VBNAVQQA-01AirScale Base Transceiver Station Radio Unit

Nokia Solutions and Networks Tel: (972) 936-7500 3201 Olympus Blvd Fax: (972) 936-7273 Dallas, Texas 75019 Covered Equipment Certification Attestation Letter September 11, 2024 Nemko North America, Inc. 303 River Road Ottawa K1V 1H2 Canada ATTN.: Reviewing Engineer FCC ID: VBNAVQQA-01 Nokia Solutions and Networks (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. Nokia Solutions and Networks (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Signed: Printed name: Steve Mitchell Title: Compliance Engineer Company Name: Nokia Solutions and Networks Date: 9/10/2024

* the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. U.S. Agent Designation for Service of Process - Certification Attestation Letter September 11, 2024 Nemko North America, Inc. 303 River Road Ottawa K1V 1H2 Canada ATTN.: Reviewing Engineer FCC ID: VBNAVQQA-01, Applicant FRN: 0016412652 Per section 2.911(d)(7) of the FCC rules, Nokia Solutions and Networks (“the applicant”) certifies that the equipment for which authorization is sought is designated to the following U.S. Designated agent* for service of process: Company Name: Nokia Solutions and Networks Physical U.S. Company Address: 3201 Olympus Blvd; Dallas, Texas 75019 Agent name: Agent Email Address: Agent FRN: Steve Mitchell [email protected] 0016412652 The above contact person accepts the obligation for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Signed: Designated Agent Signed: (Required, if different to Applicant): Signed: Signed: Printed name: Steve Mitchell Printed name: Click here to enter text. Title: Compliance Engineer Title: Click here to enter text. Company Name: Nokia Solutions and Networks Company Name: Click here to enter text. Date: September 10, 2024 Date: Click here to enter a date.

Nokia Solutions and Networks Tel: (972) 936-7500 3201 Olympus Blvd Fax: (972) 936-7273 Dallas, Texas 75019 Nemko North America, Inc. 303 River Road, Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent for FCC application On our behalf, I appoint Spencer Zhong of Nemko Canada, Inc. at 303 River Road, Ottawa, Ontario, Canada K1V 1H2, to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in FCC regulations will have affixed to it a label identical to that submitted for approval with this application. In signing this letter, Applicant certifies that neither the applicant nor any party to the application is not subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. § 862 because of a conviction for possession or distribution of a controlled substance. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. We also declare that the information provided to the FCC is true and correct to the best of our knowledge (47 CFR 2.911(d)) and we have been informed of the grantee responsibilities (47 CFR 2.909) with regard to certified equipment. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with Nokia Solutions and Networks, 3201 Olympus Blvd; Dallas, Texas 75019. Dated: September 11, 2024 Agency agreement expiration date: 2025-09-09 *Up to 12 months Signed by: Steve Mitchell Signature Print name Compliance Engineer Title 972-936-7500 Phone On behalf of: Nokia Solutions and Networks Company name

Nokia Solutions and Networks Tel: (972) 936-7500 3201 Olympus Blvd Fax: (972) 936-7273 Dallas, Texas 75019 September 10 th , 2024 To whom it may concern: This is a request to hold the internal photos and user manual for FCC ID: VBNAVQQA-01 under long term confidentiality. The transmitter is a Base Station where access is controlled and only available to trained personnel. Please note that the internal photos are being asked to be confidential under the FCC guidelines that this is a non-consumer device (Base Station) and is inaccessible to the general public due to the location of the device and it is only serviceable by the licensee or his designated technicians. The user manual is being requested to be confidential under the FCC guidelines that the manual is very technical and is not provided to the general public. The user manual contains proprietary information required for trained installers to commission the base station. The user manual will be used by the licensee or his designated technicians only. Nokia Solutions and Networks has spent substantial effort in developing this product as a leader in the industry. Having the subject information easily available to competitiors would negate the advantage we have achieved by developing this product. Not protecting the details of design will result in financial hardship. Sincerely, __________________________________________ ______Steve Mitchell__________________ (Signature/Title) (Printed name)

