VBNAKQW-01AKQW AirScale RRH 8T8R n77 320W

Applicant: Nokia Solutions and Networks -1 - FCC ID: VBNAKQW-01 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 12/12/23 Ref: Attestation Statements Part 2.911(d)(7) Filing FCC ID: VBNAKQW-01 Nokia Solutions and Networks (“the applicant”) certifies that, as of the date of the filing of the application, we designate ourselves as the U.S. agent for service of process. Designated U.S. Agent Information: FRN: 0016412652 Name: Nokia Solutions and Networks Address: 3201 Olympus Blvd Dallas, Texas 75019, USA Contact Person: Steve Mitchell Tel.: 972-936-7500 Email: [email protected] Sincerely, _______________________________ Steve Mitchell Nokia Solutions and Networks

Applicant: Nokia Solutions and Networks -1 - FCC ID: VBNAKQW-01 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 12/12/23 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: VBNAKQW-01 Nokia Solutions and Networks (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Steve Mitchell Nokia Solutions and Networks 3201 Olympus Blvd Dallas, Texas 75019 USA 972-936-7500 [email protected] Applicant: Nokia Solutions and Networks -2 - FCC ID: VBNAKQW-01 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 12/12/23 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: VBNAKQW-01 Nokia Solutions and Networks (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing“covered” equipment. Sincerely, Steve Mitchell Nokia Solutions and Networks 3201 Olympus Blvd Dallas, Texas 75019 USA 972-936-7500 [email protected]

APPLICANT: Nokia Solutions and Networks FCC ID: VBNAKQW-01 Public Page 1 of 2 Exhibit 3 – FCC REQUIRED INFORMATION The following information is presented in the content and format requested by FCC: Section 2.1033 (c)(1): The full name and mailing address of the manufacturer of the device and the applicant for certification Manufacturer: NOKIA SOLUTIONS AND NETWORKS OY KARAKAARI 7, FI-02610 ESPOO FINLAND Applicant: Nokia Solutions and Networks 3201 Olympus Blvd Dallas, Texas 75019 USA Attention: Steve Mitchell Phone: 972-936-7500 email: [email protected] Section 2.1033(c)(5): FCC Identifier: VBNAKQW-01 Section 2.1033(c)(7): Type or types of emission: The Nokia AKQW AirScale RRH 8T8R n77 320W is capable of amplifying transmission involving the following types of emissions: Bandwidth (MHz) Emissions Designator 20 18M9G7W 30 28M0G7W 40 37M9G7W 50 47M4G7W 60 58M1G7W 70 67M6G7W 80 77M7G7W 90 87M5G7W 100 97M3G7W APPLICANT: Nokia Solutions and Networks FCC ID: VBNAKQW-01 Public Page 2 of 2 Section 2.1033(c)(8): Frequency range, Transmit/Receive: Band Transmit/Receive Range (MHz) Bandwidth (MHz) n77 3700-398010-100 Section 2.1033(c)(9): Range of operating power values or specific operating power levels, and description of any means provided for variation of operating power. Response: The AKQW AirScale RRH 8T8R n77 320W is capable operating from 33 dBm to 46 dBm/port in 0.1 dB steps. Section 2.1033(c)(10): Maximum power rating as defined in the applicable part (s) of the rules. Response: The maximum average power output of the AKQW AirScale RRH 8T8R n77 320W at the Antenna connection is summarized in the following table: Operation Mode Max Power per Port Total Max Power Modulation 8T8R 40W320.0 W5G-NR

APPLICANT: Nokia Solutions and Networks FCCID: VBNAKQW-01 EXHIBIT 2 Section 2.911 (d) CERTIFICATION OF TECHNICAL TEST DATA To Whom it may Concern: This is to certify that the AKQW AirScale RRH 8T8R 320W Radio Unit, Operating in Band n77 with FCCID: VBNAKQW-01, manufactured by Nokia is compliant with FCC part 27 and operates in the n77 5G-NR frequency band, 3700 - 3980 MHz. R.J. Johnson Technical Manager FCC Compliance Test Group Section 2.911 (e) QUALIFICATION OF ENGINEERS Nilesh Patel is a Member of Technical Staff at Nokia. He received a BE in Electronics and Telecommunications degree in 1996 from College of Engineering, Pune, India. He has more than 20 years of experience in the EMC regulatory industry. He has developed test plans and conducted RF tests including the required FCC tests for radio equipment certification. Section 2.911(d) CERTIFICATION OF TECHNICAL TEST DATA I hereby certify that the technical test data are the results of tests supervised by me. Nilesh Patel Member of Technical Staff Public Page 1 of 1

