VE3-STS1RFID Reader

En-Vision America, Inc.

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Jan 29, 2008
Application Purpose: Original Equipment
Date of Application: Jan 29, 2008
Equipment Note: RFID Reader
Frequency Range: 13.56000000 - 13.56000000
Company: En-Vision America, Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Table of Contents 1 Introduction to ScripTalk Station...........................................2 2 What’s in this package?........................................................3 3 Getting Started......................................................................3 4 How to Use ScripTalk Station...............................................4 4.1 General Instructions for Setup.....................................4 4.2 Powering on the ScripTalk Station...............................4 4.3 Scanning & Reading Prescriptions..............................4 4.4 Changing the Voice Speed..........................................6 4.5 Changing the Voice Pitch...........................................6 4.6 Operating with Batteries..............................................6 4.7 Low Battery Indication.................................................6 4.8 Other Information about your ScripTalk Station..........7 5 Warranty...............................................................................7 6 Contact Us............................................................................8 Seller in any way, but Seller agrees to assign to Buyer any warranty rights in such products that Seller may have from the original manufacturer. This exclusive remedy shall not be deemed to have failed of its essential purpose so long as the Seller is willing and able to repair or replace nonconforming products or credit the purchase price within ninety (90) days of the date the Seller determines that such products are nonconforming. Any suggestions by Seller or Seller’s agents regarding use, application, or suitability of the products shall not be construed as an expressed warranty unless confirmed to be such in writing by Seller. Warning: Changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment 6 Contact Us For more information, please contact us at: En-Vision America, Inc. 1845 W. Hovey Ave. Normal, IL 61761 Toll Free: (800) 890-1180 Customer Service: (309) 452-3088 Tech Support: (309) 452-9368 Fax: (309) 452-3643 E-mail: [email protected] Website: www.envisionamerica.com En-Vision America, Inc. (hereafter “Seller”) warrants that the products manufactured by it and supplied hereunder are free from defects in material and workmanship. If any such product shall be proved to Seller’s satisfaction to be non-conforming within twelve (12) months from date of delivery, Seller shall have the option to credit the purchase price of such product or repair or replace such product. Such credit, repair, or replacement shall be Seller’s sole obligation and Buyer’s exclusive remedy hereunder and shall be conditioned upon Seller’s receiving written notice of any alleged nonconformity within fifteen (15) days after receipt of shipment and, at Seller’s option, return of such products to Seller, F.O.B; its factory. Products supplied by Seller that are manufactured by someone else are not warranted by IMPORTANT SAFETY INSTRUCTIONS: READ ALL INSTRUCTIONS BEFORE USING Warning! If you have difficulty reading a label, find a caregiver to read the printed label on the prescription. Do not guess or make assumptions as to the contents or directions for any prescription medication. Warning! Only use the DC power supply provided by En-Vision America. Damage may occur if a different power supply is used. Warning! The reader is water resistant only. It should not be placed in water. If dropped into water, it should be removed immediately and dried off. 1 Introduction to ScripTalk Station ScripTalk Station is a portable electronic device that aids individuals (blind, visually impaired, or otherwise print impaired) with the ability to manage their own medications in a convenient and effective way. ScripTalk Station identifies the data within a Talking Label or RFID tag placed on a medication container and verbalizes the user’s prescription information. 4.8 Other Information about your ScripTalk Station Reader Leaving the ScripTalk Station On If the device is left on battery power for more than 5 minutes, an audio chirp will be heard every 1.5 minutes as a reminder to turn off the device. What Happens If the Reader Doesn’t Find a ScripTalk Label? After pressing the Read Button, the device will try to find and read a Talking Label for about 15 seconds. If during this process the label is removed from the reading range of the device or no label is presented, the device will timeout. You will hear the prompt “Warning, unable to read label. It is very important that you do not make guesses as to the contents or directions for this prescription. If you continue to have difficulty, contact a care-giver to visually read this prescription or contact your pharmacy.” You will then hear two beeps. Listening to the ScripTalk Station Onboard Help To hear an introduction, instructions and basic help information, press and hold the Read Button for about 3 seconds. To stop this playback of information, press the Read Button again. 5 Warranty 2 What’s in this package? The ScripTalk Station Package consists of: ∑ The ScripTalk Station Reader ∑ AC/DC Power Adapter (5V) ∑ Two AA Batteries ∑ One Sample Pill Bottle – Used for demonstrating ScripTalk Station features ∑ User’s Manual (printed version & recorded CD version) & Warranty Card 3 Getting Started ∑ Place the ScripTalk Station unit on the table in front of you with the 3 buttons closest to your body. The button at the center is an oval-shaped Read Button. The button on the right-hand side is the Previous Button (or “Up Arrow” button) and the button on the left-hand side is the Next Button (or “Down Arrow” button). ∑ On the top of the device is a semi-circle of tactile dots which are a guide for prescription placement. The prescription should be placed within this semi-circle when reading. ∑ On the front edge of the device, there is a thumbwheel switch provided for ON/OFF and Volume control. On the back edge of the ScripTalk S…

