VAAWFTLV5Laser trigger

DATE : 2012-11-05 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: VAAWFTLV5 Product Name: Laser trigger Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) • Schematics • Block diagram • Operational Description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this Day of 20 Agency agreement expiration date: Nov. 05, 2012 to Nov. 04, 2013 By: Wai Kwan Ling Si gnature Printed Title: Director On behalf of : Harvest One Limited Telephone: 852-3525-0116

DATE : 2012-11-05 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Christy Chen of CENTRE TESTING INTERNATIONAL / Building C, Hongwei Industrial Zone, Baoan 70 District _, (Name and address，person). to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with Harvest One Limited / 9D On Shing Industrial Building, 2-16 Wo Liu Hang Road, Fo Tan, N.T., Hong Kong Dated this Day of 20 Agency agreement expiration date: Nov. 05, 2012 to Nov. 04, 2013 By: Wai Kwan Ling Signature Printed Title: Director On behalf of : Harvest One Limited Telephone: 852-3525-0116

FCC LABEL INFORMATION: Label

Cactus Laser Trigger LV5 BOM Cactus Laser Trigger LV5 BOMCactus Laser Trigger LV5 BOM Cactus Laser Trigger LV5 BOM Date : 2 Nov., 2012 * Laser unit* Sensor unit SMD LEVEL SMD LEVELSMD LEVEL SMD LEVEL ItemPart No.DescriptionQty (TX)Qty (RX)Qty (Total)Ref (TX)Ref (RX) S01 BIC-00002-A00 Binary Counter, 4060, SOIC-16101 U1 S02 INV-00002-A00 Hex Inverter, SOIC, 14-pin112 U4U2 S03 COV-00001-A00 Synchronous Boost Converter, 0.85V startup, 1MHz, 300mA lout, SOT23-5 112 U2U1 S04 IND-00001-A00 Chip Inductor, 33uH, 3 x3.6mm, SMD 112 L1L1 S05 CAP-00001-A00 Chip Cap, 0.1uF, +80~20%, 16V OR ABOVE, 0603, X7R3 58 C1,6-7C1,3-4,7,18 S06 CAP-00003-A00 Chip Cap, 100pF, NPO, 16V OR ABOVE, 0603 123 C8C10-11 S07 CAP-00004-A00 Chip Cap, 22pF, NPO, 16V OR ABOVE, 0603224 C2-3C9,13 S08 CAP-00002-A00 Chip Cap, 0.01uF, +80~20%, 16V OR ABOVE, 0603, X7R033C14-15, 16 S09 CAP-00005-A00 Chip Cap, 1uF, +80~20%, 6.3V, 0603, X5R0 44C5, 19-21 S11 RCT-00008-A00 Chip Resistor, 470R OHM, 5%, 0603101 R6 S12 RCT-00005-A00 Chip Resistor, 4.7K OHM, 5%, 0603224 R7,10R19,20 S13 