Applicant: Nokia Solutions and Networks FCC ID: VBNAKQW-01 Public Timco Engineering Inc. Nokia Global Product Compliance Laboratory FCC Authorized Telecommunication Certification Body 600-700 Mountain Avenue, Room 5A-107 13146 NW 86th Drive Suite 400 Alachua, FL 32615 Murray Hill, NJ 07974, USA 01/05/2024 Subject: Application for Original Equipment Certification under FCC ID: VBNAKQW-01 for AKQW AirScale RRH 8T8R 320W. Dear Examiner: The Nokia AKQW AirScale RRH 8T8R n77 320W (hereinafter referred to as “AKQW”) is a RRH operating under the regulations of FCC Part 27 - Cellular Telephone Systems Operating in Band n77, 3700-3980 MHz. The AKQW supports 5G-NR TDD technology, up to 8 MIMO ports configured for 8x40W (320W Total). The AKQW supports single and multiple contiguous and non-contiguous carriers. The power levels tested were limited for 20MHz (160 W), 30 MHz (240 W) and 40 MHz (280 W) carriers. The full 320 W power capability of the EUT was tested for all remaining configurations. The key data are summarized below. FCC ID: VBNAKQW-01 FCC Rules: Part 27 Frequency Range: Band n77, 3700-3980 MHz Conducted Output Power: Up to 46 dBm/Port (320W Total) Frequency Tolerance: ± 0.05 ppm Emissions Designators: 18M9G7W, 28M0G7W, 37M9G7W, 47M4G7W, 58M1G7W, 67M6G7W, 77M7G7W, 87M5G7W, 97M3G7W Enclosed in this application package are FCC 731 Form, letters of Request for Permanent Confidentiality, agent authorization letter, the required measurement data, and other required exhibits specific to this request for authorization of the subject product. The measurement exhibits attached to this application demonstrate full compliance with FCC Part 27 following the procedural requirements specified in FCC Part 2 Subpart J – Equipment Authorization Procedures. The supporting exhibits are assembled and presented in accordance with the Table of Contents attached below. Should there be any questions or procedural issues please feel free to contact me by email and/or phone. Sincerely, Applicant: Nokia Solutions and Networks FCC ID: VBNAKQW-01 Public Raymond J. Johnson Technical Manager Global Product Compliance Laboratory Phone: 908-679-6220 email: [email protected] Filing Engineer Nilesh Patel email: [email protected] Applicant: Nokia Solutions and Networks FCC ID: VBNAKQW-01 Public TABLE OF CONTENTS Cover Letter Agent Authorization Letter Letter of Confidentiality Request Attestation Statements Part 2.911(d)(5)(i)(ii) Filing Attestation Statements Part 2.911(d)(7) Filing Required Exhibits: Exhibit Number FCC Rule Number Description 1 Section 2.1033(a), 2.911(d) FCC Form 731 2 Section 2.911(d) Qualifications and Certifications 3 Section 2.1033(c) (1,5,7‐10) Manufacturers, FCC Identifier, Emission, Range of RF Power & Frequency 4 Section 2.1033(c)(14), 2.925(a)(1) Drawing of the Identification Label 5 Section 2.1033(c)(11,12,16) Active Device Tune‐up, Modulation System, Operation (Confidential) 6 Section 2.1033(c)(13) Block Diagram (Confidential) 7 Section 2.1033(c)(13) Complete Circuit Diagrams (Confidential) 8 Section 2.1033(c)(6) Installation Manual (Confidential) 8a Section 2.1033(c)(6) Manual ‐ NDA (Confidential) 9 Section 2.1033(c)(15) Internal Photographs of the Equipment (Confidential) 10 Section 2.1033(c)(15) External Photographs of the Equipment 11 Section 2.1033(c)(24) Photographs of the Test Setups 12 Sections 2.1033(f), 1.1307 & 1.1310 RF Exposure Assessment (MPE Report) 13 Section 2.1033(c)(13) Parts List (Confidential) 14 Section 2.1033(17), 2.911(e) Test Report

