V5PSK700Smart Kiosk

SK700 Smart Kiosk Note: Product images shown may be different than actual product received PAX TECHNOLOGY LIMITED 1、ContentsChecklist Please check the components after unpacking. If any are missing, please contact the dealer. Name Qty SK700 Smart Kiosk 1 SK700 Wall Bracket 1 Printer Key 2 Thermal Paper Roll 1 M4-10 Combination Screw 2 Expansion Screw 6 Plastic Packaging 1 Power Cable 1 Quick Setup Guide 1 2、Product Description S ide View Front View Interface Diagram 3.Operating Instruction · Power on: Plug in the AC power cable, press and hold the Power button for threesecondsuntil the boot animation appears.  Power off: Press and hold the Power button for threeseconds until the shutdown menu displays. Select Power off. Theterminal turns off after a few seconds. 4. Payment Options  Magnetic stripe card Insert magnetic stripe card into card slot and push to the end with magnetic stripe facing down, then pull out the card at a constant speed to swipe card.  IC chip card Insert card with IC chip facing up, then push it to theend of the card slot. Leave card inserted until prompted to remove.  Contactless card Place the contactless card over the center of contactless card reader logo area.  Scan When the scan indicator is on, hold your QR code & bar code device in front of the scan window to scan code. 5、Load Printer Paper 1. I nsert the key into the keyhole and turn it counterclockwise to open printer cover. 2. Completely open the printer cover. 3. Insert the new paper roll into the printer. 4. Pull out the end of the paper so that itextends past the cutting blade, Make surethe paper roll is placed in the direction asshown in the figure below. 5.Close the printer cover, and pull outthe key. Printer will automatically cut offthe extra paper, the paper is changed successfully. 6、Wall-mounted Installation  Parts List No. Part Picture Qty/pcs 1 SK700Kiosk 1 2 Wall Bracket 1 3 M6-50 Expansion Screw 6 4 M4-10 Combination Screw 2 Installation Steps 1.U se 6pcs expansion screws to fix the bracket on the wall. •Use an 8.0 mm diameter drill bit to drill holes in the wall according to the position of th e b racket fixing hole. The size is shown in the figurebelow: •Note: Holediameter is 8.0mm, Hole depth is above 60.0mm. 2.Use the 4pcs hooks on the back of the device to hang the whole device on the wall bracket. 3.Use 2pcs M4-12 combination 3screws to attach the machine to the wall bracket at the bottom of the machine. 4.The device installation is completed. 7. Usage Tips 1)There is no built-in battery, and the device can only be powered by the power adapter. 2) A void exposing the device in overheated, humid, dusty, or strong electromagnetic environment. 3) D o not vibrate, shake, or drop the device. 4) D o not insert or unplug any part of the device while it is powered on. Otherwise, it may cause damage to the internal circuit. 5) I f necessary, please contact PAX technical support for assistance with the device. 6) B efore using the magnetic stripe /IC/contactless card, check if there is any suspicious person nearby, if so, pay attention to guard against theft. F CC compliance statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. c hanges or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. ISED compliance statement This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. L’émetteur/récepteur exempt de licencecontenu dans le présentappareilestconforme aux CNR d’Innovation, Sciences et Développementéconomique Canada applicables aux appareils radio exempts de licence. L’exploitationestautorisée aux deux conditions suivantes : (1) L’appareil ne doit pas produire de brouillage; (2) L’appareildoit accepter tout brouillage radioélectriquesubi, même si le brouillageest susceptible d’encompromettre le fonctionnement. I SED 5G Wi-Fistatement The user manual for LE-LAN devices shall contain instructions related to the restrictions mentioned in the above sections, namely that: i.the device for operation in the band 5150–5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems; ii.where applicable, antenna type(s), antenna models(s), and worst-case tilt angle(s) necessary to remain compliant with the e.i.r.p. elevation mask requirement set forth in section 6.2.2.3 …
