VGD-MAGNA6668 CHANNELS WIRELESS THERMOCOUPLE MONITOR

ThermoSpyder™ 8-Channel Thermocouple Monitor Copyright © 2007 by Magna Systems, L.L.C. Revision A (07/2007) Rev. A i Warranty General Terms Magna Systems, L.L.C. warrants this product to be free from defects in material and workmanship for a period of one year from the date of shipment. If this product is found to be defective during the warranty period, the product will either be repaired or replaced at Magna Systems’ sole option. To Use This Warranty To exercise this warranty, write or telephone your local Magna Systems representative or contact Magna Systems headquarters in California. Detailed contact information may be found on the Magna Systems web site, www.magnasystems.net . You will receive prompt assistance and return instructions. Send the product, shipping prepaid, to the indicated service facility. The repaired or replacement product will be returned to you with shipping prepaid. The repaired or replaced product will be warranted for the remainder of the original warranty term or ninety days whichever is longer. Limitation of Warranty This warranty does not apply to defects or malfunctions resulting from modification or misuse of any product or part. This warranty does not apply to fuses or other circuit protection components, to batteries, damage from battery leakage or damage resulting from improper battery installation. Entire Warranty This warranty is the complete warranty and stands in lieu of any or all other warranties, expressed or implied, including any implied warranty of merchantability or suitability for a particular use. Magna Systems, L.L.C. shall not be liable for any indirect, special or consequential damages. Rev. A ii Symbols Used in This Manual CAUTION Indicates potential for equipment damage. Refer to procedures or instructions. CAUTION Indicates potential risk of electrical shock. Take suitable precautions. Regulatory Statements Industry Canada Notice to Users Operation is subject to the following two conditions: (1) This device may not cause interference and (2) This device must accept any interference, including interference that may cause undesired operation of the device. See RSS-GEN 7.1.5 FCC Notice to Users Magna Systems has not approved any changes or modifications to the ThermoSpyder made by the user. Antenna modification, antenna replacement or use of an antenna not approved by Magna Systems is not authorized. Any changes or modifications could void the user’s authority to operate this equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio / TV technician for help. Battery Disposal Please do not throw batteries in the trash. Used batteries must be disposed of in accordance with local regulation. For information about how to recycle batteries in your area, visit the Rechargeable Battery Recycling Corporation (RBRC©) at www.rbrc.org. Rev. A iii Important Safety Information Electrical Shock Hazard There are no hazardous voltages present in the ThermoSpyder, however the American National Standards Institute (ANSI) states that a shock hazard exists when probes or sensors are exposed to voltages greater than 42 VDC or 42 V peak AC. In some applications thermocouples may be attached to objects or surfaces between which voltages in excess of the ANSI shock hazard standard exist. Despite the electrical isolation designed into the thermocouple assemblies, conditions may exist such that hazardous voltages could be present at the dual row connector of the thermocouple assembly. In such cases, users must handle the dual row connector of the thermocouple assembly in a manner consistent with the presence of hazardous voltages. Exposure to Radio Frequency (RF) Energy The ThermoSpyder contains a radio transmitter and receiver. Whenever powered, the ThermoSpyder will receive and emit radio frequency energy. The ThermoSpyder is designed to comply with local regulatory requirements including those concerned with the exposure of human beings to RF energy. Use of Rechargeable Batteries Under conditions of heavy use it may be advantageous to use rechargeable batteries to power the ThermoSpyder. Most rechargeable batteries, due to the chemical recombination process within the batteries, will vent non-corrosive gases to the ambient atmosphere. Ensure that the ThermoSpyder is used with adequate ventilation when rechargeable batteries are used. Explosive Environments DO NOT USE THE ThermoSpyder IN EXPLOSIVE ENVIRONMENTS. Areas with potentially explosive atmospheres are often, but not always, posted. Such areas may include, but are not limited to, fueling areas, enclosed areas where fumes may accumulate (such as below decks on boats or areas near poorly ventilated gas powered appliances), chemical transfer or storage areas, laboratories, and areas when there are airborne particulates such as grain, dust, aerosolized paints or fine metal powders. DO NOT USE THE ThermoSpyder IN SUCH AREAS. The installation or removal of batteries may cause sparks which could cause an explosion or fire. Not …

Text truncated - open the document above for the full version.

