VA5REC320-1WSPkeyless entry system (Model: 1WG7R-SP)

SEGI LIMITED

Click to zoom

Application Details

Equipment Class: DSC - Part 15 Security/Remote Control Transmitter
Date of Grant: Jul 25, 2012
Application Purpose: Original Equipment
Date of Application: Jul 23, 2012
Equipment Note: keyless entry system (Model: 1WG7R-SP)
Frequency Range: 433.92000000 - 433.92000000
Company: SEGI LIMITED
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

www.compustar.comwww.firstechonline.com Este dispositivo está sujeto a la seccion 15 de las reglas de FCC. El funcionamiento está sujeto a las siguientes condiciones; (1)este dispositivo no puede causar interferencia dañosa. (2)este dispositivo puede aceptar cualquier interferencia recibida, incluso interferencia que pueda causar mal funcionamiento al equipo. CUATELA: Cambios ó modificaciones no expresamente aprobadas por la parte responsable del cumplimiento de la norma, pueden anular la autorizacion del usuario para operar este dispositivo. Manual de Usuario Aplicable al remoto (s siguiente) A todos los remotos de 1 Via con 4 Botónes Applicable to the following remote(s):All 1Way 4Button Remote www.compustar.comwww.firstechonline.com Remote FCC ID Number IC ID Number (US Only)(International Only) 1WAMR-FianceO44J1WAM4R5532A-J1WAM4R 1WAMR-1600O44JR16005532A-JR1600 1WAMR-1800O44JR1800A4337087A-R1800AM 1WAMR-1900O44JR5120AMSH7087A-R5120AM 1WAMR-762VA5JR762A4337087A-R762A433 1WAMR-763VA5JR763AM4337087A-R763A433 NU1000RO44JR1700A4337087A-R150A433 NU2000RN/A7087A-R150F433 1WFMR-FianceO44J1WFM4R7087A-1WFM4R 1W900FMRN99J1WPLL4R5532A-J1WPLL4R RemotoNo. ID FCCNo. ID IC (Solamente EEUU )(Internacional Solamente) 1WAMR-FianceO44J1WAM4R5532A-J1WAM4R 1WAMR-1600O44JR16005532A-JR1600 1WAMR-1800O44JR1800A4337087A-R1800AM 1WAMR-1900O44JR5120AMSH7087A-R5120AM 1WAMR-762VA5JR762A4337087A-R762A433 1WAMR-763VA5JR763AM4337087A-R763A433 NU1000RO44JR1700A4337087A-R150A433 NU2000RN/A7087A-R150F433 1WFMR-FianceO44J1WFM4R7087A-1WFM4R 1W900FMRN99J1WPLL4R5532A-J1WPLL4R RemotoNo. ID FCCNo. ID IC (Solamente EEUU )(Internacional Solamente) 1W900FMR-ProVA5JR762F9077087A-762F907 1W900SHR-961VA5JR961AM7087A-R961AM 1WSS-25VA5JR762WSS7087A-R762WSS 1WG5R-SSVA5JR961-1WSS7087A-R961WSS VZ1WAMR-960N/A7087A-R960A433 FTX1400R-AMVA5JR500-1A4337087A-R500A433 1WG6R-AMVA5REC310-1W4337087A-1WREC310433 1WG8R-SSVA5JR762WSS7087A-R762WSS 1WG7R-SPVA5REC320-1WSP7087A-1WREC320SP 1WG9R-SPVA5REC340-1WSP7087A-1WREC340SP Remote FCC ID Number IC ID Number (US Only)(International Only) 1W900FMR-ProVA5JR762F9077087A-762F907 1W900SHR-961VA5JR961AM7087A-R961AM 1WSS-25VA5JR762WSS7087A-R762WSS 1WG5R-SSVA5JR961-1WSS7087A-R961WSS VZ1WAMR-960N/A7087A-R960A433 FTX1400R-AMVA5JR500-1A4337087A-R500A433 1WG6R-AMVA5REC310-1W4337087A-1WREC310433 1WG8R-SSVA5JR762WSS7087A-R762WSS 1WG7R-SPVA5REC320-1WSP7087A-1WREC320SP 1WG9R-SPVA5REC340-1WSP7087A-1WREC340SP ss@ @ ZZ t@@ਫ਼ic੟@@@@@@@@i@c@@@@N ccaauuttiioonn@ @ ZZ t@u@@@@@@@@@੝@@@@@N@ t@@@@p@QU@@@fcc@N@o@@@@@@[@@ HQI@t@@@@@@N@@@@@@ HRI@t@@@@@@L@@@@@@@N@@@@@@@@ ccaauuttiioonn@ @ ZZ c@@@@@@@@@@@@@@@੝@@@@@N@@ t@@@@rf@@@L@@@@@@@@@@@@@@ @RP@@@@@@N@cM@@@@@@@@@@@@N@ By Firstech, LLC 2 t@o@c iS w@cS q@rT g@s@fW v@mT r@m@M@b@rU Q@w@r@b@fU a@lOa@@uOdW a@t@r@s@fW m@t@r@s@f@Hr@mI X a@r@mX c@r@mY t@rY s@aOdY s@s@oOoY r@c@O@p@rHIQP p@Qw@Tb@rQP a@dQR r@s@e@dQQ l@l@wQT a@s@fQP By Firstech, LLC 2 3 By Firstech, LLC Introduction Thank you for purchasing a Firstech system for your vehicle. In order to truly enjoy the benefits of this system, we recommend that you thoroughly review the following manual. Please note that this manual applies to the 1 Way-4 Button Non Liquid Crystal Display Remotes, regardless of whether you purchased the alarm only, starter only or alarm/starter combination. There are certain features listed in this manual that may not be available for your system. There may also be features listed in this manual that require additional installation or programming before they are active. If you have any questions, please contact the original place of purchase. For further information you may also contact our customer support center by calling 888-820-3690. Warranty Coverage Caution: The Manufacture’s warranty will be voided if this product is installed by anyone other than an authorized Firstech dealer. For complete warranty details visit www.compustar.com or the last page of this manual. Firstech remotes carry a 1 year warranty from original date of purchase. Warranty registration can be completed online by visiting www.compustar.com. Please complete the registration form within 10 days of purchase. We do not include a mail in warranty registration card with each unit. Registration must be done online. To verify that an authorized dealer installed your system, we highly recommend that you keep a copy of the original proof of purchase, such as the dealer invoice in a safe place. 5 By Firstech, LLC By Firstech, LLC 4 Quick Reference When servicing or loaning your vehicle to others, the system should be in Valet mode. Valet mode prevents the system from remote starting and disables all alarm functions. IMPORTANT:While in Valet mode the remote will still control power lock and unlock systems. The parking lights will not flash. The system can be put into valet one of three ways:…

