V5PM50Mobile Payment Cell Phone

1. Contents Checklist Please check the components after unpacking. If any are missing, please contact the dealer. Name Qty. M50 Mobile Payment Terminal 1 AC Power Adapter (optional) 1 USB Cable 1 Mobile phone Card Pick-up Needle 1 Product Manual 1 2. Product Description Rear-Camera Flash Light Denoise MIC NFC Reading area Touch Keypad 1.54 inch LCD Bottom View 3. Installation TYPE_C port: Connect USB device or PC. SIM card: ○ 1 Take the Card Pick-up Needle out of the box; ○ 2 Insert the Card Pick-up Needle into the SIM card slot; ○ 3 Insert SIM card into the pop-up card-slot. microSD card: ○ 1 Take the Card Pick-up Needle out of the box; ○ 2 Insert the Card Pick-up Needle into the microSD card slot; TYPE-C Speaker Main-MIC Volume + Volume - Power Button SIM/microSD Card-Slot IC Card-Slot Audio-Jack Fingerprint Touch Screen Proximity Seneor Receiver Front Camera TOP View Type-C ○ 3 Insert microSD card into the pop-up card-slot. 4. Instructions 1） Power ON/OFF Power on: press and hold the Power button for five seconds until the LCD besides, and then the terminal is being turned on. Power off: press and hold the Power button for three seconds until the shutdown menu appears, tap Shutdown > Click Shutdown, and then “Shutting...” appears, the terminal is being turned off. 2）IC card Place the chip face up, insert the IC card into the IC card slot, and push it to the end. microSD Nano SIM Nano SIM OR 3）Swiping contactless card Place a contactless card close to the sensor area of swiping which is at the back of the terminal. 5. Installation and Usage Tips 1）Avoid putting the terminal in direct sunlight, high temperature, moist, or dusty environment. 2）Forbid non-professional to repair the terminal. 3）Before insert the card, please check internal and around of IC card slot. When you found some suspicious objects, must report to related administrator. Working Environment： Temperature: -10°C~50°C(32°F~122°F) R.H.:5%~96%(non-condense) Storage Environment： Temperature: -20°C~70°C(-4°F~158°F) R.H.:5%~95%(non-condense) 6. Lithium Ion Polymer Battery Usage Tips WARNING: 1）Don't use the terminal in sunlight or smoke, dust environment. 2）Prohibited to strike, squeeze and tread on battery or throw it into the liquid and fire. 3）If battery is impressive, deformed, damaged or exothermic seriously, please stop using immediately and replace it! 4）The battery replacement shall be done only by either cells supplier or device supplier and never be done by the user! 5）Must use the specified battery model and charger, otherwise there will be explosion 6）Charging time can not exceed 24 hours. If the battery is out of power, please recharge in time. Avoid damaging the battery in over-charge and over-discharge. 7）If be non-use for long time, please recharge the battery per 6 months to avoid shortening its life. 8）Suggest to replace it when the battery have been used for 2 years. 7. Icon shows Do not throw away, need professional recycling. Class II Equipment For indoor use only Energy Efficiency Marking AC voltage DC voltage Trademark notice: “microSD logo is a trademark of SD-3C LLC.” The full text of the EU declaration of conformity is available at the following internet address: https://www.pax.com.cn/ProductCE/index.aspx E-Label This device has E-Lable, Steps to access the e-label is Setting—About phone---Regulatory labels. FCC compliance statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. FCC SAR statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End user must follow the specific operating instructions for satisfying RF exposure compliance. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. The portable device is designed to meet the requirements for exposure to radio waves established by the Federal Communications Commission (USA). These requirements set a SAR limit of 1.6 W/kg averaged over one gram of tissue. The highest SAR value reported under this standard during product certification for use when properly worn on the body The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. While there may be differences between the SAR levels of various devices and at various positions, they all meet the government requirement. ISED compliance statement This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s lic…

Text truncated - open the document above for the full version.

PAX Technology Limited Date: 2020-12-24 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: V5PM50 To whom it may concern: We, the undersigned, hereby authorize SGS-CSTC Standards Technical Services Co., Ltd. (SGS) Shenzhen Branch and Keny Xu in SGS-CSTC Standards Technical Services Co., Ltd. (SGS) Shenzhen Branch to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with PAX Technology Limited. This authorization is valid until further written notice from the applicant. Print Name: Jenna Tan Title: Certification Leader Signature: On behalf of Company: PAX Technology Limited Telephone: 86-755-86156663 E-mail: [email protected]

PAX Technology Limited TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: Confidentiality Request regarding application for FCC ID: V5PM50 LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions BOM List Tune Up Procedure Software Security Description The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. SHORT TERM CONFIDENTIALITY Additionally, the applicant requests the following documents be held confidential until the device is marketed or 180 days from the grant date, whichever is less. If the device is marketed within 180 days of the Grant Date, the applicant will notify the TCB per FCC KDB 726920 D01 Confidentiality Request Procedures. External Photos Internal Photos Test Setup Photos User manual(s) Sincerely, Print Name: Jenna Tan Title: Certification Leader Signature: On behalf of Company: PAX Technology Limited Telephone: 86-755-86156663 E-mail: [email protected]