Text truncated - open the document above for the full version.

Cover Letter(s)

Phone (800) 890-1180 Fax (309) 452-3643 1845 West Hovey Avenue • Normal, Illinois 61761 September 6, 2007 PCTEST Engineering Laboratory Inc. 6660-B Dobbin Road Columbia, MD 21045 In re: En-Vision America, Inc. FCC ID: VE3-STS1 Request for Confidentiality Gentlemen: In accordance with 0.459 of CFR 47, En-Vision America hereby requests confidentiality of the Block Diagrams, Schematics and Operational Description attachments for the subject application. These documents contain detailed system and equipment description and related information about the product, which En-Vision America considers being proprietary, confidential, and a custom design and, otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, En-Vision America considers that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, David Raistrick Vice President En-Vision America, Inc.

Cover Letter(s)

Subject: RE: Questions Regarding FCC ID: VE3-STS1 Subject: FW: Questions Regarding FCC ID: VE3-STS1 Hi Greg , Here are your answers in Red: 1. Please describe the antenna, and address Section 15.203. The antenna is inseparable from the PCB board which is internal to the unit and is therefore not user accessible. This meets the antenna requirements as described in 15.203. 2. Please verify that the modification required for compliance (addition of the ferrite core to the power adapter cable) will be implemented in all units sold. The ferrite core will be implemented on all adapters. 3. Please resubmit the user’s manual, including the statement required by Section 15.21. The manual has been amended to include the statement as required by Section 15.21. See page 8 of attached revised manual. 4. The Confidentiality Request references exhibits that were not submitted (e.g., parts list, circuit description). Please resubmit a Confidentiality Request that only references exhibits that have been submitted. Please see attached revised confidentiality request letter. .

External Photos

EN-VISION AMERICA FCC ID: VE3-STS1 EUT Photographs © 2007 PCTEST Lab. EUT Type: RFID Reader Model: ScripTalk Station EN-VISION AMERICA FCC ID: VE3-STS1 EUT Photographs © 2007 PCTEST Lab. EUT Type: RFID Reader Model: ScripTalk Station EN-VISION AMERICA FCC ID: VE3-STS1 EUT Photographs © 2007 PCTEST Lab. EUT Type: RFID Reader Model: ScripTalk Station EN-VISION AMERICA FCC ID: VE3-STS1 EUT Photographs © 2007 PCTEST Lab. EUT Type: RFID Reader Model: ScripTalk Station