RCT-00006-A00 Chip Resistor, 100K OHM, 5%, 0603369 R2-3,8R4-7,13,21 S14 RCT-00009-A00 Chip Resistor, 1M OHM, 5%, 0603224 R1,5R11,14 S15 RCT-00004-A00 Chip Resistor, 10K OHM, 5%, 0603246 R9,11 R3,8,23,24 S16 RCT-00003-A00 Chip Resistor, 47R OHM, 5%, 0603022R2,R18 S17 RCT-00002-A00 Chip Resistor, 100R OHM, 5%, 0603022R1,17 S18 RCT-00010-A00 Chip Resistor, 1K OHM, 5%, 0603011R12 S19 RCT-00007-A00 Chip Resistor, 470K OHM, 5%, 0603033R15-16,26 S20 RCT-00011-A00 Chip Resistor, 2M OHM, 5%, 0603022R9.10 S21 CAP-00011-A01 Tant Cap, 10uF, 10V, 10%, TYP. A123 C4C2,17 S22 TRA-00001-A00 Transistor, NPN, 25V, 0.8A, SOT-23246 Q1,Q3Q1-2,4-5 S23 TRA-00002-A00 Transistor, PNP, 25V, 0.8A, SOT-23112 Q2Q3 S24 SWI-00003-A00 Slide switch, 1P2T, SKYB-12D22-G2-0A1 23S2S2,3 S25 SWI-00004-A01 Slide switch, TS-1135HSV-E-250-REEL112S3S5 S26 CAP-00010-A00 SMD E cap, V-chip Type VE, 47uF, 6.3V Size:5x5mm123 C5C8, C12 S27 DIO-00001-A00 Schottky Barrier Diode, 20V, 0.625A, SOD-323224 D1-2D2,3 S28 WAF-00002-A01 Wafer, 4P SMT, STRAIGHT, PITCH 1.25MM, for Power112 J1J1 S29 VOD-00001-A00Voltage Detector, 2.1V, +/-1%, N-ch output, SOT-23011U3 S30 LED-00002-A00 CHIP LED, BI-COLOR, 3.2x1.6mm SMD011LED1 S31 SWI-00001-A00 Rotary Dip Switch, Real Code, 16 Position, SMD011S1 S32 SWI-00008-A00 Double Action switch011S4 S33 DIO-00002-A00 Diode, LL4148011D1 S34 JAC-00002-A00 Phone Jack, 3.5MM, Stereo, SMD TYPE011J2 S35 FPC-LV5A-A01 FPC connector, upper connection, PITCH 1.0mm, PIN 20011J4 S36 FPC-LV5B-A02 FPC, 21X 25.5mm011 S37 RFM-00001-A02 2.4 Ghz RF module, VT-CC2500PA-H1011RF1 S38 MCU-00002-A00 MCU, PIC16F723, SSOP28011U4 S39 PCB-LV5ER-A00 MAIN PCB, 45.50*53.00mm, 1.60mm Thick, Lead free HASL Finishing101 S40 PCB-LV5SR-A00 MAIN PCB, 45.50*53.00mm, 1.60mm Thick, Lead free HASL Finishing011 MOD LEVEL MOD LEVELMOD LEVEL MOD LEVEL ItemNew Part No.DescriptionQty (TX)Qty (RX)Qty (Total)Ref (TX)Ref (RX) B01 QUA-00001-A01 Quartz , 32.768kHZ, +/-10ppm, 2 x6mm, C-002RX112 X1X1 B02 WIR-00003-A00 Wire assembly, 4P, L=42mm, UL1571112 B03 LAS-00001-A02 Laser module, dia. 7mm, baking varnish Pantone black C101 B04 SEN-00001-A00 Photo Sensor, 3mm011SEN1