Applicant Declaration Applicant Declaration Rev:0.0 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name PAX Technology Limited Address Room 2416, 24/F., Sun Hung Kai Centre, 30 Harbour, Hong Kong, China Grantee Code V5P FCC ID V5PM50 Authorized Contact Name Jenna Tan Contact Email [email protected] Contact Phone 86-755-86156663 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Applicant Signature: Date: December 23, 2020 Print Name: Jenna Tan Title: Certification Leader *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 1 of 6 External Photos for SZEM2012013028CR FCC ID: V5PM50 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 2 of 6 EUT Constructional Details (EUT Photos) SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 3 of 6 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 4 of 6 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 5 of 6 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 6 of 6

Access to E-Label This device has E-Label, Steps to access the e-label is setting—about phone---Regulatory labels. 1、Click--Setting 2、Click--About phone 3、Click--Regulatory labels 4、Content

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 1 of 10 Internal Photos for SZEM2012013028CR FCC ID: V5PM50 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 2 of 10 EUT Constructional Details (EUT Photos) BT/WIFI/GPS antenna 3G4G Div antenna 3G4G Main antenna SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 3 of 10 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 4 of 10 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 5 of 10 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 6 of 10 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 7 of 10 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 8 of 10 NFC antenna SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 9 of 10 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 10 of 10

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM201201302806 Page: 1 of 31 Keny Xu EMC Laboratory Manager TEST REPORT Application No.: SZEM2012013028CR Applicant: PAX Technology Limited Address of Applicant: Room 2416, 24/F., Sun Hung Kai Centre, 30 Harbour, Hong Kong, China Manufacturer: PAX Computer Technology(Shenzhen) Co., Ltd. Address of Manufacturer: 4/F, No.3 Building, Software Park, Second Central Science-Tech Road, High-Tech industrial Park, Shenzhen, Guangdong, P.R.C. Equipment Under Test (EUT): EUT Name: Mobile Payment Cell Phone Model No.: M50 Trade Mark: PAX FCC ID: V5PM50 Standard(s) : 47 CFR Part 15, Subpart C 15.225 Date of Receipt: 2020-12-17 Date of Test: 2020-12-18 to 2021-01-04 Date of Issue: 2021-01-07 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM201201302806 Page: 2 of 31 Revision Record Version Chapter Date Modifier Remark 01 2021-01-07 Original Authorized for issue by: Calvin Weng/Project Engineer Eric Fu/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM201201302806 Page: 3 of 31 2 Test Summary Radio Spectrum Matter Part Item Standard Method Requirement Result 20dB Bandwidth 47 CFR Part 15, Subpart C 15.225 ANSI C63.10 (2013) Section 6.9 47 CFR Part 15, Subpart C 15.215 Pass Conducted Emissions at Mains Terminals (150kHz-30MHz) 47 CFR Part 15, Subpart C 15.225 ANSI C63.10 (2013) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass Conducted Emissions at Mains Terminals (9kHz-30MHz) 47 CFR Part 15, Subpart C 15.225 ANSI C63.10 (2013) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass Emission Mask 47 CFR Part 15, Subpart C 15.225 ANSI C63.10 (2013) Section 6.4 47 CFR Part 15, Subpart C 15.225(a)&(b)&(C ) Pass Frequency tolerance 47 CFR Part 15, Subpart C 15.225 ANSI C63.10 (2013) Section 6.8 47 CFR Part 15, Subpart C 15.225(e) Pass Radiated Emissions (30MHz-1GHz) 47 CFR Part 15, Subpart C 15.225 ANSI C63.10 (2013) Section 6.4&6.5 47 CFR Part 15, Subpart C 15.225(d) & 15.209 Pass Radiated Emissions (9kHz-30MHz) 47 CFR Part 15, Subpart C 15.225 ANSI C63.10 (2013) Section 6.4&6.5 47 CFR Part 15, Subpart C 15.225(d) & 15.209 Pass SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM201201302806 Page: 4 of 31 3 Contents Page 1 COVER PAGE ..................................................................................................................................... 1 2 TEST SUMMARY ................................................................................................................................. 3 3 CONTENTS ......................................................................................................................................... 4 4 GENERAL INFORMATION .................................................................................................................. 6 4.1 DETAILS OF E.U.T. ......................................................................................................................... 6 4.2 DESCRIPTION OF SUPPORT UNITS .................................................................................................... 6 4.3 MEASUREMENT UNCERTAINTY ......................................................................................................... 6 4.4 TEST LOCATION ............................................................................................................................. 7 4.5 TEST FACILITY ............................................................................................................................... 7 4.6 DEVIATION FROM STANDARDS ......................................................................................................... 7 4.7 ABNORMALITIES FROM STANDARD CONDITIONS ................................................................................. 7 5 EQUIPMENT LIST ............................................................................................................................... 8 6 RADIO SPECTRUM MATTER TEST RESULTS .................................................................................11 6.1 20DB BANDWIDTH .........................................................................................................................11 6.1.1 E.U.T. Operation .....................................................................................................................11 6.1.2 Test Mode Description ............................................................................................................11 6.1.3 Test Setup Diagram ................................................................................................................11 6.1.4 Measurement Procedure and Data .........................................................................................11 6.2 CONDUCTED EMISSIONS AT MAINS TERMINALS (150KHZ-30MHZ) ......................................................13 6.2.1 E.U.T. Operation .....................................................................................................................13 6.2.2 Test Mode Description ............................................................................................................13 6.2.3 Test Setup Diagram ................................................................................................................13 6.2.4 Measurement Procedure and Data .........................................................................................14 6.3 EMISSION MASK ............................................................................................................................17 6.3.1 E.U.T. Operation .....................................................................................................................17 6.3.2 Test Mode Description ................................................................................…