1 / 6 Mutual Global NDA Confidential © 2023 Nokia 1 Mutual non-disclosure agreement [Note to drafter: Please check/remove yellow highlighting before sending out.] This Mutual Non-Disclosure Agreement (“Agreement”) is entered into by and between Nokia Solutions and Networks Oy, a corporation validly organized and existing under the laws of Finland, having its principal place of business at Karakaari 7, 02610, Espoo, Finland, business identity code 2058430-6 (“Nokia”) and [insert name of other party], a corporation validly organized and existing under the laws of [insert the country of i[ncorporation of the other party] having its principal place of business at [insert address of the other party] , business identity code [ ] (“Company”) hereinafter referred to as “Party” or “Parties” respectively WHEREAS: a. For the purpose of discussions concerning [Example A: a possible business relationship in which the Company will provide [please describe the products and/or services] to Nokia for Nokia’s internal business purposes and/or for use in and in connection with Nokia’s product/service offerings to its end customers and end users. Example B: a possible business relationship in which the Company will perform certain development work for Nokia in furtherance of Nokia’s internal business activities and/or in support of Nokia’s product/service offerings to its customers and the possible business relationship which is a consequence of said discussions.] (hereinafter "Purpose"), b. The Parties may, in conjunction with the Purpose and for their mutual benefit, disclose to each other information which the Parties regard as confidential and the Parties are willing to undertake to restrict the use and further disclosure of such information. NOW THEREFORE IT IS HEREBY AGREED 1. “Information” shall mean any technical and/or commercial information relating to the disclosing Party’s or any of its Affiliates’ businesses, facilities, products, services, techniques and processes in whatever form, including but not limited to oral disclosure, electronic communication, demonstration, device, apparatus, model, sample of any kind, computer program, optical or magnetic medium, document, specification, circuit diagram, or drawing (including but not limited to information of a general nature or information not necessarily in the form as applied to wireless or fixed telecommunications systems) and visual observation of the aforesaid which is proprietary to the disclosing Party or to its Affiliates or to a disclosing Party’s or its Affiliates’ licensors, contractors or customers (hereinafter "Information"). For the avoidance of doubt, the existence and the contents of this Agreement and the 2 / 6 Mutual Global NDA Confidential © 2023 Nokia discussions between the Parties related to the Purpose shall be considered Information as set out in this Article 1. 2. “Affiliate” of a Party shall mean an entity a. which is directly or indirectly controlling such Party; b. which is under the same direct or indirect ownership or control as such Party; or c. which is directly or indirectly owned or controlled by such Party. For these purposes, an entity shall be treated as being controlled by another if that other entity has fifty percent (50 %) or more of votes in such entity, is able to direct its affairs and/or to control the composition of its board of directors or equivalent body. 3. The receiving Party shall a. keep confidential all Information received by it from the disclosing Party with the same degree of care as is used with respect to the receiving Party's own equally important confidential information to avoid disclosure to any third party, but at least with reasonable care; b. neither disclose Information received by it from the disclosing Party to third parties nor use it for any purpose other than the above-mentioned Purpose without the prior written permission of the disclosing Party; and c. undertake to institute and maintain, and/or cause to be instituted and maintained, appropriate data protection and security measures based upon the sensitive nature of the Information disclosed. 4. The Parties recognize that they are part of organizations of multiple legal entities in several jurisdictions and that it may be necessary for the Parties to provide Information to their Affiliates. For this purpose, the Parties agree (both as the disclosing Party and as the receiving Party hereunder) that a. the Parties may disclose Information to their Affiliates but only to the extent that such Affiliate has a need to know for the purpose of carrying out the Purpose and provided that such Affiliate accepts confidentiality obligations similar to those contained in this Agreement and the receiving Party shall be held liable for any breaches of the obligations included in this Agreement by such Affiliate in the same manner as if such obligations had been directly assumed by such Affiliate; and b. Nokia may disclose Information to its contractors, consultants and outsourcing partners to the extent they have a need to know for the purpose of carrying out the Purpose and provided that such contractor, consultant or outsourcing partner accepts confidentiality obligations at least as restrictive as those contained in this Agreement. Nokia shall be fully responsible and liable for any non-compliance by any contractors, consultants and outsourcing partners with the terms of this Agreement. 3 / 6 Mutual Global NDA Confidential © 2023 Nokia c. The Company may disclose information to its contractors, consultants and outsourcing partners listed in Appendix 1 hereto, to the extent they have a need to know for the purpose of carrying out the Purpose and provided that such contractor, consultant or outsourcing partner accepts confidentiality obligations at least as restrictive as those contained in this Agreement. The Company shall be fully responsible and liable for any non-compliance by any contractors, consultants and outsourcing partners with …