Internal Photos

Test Report

Reviewed by: FCC ID: VE3-STS1 FCC Pt. 15.225 MEASUREMENT REPORT Certification Quality Manager Test Report S/N: Test Dates: EUT Type: 0706150608.VE3 July 28, 2007 RFID Reader Page 1 of 20 © 2008 PCTEST Engineering Laboratory, Inc. REV 1.0FMT 05/14/07 Applicant Name: Date of Testing: En-Vision America, Inc. July 28, 2007 1845 W. Hovey Ave. Test Site/Location: Normal, IL 61761 PCTEST Lab, Columbia, MD, USA Test Report Serial No.: 0706150608.VE3 FCC ID: VE3-STS1 APPLICANT: En-Vision America, Inc. Model(s): ScripTalk Station EUT Type: RFID Reader Frequency Range: 13.56MHz FCC Classification: Part 15 Low Power Communication Device Transmitter (DXX) FCC Rule Part(s): FCC Part 15 Subpart C (15.225) The device bearing the FCC Identifier specified above has been shown to comply with the applicable technical standards as indicated in the measurement report and has been tested in accordance with the measurement procedures specified in ANSI C63.4-2003 (See Test Report). These measurements were performed with no deviation from the standards. I authorize and attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. 410.290.6652 / Fax 410.290.6554 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE FCC Part 15.225 Certification Reviewed by: FCC ID: VE3-STS1 FCC Pt. 15.225 MEASUREMENT REPORT Certification Quality Manager Test Report S/N: Test Dates: EUT Type: 0706150608.VE3 July 28, 2007 RFID Reader Page 2 of 20 © 2008 PCTEST Engineering Laboratory, Inc. REV 1.0FMT 05/14/07 TABLE OF CONTENTS FCC CERTIFICATION TEST REPORT........................................................................................3 1.0 INTRODUCTION ..............................................................................................................................4 1.1 EVALUATION PROCEDURE................................................................................................................ 4 1.2 SCOPE .................................................................................................................................................. 4 1.3 PCTEST TEST LOCATION ................................................................................................................... 4 2.0 PRODUCT INFORMATION..............................................................................................................5 2.1 EQUIPMENT DESCRIPTION ................................................................................................................ 5 2.2 OPERATION MODE.............................................................................................................................. 5 2.3 EMI SUPPRESSION DEVICE(S)/MODIFICATIONS ............................................................................. 5 2.4 LABELING REQUIREMENTS ............................................................................................................... 5 3.0 DESCRIPTION OF TEST.................................................................................................................6 3.1 CONDUCTED EMISSIONS ................................................................................................................... 6 3.2 RADIATED EMISSIONS........................................................................................................................ 7 4.0 SAMPLE CALCULATIONS ..............................................................................................................8 4.1 CONDUCTED EMISSION MEASUREMENT SAMPLE CALCULATION ............................................... 8 4.2 RADIATED EMISSION MEASUREMENT SAMPLE CALCULATION.................................................... 8 5.0 TEST EQUIPMENT CALIBRATION DATA ......................................................................................9 6.0 ENVIRONMENTAL CONDITIONS .................................................................................................10 7.0 TEST DATA ....................................................................................................................................11 7.1 SUMMARY .......................................................................................................................................... 11 7.2 20DB BANDWIDTH MEASUREMENT ................................................................................................ 12 7.3 IN-BAND RADIATED SPURIOUS EMISSION MEASUREMENTS...................................................... 13 7.4 RADIATED SPURIOUS EMISSION MEASUREMENTS, OUT-OF-BAND .......................................... 14 RADIATED SPURIOUS EMISSION MEASUREMENTS, OUT-OF-BAND (CONT’D).................................... 15 7.5 LINE CONDUCTED MEASUREMENT DATA ..................................................................................... 16 7.6 FREQUENCY STABILITY TEST DATA............................................................................................... 18 8.0 CONCLUSION................................................................................................................................20 Reviewed by: FCC ID: VE3-STS1 FCC Pt. 15.225 MEASUREMENT REPORT Certification Quality Manager Test Report S/N: Test Dates: EUT Type: 0706150608.VE3 July 28, 2007 RFID Reader Page 3 of 20 © 2008 PCTEST Engineering Laboratory, Inc. REV 1.0FMT 05/14/07 MEASUREMENT REPORT FCC Part 15.225 § 2.1033 General Information APPLICANT: En-Vision America, Inc. APPLICANT ADDRESS: 1845 W. Hovey Ave. Normal, IL 61761 TEST SITE: PCTEST ENGINEERING LABORA…

Text truncated - open the document above for the full version.

Test Setup Photos
