V5PS500RFEFT-POS Terminal

EFT-POS Terminal Instruction Manual （S500） 1. Installation POWER port connects to the external power adapter. LINE port connects to telephone line. PINPAD port connects to PINPAD. RS232 port connects to serial port. LAN port connects to the network cable (optional). PHONE port connects to telephone (optional). 2. Instructions 1）Power ON/OFF Power on：Press the ON/OFF button two seconds until LCD backlight light, the terminal turns on successfully. Power off：Press the ON/OFF button two seconds until LCD no display, the terminal turns off successfully. 2）Magnetic Stripe Card Put magnetic stripe side of magnetic card towards device interior, swipe the card with a steady speed during through magnetic reader slot. (Support bi-directional swiping) 3）IC Card Put IC card chip side upward, push-in IC card slot and to bottom. 4）Tap contactless card (optional). Put the contactless card into the sensing area above the LCD 5）Shred paper operating Instructions Make paper 45 degrees angle right to paper knife and shred paper. 3. Installation and Usage Tips 1）Avoid putting the terminal in direct sunlight, high temperature, moist, or dusty environment. 2）Forbid non-professional to repair the terminal. 3）Before insert the card, please check internal and around of IC card slot . when you found some suspicious objects , must report to related administrator. 4. Password Entering Tips It is highly recommended to enter password as following ways: 1）Set up peep shields. Enter password with shield by the structures of cashier desk; 2）Place the POS terminal at an appropriate angle and make sure it is difficult to peer the password. For example, the POS was installed above the movable bracket. 3）In enter password perspective, avoid surrounding video surveillance; 4）Paste text instructions to remind the customers to shelter with body or palm when enter password. 5）Merchants can also choose other ways to protect the customer input password. FCC Regulations This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment complies with Part 68 of the FCC rules and the requirements adopted by the ACTA. On the body of this equipment is a label that contains, among other information, a product identifier . If requested, this number must be provided to the telephone company. RF Exposure Information This device meets the government’s requirements for exposure to radio waves. This device is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Government. This device complies with FCC radiation exposure limits set forth for an uncontrolled environment. PAX TECHNOLOGY LIMITED To know more product details, please visit http://www.pax.com.cn P/N：200312000000198 FCC Caution. § 15.19 Labelling requirements. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. § 15.21 Information to user. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. § 15.105 Information to the user. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. Customer Information This equipment complies with Part 68 of the FCC rules and the requirements adopted by the ACTA. On the bottom of this equipment is a label that contains, among other information, a product identifier in the format US: AAAEQ##TXXXX. If requested, this number must be provided to the telephone company. This equipment uses the following USOC jacks: RJ11C A plug and jack used to connect this equipment to the premises wiring and telephone network must comply with the applicable FCC Part 68 rules and requirements adopted by the ACTA. A compliant telephone cord and modular plug is provided with this product. It is designed to be connected to a compatible modular jack that is also compliant. See installation instructions for details. The REN is used to determine the number of devices that may be connected to a telephone line. Excessive RENs on a telephone line may result in the devices not ringing in response to an incoming call. In most but not all areas, the sum of RENs should not exceed five (5.0). To be certain of the number of devices that may be connected to a line, as determined by the total RENs, contact the local telephone company. For products approved after July 23, 2001, the REN for this product is part of the product identifier that has the format US:AAAEQ##TXXXX. The digits represented by ## are the REN without a decimal point (e.g., 03 is a R…

Text truncated - open the document above for the full version.

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 PAX Technology Limited 2014/8/11 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: V5PS500RF We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature : Client’s name / title: Xudong An/Manager Contact information / address: Room 2416, 24/F., Sun Hung Kai Centre 30 Harbour Road Wanchai China

Title: EMC Test Report for EFT-POS Terminal Main Model: S500 Serial Model: N/A To: FCC Part 15 Subpart B Class B: 2013 , ANSI C63.4:2009 Report No.: 14070371-FCC-E1 Issue Date: August 06, 2014 Page: 32 of 50 www.siemic.com.cn Annex B. EUT AND TEST SETUP PHOTOGRAPHS Annex B.i. Photograph 1: EUT External Photo Whole Package - Top View Adapter – Front View Title: EMC Test Report for EFT-POS Terminal Main Model: S500 Serial Model: N/A To: FCC Part 15 Subpart B Class B: 2013 , ANSI C63.4:2009 Report No.: 14070371-FCC-E1 Issue Date: August 06, 2014 Page: 33 of 50 www.siemic.com.cn EUT - Top View EUT - BottomView Title: EMC Test Report for EFT-POS Terminal Main Model: S500 Serial Model: N/A To: FCC Part 15 Subpart B Class B: 2013 , ANSI C63.4:2009 Report No.: 14070371-FCC-E1 Issue Date: August 06, 2014 Page: 34 of 50 www.siemic.com.cn EUT – Front View EUT – Rear View Title: EMC Test Report for EFT-POS Terminal Main Model: S500 Serial Model: N/A To: FCC Part 15 Subpart B Class B: 2013 , ANSI C63.4:2009 Report No.: 14070371-FCC-E1 Issue Date: August 06, 2014 Page: 35 of 50 www.siemic.com.cn EUT – Left View EUT – Right View

