address : Suite 407,Gold, 217 Yangjiae-dong,Seocho-gu,Seoul,Korea Contact Person : Mr. Shin Tae Hun Telephone : +82-70-7019-8520 Received Date : February 5, 2008 Test period : Start : March 03, 2008 End : March 17, 2008 Test Results : In Compliance Not in Compliance The test results presented in this report relate only to the object tested. Tested by Reviewed by Kyu-Chul, Shin Test Engineer Young-Joon, Park Technical Manager Date: March 17, 2008 Date: March 17, 2008 CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Test Rep o r t No .: 2008030036 Date: March 17, 2008 Page 2 of 78 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 SubpartC(Rev.2) REPORT REVISION HISTORY Date Revision Page No March 17, 2008 Issued (2008030036) All This report shall not be reproduced except in full, without the written approval of CTK Co., Ltd. This document may be altered or revised by CTK Co., Ltd. personnel only, and shall be noted in the revision section of the document. Any alteration of this document not carried out by CTK Co., Ltd. will constitute fraud and shall nullify the document. CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Test Rep o r t No .: 2008030036 Date: March 17, 2008 Page 3 of 78 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 SubpartC(Rev.2) TABLE OF CONTENTS ◈ TEST REPORT 1.1 SCOPE 4 2.1 GENERAL INFORMATION 4 3.1 DESCRIPTION OF TESTS 5 4.1 TEST DATA 9 4.1.1 CONDUCTED OUTPUT POWER 9 4.1.2 EFFECTIVE RADIATED POWER OUTPUT 10 4.1.3 EQUIVALENT ISOTROPIC RADIATED POWER 11 4.1.4 CDMA RADIATED MEASUREMENTS 12 4.1.10 FREQUENCY STABILITY(CDAM) 18 5.1 PLOTS OF EMISSIONS 26 6.1 LIST OF TEST EQUIPMENT 27 7.1 SAMPLE CALCULATIONS 28 8.1 CONCLUSION 29 9.1 TEST PLOTS 30 CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Test Rep o r t No .: 2008030036 Date: March 17, 2008 Page 4 of 78 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 SubpartC(Rev.2) TEST REPORT 1. 1 Scope Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. 2.1 General Information Classification : PCS licensed transmitter (PCB) EUT Type : CDMA 800/1900 CELL-PCS MODULE (1xRTT/1xEV-DO) FCC Rule Part(s) : §2; §22(H), §24(E) Model name : M893 Serial number : Identical prototype Emission Designators: : CDMA : 1M28F9W PCS CDMA : 1M27F9W Tx Freq. Range : 824.70 ~ 848.31 MHz (CDMA) 1851.25 ~ 1908.75 MHz (PCS CDMA) Rx Freq. Range 869.70 ~ 893.31 MHz (CDMA) 1931.25 ~ 1988.75 MHz (PCS CDMA) Modulation(s): : CDMA / PCS CDMA Frequency Tolerance: : ± 0.00025 % (2.5ppm) Maximum Output Power : CDMA : 25.08dBm for 1xRTT , 25.74dBm for 1XEV-DO PCS CDMA : 24.68dBm for 1xRTT , 23.38dBm for 1XEV-DO Maximum EIRP CDMA : 24.91dBm for 1xRTT , 23.48dBm for 1XEV-DO PCS CDMA : 24.89dBm for 1xRTT , 24.43dBm for 1XEV-DO Power Source : 3.6 Vdc CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Test Rep o r t No .: 2008030036 Date: March 17, 2008 Page 5 of 78 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 SubpartC(Rev.2) 3.1 DESCRIPTION OF TESTS 3.1.1 Occupied Bandwidth Emission Limits (a) On any frequency outside a licensee’s frequency block, the power of any emission shall be attenuated below the transmitter power (P) by at least 43 + 10 log(P) dB. (b) When measuring the emission limits, the nominal carrier frequency shall be adjusted as close to the licensee’s frequency block edges, both upper and lower, as the design permits. (c) The measurement of emission power can be expressed in peak or average values, provided they are expressed in the same parameters as the transmitter power. 3.1.2 Occupied Bandwidth The 99% power bandwidth was measured with a calibrated spectrum analyzer. 3.1.3 Spurious and Harmonic Emissions at Antenna Terminal The level of the carrier and the various conducted spurious and harmonic frequencies is measured by means of a calibrated spectrum analyzer. The spectrum is scanned from the lowest frequency generated in the equipment up to 10 GHz(PCS Mode:20GHz). CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Test Rep o r t No .: 2008030036 Date: March 17, 2008 Page 6 of 78 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 SubpartC(Rev.2) 3.1.4 Frequencies At the input terminals of the spectrum analyzer, an isolator (RF pad) and a high-pass filter are connected between the test transceiver (for conducted tests) or the receive antenna (for radiated tests) and the analyzer. The high- pass filter is to limit the fundamental frequency from interfering with the measure…