Text truncated - open the document above for the full version.

Cover Letter(s)

Date: June 20, 2012 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 c.c. Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize Mr. CY_Choi/ RAPA, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Mr. CY_Choi / RAPA on our behalf shall have the same effect as acts of our own. I, t he u ndersigned, h ereby cert ify that we are not su bject to a denial o f f ederal benefits, th at includes FCC b enefits, pursuant to Section 5301 of the Anti-Drug Abuse Act o f 1988, 21 U.S.C. 853(a). In authorizing RAPA as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Name: Young il / President Company: SEGI LIMITED REMARK: 1. This aut horization letter wi ll be sent along wi th yo ur application wh en fi ling wi th t he Certification Division. 2. Please follow the format and type it on company letterhead and send original to us. 3. Authorized signature must be in agreement with grantee code contact in FCC database.

Cover Letter(s)

SEGI LIMITED Room 1808, 18/F, Tower 2, Admiralty Center, 18 Harcourt Road, Admiralty, Hongkong city, 186, CHINA E-MAIL : [email protected] Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with Section pertaining to confidential material SEGI LIMITED would like the following documents regarding this submission for FCC ID : VA5REC320-1WSP to be kept confidenti al. 1. Block Diagram 2. Schematic 3. Operational Description The ab ov e m aterial contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely, Date 20th of June , 2012 By Eui Seok Chung Title : Associate Research Engineer ============================================================