Federal Communications Commission Authorization and Evaluation Division Date: December 13, 2023 Confidentiality Request for: FCC ID: VBNAKQW-01 To Whom It May Concern, Pursuant to FCC 47 CRF 0.457(d) and 0.459, Section 10, Nokia Solutions and Networks requests that a part of the subject FCC and/or IC application listed below be held permanently confidential and permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. • Exhibit 5 Active Device Tune Up, Modulation System, Operation Block Diagram • Exhibit 6 Block Diagrams • Exhibit 7 Complete Circuit Diagram • Exhibit 8 Installation Manual • Exhibit 8a NDA • Exhibit 9 Internal Photographs • Exhibit 13 Parts List Confidentiality of the User Manual is maintained by requiring that any party that is supplied a user manual must first sign a non-disclosure agreement. Currently only cellular system operators have access to these manuals. Internal photos are kept confidential by virtue of the fact that the end product is a non- consumer product, certified and housed in a sealed enclosure, and is only accessible by trained /approved maintenance personnel. Further, the Applicant has spent substantial effort in developing this product, some aspects of which are deemed to be trade secret and proprietary. Having the subject information easily available to our competitors in this market would negate the advantage we have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Sincerely, ______________________________ Steve Mitchell Nokia Solutions and Networks 3201 Olympus Blvd Dallas, Texas 75019 USA 972-936-7500 [email protected] Permanent Confidentiality Request Letter

Applicant: Nokia Solutions and Networks -1 - FCC ID: VBNAKQW-01 Agent Authorization Letter Date: December 12, 2023 We, Nokia Solutions and Networks, declare that Raymond Johnson, Walter Majkowski, Steven Gordon, Qin Yu and Nilesh Patel of Nokia Global Products Compliance Laboratory (GPCL) are authorized agents to sign applications pertinent to FCC and Industry Canada applications. These employees of Nokia Global Product Compliance Laboratory are authorized to make representations to the FCC, Industry Canada and their respective Telecommunications Certified Body (TCB) agents on our behalf. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in FCC and Industry Canada's regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by the TCB, still resides with Nokia Solutions and Networks. I hereby certify on behalf of Nokia Solutions and Networks ("Applicant") that neither Applicant nor any party to the application (officers, directors, and 5% shareholders) is subject to a denial of Federal benefits that includes FCC benefits pursuant to section 5301 of the Anti-Drug Abuse Act of 198821 U.S.C. 853a. Sincerely, _______________________________ Steve Mitchell Nokia Solutions and Networks 3201 Olympus Blvd Dallas, Texas 75019 USA 972-936-7500 [email protected]

APPLICANT: Nokia Solutions and Networks FCC ID: VBNAKQW-01 Public Page 1 of 6 EXHIBIT 10 EXTERNAL PHOTOGRAPHS SECTION 2.1033 (c) (15) External Photographs of the Equipment Photographs (8"x10") of the equipment of sufficient clarity to reveal equipment construction and layout, including meters, if any, and labels for controls and meters and sufficient views of the internal construction to define component placement and chassis assembly. Insofar as these requirements are met by photographs or drawings contained in the instruction manuals supplied with the product certification request, additional photographs are necessary only to complete the required showing. Response: The external photographs of the Nokia AKQW AirScale RRH 8T8R n77 320W, are included in this original filing under FCCID: VBNAKQW-01 . APPLICANT: Nokia Solutions and Networks FCC ID: VBNAKQW-01 Public Page 2 of 6 APPLICANT: Nokia Solutions and Networks FCC ID: VBNAKQW-01 Public Page 3 of 6 APPLICANT: Nokia Solutions and Networks FCC ID: VBNAKQW-01 Public Page 4 of 6 APPLICANT: Nokia Solutions and Networks FCC ID: VBNAKQW-01 Public Page 5 of 6 APPLICANT: Nokia Solutions and Networks FCC ID: VBNAKQW-01 Public Page 6 of 6

EXHIBIT 4: ID LABEL SAMPLE AND LOCATION INFORMATION Public Page 1 of 3 SECTION 2.1033(c) (14) also SECTION 2.925 (a) (1) A photograph or drawing of the equipment identification plate or label showing the information to be placed thereon. Response: The drawing of the equipment identification label of the Nokia AKQW AirScale RRH 8T8R n77 320W is attached. A drawing showing label location and drawings of the equipment identification label is attached. FCC ID: VBNAKQW‐01 Applicant: Nokia Solutions and Networks AKQW Label