Label location

Title: EMC Test Report for EFT-POS Terminal Main Model: S500 Serial Model: N/A To: FCC Part 15 Subpart B Class B: 2013 , ANSI C63.4:2009 Report No.: 14070371-FCC-E1 Issue Date: August 06, 2014 Page: 36 of 50 www.siemic.com.cn Annex B.ii. Photograph 2: EUT Internal Photo Cover Off - Top View LED - Top View Title: EMC Test Report for EFT-POS Terminal Main Model: S500 Serial Model: N/A To: FCC Part 15 Subpart B Class B: 2013 , ANSI C63.4:2009 Report No.: 14070371-FCC-E1 Issue Date: August 06, 2014 Page: 37 of 50 www.siemic.com.cn LED - Bottom View Mainborad - Front View Title: EMC Test Report for EFT-POS Terminal Main Model: S500 Serial Model: N/A To: FCC Part 15 Subpart B Class B: 2013 , ANSI C63.4:2009 Report No.: 14070371-FCC-E1 Issue Date: August 06, 2014 Page: 38 of 50 www.siemic.com.cn Mainborad - Rear View Keyborad 1 - Front View Title: EMC Test Report for EFT-POS Terminal Main Model: S500 Serial Model: N/A To: FCC Part 15 Subpart B Class B: 2013 , ANSI C63.4:2009 Report No.: 14070371-FCC-E1 Issue Date: August 06, 2014 Page: 39 of 50 www.siemic.com.cn Keyborad 1 - Rear View Keyboard 2 – Front View Title: EMC Test Report for EFT-POS Terminal Main Model: S500 Serial Model: N/A To: FCC Part 15 Subpart B Class B: 2013 , ANSI C63.4:2009 Report No.: 14070371-FCC-E1 Issue Date: August 06, 2014 Page: 40 of 50 www.siemic.com.cn Keyboard 2 - Rear View Magnetic Sensor - Front View Title: EMC Test Report for EFT-POS Terminal Main Model: S500 Serial Model: N/A To: FCC Part 15 Subpart B Class B: 2013 , ANSI C63.4:2009 Report No.: 14070371-FCC-E1 Issue Date: August 06, 2014 Page: 41 of 50 www.siemic.com.cn Magnetic Sensor - Rear View Motor – Front View Title: EMC Test Report for EFT-POS Terminal Main Model: S500 Serial Model: N/A To: FCC Part 15 Subpart B Class B: 2013 , ANSI C63.4:2009 Report No.: 14070371-FCC-E1 Issue Date: August 06, 2014 Page: 42 of 50 www.siemic.com.cn Motor – Rear View 13.56MHz Antenna – View