External Photos

ID Label/Location Info

Internal Photos

Test Report

Page : 2 of 19 Report No. : RAPA12-O-410 It should not be reproduced in full or partly without the written approval by TCL of RAPA. FCC CFR Part15.231(Rev.0) Testing and Certification Laboratory CONTENTS 1. General description of EUT -------------------------------------------------------------------------------------3 1.1 Applicant---------------------------------------------------------------------------------------------------------------3 1.2 Manufacturer ---------------------------------------------------------------------------------------------------------3 1.3 Basic description of EUT ------------------------------------------------------------------------------------------3 1.4 Technical specification of EUT -----------------------------------------------------------------------------------4 2. General information of test -------------------------------------------------------------------------------------5 2.1 Standard for measurement method ----------------------------------------------------------------------------5 2.2 Description of EUT modification ---------------------------------------------------------------------------------5 2.3 Test configuration ------------------------------------------------------------------------------------------5 3. Measurement data ---------------------------------------------------------------------------------------------------5 3.1 Transmission time ---------------------------------------------------------------------------------------------------6 3.2 Field strength of fundamental and spurious emission ----------------------------------------------------14 3.3 20 dB bandwidth ---------------------------------------------------------------------------------------------------17 4. Test equipment list -------------------------------------------------------------------------------------------------19 Page : 3 of 19 Report No. : RAPA12-O-410 It should not be reproduced in full or partly without the written approval by TCL of RAPA. FCC CFR Part15.231(Rev.0) Testing and Certification Laboratory 1. General description of EUT 1.1 Applicant • Company name : SEGI LIMITED • Address : Room 1808, 18/F, Tower 2, Admiralty Centre, 18 Harcourt Rd., Admiralty, Hong Kong • Contact person : Eui Seok, Chung • Phone/Fax : 82-32-623-5550 / 82-32-623-6667 1.2 Manufacturer • Company name : SEGI ELECTRONICS CO., LTD • Address : Chenjiapucun, Liaobu Town, Dongguan City, Guangdong Province, P.R.China • Contact person : Eui Seok, Chung • Phone / Fax : 82-32-623-5550 / 82-32-623-6667 1.3 Basic description of EUT • Product name : Keyless Entry System • Model name : 1WG7R-SP • Serial number : Not available(Proto Type) • Frequency : 433.92 MHz(Tx) • Channel number : 1 Channel • Modulation method : ASK • FCC Rule Part(s) : FCC CFR47 Part 15 Subpart C Section 15.231 • IC Rule Part(s) : IC RSS-210 Issue8 Annex 1-2010 • FCC classification : DSC / Part 15 Security/Remote control Transmitter • IC classification : Annex 1 / Momentarily Operated Devices and Remote Control • Date of test : June 18, 2012 to July 2, 2012 • Date of issue : July 3, 2012 • Place of test : Head office 824, B104, Anyang Megavalley, 799, Gwanyang-dong, Dongan-gu, Anyang-si, Gyeonggi-do, Korea, 483-060 Open area test site 80, Jeil-ri, Yangji-myun, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea, 449-825 (FCC Registration Number : 337229) (IC Submission Number : 143881) (KCC Designation Number : KR0027) Page : 4 of 19 Report No. : RAPA12-O-410 It should not be reproduced in full or partly without the written approval by TCL of RAPA. FCC CFR Part15.231(Rev.0) Testing and Certification Laboratory 1.4 Technical specification of EUT Model Name 1WG7R-SP Product Name Keyless Entry System Size(mm) 34.0 x 58.4 x 13.7 (W x L x H) Battery Size CR2016 Battery 2EA Transmit Frequency 433.92 MHz Modulation Method ASK Page : 5 of 19 Report No. : RAPA12-O-410 It should not be reproduced in full or partly without the written approval by TCL of RAPA. FCC CFR Part15.231(Rev.0) Testing and Certification Laboratory 2. General information of test 2.1 Standard for measurement methods 2.2 Description of EUT modification During the test, there was no mechanical or circuitry modification to improve RF and spurious characteristic, and any RF and spurious suppression device(s) was not added against the device tested. 2.3 Test configuration • Type of peripheral equipment used Description Model Name Serial No.ManufacturerFCC ID IC Number EUT 1WG7R-SP N/A SEGI Electronics Co., Ltd. VA5REC320-1WSP 7087A-1WREC320SP • Type of cable used Device from Device to Type of Cable Cable Number Length - - - - - Applied Standard : FCC CFR47 Part 15 Subpart C, IC RSS-210 Issue8 Annex 1-2010 FCC IC Description of Test Limit Result 15.231(a) A1.1.1 Transmission Time(s) 5 Pass 15.231(b) A1.1.2 Field Strength of Fundamental (dBμV/m) 101.24(Peak) / 81.24(AVG) Pass 15.231(b) & 15.209 A1.1.2 Radiated Emission(dBμV/m) 81.24(Peak) / 61.24(AVG) Pass 15.231(c) A1.1.3 Occupied Bandwidth(kHz) 1 084.8 kHz Pass Page : 6 of 19 Report No. : RAPA12-O-410 It should not be reproduced in full or partly without the written approval by TCL of RAPA. FCC CFR Part15.231(Rev.0) Testing and Certification Laboratory EUT Spectrum Analyzer 3. Measurement data 3.1 Transmission time 3.1.1 Definitions A transmission time is a switching time that will automatically deactivate the transmission of transmitter of EUT. 3.1.2 Specification FCC Rules Part 15 Subpart C Section 15.231(a)(1) IC Rules RSS-210 Issue8 Annex 1-2010 A1.1.1 3.1.3 Measurement method The device output is connected to the spectrum analyzer. 3.1.4 Set-Up 3.1.5 Test equipment list Equipment Model Name Manufacture EUT 1WG7R-SP SEGI Electronics Co., Ltd. Spectrum Analyzer N9020A Agilent 3.1.6 Test procedure Spectrum analyzer setting; • Center Frequency: 433.92 MHz • Span: Zero • RBW: 100 kHz • VBW: 100 kHz • Sweep time: 1 s • Detect Mode: Peak 3.1.7 Test condition • Test place: Shield Room • Test mode: Normal Operation • Test envi…

Text truncated - open the document above for the full version.

Test Setup Photos

SEGI LIMITED Keyless Entry System 1WG7R-SP It should not be reproduced in full or partly without the written approval by TCL of RAPA. Testing and Certification Laboratory Appendix 1. Photos of Test Setup 1. Test Setup of Radiation (30 MHz ~ 300 MHz) SEGI LIMITED Keyless Entry System 1WG7R-SP It should not be reproduced in full or partly without the written approval by TCL of RAPA. Testing and Certification Laboratory Appendix 1. Photos of Test Setup 2. Test Setup of Radiation (300 MHz ~ 1 GHz) SEGI LIMITED Keyless Entry System 1WG7R-SP It should not be reproduced in full or partly without the written approval by TCL of RAPA. Testing and Certification Laboratory Appendix 1. Photos of Test Setup 3. Test Setup of Radiation (1 GHz ~ 5 GHz)