Report No. : EESZE07270003-1 Page 2 of 22 TABLE OF CONTENTS 1. GENERAL INFORMATION ......................................................................................... 3 2. TEST SUMMARY ........................................................................................................ 3 3. MEASUREMENT UNCERTAINTY .............................................................................. 3 4. TEST EQUIPMENT LIST ............................................................................................. 4 5. SUPPORT EQUIPMENT LIST .................................................................................... 4 6. PRODUCT INFORMATION ......................................................................................... 4 7. 20DB & 99% BANDWIDTH MEASUREMENT ............................................................ 5 7.1 LIMITS ............................................................................................................ 5 7.2 BLOCK DIAGRAM OF TEST SETUP ............................................................ 5 7.3 TEST PROCEDURE ....................................................................................... 5 7.4 TEST RESULT ................................................................................................ 5 8. RADIATED EMISSIONS MEASUREMENT ................................................................ 8 8.1 LIMITS ............................................................................................................ 8 8.2 BLOCK DIAGRAM OF TEST SETUP ............................................................ 8 8.4 TEST RESULT .............................................................................................. 10 9. BAND EDGE EMISSION MEASUREMENT .............................................................. 16 9.1 LIMITS .......................................................................................................... 16 9.2 BLOCK DIAGRAM OF TEST SETUP .......................................................... 16 9.3 TEST PROCEDURE ..................................................................................... 16 9.4 TEST RESULT .............................................................................................. 16 APPENDIX 1 PHOTOGRAPHS OF TEST SETUP ....................................................... 18 APPENDIX 2 PHOTOGRAPHS OF EUT ...................................................................... 19 (Note: N/A means not applicable) Report No. : EESZE07270003-1 Page 3 of 22 1. GENERAL INFORMATION The above equipment was tested by Centre Testing International for compliance with the requirements set forth in the FCC Rules and Regulations Part 15 and the measurement procedure according to ANSI C63.4:2009. 2. TEST SUMMARY The complete list of measurements is given below: No. Test Item Rule Result 1 20dB Bandwidth FCC 15.215(c) PASS 2 Radiated Emission FCC 15.209 PASS 3 Out of Band Emission FCC 15.249 (d) PASS 4 Antenna Requirements * FCC 15.203 PASS *: According to Section 15.203, an intentional radiator shall be designed to ensure that no antenna other than that furnished by the responsible party shall be used with the device. The EUT has a built in antenna which is a short wire solder on the PCB, this is permanently attached antenna and meets the requirements of this section. 3. MEASUREMENT UNCERTAINTY This uncertainty represents an expanded uncertainty expressed at approximately the 95% confidence level using a coverage factor of k=2. Measurement items Uncertainty Radiated Emissions 4.5 dB Applicant: Harvest One Limited 9D On Shing Industrial Building, 2-16 Wo Liu Hang Road, Fo Tan, N.T.,Hong Kong FCC ID: VAAWFTLV5 Product: Laser trigger Trade mark: N/A Model/Type reference: LV5 Serial Number: N/A Report Number: EESZE07270003-1 Sample Received Date: Oct. 29, 2012 Sample tested Date: Oct. 29, 2012 to Nov. 05, 2012 Report No. : EESZE07270003-1 Page 4 of 22 4. TEST EQUIPMENT LIST Equipment Manufacturer Model Number Serial Number Due Date 3M Chamber & Accessory Equipment ETS-LINDGREN FACT-3 3510 07/09/2013 Spectrum Analyzer Agilent E4440A MY46185649 03/07/2013 TRILOG Broadband Antenna schwarzbeck VULB 9163 401 07/06/2013 Multi device Controller ETS-LINGREN 2090 00057230 N/A Horn Antenna ETS-LINGREN 3117 00057407 07/06/2013 Microwave Preamplifier Agilent 8449B 3008A02425 03/29/2013 Loop Antenna ETS-LINDGERN 6502 71730 07/06/2013 5. SUPPORT EQUIPMENT LIST No. Device Type Brand Model Series No. Data Cable Power Cord ---- ---- ---- ---- ---- ---- ---- ---- ---- ---- ---- ---- ---- ---- ---- ---- ---- ---- ---- ---- ---- 6. PRODUCT INFORMATION Items Description Rating DC 3V Intentional Transceiver Intentional Transmitter Modulation MSK Frequency Range 2.4457967832.480988190GHz Channel Number 16 Frequency 2.445796783GHz, 2.445796783GHz, 2.445796783GHz, 2.445796783GHz, 2.445796783GHz, 2.448996002GHz, 2.452195221GHz, 2.455394440GHz, 2.458593658GHz, 2.461792877GHz, 2.464992096GHz, 2.468191315GHz, 2.471390533GHz, 2.474589752GHz, 2.477788971GHz, 2.480988190GHz Type PCB Antenna Connector fixed on board Report No. : EESZE07270003-1 Page 5 of 22 7. 20DB BANDWIDTH MEASUREMENT 7.1 LIMITS None 7.2 BLOCK DIAGRAM OF TEST SETUP 7.3 TEST PROCEDURE 1. The transmitter output (antenna port) was connected to the spectrum analyzer. 2. Set spectrum analyzer’s RBW and VBW to applicable value with Peak in Max Hold. 3. A PEAK output reading and 20dB BW function in spectrum analyzer were taken. 7.4 TEST RESULT 20dB Bandwidth: Channel Frequency (GHz) 20 dB BW (MHz) Result (MHz) Low 2.445796783 1.027 1.039 Middle 2.464992096 1.005 High 2.480988190 1.039 Report No. : EESZE07270003-1 Page 6 of 22 Channel low Channel middle Report No. : EESZE07270003-1 Page 7 of 22 Channel high Report No. : EESZE07270003-1 Page 8 of 22 8. RADIATED EMISSIONS MEASUREMENT 8.1 LIMITS (1) The field strength of emissions from intentional radiators operated within these frequency bands shall comply with the following: Fundamental fr…