PAX Technology Limited EFT-POS Terminal Main Model: S500 Serial Model: N/A August 06, 2014 Report No.: 14070371-FCC-E1 (This report supersedes NONE) Modifications made to the product : None This Test Report is Issued Under the Authority of: Kahn Yang Compliance Engineer Alex Liu Technical Manager This test report may be reproduced in full only. Test result presented in this test report is applicable to the representative sample only. Title: EMC Test Report for EFT-POS Terminal Main Model: S500 Serial Model: N/A To: FCC Part 15 Subpart B Class B: 2013 , ANSI C63.4:2009 Report No.: 14070371-FCC-E1 Issue Date: August 06, 2014 Page: 2 of 38 www.siemic.com.cn Laboratory Introduction ATION SIEMIC, headquartered in the heart of Silicon Valley, with superior facilities in US and Asia, is one of the leading independent testing and certification facilities providing customers with one-stop shop services for Compliance Testing and Global Certifications. In addition to testing and certification, SIEMIC provides initial design reviews and compliance management through out a project. Our extensive experience with China, Asia Pacific, North America, European, and international compliance requirements, assures the fastest, most cost effective way to attain regulatory compliance for the global markets . SIEMIC (Shenzhen-China) Laboratories Accreditations for Conformity Assessment Country/Region Scope USA EMC , RF/Wireless , Telecom Canada EMC, RF/Wireless , Telecom Taiwan EMC, RF, Telecom , Safety Hong Kong RF/Wireless ,Telecom Australia EMC, RF, Telecom , Safety Korea EMI, EMS, RF , Telecom, Safety Japan EMI, RF/Wireless, Telecom Singapore EMC , RF , Telecom Europe EMC, RF, Telecom , Safety Title: EMC Test Report for EFT-POS Terminal Main Model: S500 Serial Model: N/A To: FCC Part 15 Subpart B Class B: 2013 , ANSI C63.4:2009 Report No.: 14070371-FCC-E1 Issue Date: August 06, 2014 Page: 3 of 38 www.siemic.com.cn This page has been left blank intentionally. Title: EMC Test Report for EFT-POS Terminal Main Model: S500 Serial Model: N/A To: FCC Part 15 Subpart B Class B: 2013 , ANSI C63.4:2009 Report No.: 14070371-FCC-E1 Issue Date: August 06, 2014 Page: 4 of 38 www.siemic.com.cn CONTENTS 1 EXECUTIVE SUMMARY & EUT INFORMATION .......................................................................................... 5 2 TECHNICAL DETAILS.......................................................................................................................................... 6 3 MODIFICATION ..................................................................................................................................................... 7 4 TEST SUMMARY .................................................................................................................................................... 8 5 MEASUREMENTS, EXAMINATION AND DERIVED RESULTS................................................................... 9 ANNEX A. TEST INSTRUMENTATION & GENERAL PROCEDURES ............................................................. 14 ANNEX B. EUT AND TEST SETUP PHOTOGRAPHS ........................................................................................... 20 ANNEX C. TEST SETUP AND SUPPORTING EQUIPMENT ................................................................................ 33 ANNEX D. USER MANUAL / BLOCK DIAGRAM / SCHEMATICS / PART LIST ............................................. 37 ANNEX E. DECLARATION OF SIMILARITY ........................................................................................................ 38 Title: EMC Test Report for EFT-POS Terminal Main Model: S500 Serial Model: N/A To: FCC Part 15 Subpart B Class B: 2013 , ANSI C63.4:2009 Report No.: 14070371-FCC-E1 Issue Date: August 06, 2014 Page: 5 of 38 www.siemic.com.cn 1 EXECUTIVE SUMMARY & EUT INFORMATION The purpose of this test programme was to demonstrate compliance of the PAX Technology Limited, EFT-POS Terminal and Model: S500 against the current Stipulated Standards. The EFT-POS Terminal has demonstrated compliance with the FCC Part 15 Subpart B Class B: 2013, ANSI C63.4: 2009. EUT Information EUT Description : EFT-POS Terminal Main Model : S500 Serial Model N/A Input Power : Adapter: Model: HKA00909010-8F Input: 100-240V; 50/60Hz 0.3A Output: 9.0V; 1.0A Classification Per Stipulated Test Standard : Class B Emission Product Per FCC Part 15 Subpart B Class B: 2013, ANSI C63.4: 2009 Title: EMC Test Report for EFT-POS Terminal Main Model: S500 Serial Model: N/A To: FCC Part 15 Subpart B Class B: 2013 , ANSI C63.4:2009 Report No.: 14070371-FCC-E1 Issue Date: August 06, 2014 Page: 6 of 38 www.siemic.com.cn 2 TECHNICAL DETAILS Purpose Compliance testing of EFT-POS Terminal with stipulated standards Applicant / Client PAX Technology Limited Room 2416, 24/F., Sun Hung Kai Centre 30 Harbour Road Wanchai China Manufacturer PAX Computer Technology (Shenzhen) Co., Ltd. 4/F, No.3 Building, Software Park, Second Central Science-Tech Road, High- Tech industrial Park, Shenzhen, Guangdong, P.R.C. Laboratory performing the tests SIEMIC (Shenzhen-China) Laboratories Zone A, Floor 1, Building 2, Wan Ye Long Technology Park, South Side of Zhoushi Road, Bao'an District, Shenzhen, Guangdong, China Tel: +86-0755-2601 4629 / 2601 4953 Fax: +86-0755-2601 4953-810 Email: [email protected] Test report reference number 14070371-FCC-E1 Date EUT received July 17, 2014 Standard applied FCC Part 15 Subpart B Class B: 2013, ANSI C63.4: 2009 Dates of test (from – to) July 22 to July 23, 2014 No of Units #1 Equipment Category Class B Emission Product Trade Name PAX FCC ID V5PS500RF Title: EMC Test Report for EFT-POS Terminal Main Model: S500 Serial Model: N/A To: FCC Part 15 Subpart B Class B: 2013 , ANSI C63.4:2009 Report No.: 14070371-FCC-E1 Issue Date: August 06, 2014 Page: 7 of 38 www.siemic.com.cn 3 MODIFICATION NONE Title: EMC Test Report for EFT-POS Terminal Main Model: S500 Serial Model: N/A To: FCC Part 15 Subpart B Class B: 2013 , ANSI…