Applicant: Nokia Solutions and Networks FCC ID: VBNAKQW-01 Public Page 1 of 2 EXHIBIT 12 RF EXPOSURE ASSESSMENT Section 1.1307 (b) Environmental Assessment Requirement for Equipment Authorization Commission actions granting construction permits, licenses to transmit or renewals thereof, equipment authorizations or modifications in existing facilities, require the preparation of an Environmental Assessment (EA) if the particular facility, operation, or transmitter would cause human exposure to levels of radiofrequency radiation in excess of the limits in §§ 1.1310 and 2.1093 of this chapter. Section 1.1310 Radio Frequency Radiation Exposure Limits The criteria listed in Table 1 shall be used to evaluate the environmental impact of human exposure to radiofrequency (RF) radiation as specified in Section 1.1307(b), except in the case of portable devices which shall be evaluated according to the provisions of § 2.1093 of this chapter. Further information on evaluating compliance with these limits can be found in the FCC’s OST/OET Bulletin Number 65, ‘‘Evaluating Compliance with FCC-Specified Guidelines for Human Exposure to Radiofrequency Radiation.’’ Response  The Nokia AKQW AirScale RRH 8T8R 320W is typically installed on poles or walls in fixed locations. Therefore, the AKQW is neither a portable nor a mobile wireless device. The Nokia AKQW is an 8 port radio head that transmits 40 Watts per port over the B77 spectrum (3700 - 3980 MHz). This product supports Single Carriers 20, 30, 40, 50, 60, 70, 80, 90, 100 MHz and Dual Carriers 20+20, 100+100 MHz in Contiguous and Non-Contiguous configurations utilizing QPSK, 16 QAM, 64QAM and 256QAM modulation formats. The 8 individual transmit ports are identical in design, rated power, and performance. The RF exposure assessment for the overall AKQW will be evaluated separately to ensure the compliance. Table 13.1 Product Specifications on AKQW 5G-NR RRH Band 77 Product Technologies Transmitting Frequency (MHz) Max Total Output Power (Watts) AKQW 5G-NR 20, 30, 40, 50, 60, 70, 80, 90, 100 MHz, Q16/64/256QAM Band 77 3700 - 3980 320.0 Applicant: Nokia Solutions and Networks FCC ID: VBNAKQW-01 Public Page 2 of 2 AKQW Antenna No antenna is supplied with this product. Therefore, no Safety Distances are provided. The Table below shows the Maximum Conducted Total Power (Watts) for each bandwidth supported by the AKQW. Table 13.2 Maximum Conducted Total Power (Watts) Bandwidth (MHz) Maximum Conducted Total Power (Watts) 20 154.15 30 240.7 40 280.47 50 338.90 60 333.62 70 329.34 80 328.47 90 335.75 100 372.45 20+20 334.58 100+100 377.86