Page 1 of 3 450C First Street Los Altos, CA 94022 www.magnasystems.net THERMOSPYDER™ BLOCK DIAGRAM Page 2 of 3 450C First Street Los Altos, CA 94022 www.magnasystems.net THERMOSPYDER™ BLOCK DIAGRAM For radio communications this device uses the CC1020 Single Chip Low Power RF Transceiver for Narrowband Systems manufactured by ChipCon AS / Texas Instruments. The transceiver is a true single-chip RF communications solution which requires a minimum number of external components. Communications and control of the transceiver is affected via digital interface signals from the microcontroller unit (MCU). A block diagram of the radio frequency section is shown below. RADIO FREQUENCY SECTION BLOCK DIAGRAM Channel Selector Switch (MUX) Analog To Digital Converter 1 2 3 4 5 6 7 8 “Cold” Junction MCU Cold Junction Temperature Monito r Differential Amplifier Flash Memory Real Time Clock Radio Transceiver RX Output Matching Network Single-Chip Radio Transceiver CC1020 Input Matching Network Digital Control Interface Digital Data Interface TX Tx / Rx Switch ANT 14.7456 MHz Crystal Page 3 of 3 Output matching is accomplished with a π-type network which provides an impedance match at the fundamental frequency and harmonics. The use of a transmit / receive switch reduces power consumption during transmission at high output power levels and also improved receiver sensitivity. The switch is controlled by digital signals from the transceiver chip. The simplified transceiver block diagram is reproduced from the manufacturer’s datasheet. The manufacturer’s datasheet provides a discussion of the architecture and features of the transceiver as well as instructions for design of circuitry and operation of devices utilizing the CC1020. The datasheet may be accessed by the Internet here- http://focus.ti.com/lit/ds/symlink/cc1020.pdf TRANSCEIVER BLOCK DIAGRAM FROM CC1020 DATASHEET (CHIPCON AS / TEXAS INSTRUMENTS)

June 29, 2007 To: Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: VGD-MAGNA888 FCC ID: VGD-MAGNA666 We hereby request that the information accompanying this application, as designated below, be treated with permanent confidentiality: • Schematic diagrams (file name: schematics.pdf) We hereby request that the information accompanying this application, as designated below, be treated with short-term confidentiality: • Internal photographs (file name: EUT internal photos.pdf) The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 and Section 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Steven M. Clark Managing Member Magna Systems, L.L.C. 450C First Street Los Altos, CA 94022 +1 650 917 5900 www.magnasystems.net

SCS-F19: Confidentiality Request Letter Rev 1.0 Nov 14, 2006 June 29, 2007 Federal Communication Commission 7435 Oakland Mills Road Columbia, MD 21046 RE: FCC ID: VGD-MAGNA888 FCC ID: VGD-MAGNA666 TIMCO Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 To Whom It May Concern: This letter is to ascertain that the Magna Systems, L.L. C, Gateway and ThermoSpyder has been the unit used for conducting FCC and IC compliance testing. If you have any question or concerns, please contact me. Sincerely, Steven M. Clark Managing Member Magna Systems, L.L.C. 450C First Street Los Altos, CA 94022 +1 650 917 5900 www.magnasystems.net

Magna Systems L.L.C. 8-Channels ThermalSpder Test Unit Photo EUT Front View EUT Rear Vew

Sample FCC Label for ThermoSpyder™ Product FCC ID: VGD-MAGNA666 IC: 7231A-MAGNA666 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Mfr: MAGNA SYSTEMS ThermoSpyder™