Text truncated - open the document above for the full version.

Nokia Solutions and Networks Tel: (972) 936-7500 3201 Olympus Blvd Fax: (972) 936-7273 Dallas, Texas 75019 September 11, 2024 Nemko North America, Inc. 303 River Road Ottawa, Ontario, Canada K1V 1H2 REQUEST FOR CONFIDENTIALITY - FCC FCC ID: VBNAVQQA-01 Pursuant to Sections 0.457(d) and 0.459 of the Commission’s Rules and FCC Guidance document 726920, we hereby request permanent confidential treatment of exhibits identified as such in the table below and request they are permanently withheld from public review based on the documents containing trade secrets and proprietary information not customarily released to the public. The public disclosure of this information might be harmful to the applicant and provide unjustified benefits to its competitors. We also request short-term confidentiality on certain exhibits until the intended date of marketing as outlined below. We request the exhibits be withheld from public view for a period of 180 days. We attest marketing of the product will only commence after the period of short-term confidentiality expires, or if marketing is to commence before the requested number of days listed above, the grantee will inform Nemko to release the Short-Term Confidentiality information withheld on the FCC equipment authorization website. Exhibit Type of Confidentiality Requested Block Diagrams ☒ Permanent ☐ Short Term External Photos ------------------ ☐ Short Term Internal Photos ☒ Permanent* ☐ Short Term Operation Description ☒ Permanent ☐ Short Term Parts List & Placement/BOM ☒ Permanent ☐ Short Term Tune-Up Procedure ☒ Permanent ☐ Short Term Schematic Diagrams ☒ Permanent ☐ Short Term Test Setup Photos ------------------ ☐ Short Term User’s Manual ☒ Permanent* ☐ Short Term The asterisked items (*) require further information to be provided in this justification letter before permanent confidentiality will be extended to these exhibits. Please refer to FCC KDB 726920 D01 found at: https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=41731 and review section II, 3) regarding specific information that must accompany these requests. Note: any documents held under the Short-Term confidentiality will automatically become public after the requested time if an appropriate extension request has not been received. Any exhibits (i.e., schematic diagrams) that may have already been requested to have “Permanent” confidentiality as shown above need not be repeated under Short-Term confidentiality request. These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Nokia Solutions and Networks Tel: (972) 936-7500 3201 Olympus Blvd Fax: (972) 936-7273 Dallas, Texas 75019 Sincerely, Signed: Printed name: Steve Mitchell Title: Compliance Engineer Company Name: Nokia Solutions and Networks

AVQQA Label Format & Location Label Material: White Polyester? FCC ID: VBNAVQQA-01