Title 47 Code of Federal Regulations Test Report Global Product Compliance Laboratory Report No.: TR- 2023-0137-FCC2-27 Product: AKQW AirScale RRH 8T8R n77 320W PUBLIC Page 31 of 63 4. FCC Section 2.1049 – Occupied Bandwidth/Edge of Band Emissions 4.1 Occupied Bandwidth In 47CFR 2.1049 the FCC requires: “The occupied bandwidth, that is the frequency bandwidth such that , below its lower and above its upper frequency limits, the mean powers radiated are each equal to 0.5 percent of the total mean power radiated by a given emission shall be measured under the following condi tions as applicable.” This required measurement is the 99% Occupied Bandwidth, also called the designate d signal bandwidth and needs to be within the parameters of the products specified emissions designator . During these measurements it is customary to evaluate the Edge of Band emissions at block/band edges. The transmitted signal occupied bandwidth was measured using a Keysight MXA Signal Analyzer. All emission s were within the parameters as required. # of Carrier Signal BW MHz Modulation TX Port Channel Frequency MHz 99% Occupied BW MHz 1 20 64QAM 3 3710 18.396 1 20 QPSK/16QAM 3 3800 18.866 1 20 256QAM 3 3970 18.470 1 30 64QAM 5 3715 27.685 1 30 QPSK/16QAM 5 3800 28.010 1 30 256QAM 4 3965 27.824 1 40 64QAM 5 3720 37.253 1 40 QPSK/16QAM 5 3800 37.610 1 40 64QAM 5 3960 37.944 1 50 64QAM 5 3725 47.184 1 50 QPSK/16QAM 5 3800 47.290 1 50 256QAM 5 3955 47.392 1 60 64QAM 5 3730 57.801 1 60 64QAM 5 3800 58.074 1 60 256QAM 5 3950 57.592 1 70 64QAM 5 3735 67.185 1 70 QPSK/16QAM 5 3800 67.573 1 70 256QAM 5 3945 67.035 1 80 64QAM 5 3740 77.109 1 80 QPSK/16QAM 5 3800 77.725 1 80 256QAM 5 3940 77.170 1 90 64QAM 5 3745 86.965 1 90 QPSK/16QAM 5 3800 87.493 1 90 256QAM 5 3935 86.800 1 100 64QAM 5 3750 96.780 1 100 QPSK/16QAM 5 3800 97.001 1 100 256QAM 5 3930 97.258 2 20+20 QPSK/16QAM 5 3710+3730 38.556 2 20+20 QPSK/16QAM 5 3710+3890 18.368+18.227 2 20+20 QPSK/16QAM 5 3790+3810 38.139 2 20+20 256QAM 5 3790+3970 18.166+18.110 Title 47 Code of Federal Regulations Test Report Global Product Compliance Laboratory Report No.: TR- 2023-0137-FCC2-27 Product: AKQW AirScale RRH 8T8R n77 320W PUBLIC Page 32 of 63 2 20+20 256QAM 1 3950+3970 37.836 2 100+100 QPSK/16QAM 5 3750+3850 196.24 2 100+100 256QAM 5 3830+3930 195.87 Title 47 Code of Federal Regulations Test Report Global Product Compliance Laboratory Report No.: TR- 2023-0137-FCC2-27 Product: AKQW AirScale RRH 8T8R n77 320W PUBLIC Page 33 of 63 4.2 99% Occupied Bandwidth Plots NOTE: Only the plot with the maximum bandwidth measured is used in this report. The full suite of raw da ta resides at the MH, New Jersey location. 20MHz BW, TM3.2, QPSK/16QAM, TX3, 3800MHz 30MHz BW, TM3.2, QPSK/16QAM, TX5, 3800MHz Title 47 Code of Federal Regulations Test Report Global Product Compliance Laboratory Report No.: TR- 2023-0137-FCC2-27 Product: AKQW AirScale RRH 8T8R n77 320W PUBLIC Page 34 of 63 40MHz BW, TM3.1, 64QAM, TX5, 3960MHz 50MHz BW, TM3.1a, 256QAM, TX5, 3955MHz Title 47 Code of Federal Regulations Test Report Global Product Compliance Laboratory Report No.: TR- 2023-0137-FCC2-27 Product: AKQW AirScale RRH 8T8R n77 320W PUBLIC Page 35 of 63 60MHz BW, TM3.1, 64QAM, TX5, 3800MHz 70MHz BW, TM3.2, QPSK/16QAM, TX5, 3800MHz Title 47 Code of Federal Regulations Test Report Global Product Compliance Laboratory Report No.: TR- 2023-0137-FCC2-27 Product: AKQW AirScale RRH 8T8R n77 320W PUBLIC Page 36 of 63 80MHz BW, TM3.2, QPSK/16QAM, TX5, 3800MHz 90MHz BW, TM3.2, QPSK/16QAM, TX5, 3800MHz Title 47 Code of Federal Regulations Test Report Global Product Compliance Laboratory Report No.: TR- 2023-0137-FCC2-27 Product: AKQW AirScale RRH 8T8R n77 320W PUBLIC Page 37 of 63 100MHz BW, TM3.1a, 256QAM, TX5, 3930MHz 20+20MHz BW, TM3.2, QPSK/16QAM, TX5, 3710+3730MHz Title 47 Code of Federal Regulations Test Report Global Product Compliance Laboratory Report No.: TR- 2023-0137-FCC2-27 Product: AKQW AirScale RRH 8T8R n77 320W PUBLIC Page 38 of 63 100+100MHz BW, TM3.2, QPSK/16QAM, TX5, 3750+3850MHz Title 47 Code of Federal Regulations Test Report Global Product Compliance Laboratory Report No.: TR- 2023-0137-FCC2-27 Product: AKQW AirScale RRH 8T8R n77 320W PUBLIC Page 39 of 63 4.3 Edge of band Emissions The Edge of Band emissions of the EUT at the external antenna connector (EAC) were measured using a Ke ysight MXA Signal Analyzer. Before measuring the Edge of Band emissions, the RF power level was confirme d with the Keysight MXA Signal Analyzer. The RF output from the EAC port to signal analyzer was reduce d (to an amplitude usable by the signal analyzer) by using a calibrated attenuator and RF Switch. The path attenuation was offset on the display and the signal for the carrier was adjusted to the correc ted RF power level for the resolution bandwidth used for the transmit signal. All mask values were adj usted based upon the designated signal bandwidth and measurement bandwidths. In accordance with KDB 662 911 D01 Multiple Transmitter Output, the limit of -13 dBm has been adjusted to -22 dBm to reflect 10 log(n ) where n=8 for the 8x8 MIMO operation. 4.3.1 Edge of Band Emissions – Plots All of the measurements met the requirements of Part 27.53 when measured per Part 2.1049. NOTE: The full suite of raw data resides at the MH, New Jersey location. Edge of Band Emissions 20MHz BW Title 47 Code of Federal Regulations Test Report Global Product Compliance Laboratory Report No.: TR- 2023-0137-FCC2-27 Product: AKQW AirScale RRH 8T8R n77 320W PUBLIC Page 40 of 63 Edge of Band Emissions 30MHz BW Edge of Band Emissions 40MHz BW Title 47 Code of Federal Regulations Test Report Global Product Compliance Laboratory Report No.: TR- 2023-0137-FCC2-27 Product: AKQW AirScale RRH 8T8R n77 320W PUBLIC Page 41 of 63 Edge of Band Emissions 50MHz BW Edge of Band Emissions 60MHz BW Title 47 Code of Federal Regulations Test Report Global Product Compliance Laboratory Report No.: TR- 2023-0137-FCC2-27 Product: AKQW AirScale RRH 8T8R …