FCC Labeling Location FCC ID: VGD-MAGNA666 IC: 7231A-MAGNA666 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Magna Systems L.L.C. 8-Channels ThermalSpyder Test Unit Photo EUT Cover Off View EUT Main Board Top View EUT Main Board Bottom View

Page 1 of 2 450C First Street Los Altos, CA 94022 www.magnasystems.net THERMOSPYDER™ OPERATIONAL D ESCRIPTION Page 2 of 2 450C First Street Los Altos, CA 94022 www.magnasystems.net How the ThermoSpyder Works A simplified block diagram of the ThermoSpyder with a thermocouple assembly attached is shown below. To make a measurement, the microcontroller unit selects the desired thermocouple by sending control signals to the channel selector switch. The switch connects the selected thermocouple across the inputs of the differential amplifier. This low-noise, zero-drift amplifier magnifies the relatively small thermocouple voltage such that an effective measurement can be made. The amplified voltage is presented to the input of the analog to digital converter where it is converted to a digital code. The digital code is read by the microcontroller unit and stored in memory. In order to interpret the digital code representing the thermocouple temperature correctly, the “cold” junction voltage must be compensated. The ThermoSpyder uses an integrated circuit temperature sensor to accurately measure the “cold” junction temperature and the microcontroller then performs software based compensation. The microcontroller then selects the next channel to be measured and the process is repeated as required. The radio transceiver is used to periodically transfer acquired temperature data to DataLink using the GateWay network access node. If, for any reason, the data is not transferred to DataLink, the ThermoSpyder stores the data in the flash memory and transmits the data later. Channel Selector Switch (MUX) Analog To Digital Converter 1 2 3 4 5 6 7 8 “Cold” Junction MCU Cold Junction Temperature Monito r Differential Amplifier Flash Memory Real Time Clock Radio Transceiver