1 / 28 HATNKVKZMJPP-1868097887-1987 PUBLIC © Nokia 2024 RF exposure compliance assessment AirScale High Power Wide Band Massive MIMO Adaptive Antenna Product – AVQQA Author Kamil Bechta Owner Christophe Grangeat Organization MN RAN R&D A&S Approver Osmo Keskitalo Document Type Final Document ID HATNKVKZMJPP-1868097887-1987 Document location https://nokia.sharepoint.com/:f:/r/sites/EMF- ProductsRFexposureassessment/Shared%20Documents/Original/Products-RF-exposure- assessment/AVQQA?csf=1&web=1&e=PUQaWC Change History Version Status Date Author Owner Reviewed by Reviewed date Approver Approval date Description of changes 1.0 Final 06-11-2023 K. Stopa, K. Bechta C. Grangeat C. Grangeat 13-11-2023 Yi Rao 17-11-2023 2.0 Final 04-07-2024 K. Bechta C. Grangeat C. Grangeat 06-08-2024 O. Keskitalo 06-08-2024 Simulation model update; editorial corrections This material, including documentation and any related computer programs, is protected by copyright controlled by Nokia. All rights are reserved. Copying, including reproducing, storing, adapting or translating, any or all of this material requires the prior written consent of Nokia. This material also contains confidential information, which may not be disclosed to others without the prior written consent of Nokia. FCC ID: VBNAVQQA-01 2 / 28 HATNKVKZMJPP-1868097887-1987 PUBLIC © Nokia 2024 Contents 1 General content ...................................................................................................................5 2 References............................................................................................................................5 Applicable RF exposure standards and regulations ........................................................5 Product and assessment method .....................................................................................5 3 RF exposure limits ...............................................................................................................7 4 Description of the equipment under test (EUT) ..............................................................8 5 RF exposure assessment method .....................................................................................15 6 RF exposure computation results .....................................................................................15 Regions of application: EU/ICNIRP, Australia/NZ and US/related ..................................15 Regions of application: Canada .........................................................................................21 7 Conclusion and installation recommendations ...............................................................25 List of Tables Table 1 – Applicable RF exposure levels in n77 band expressed in power density ........................... 7 Table 2 – AVQQA product general technical characteristics ................................................................ 8 Table 3 - Reference system used in this report (from NGMN white paper [16]) ........................................ 9 Table 4 – Antenna patterns for the boresight direction for 3500 MHz ............................................ 10 Table 5 – Antenna patterns for max azimuth steering for 3500 MHz ...................................................... 11 Table 6 – Antenna patterns for max down-tilt steering for 3500 MHz ..................................................... 12 Table 7 – Antenna patterns for max up-tilt steering for 3500 MHz.......................................................... 13 Table 8 – Antenna gain characteristics for various beam steering directions used during EMF evaluation ................................................................................................................................................................... 14 Table 9 - Validation of the antenna model at 3500 MHz .......................................................................... 15 Table 14 – AVQQA RF exposure compliance distances based on the time-averaged maximum transmitted power of 360.2 W for EU/ICNIRP, Australia/NZ and US/related................................... 26 Table 15 – AVQQA RF exposure compliance distances based on the time-averaged maximum transmitted power of 360.2 W for Canada .......................................................................................... 26 Table 16 – AVQQA RF exposure compliance distances based on the actual EIRP threshold of 74.5 dBm for EU/ICNIRP, Australia/NZ and US/related ............................................................................... 27 Table 17 – AVQQA RF exposure compliance distances based on the actual EIRP threshold of 74.5 dBm for Canada ....................................................................................................................................... 27 3 / 28 HATNKVKZMJPP-1868097887-1987 PUBLIC © Nokia 2024 List of Figures Figure 1 – Shape of the compliance boundary used for the RF exposure compliance assessment (from [12]). ............................................................................................................................................... 14 Figure 2 – Top view of the power density for the time-averaged maximum transmitted power of 360.2 W and beam oriented in azimuth = 0° & elevation = +6° with a gain of 24.9 dBi (EU/ICNIRP, Australia/NZ and US/related) ................................................................................................................. 16 Figure 3 - Top view of the power density for the actual maximum transmitted power of 90 W (corresponding to the actual EIRP threshold of 74.5 dBm) and beam oriented in azimuth = 0° & elevation = +6° with a gain of 24.9 dBi (EU/ICNIRP, Australia/NZ and US/related) ................................... 16 Figure 4 – Top view of the power density for the time-averaged maximum transmitted power of 360.2 W and beam oriented in azimuth = -51° & elevation = +4° with a gain of 20.8 dBi (EU/ICNIRP, Australia/NZ and US/relat…

