Model number : ANT-2WSH Photographs (Outside)

Model Number : ANT-2WSH Label Information

Model Number : ANT-2WSH Photographs (Inside) Model Number : ANT-2WSH Photographs (Inside)

Report No.: 10-341-027 Page 1 of 16 Pages 1271-12, Sa-Dong Sangnok-Gu, Ansan-si Gyunggi-Do , Korea. Tel. : +82-31-5000-133 http://www.ktl.re.kr Fax. : +82-31-5000-149 FP-204-03-01 TEST REPORT 1. Applicant Name : SEGI LIMITED Address : Room 1808, 18/F, Tower 2, Admiralty Center, 18 Harcourt road, Hongkong City, 186, CHINA 2. Products Name : Security/Remote Control transceiver (Car Alarm System) Model/Type : ANT-2WSH Manufacturer : SEGI LIMITED 3. Test Standard : FCC CFR 47 Part 15, Subpart C section 15.231 IC RSS 210 Annex I - 2007 4. Test Method : ANSI C63.4-2003 5. Test Result : Positive 6. Date of Application : June. 26, 2010 7. Date of Issue : August. 4, 2010 Tested by Approved by ` Jong-gon Ban Jeong-min Kim Telecommunication Center Engineer Telecommunication Center Manager The test results contained apply only to the test sample(s) supplied by the applicant, and this test report shall not be reproduced in full or in part without approval of the KTL in advance. Report No.: 10-341-027 Page 2 of 16 Pages 1271-12, Sa-Dong Sangnok-Gu, Ansan-si Gyunggi-Do , Korea. Tel. : +82-31-5000-133 http://www.ktl.re.kr Fax. : +82-31-5000-147 FP-204-03-01 TABLE OF CONTENTS 1. GENERAL INFORMATIONS .................................................................................................. 3 1.1. Applicant (Client) .............................................................................................................................................. 3 1.2. Equipment (EUT) ............................................................................................................................................... 3 1.3. Testing Laboratory ............................................................................................................................................ 4 2. SUMMARY OF TEST RESULTS ............................................................................................ 5 3. TEST RESULTS .................................................................................................................... 6 3.1. Transmission Requirements [FCC Part 15.231(a) & RSS-210 A1.1.1] ......................................................... 6 3.1.1. Requirements of Transmission Time ........................................................................................................ 6 3.1.2. Test Results .............................................................................................................................................. 6 3.2. Bandwidth of Momentary Signals [FCC Part 15.231(c) & RSS-210 A1.1.3] ................................................. 7 3.2.1. Requirements of Bandwidth ..................................................................................................................... 7 3.2.2. Test Results (20 dB Bandwidth) ............................................................................................................... 7 3.2.3. Test Results (99% Bandwidth) ................................................................................................................. 8 3.3. Duty Cycle Correction Factor .......................................................................................................................... 9 3.4. Radiated Spurious Emissions : Session 15.205 & 15.209 .......................................................................... 11 3.4.1. Test Procedure ....................................................................................................................................... 11 3.4.2. Limits ...................................................................................................................................................... 12 3.4.3. Test configuration ................................................................................................................................... 12 3.4.4. Test Results ............................................................................................................................................ 13 4. TEST EQUIPMENT .............................................................................................................. 15 APPENDIX.1 TEST SETUP PHOTO ........................................................................................ 16 Report No.: 10-341-027 Page 3 of 16 Pages 1271-12, Sa-Dong Sangnok-Gu, Ansan-si Gyunggi-Do , Korea. Tel. : +82-31-5000-133 http://www.ktl.re.kr Fax. : +82-31-5000-147 FP-204-03-01 1. GENERAL INFORMATIONS 1.1. Applicant (Client) Name SEGI LIMITED Address Room 1808, 18/F, Tower 2, Admiralty Center, 18 Harcourt road, Hongkong City,186, CHINA Contact Person Hyun-suk, Kim Telephone No. 82-32-623-5550 (#278) Facsimile No. 82-32-623-6667 E-mail address [email protected] Manufacturer Name SEGI LIMITED Manufacturer Address Chenjiapucun, Liaobu Town, Dongguan City, Guangdong Province, P.R.China(523-408) 1.2. Equipment (EUT) Type of equipment Security/Remote Control transceiver (Car Alarm System) Model Name ANT-2WSH FCC ID VA5JA580-2A433 IC Number 7087A-A580A433 Frequency Band 433.92 MHz EUT Modes of Operation Transceiver Type of Modulation ASK Number of Channels 1 channel Input power supply DC 12 V Report No.: 10-341-027 Page 4 of 16 Pages 1271-12, Sa-Dong Sangnok-Gu, Ansan-si Gyunggi-Do , Korea. Tel. : +82-31-5000-133 http://www.ktl.re.kr Fax. : +82-31-5000-147 FP-204-03-01 1.3. Testing Laboratory Testing Place Korea Testing Labortory (KTL) 1271-12, Sa-Dong Sangnok-Gu, Ansan-si Gyunggi-Do , Korea FCC registration number 408324 Industry Canada filing number 6298A-1 Test Engineer Jong-gon Ban Telephone number +82 31 5000 133 Facsimile number +82 31 5000 149 E-mail address [email protected] Other Comments - Report No.: 10-341-027 Page 5 of 16 Pages 1271-12, Sa-Dong Sangnok-Gu, Ansan-si Gyunggi-Do , Korea. Tel. : +82-31-5000-133 http://www.ktl.re.kr Fax. : +82-31-5000-147 FP-204-03-01 2. SUMMARY OF TEST RESULTS Testing performed for : SEGI LIMITED Equipment Under Test : ANT-2WSH Receipt of Test…

Text truncated - open the document above for the full version.

1271-12, Sa-Dong Sangnok-Gu, Ansan-si Gyunggi-Do , Korea. Tel. : +82-31-500-0133 http://www.ktl.re.kr Fax. : +82-31-500-0149 FP-204-03-01 Test Setup photos <X plane> <Y plane> 1271-12, Sa-Dong Sangnok-Gu, Ansan-si Gyunggi-Do , Korea. Tel. : +82-31-500-0133 http://www.ktl.re.kr Fax. : +82-31-500-0149 FP-204-03-01 <Z plane>