Text truncated - open the document above for the full version.

PUBLIC Global Product Compliance Laboratory 600-700 Mountain Avenue Room 5B-108 Murray Hill, New Jersey 07974-0636 USA TESTING NVLAP LAB CODE: 100275-0 Title 47 Code of Federal Regulations Test Report Regulation: FCC Part 2 and 27 Client: NOKIA SOLUTIONS AND NETWORKS, OY Product Evaluated: AKQW AirScale RRH 8T8R n77 320W Report Number: TR-2023-0137-FCC2-27 Date Issued: January 4, 2024 This report shall not be reproduced, in whole or in part without the approval of Nokia Global Product Compliance Laboratory. Title 47 Code of Federal Regulations Test Report Global Product Compliance Laboratory Report No.: TR-2023-0137-FCC2-27 Product: AKQW AirScale RRH 8T8R n77 320W PUBLIC Page 2 of 63 Table of Contents 1. SYSTEM INFORMATION AND REQUIREMENTS............................................................................................. 4 1.1 INTRODUCTION ............................................................................................................................................. 5 1.2 PURPOSE AND SCOPE ..................................................................................................................................... 5 1.3 EUT DETAILS ................................................................................................................................................ 6 1.4 TEST REQUIREMENTS ..................................................................................................................................... 9 1.5 TEST STANDARDS & MEASUREMENT PROCEDURES ............................................................................................. 9 1.6 EXECUTIVE SUMMARY ................................................................................................................................... 11 1.7 TEST CONFIGURATION .................................................................................................................................. 12 2. FCC SECTION 2.1046 - RF POWER OUTPUT .............................................................................................. 14 2.1 RF POWER OUTPUT ..................................................................................................................................... 14 2.2 PEAK-TO-AVERAGE POWER RATIO (PAPR) ...................................................................................................... 27 3. FCC SECTION 2.1047 - MODULATION CHARACTERISTICS ....................................................................... 29 3.1 MODULATION CHARACTERISTICS .................................................................................................................... 29 4. FCC SECTION 2.1049 – OCCUPIED BANDWIDTH/EDGE OF BAND EMISSIONS ......................................... 31 4.1 OCCUPIED BANDWIDTH ................................................................................................................................ 31 4.2 99% OCCUPIED BANDWIDTH PLOTS .............................................................................................................. 33 4.3 EDGE OF BAND EMISSIONS ............................................................................................................................ 39 5. FCC SECTION 2.1051 - SPURIOUS EMISSIONS AT TRANSMIT ANTENNA PORT ....................................... 45 5.1 MEASUREMENT OF SPURIOUS EMISSIONS AT TRANSMIT ANTENNA PORT ............................................................... 45 6. FCC SECTION 2.1053 - FIELD STRENGTH OF SPURIOUS RADIATION ...................................................... 50 6.1 SECTION 2.1053 FIELD STRENGTH OF SPURIOUS EMISSIONS ............................................................................ 50 6.2 FIELD STRENGTH OF SPURIOUS EMISSIONS - LIMITS .......................................................................................... 50 7. FCC SECTION 2.1055 - MEASUREMENT OF FREQUENCY STABILITY ........................................................ 51 8. NVLAP CERTIFICATE OF ACCREDITATION ................................................................................................. 63 Title 47 Code of Federal Regulations Test Report Global Product Compliance Laboratory Report No.: TR-2023-0137-FCC2-27 Product: AKQW AirScale RRH 8T8R n77 320W PUBLIC Page 3 of 63 Revisions Date Revision Section Change 1/4/2024 0 Initial Release Nokia Global Product Compliance Laboratories is accredited by the National Voluntary Laboratory Accreditation Program (NVLAP®) for specific services, listed on the Scope of Accreditation, for: Electromagnetic Compatibility and Telecommunications. This laboratory is accredited in accordance with the recognized International Standard ISO/IEC 17025:2005. This accreditation demonstrates technical competence for a defined scope and the operation of a laboratory quality management system (refer to joint ISO-ILAC-IAF Communiqué dated January 2009). NVLAP LAB CODE: 100275-0. Nokia Global Product Compliance Laboratory represents to the client that the laboratory’s accreditation or test reports in no way constitutes or implies product certification, approval, or endorsement by NVLAP, NIST, or any agency of the U.S. government. Prepared By: Approved By: Signed: 1/4/2024 Signed: 1/4/2024 Mark Nguyen Compliance Engineer NVLAP Signatory [email protected] Raymond Johnson Technical Manager NVLAP Signatory [email protected] Reviewed By: Signed: 1/4/2024 Steve Gordon EMC Engineer NVLAP Signatory [email protected] Title 47 Code of Federal Regulations Test Report Global Product Compliance Laboratory Report No.: TR-2023-0137-FCC2-27 Product: AKQW AirScale RRH 8T8R n77 320W PUBLIC Page 4 of 63 1. System Information and Requirements Report copies and other information not contained in this report are held by either the product engineer or in an identified file at the Global Product Compliance Laboratory in Murray-Hill, NJ. Equipment Under Test (EUT): AKQW AirScale RRH 8T8R n77 320W Ser…

