VFC031604Key Fob Control

Form No. 3309525.016 9/06 (Replaces 3309525.008) (French 3309552.011) ©2006 Dometic Corporation LaGrange, IN 46761 USER’S GUIDE Control System Control Box + – POWER 12 VDC DOOR MOTOR PATIO MOTOR DOOR SWITCH PATIO SWITCH LIMIT SWITCH WIND SENSOR 24 21 18 15 12 WIND ON U.S.A. PATENT NO 6,798,158. Remote Rocker Switch Remote Control (Key FOB) USA SERVICE OFFICE Dometic Corporation 2320 Industrial Parkway Elkhart, IN 46516 574-294-2511 CANADA Dometic Corporation 46 Zatonski, Unit 3 Brantford, ON N3T 5L8 CANADA 519-720-9578 For Service Center Assistance Call: 800-544-4881 Electronic Control Kit 3309424.XXX 3310287.XXX WeatherPro Awning User’s Guide 2 To Open Awning: A. Using The Remote Control (Key FOB) a. Press and hold the “Extend” button for 3 seconds and the awning will automatically open. If not held for three seconds the awning will re- main in the position when button is released and will continue to extend when pressed again. B. Using The Remote Rocker Switch a. Press and hold the “Extend” button for 3 seconds and the awning will automatically open. If not held for three seconds the awning will re- main in the position when button is released and will continue to extend when pressed again. Important: When the power has been interrupted, wait approximately 30 seconds before depressing but- ton again. The control box will automatically restore power when button is pressed again. Important: When installed correctly on a motorized RV, this system is wired to prevent accidental awning “extension” when vehicle ignition key is in the “ON” position. When the ignition key is turned “ON”, the “extension” mode is de-activated and awning will not extend. This however, will not prevent the awning from being retracted. The A & E WeatherPro awning is equipped with a wind sensing device that will automatically close the awning when wind conditions are present that may damage the awning. The factory preset setting is 18 MPH. To activate the wind sensor feature, locate the control box (usually mounted in a storage compartment), simultaneously de- press and hold buttons 1 & 2 on the Remote Control (Key FOB) for 3 seconds. One of the wind speed LED’s will illuminate. To de-activate the wind sensor feature, simultaneously depress and hold buttons 3 & 4 on the Remote Control (Key FOB) for 3 seconds. There are no wind speed LED’s illuminated when de-activated. Damage to the awning can occur in high winds if the awning is left in the open position with this feature de-activated. Wind sensor is activated when shipped from the factory. Important: Do not attach or hang any objects from the awning or tie the awning down. If the sensor is activated or the retract button is depressed and the awning rolls up, damage to the awning and attached objects can occur. There are six (6) LED’s in the WeatherPro control and one (1) button for selecting the wind speed. A. 12 VDC Power Indicator/Fault Indicator 1 When the LED is constant Yellow this indicates that there is 12 VDC power at the control. 2. When the LED is flashing Yellow at the rate of 1 time per second, this indicates that the voltage is below 10 (± .50) VDC. Awning will not operate. 3. When the LED is flashing Yellow and alternates flashing with the selected wind speed LED, this indicates a communication fault between the wind sensor and the control box. B. Wind Speed Setting 1. The LED that is yellow indicates the wind speed currently selected. C. Wind Speed Selection Button 1. Wind speed is preset from the factory at 18 MPH. 2. The wind speed can be adjusted by pressing the wind speed selection button. To increase or de- crease the sensor sensitivity, press and release the wind speed selection button until the desired wind speed LED is lit. The recommended setting is 18 MPH. Note: Awning is not intended for cold weather operation. Awning will automatically close when outside temperature reaches 32° F. when the wind sensor is activated. When this condition occurs, the bottom 2 wind speed LED’s will blink alternately. To de-activate the wind sensor simulta- neously press and hold buttons 3 & 4 for 3 seconds. To activate the wind sensor, simultane- ously press and hold buttons 1 & 2 for 3 seconds. 1 2 3 4 Obstructions in the proximity of the wind sensor can dimin- ish the sensitivity. If wind sensor is de-activated and dam- age to awning occurs, the awning warranty will be void. The wind sensor is specifically designed to allow air to pass across sensor probe. Important: The wind sensor will only function cor- rectly if the airway to the sensing probe is clear. Keep airway clear of dust, insects, ice, snow, or other debris. The sensing probe can be cleaned with a mild soap solution and a small soft bristle brush. WeatherPro Awning User’s Guide 3 WeatherPro Control Box The A&E WeatherPro awning is extremely durable and can be operated during light rain and light wind conditions. However, when periods of heavy rain, or wind is expected; or you leave the awning unattended the awning must be closed. Damage caused by wind and rain is not covered by warranty. Your A & E awning is designed to shed water if left out in light rain. If water builds up on the awning, the spring loaded left arm will automatically lower the height of the awning approximately 9 inches to allow water to run off. When there is no longer the need to shed water it will return Spring Loaded Left Arm: To Close Awning: Pinch Hazard. When closing awning, bottom arm will fold down and against back channel. This area must be kept clear of people and objects. Failure to heed this warning could cause severe personal injury and/or property damage A. Using The Remote Control (Key FOB) 1. Press and hold the “Retract” but- ton for 3 seconds and the awning will automatically close. If not held for three seconds the awning will remain in the position when button is released and continue to close when pressed again. B Using The Remote Rocker Switch 1. Press and hold the “Retract” but- ton for 3 seconds and the…
