VGCTP550BASE STATION TRANSCEIVER

Matrix Product Development 10-2-07 djp User Manual TP550 Introduction: The TP550 is battery operated, wireless temperature probe. It is designed to operate in conjunction with a TP1000 Base Station. Technical Specifications: Battery: 3.6V or 3.9V Single cell lithium Temp Range: -20C to +100C Life Span: ~2yrs, depending on how often Probe transmits. Frequency: 433MHz Case Material: Polycarbonate Basic Operation: The TP550 (Probe) is turned on via an on-board reed switch using external magnet. To turn on, hold a magnet up to the TP550 (Probe), in a parallel fashion, for 3-5 seconds. To turn off, repeat the same process as above. When the TP550 gets woken up with an external magnet it immediately sends out a packet to the TP1000. The transmit sequence is as follows: The Probe will transmit a packet every 5 seconds for up to one minute until it receives an acknowledge from the Base. If the Probe receives an acknowledge prior to one minute it will revert to it’s standard operating mode. In standard operating mode the Probe will transmit once every 55 seconds. If the Probe does not receive an acknowledge within one minute of power up it enters into a retry mode in which the Probe will continue trying to transmit it’s packet up to three times every 55 seconds. The packet is roughly 16.66ms long. It’s contents include temperature, RSSI value, tag ID, and etc... THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER'S AUTHORITY TO OPERATE THE EQUIPMENT.

From: "Ron Pulvermacher" <[email protected]> To: "'David'" <[email protected]> Subject: FW: revise operational description-further clarification Date: Mon, 11 Feb 2008 12:29:48 -0600 X-Mailer: Microsoft Office Outlook 12.0 Thread-Index: AchcbQllW0nWimj9RhGhSke8Em1h7ABaO+rQAAEaMpAAAICQIAAD5OHAADHo 1GACJAyMAAA6tD7gACgP4CAAA4v0MAD/wM/g X-Nonspam: None X-Antivirus: avast! (VPS 080118-0, 01/18/2008), Inbound message X-Antivirus-Status: Clean Joe, That is correct. From: Joe Dichoso [mailto:[email protected]] Sent: Wednesday, February 06, 2008 8:46 AM To: Ron Pulvermacher; David Cc: John Reed; Andrew Leimer Subject: RE: revise operational description-further clarification Hello Ron, Sounds good to me. I take it that the device no longer will send an integrity signal. -Joe ---------- From: Ron Pulvermacher [mailto:[email protected]] Sent: Tuesday, February 05, 2008 2:43 PM To: Joe Dichoso; 'David' Cc: John Reed; Andrew Leimer Subject: RE: revise operational description-further clarification Joe, We will change our software so that the device only transmits during an alarm mode where the temperature exceeds a set point and will conform to 15.231 a-d. This will satisfy our initial customer. Because we need a international frequency and a low frequency that transmits through liquids, we cannot use 915MHz. For other customers we will begin a new FCC certification under 15.231e that limits the power. Does this make sense? Regards, Ron Pulvermacher Matrix Product Development, Inc. 608-834-1661 www.matrixpd.com

RF LABORATORIES, INC 1412 Center Avenue • Oostburg, Wisconsin 53070 (920) 564-2700 • FAX (920) 564-1027 • e-mail: [email protected] Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: VGCTP550. Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Operational Description For TP550 and TP1000.doc Operational Description TP550 and TP1000 Radios.doc TP550 Antenna Description.pdf TP550 Probe Schematic.pdf BLOCK DIAGRAM_110807.doc The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Pursuant to DA 04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below: Internal Photos External Photos user manual_TP550.doc The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, David J. Zima Attached: Copy of FCC Confidentiality Policy

APPLICANT: MATRIX PRODUCT DEVELOPMENT, INC. FCC ID: VGCTP500 EXTERNAL PHOTOS:

6.95 .64 Sketch of Label Location REV.DESCRIPTIONDATEAPPROVED TP550 DO NOT SCALE DRAWING SHEET 1 OF 1 DJP UNLESS OTHERWISE SPECIFIED: SCALE: 1:4 WEIGHT: REV DWG. NO. A SIZE TITLE: NAME DATE COMMENTS: Q.A. MFG APPR. ENG APPR. CHECKED DRAWN - FINISH MATERIAL INTERPRET GEOMETRIC TOLERANCING PER: DIMENSIONS ARE IN INCHES TOLERANCES: FINISH: 125 RMS ANGULAR: MACH 0.5 BEND 1 TWO PLACE DECIMAL .02 THREE PLACE DECIMAL .005 PROPRIETARY AND CONFIDENTIAL THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF MATRIX PRODUCT DEVELOPMENT, INC. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF MATRIX PRODUCT DEVELOPMENT, INC. IS PROHIBITED. 5 4 3 2 1 MATRIX PRODUCT DEVELOPMENT 2-13-07 TP550

APPLICANT: MATRIX PRODUCT DEVELOPMENT, INC. FCC ID: VGCTP500 INTERNAL PHOTOS:

APPLICANT: MATRIX PRODUCT DEVELOPMENT, INC. FCC ID: VGCTP550 REPORT: W:\M\MATRIX_VGC\3311AUT7\3311AUT7TestReport.doc Page 2 of 15 mdea 09.20.2007 FCC PART 15.231 TEST REPORT LOW POWER UNLICENSED TRANSMITTER Applicant MATRIX PRODUCT DEVELOPMENT, INC. Address 13 N. BIRD STREET SUN PRAIRIE, WI 53590 FCC ID VGCTP550 Product Description PROBE TRANSCEIVER Date Sample Received OCTOBER 19, 2007 Date Tested OCTOBER 29, 2007 Tested By NAM NGUYEN Approved By NAM NGUYEN Timco Report No. 3311AUT7TestReport.doc Test Results Pass Fail THE ATTACHED REPORT SHALL NOT BE REPRODUCED EXCEPT IN FULL WITHOUT THE WRITTEN APPROVAL OF TIMCO ENGINEERING, INC. 849 NW STATE ROAD 45 NEWBERRY, FL 32669 USA PH: 888.472.2424 OR 352.472.5500 FAX: 352.472.2030 EMAIL: [email protected] HTTP: //WWW.TIMCOENGR.COM Certificate # 0955-01 APPLICANT: MATRIX PRODUCT DEVELOPMENT, INC. FCC ID: VGCTP550 REPORT: W:\M\MATRIX_VGC\3311AUT7\3311AUT7TestReport.doc Page 3 of 15 mdea 09.20.2007 TABLE OF CONTENTS GENERAL REMARKS ....................................................................................................4 REPORT SUMMARY ......................................................................................................5 TEST ENVIRONMENT....................................................................................................5 TEST SETUP .................................................................................................................5 DUT SPECIFICATION ....................................................................................................6 MANUFACTURE DECLARATION OF COMPLIANCE WITH PART 15.231(A)......................7 TEST EQUIPMENT LIST ................................................................................................8 TEST PROCEDURES .....................................................................................................9 RADIATION INTERFERENCE .......................................................................................10 CALCULATION OF DUTY CYCLE .................................................................................12 OCCUPIED BANDWIDTH.............................................................................................14 POWER LINE CONDUCTED INTERFERENCE ..............................................................15 APPLICANT: MATRIX PRODUCT DEVELOPMENT, INC. FCC ID: VGCTP550 REPORT: W:\M\MATRIX_VGC\3311AUT7\3311AUT7TestReport.doc Page 4 of 15 mdea 09.20.2007 GENERAL REMARKS The attached report shall not be reproduced except in full without the written permission of Timco Engineering Inc. Summary The device under test does: fulfill the general approval requirements as identified in this test report not fulfill the general approval requirements as identified in this test report Attestations This equipment has been tested in accordance with the standards identified in this test report. To the best of my knowledge and belief, these tests were performed using the measurement procedures described in this report. All instrumentation and accessories used to test products for compliance to the indicated standards are calibrated regularly in accordance with ISO 17025 requirements. Certificate # 0955-01 I attest that the necessary measurements were made, under my supervision, at: Timco Engineering Inc. 849 NW State Road 45 Newberry, Fl 32669 Authorized Signatory Name: Mario de Aranzeta Mario de Aranzeta C.E.T. Compliance Engineer/ Lab. Supervisor Date: 11/5/2007 Tested By: Nam Nguyen Signature: on file APPLICANT: MATRIX PRODUCT DEVELOPMENT, INC. FCC ID: VGCTP550 REPORT: W:\M\MATRIX_VGC\3311AUT7\3311AUT7TestReport.doc Page 5 of 15 mdea 09.20.2007 REPORT SUMMARY Disclaimer The test results only relate to the item tested. Applicable Rule(s) FCC Pt 15.231, Pt 15.209, Pt 15.207, ANSI C63.4: 2003 Related Report(s) or Approval(s) 3311BUT7TestReport.doc Receiver The receiver portion of this system has been tested and meets all of the FCC requirements per FCC rules Part 15.109. A report was issued and a copy of this report is available upon request. TEST ENVIRONMENT Test Facility The test sites are located at 849 NW State Road 45 Newberry, FL 32669 USA. Test Condition: Temperature: 26ºC Relative humidity: 50% TEST SETUP Test Exercise (e.g software description, test signal, etc.): The DUT was placed in continuous transmit mode of operation. Deviation from the standard(s) No deviation from the standard(s) Modification to the DUT: No modification was made to the DUT. Supporting Peripheral Equipment Not applicable. The device is a stand-alone remote control radio. APPLICANT: MATRIX PRODUCT DEVELOPMENT, INC. FCC ID: VGCTP550 REPORT: W:\M\MATRIX_VGC\3311AUT7\3311AUT7TestReport.doc Page 6 of 15 mdea 09.20.2007 DUT SPECIFICATION Applicant MATRIX PRODUCT DEVELOPMENT, INC. Description PROBE TRANSCEIVER FCC ID VGCTP550 Model Number TP550 Frequency Range 433.5 – 433.5 MHz 110–120Vac/50– 60Hz DC Power DUT Power Source Battery Operated Exclusively Test Item Prototype Pre-Production Production Type of Equipment Fixed Mobile Portable APPLICANT: MATRIX PRODUCT DEVELOPMENT, INC. FCC ID: VGCTP550 REPORT: W:\M\MATRIX_VGC\3311AUT7\3311AUT7TestReport.doc Page 7 of 15 mdea 09.20.2007 MANUFACTURE DECLARATION OF COMPLIANCE WITH PART 15.231(a) Item Description Yes No 1 Does this device transmit a signal that is only used to control another device? X 2 Does this device send data with this control signal? X 3 Does this device send data? Data is, things like: temperature, wind direction, fluid amount, rate of flow, etc. X 4 Does this device transmit continuously? X 5 Does this device transmit automatically? X 6 If manually operated does this device stop transmitting within 5 seconds of releasing the button? N/A 7 If automatically operated does it deactivate 5 seconds after activation? X 8 Does it transmit at regular predetermined intervals? X Does it poll or send supervisory information? X 9 If yes does it do a system integrity check? How often? X Is this a fire,…