Text truncated - open the document above for the full version.

APPLICANT: Nokia Solutions and Networks FCC ID: VBNAKQW-01 Public Page 1 of 6 EXHIBIT 11 SETUP DRAWINGS OR PHOTOGRAPHS Test Setup Photos SECTION 2.1033(c) (21) Test Setup Photographs Contain at least one drawing or photograph showing the test set-up for each of the required types of tests applicable to the device for which certification is requested. These drawings or photographs must show enough detail to confirm other information contained in the test report. Any photographs used must be focused originals without glare or dark spots and must clearly show the test configuration used. Response: The following setup drawings and photos show the test setup for the measurements in the Test Report. Figure 1. Setup Diagram of Conducted Test for RF Output Power, Power Spectrum Density, Modulation Characteristics, Occupied Bandwidth and Unwanted Emissions. EUT Power Meter or Spectrum Analyzer RF Attenuator and/or RF Filter Computer APPLICANT: Nokia Solutions and Networks FCC ID: VBNAKQW-01 Public Page 2 of 6 Figure 2. Setup Diagram of Radiated Test Chamber Computer MCO 50  Load DC Power Module EUT APPLICANT: Nokia Solutions and Networks FCC ID: VBNAKQW-01 Public Page 3 of 6 Figure 3. Photo of RF Conducted Tests APPLICANT: Nokia Solutions and Networks FCC ID: VBNAKQW-01 Public Page 4 of 6 Figure 4. RADIATED EMISSIONS, 30 MHz – 1 GHz APPLICANT: Nokia Solutions and Networks FCC ID: VBNAKQW-01 Public Page 5 of 6 Figure 5. RADIATED EMISSIONS, 1 – 40 GHz APPLICANT: Nokia Solutions and Networks FCC ID: VBNAKQW-01 Public Page 6 of 6 Figure 6. Frequency Stability Setup