Text truncated - open the document above for the full version.

This report must not be used to claim product certification, approval, or endorsement by A2LA or any agency of the U.S. Government. This Report shall not be reproduced, except in full without written approval of the laboratory. Radio Test Report Application for Grant of Equipment Authorization FCC Part 27 [3450MHz – 3550MHz and 3700MHz – 3980MHz] FCC ID: VBNAVQQA-01 Nokia Solutions and Networks Airscale Base Transceiver Station Radio Unit Model: AVQQA Report: NOKI0075.0 Rev. 1, Issue Date: September 12, 2024 TABLE OF CONTENTS 2023.04.17 Section Page Number Certificate of Test ............................................................................................ 3 Revision History .............................................................................................. 4 Accreditations .................................................................................................. 5 Facilities .......................................................................................................... 6 Measurement Uncertainty ............................................................................... 7 Test Setup Block Diagrams ............................................................................. 8 Product Description ......................................................................................... 11 Configurations ................................................................................................. 16 Modifications ................................................................................................... 32 Average Power – Band 3.45G, All Port ........................................................... 33 Average Power – Band 3.7G, All Port ............................................................. 53 Average Power - Band 3.45G ......................................................................... 73 Average Power - Band 3.7G ........................................................................... 81 Average Power - Dual Band ............................................................................ 89 Average Power – Multicarrier Band 3.7G ........................................................ 93 Power Spectral Density - Band 3.45G ............................................................. 99 Power Spectral Density - Band 3.7G ............................................................... 109 Peak to Average Power - Band 3.45G ............................................................ 120 Peak to Average Power - Band 3.7G .............................................................. 131 Occupied Bandwidth - Band 3.45G ................................................................. 143 Occupied Bandwidth - Band 3.7G ................................................................... 152 Band Edge Compliance - Band 3.45G ............................................................ 163 Band Edge Compliance - Band 3.7G .............................................................. 176 Band Edge Compliance - Dual Band ............................................................... 189 Band Edge Compliance – Multicarrier Band 3.7G ........................................... 199 Spurious Conducted Emissions - Band 3.45G ................................................ 208 Spurious Conducted Emissions - Band 3.7G .................................................. 222 Spurious Conducted Emissions - Dual Band................................................... 233 Spurious Conducted Emissions – Multicarrier Band 3.7G ............................... 246 Spurious Radiated Emissions ......................................................................... 259 Frequency Stability .......................................................................................... 282 End of Report .................................................................................................. 296 Report No. NOKI0075.1 Rev. 12/296 CERTIFICATE OF TEST 2022-04-01 Product compliance is the responsibility of the client; therefore, the tests and equipment modes of operation represented in this report were agreed upon by the client, prior to testing. The results of this test pertain only to the sample(s) tested. The specific description is noted in each of the individual sections of the test report supporting this certificate of test. This report reflects only those tests from the referenced standards shown in the certificate of test. It does not include inspection or verification of labels, identification, marking or user information. As indicated in the Statement of Work sent with the quotation, Element’s standard process is to always use the latest published version of the test methods even when earlier versions are cited in the test specification. Issuance of a purchase order was de facto acceptance of this approach. Otherwise, the client would have advised Element in writing of the specific version of the test methods they wanted applied to the subject testing. Last Date of Test: August 22, 2024 Nokia Solutions and Networks EUT: Airscale Base Transceiver Station Radio Unit Model: AVQQA Radio Equipment Testing Standards Specification Method Code of Federal Regulations (CFR) Title 47 Part 2 CFR Title 47 Part 27 Subpart C ANSI C63.26-2015 with FCC KDB 971168 D01 v03r01 FCC KDB 662911D01 v02r01 FCC KDB 662911D02 v01 Results Test Description Result Comments Average Power Pass Power Spectral Density and EIRP Calculations Pass Peak to Average Power Pass Occupied Bandwidth Pass Band Edge Compliance Pass Spurious Conducted Emissions Pass Spurious Radiated Emissions Pass Frequency Stability Pass Deviations From Test Standards None Approved By: Jeff Alcoke, Senior EMC Test Engineer Signed for and on behalf of Element Report No. NOKI0075.1 Rev. 13/296 REVISION HISTORY 2018.07.17 Revision Number Description Date (yyyy-mm-dd) Page Number 01 Corrected measurement value typos in Frequency Stability data 2024-09-12 283-284 Report No. NOKI0075.1 Rev. 14/29…