TEST REPORT FROM FOR Magna Systems LLC 8-Channels ThermoCouple Monitor Model: THERMOSPYDER TM TO 47 CFR 15.249 :2007 Test Report Serial No.: SL07062101-MSL-001(ThermoSpyder) This report supersedes None Remarks: Equipment complied with the specification [X ] Equipment did not comply with the specification [ ] This Test Report is Issued Under the Authority of: ............................................................................................................. Tested by: Snell Leong, Test Engineer ............................................................................................................. Reviewed by: Leslie Bai, Reviewer Issue date: 06 July 2007 Manufacturer: Magna Systems LLC This test report may be reproduced in full only. This test report may be reproduced in full only. Registration No. 783147 Registration No. 2195 Registration No. 4842 RTA No. D23/16V Lab Code: KR0032 Title: Magna Systems LLC FCCID: VGD-MAGNA666 To: 47 CFR 15.249 :2007 Serial# SL07062101-MSL-001(ThermoSpyder) Issue Date 06 July 2007 Page 2 of 21 www.siemic.com This page has been left blank intentionally. Title: Magna Systems LLC FCCID: VGD-MAGNA666 To: 47 CFR 15.249 :2007 Serial# SL07062101-MSL-001(ThermoSpyder) Issue Date 06 July 2007 Page 3 of 21 www.siemic.com CONTENTS EXECUTIVE SUMMARY ................................................................................................................................................. 5 1 TECHNICAL DETAILS ............................................................................................................................................. 6 2 TESTS REQUIRED ..................................................................................................................................................... 7 3 ANTENNA REQUIREMENT..................................................................................................................................... 8 4 MEASUREMENTS, EXAMINATIONS AND DERIVED RESULTS .................................................................. 9 5 TEST INSTRUMENTATION .................................................................................................................................. 13 APPENDIX A: EUT TEST CONDITIONS .................................................................................................................... 14 APPENDIX B: EXTERNAL PHOTOS .......................................................................................................................... 15 APPENDIX C: 99% BANDWIDTH AND EMISSION DESIGNATOR .................................................................... 16 APPENDIX D: INTERNAL PHOTOS ........................................................................................................................... 17 APPENDIX E: PRODUCT DESCRIPTION.................................................................................................................. 18 APPENDIX F: FCC LABEL LOCATION ..................................................................................................................... 19 APPENDIX G: USER MANUAL .................................................................................................................................... 20 Title: Magna Systems LLC FCCID: VGD-MAGNA666 To: 47 CFR 15.249 :2007 Serial# SL07062101-MSL-001(ThermoSpyder) Issue Date 06 July 2007 Page 4 of 21 www.siemic.com This page has been left blank intentionally. Title: Magna Systems LLC FCCID: VGD-MAGNA666 To: 47 CFR 15.249 :2007 Serial# SL07062101-MSL-001(ThermoSpyder) Issue Date 06 July 2007 Page 5 of 21 www.siemic.com Executive Summary The purpose of this test programme was to demonstrate compliance of the Magna Systems LLC, 8- Channels ThermoCouple Monitor , model THERMOSPYDER TM against the current 47 CFR 15.249 :2007 . The 8-Channels ThermoCouple Monitor demonstrated compliance with the 47 CFR 15.249 :2007 . Magna Systems LLC is the applicant and claimed manufacturer of this tested product. For the detailed description of this product, please refer to the 8-Channels ThermoCouple Monitor User Manual. The equipment under test operating frequency is 915MHz. The test has demonstrated that this unit complies with stipulated standards. Title: Magna Systems LLC FCCID: VGD-MAGNA666 To: 47 CFR 15.249 :2007 Serial# SL07062101-MSL-001(ThermoSpyder) Issue Date 06 July 2007 Page 6 of 21 www.siemic.com 1 Technical Details Purpose Compliance testing of 8-Channels ThermoCouple Monitor with 47 CFR 15.249 :2007 Applicant / Client Magna Systems LLC 450C First Street Los Altos CA Manufacturer Magna Systems LLC Laboratory performing the tests SIEMIC Labs 2206 Ringwood Avenue San Jose, CA 95131 Test location(s) SIEMIC Labs 2206 Ringwood Avenue San Jose, CA 95131 Test report reference number SL07062101-MSL-001(ThermoSpyder) Date EUT received 025 April 2007 Standard applied 47 CFR 15.249 :2007 Dates of test (from – to) 25 April 2007 to 30 April 2007 No of Units: 1 Equipment Category: DXT Trade/Product Name: Magna Systems, L.L.C. Type/Model Name/No: THERMOSPYDER TM Technical Variants: N/A FCC ID No. VGD-MAGNA666 IC ID No. 7231A-MAGNA666 Title: Magna Systems LLC FCCID: VGD-MAGNA666 To: 47 CFR 15.249 :2007 Serial# SL07062101-MSL-001(ThermoSpyder) Issue Date 06 July 2007 Page 7 of 21 www.siemic.com 2 Tests Required The product was tested in accordance with the following specifications. The test results recorded in this Test Report are exclusively referred to the tested sample(s). Test Standard Description Pass / Fail 47 CFR Part 15.249: 2007 RSS 210 Issue 7: 2007 15.203 RSS GEN 7.1.4 Antenna Requirement Pass 15.207(a) RSS GEN 7.2.2 Conducted Emissions Voltage Pass 15.249 RSS 210 A.2.9 (a) 7 (b) Fundamental & Radiated Spurious Emission Limits Pass ANSI C63.4: 2003 / RSS-Gen Issue 2: 2007 Notes: Deviations to above standards are outlined in specific test sections if applicable. Cable loss and external attenuation are compensated for in the measurement system when appl…

Text truncated - open the document above for the full version.

Magna Systems L.L.C. 8-Channels ThermalSpyder Test Unit Photo Radiated Emission Setup View