Text truncated - open the document above for the full version.

AVERAGE POWER - BAND 3.7G TbtTx 2024.05.24.1 WTD.2024.01.16.0 TEST DESCRIPTION Testing was performed using the mode(s) of operation and configuration(s) noted within the report. The individuals and/or the organization requesting the test provided the modes, configurations and settings used to complete the evaluation. The actual test parameters are specified in the test data, this includes items such as investigated frequency range (scanned) and test levels. The testing methods and performance specifications, as well as the test site used for the evaluation are indicated in the test data. The measurement was made using a direct connection between the RF output of the EUT and a spectrum analyzer. The fundamental emission Output Power (maximum average conducted output power) was measured using the channels and modes as called out on the following data sheets. The transmit power was set to its default maximum. RF conducted emissions testing was performed only on one port. The AVQQA antenna ports are essentially electrically identical (the RF power variation between antenna ports is small as shown in this certification testing) and antenna port 1 was selected to perform the testing under this effort as allowed by ANSI C63.26-2015 paragraphs 5.2.5.3, 5.7.2i and 6.4. The RMS average power measurement method for FCC/IC is detailed in section 5.2 of KDB 971168 D01v03r01 and ANSI C63.26-2015 section 5.2.4.4. This method uses trace averaging across the ON and OFF times of the EUT transmissions in the spectrum analyzer channel power function using an RMS detector. Following the measurement a duty cycle correction was applied by adding [10 log (1/D)], where D is the duty cycle in decimal, to the measured power to compute the average power during the actual transmission times. The output power was measured for a single carrier over the carrier channel bandwidth. The power was measured for a single carrier over the channel bandwidth indicated in the table. The total power for multi-port (64x64 MIMO) operation was based upon ANSI C63.26 clauses 6.4.3.1 and 6.4.3.2.4 (10 log N out ). The total output power for Sixty-Four port operation is single power +18.1 dB [i.e. 10*log(64)]. TEST EQUIPMENT Description Manufacturer Model ID Last Cal. Cal. Due Analyzer - Spectrum Analyzer Keysight N9010A AFQ 2024-03-12 2025-03-12 Generator - Signal Agilent N5173B TIW 2023-08-07 2026-08-07 Block - DC Fairview Microwave SD3239 ANE 2024-02-14 2025-02-14 Report No. NOKI0075.1 Rev. 181/296 AVERAGE POWER - BAND 3.7G TbtTx 2024.05.24.1 WTD.2024.01.16.0 EUT: AVQQA Remote Radio Head Work Order: NOKI0075 Serial Number: L1242403137 Date: 2024-08-15 Customer: Nokia Solutions and Networks Temperature: 23.3°C Attendees: David Le, Joh…

Text truncated - open the document above for the full version.
